INSTALLATION, OPERATION
AND TROUBLESHOOTING
MM9000 - CLEAR COMMAND USER MANUAL
MARINE PROPULSION SYSTEMS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MM9000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ZF MM9000

Summary of Contents for ZF MM9000

  • Page 1: Clearcommand User Manual

    INSTALLATION, OPERATION AND TROUBLESHOOTING MM9000 - CLEAR COMMAND USER MANUAL MARINE PROPULSION SYSTEMS...
  • Page 2 Data subject to change without notice. We decline all responsibility for the use of non-original components or accessories wich have not been tested and submitted for approval. ZF reserves all rights regarding the shown technical information including the right to file industrial property right applica- tions and the industrial property rights resulting from these in Germany and abroad.

  • Page 3: Table Of Contents

    TABLE OF CONTENT MM9000 ClearCommand User Manual Table of Contents Table of Contents Installation, Operation and Troubleshooting Manual SW15623.OE ClearCommand User Manual............1 Table of Contents................. 3 List of Figures..................7 List of Tables ..................13 Revision List ..................15 Preface ....................
  • Page 4 TABLE OF CONTENT MM9000 ClearCommand User Manual Table of Contents Installation ..................53 Processor............................53 Control Head(s) ..........................53 Wire Harness Installation ........................53 Hard-Wired Cable ..........................58 Engine Stop Switches........................73 Push-Pull Cable Connections......................74 Set up Procedure ................77 Processor Components Used In Set Up ..................77 Activating Set Up Mode........................80...
  • Page 5 TABLE OF CONTENT MM9000 ClearCommand User Manual Table of Contents Clutch Pressure Interlock ......................132 Station Expander (SE)........................133 9001 Actuator Trolling Valve Control.....................134 Periodic Checks and Maintenance ..........135 Control Heads..........................135 Processor............................135 Power Supply..........................135 Troubleshooting ................137 10.1 General ............................137 10.2 Troubleshooting Questions......................143...
  • Page 6 TABLE OF CONTENT MM9000 ClearCommand User Manual Table of Contents MMC-343 Station Expander User Instructions ..............243 Appendix B - QFA & DVTP..............257 ENG-127 9000 Series Micro/ClearCommand Servo Throttle - Servo Clutch Qualitative Failure Analysis, Design Verification Test Procedure and Periodic Safety Test ......259 ENG-143 9000 Series ClearCommand Throttle - Solenoid Clutch Qualitative Failure Analysis, Design Verification Test Procedure and Periodic Safety Test .........

  • Page 7: List Of Figures

    LIST OF FIGURES MM9000 ClearCommand User Manual List of Figures List of Figures Figure 1-1: Basic 9120 or 9122 ClearCommand System Diagram ................22 Figure 1-2: Basic 9121 ClearCommand System Diagram ..................23 Figure 1-3: Basic 9210 ClearCommand System Diagram ..................24 Figure 1-4: Basic 9211 ClearCommand System Diagram ..................

  • Page 8: List Of Figures

    LIST OF FIGURES MM9000 ClearCommand User Manual List of Figures Figure 4-20: Clutch Cable Heat Shrink in Processor ....................69 Figure 4-21: Clutch Cable Plug Termination Connections..................70 Figure 4-22: Clutch/Troll Cable Heat Shrink in Processor ..................70 Figure 4-23: Clutch Cable Plug Termination Connections..................71 Figure 4-24: Clutch Cable Heat Shrink in Processor ....................

  • Page 9: List Of Figures

    LIST OF FIGURES MM9000 ClearCommand User Manual List of Figures Figure 5-32: Display LED Function C2 Set Up Activated..................97 Figure 5-33: Display LED Function C3 Set Up Activated..................98 Figure 5-34: Display LED Function C4 Set Up Activated..................99 Figure 5-35: Clutch Push-Pull Cable Orientation ....................

  • Page 10: List Of Figures

    LIST OF FIGURES MM9000 ClearCommand User Manual List of Figures Figure 10-13: Example Display Software Revision Level View ................147 Figure 10-14: Display Examples of Remote Stations .................... 149 Figure 10-15: Display Examples of Remote Stations A/D Value................150 Figure 10-16: Display Station A/D’s No Station Transfer Button Depressed............155 Figure 10-17: Example Display Station A/D’s Transfer Button Depressed for Stations 1 - 4 ........
  • Page 11 LIST OF FIGURES MM9000 ClearCommand User Manual List of Figures Figure MM13927-10: Clutch Connections Ahead Solenoid .................. 318 Figure MM13927-11: Clutch Connections Astern Solenoid .................. 319 Figure MM13927-12: Troll Connections Troll On/Off Solenoid ................319 Figure MM13927-13: Troll Connections (Proportional Solenoid) ................. 320 Figure MM13927-14: 2-Speed Connections ......................
  • Page 12 EN 3340.758.003a - 2014-11...

  • Page 13: List Of Tables

    LIST OF TABLES MM9000 ClearCommand User Manual List of Tables List of Tables Table 4-1: ClearCommand Processor Optional Hard-Wiring Cable List ..............60 Table 4-2: Processor Circuit Board Terminal Strip Color Coded Connections for Remote Stations ......66 Table 4-3: Processor Circuit Board Terminal Strip Color Coded Connections for Serial Communication ....68 Table 4-4: Processor Circuit Board Terminal Strip Color Coded Connections for Tachometer........
  • Page 14 LIST OF TABLES MM9000 ClearCommand User Manual List of Tables Table 10-17: Wire Harness - Throttle, Voltage (IVECO, Cummins) (p/n 13432-XX)..........181 Table 10-18: Wire Harness- Throttle, Current (MAN, MTU) (p/n 13494-XX)............182 Table 10-19: Wire Harness - Throttle, Voltage (Cummins Plug), (p/n 13565-XX)..........182 Table 10-20: Voltage Throttle Harness Pin-Out (p/n 14148-XX) ................

  • Page 15: Revision List

    Revised per ELR00048 Rev C.7 09/11 Added MMC-343, changes made per ELR00144 Rev C.8 01/13 Changed name to ZF Marine Propulsion Systems Miramar, LLC MM9000 Rev C.8 01/13 Page 15 EN 3340.758.003a - 2014-11...
  • Page 16 EN 3340.758.003a - 2014-11...

  • Page 17: Preface

    Preface IMPORTANT: Keep this manual in a safe place for future reference. It contains essential information about the installation and operation of the ZF Marine Propulsion Systems Miramar control system for your vessel. ClearCommand Processor List The processors for the systems listed below have software which includes several featured options.

  • Page 18: Important Information

    WARNING: Personal Injury could occur if the following steps are not followed exactly. CAUTION: On Control Systems with more than one Processor, ZF Marine Propulsion Systems Miramar highly recommends that ALL UNITS utilize the same software revision for each Processor.
  • Page 19 Organization (SSO). For more information on an SSO in your area, please see Section 13: Appendix C - Sales and Service Information. NOTE: ZF Marine Propulsion Systems Miramar is not liable for any damage incurred if these notices are not followed exactly.
  • Page 20 EN 3340.758.003a - 2014-11...

  • Page 21: Introduction

    INTRODUCTION MM9000 ClearCommand User Manual Introduction Introduction This manual is written to document every possible system option. Your system may not include every available option for single or twin screw reverse reduction gear applications. Only those sections that apply to your specific installation are relevant to your vessel.

  • Page 22: Figure 1-1: Basic 9120 Or 9122 Clearcommand System Diagram

    INTRODUCTION MM9000 ClearCommand User Manual Introduction The 9122 Processor controls the electrical Transmission and Trolling Valve Solenoids for shift and trolling functions, via electric cable. STATION 1 STATION 2 SERIAL COMMUNICATION TACH 1 TACH 1 AHEAD/ASTERN AHEAD/ASTERN TROLL COMMAND TROLL COMMAND...

  • Page 23: Figure 1-2: Basic 9121 Clearcommand System Diagram

    INTRODUCTION MM9000 ClearCommand User Manual Introduction 1.1.2 9121 Processor (Throttle-Servo 2, Shift-Solenoid, Troll-Servo 1) The 9121 System is designed for pleasure and light commercial marine vessels that require remote control of: • mechanically actuated engines • solenoid activated clutches •...

  • Page 24: Figure 1-3: Basic 9210 Clearcommand System Diagram

    INTRODUCTION MM9000 ClearCommand User Manual Introduction 1.1.3 9210 Processor (Throttle-Electronic, Shift-Servo 1) The 9210 System is designed for pleasure and light commercial marine vessels that require remote control of: • electronic engine governors • mechanically actuated clutches The Processor is typically mounted in the engine room area and is connected to the electronic governor with a two-conductor, shielded, electric cable.

  • Page 25: Figure 1-4: Basic 9211 Clearcommand System Diagram

    INTRODUCTION MM9000 ClearCommand User Manual Introduction 1.1.4 9211 Processor (Throttle - Electronic, Shift - Servo 1, Troll - Servo 2) The 9211 System is designed for pleasure and light commercial marine vessels that require remote control of: • electronic engine governors •...

  • Page 26: System Features

    INTRODUCTION MM9000 ClearCommand User Manual Introduction 1.1.5 9221 Processor (Throttle - Electronic, Shift - Solenoid, Troll - Servo 2) The 9221 System is designed for pleasure and light commercial marine vessels that require remote control of: • electronic engine governors •...

  • Page 27: Operation

    OPERATION MM9000 ClearCommand User Manual Operation Operation DC Power On When DC power is turned ON to the Processor: • A short steady tone, followed by an intermittent tone, will sound at all Remote Stations indicating that no station has command.

  • Page 28: Basic Operation

    OPERATION MM9000 ClearCommand User Manual Operation Basic Operation 2.3.1 Normal Operating Mode A The Control Head has three detents; Ahead, Astern and Neutral. B With the Control Head lever positioned in the Neutral (vertical) detent, the Processor will command Neutral and the throttle at Idle revolutions per minute (RPM).

  • Page 29: Start Interlock (If Used)

    OPERATION MM9000 ClearCommand User Manual Operation D Further movement through the selectable 25, 35, 45, or 55 degrees, will increase the clutch pressure to maximum while the throttle remains at Idle. Further movement through the next 40, 30, 20, or 10 degrees will increase throttle to full, except when 45 degrees is selected (where throttle is limited to 75% of full) and 55 degrees is selected (where throttle is limited to 10% of full).

  • Page 30: Station Transfer

    OPERATION MM9000 ClearCommand User Manual Operation Station Transfer WARNING: Personal Injury may result if this message is disregarded. Command can be transferred as follows: A The Station-in-Command’s lever(s) may be left in any position. B Place the Control Head’s lever(s) of the receiving Station in the Neutral/Idle detent position (refer to...

  • Page 31: Warm-Up Mode

    OPERATION MM9000 ClearCommand User Manual Operation Warm-up Mode This feature allows the operator to increase the engine’s RPM, while the Clutch remains in Neutral. Warm-Up Mode is operational only when the Control Head lever is moved in the Ahead direction.

  • Page 32: High/Low Idle

    OPERATION MM9000 ClearCommand User Manual Operation High/Low Idle The Control System provides the input to the engine, so that it may run at the standard Idle speed (typically adjusted at the governor or carburetor), or it can provide a second elevated Idle speed.

  • Page 33: One Lever Mode (Twin Screw)

    OPERATION MM9000 ClearCommand User Manual Operation One Lever Mode (Twin Screw) NOTE: One Lever Operation may be used in Troll Mode or in Non-Troll Mode. NOTE: The Green LED will always be lit while in One Lever Operation, no matter what position the Master Control Head lever is in.

  • Page 34: Figure 2-13: Step B) One Lever Operation Mode

    OPERATION MM9000 ClearCommand User Manual Operation • The Control Head lever which was left in the Ahead detent is now inactive. Figure 2-13: Step B) One Lever Operation Mode NOTE: The Control Head lever designated by the operator to be inactive in One Lever Operation, may be left in the Ahead detent or moved fully forward.

  • Page 35: Engine Synchronization (Twin Screw)

    OPERATION MM9000 ClearCommand User Manual Operation 2.10 Engine Synchronization (Twin Screw) Engine Synchronization must be selected during Set Up to have automatic synchronization. NOTE: The Control System offers two types of synchronization, Active or Equal Throttle. Synchronization is automatic and only operates when the Ahead clutch is engaged, consequently it can be left ON full time.
  • Page 36 OPERATION MM9000 ClearCommand User Manual Operation NOTE: In order for Equal Throttle Synchronization to work properly in Systems with mechanical Throttles, the bends in the push-pull cables must be kept to a minimum. There can be no back-lash in the linkage or cables.

  • Page 37: 2.11 Control System's Configurability

    OPERATION MM9000 ClearCommand User Manual Operation 2.11 Control System’s Configurability The Processor is designed in a way which allows it to be easily configured by the installer to meet the varying needs of a wide variety of vessels. Below you will find a list and a brief description of the groups of these functions.
  • Page 38 This section along with the Basic Clutch Functions Section allows the adjustment of Clutch Solenoid related items: • C5 Shift Solenoid Type - Selects the approximate current levels for the 12 or 24 VDC ZF Hurth Solenoids. • C6 ZF-Hurth Duty Cycle Ahead - Fine tunes the maximum current level to the Ahead Proportional Solenoid.

  • Page 39: 2.12 Audible Tones

    • L1 Troll Valve Function - Selects the proper current range for a particular gear. This Function must be the 3rd function set if ZF Hurth Gears are used. • L2 Troll Minimum Pressure - Adjusts the amount of current at minimum Shaft rotation.
  • Page 40 OPERATION MM9000 ClearCommand User Manual Operation 2.12.2 Throttle (Servo 2) Tones The following Tones are in addition to the Basic Processor Tones. 2.12.2.1 One Long - Two Short Tones Detail information on this tone is in Section 10: Troubleshooting. This tone indicates that the feedback potentiometer signal from Servo 2 (Throttle) has gone out of range.

  • Page 41: 2.13 Push Button Set Up

    OPERATION MM9000 ClearCommand User Manual Operation 2.12.7.2 One Long, Four Short - High Repetitive Rate Tone Detail information on this tone is in the Manual supplied with the 9001 Trolling Actuator. This tone indicates that Trolling Actuator Servo cannot reach the commanded position.

  • Page 42: 2.15 Pluggable Connections

    OPERATION MM9000 ClearCommand User Manual Operation 2.15 Pluggable Connections 2.15.1 Standard Pluggable Processor The standard Processor comes from the factory with five Pigtail Connectors for easy, mistake free pluggable installations. Not all Processors are supplied with all of these pigtails.

  • Page 43: 2.16 Optional Features Operation

    This Manual, as written, is intended for Single and Twin Screw applications only. The Processor has the capability of controlling Triple, Quad and Quint Screw vessels. In order to do so, contact your ZF Marine Propulsion Systems Miramar, LLC representative for the required information and materials.
