Summary of Contents for Green Lighting Corp GLC-SL32-3565
- Page 1 High Power LED Street Light User Manual www.mygreenlightingcorp.com...
- Page 2 Product Information 1. With our unique and innovative modular design, our street lights can be easily configured for different power and brightness. Every module is an independent light source and can be interchanged. In the unlikely event of a partial failure it will not affect the normal operation of the whole lamp.
- Page 3 11.Designed to IP67 to ensure the Street Light is Waterproof and Dustproof. 12.Reliable driver circuit design with constant current (power efficiency of >80%). 13.Automatic control: Brightness can be adjusted according to time and external environment, thereby contributing to energy savings. Product Specifications: GLC-SL52-7065 GLC-SL32-3565 GLC-SL62-14565 GLC-SL82-20065...
- Page 4 Datasheet: Number Model GLC-SL32-3565 GLC-SL52-7065 GLC-SL62-14565 GLC-SL82-20065 Input voltage AC 90～264V Frequency range 47～63Hz Power Factor 0.95 Power Efficiency (testingat rated voltage, load room temprature) Cert. short-circuit protection, overcurrent protection, undervoltage protection<76V, overvoltage Circuit Protection protection (280-300V) self-recovery, anti surge, lightning protection and over-temperature...
- Page 5 Warnings: ·Please strictly follow the installation instructions . Improper installation may cause electric shock or Death. ·Warranty will be void in case of damage due improper installation. ·Power should not exceed stated range (rated voltage 90-264V, frequency 47-63Hz), (Power AC220V must be switched off when wiring, make sure wires are connected properly.
- Page 6 Installation Instruction: Notice: Please ensure the power is switched off prior to installation. 1. Open the wiring cover , fix the waterproof Socket strip cable to the correct length as ⑤ ① shown(Diagram 1&2&3). 2. Fix cable to the lamp body: insert cable into the lamp body and fix the cable to the body by ③...
- Page 7 Diagram 3 L:RED WIRE N:BLUE WIRE Diagram 4 Diagram 6 Diagram 5...
- Page 8 M8 screws cable ② ③ （input） ④Cable holder cable(lamp) pole ⑥ ⑦ Packing: As per GLC-SL62-14565 Packing Packing specifications material Finished GLC-SL32-3565 GLC-SL52-7065 GLC-SL62-14565 GLC-SL82-20065 street light Carton 462*220*142mm 586*375*157mm 746*375*157mm 906*375*157mm Foam box(top) 445*204*63mm 570*359*46mm 730*359*46mm 890*359*46mm Foam 445*204*63mm...
