SCSI Drive Case
External Drive Case for 5.25" SCSI Device
Installation Manual
SCSI2CASE1
SCSI2CASE2
SCSI2CASE4
SCSI3CASE1
SCSI3CASE2
SCSI3CASE4
SCSI3CASE8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCSI2CASE1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for StarTech.com SCSI2CASE1

  • Page 1 SCSI Drive Case External Drive Case for 5.25" SCSI Device Installation Manual SCSI2CASE1 SCSI2CASE2 SCSI2CASE4 SCSI3CASE1 SCSI3CASE2 SCSI3CASE4 SCSI3CASE8...
  • Page 2: General Description

    General Description The StarTech.com SCSI/SCSI2/SCSI3 external drive cases provides a fast and easy way for PC or Mac users to add between 2 and 8 additional 50 pin hard drives, CD-ROMs, CD-RWs, or tape backup drives to their system. It provides 2 5.25 inch bays for SCSI/SCSI2/SCSI3 devices.
  • Page 3 Parts Description For Single Cases Overview 1) Cover 6) 5V/12V Power 2) Front panel frame 7) Key lock 3) Front panel 8) Lock pin 4) Power shield plate 9) HDD working LED 5) Wires cover box 10) Power LED...
  • Page 4 Top View 1) Working indicator 4) Audio output 2) ID Switch 5) Cooling fan 3) 50 pin cable (SCSI I/II), 68 pin cable (SCSI III) Back View 1) Power output 4) ID Switch a) 0~7 for SCSI I/II b) 0~15 for SCSI III 2) Power input 5) Connector - SCSI I/II/III 3) Power switch...
  • Page 5 For Multicase Overview 1) Chassis (Including panel and LEDs) 2) Cover...
  • Page 6 Top View 1) Power 5) HDD working indicator 2) Power switch 6) 50 pin cable (SCSI I/II), 68 pin cable (SCSI III) 3) Power cord 7) Audio outpu 4) Cooling fan 8) ID switch (4 pin for SCSI I/II) (5 pin for SCSI III)
  • Page 7 Rear View 1) Audio output (for CD ROM only) 2) Power output 4) Connectors 3) Power input 5) ID selector...
  • Page 8 & power then fasten the enclosed screws on both sides of the interior side panels, securing the device into place. (To install drive drawers that are 3.5 inches requires an adapter bracket, such as the StarTech.com BRACKET) c) For other devices, read the instructions on your device manual.
