MEMBERS PARK M3207ALP Operator's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Liquid Propane Gas (LPG)
Grill
Model M3207ALP
Natural Gas (NG) Grill
Model M3207ANG
Grill Information Center:
Call us first if you have any problem with
this product. We can help you with ques-
tions about assembly and operation or if
there are damaged or missing parts when
you unpack this unit from the shipping box.
Please call before returning to the store.
1- 800-770-9769
8am-4:30pm CST, Monday through Friday
IMPORTANT:
Ÿ
NOTE TO ASSEMBLER / INSTALLER:
Leave this manual with the consumer.
Ÿ
NOTE TO CONSUMER:
Keep this manual for future reference.
Ÿ
RECORD YOUR SERIAL # __________________
(see silver CSA label on main body of grill)
OPERATOR'S MANUAL
WARNING
!
Ÿ
Failure to comply with these instructions could
result in a fire or explosion that could cause
serious bodily injury, death or property
damage.
Ÿ
Before using this grill read all instructions
and perform all gas leak-check procedures even
if the product was pre-assembled by the retailer
or manufacturer.
Ÿ
Use your grill at least 3 feet away from
any wall or surface. Use your grill at least
3 feet away from combustible objects that can
melt or catch fire (such as vinyl or wood siding,
fences and overhangs) or sources of ignition
including pilot lights on water heaters and
live electrical appliances.
Ÿ
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
Ÿ
Combustion byproducts produced when using this
product contain chemicals known to the State of
California to cause cancer, birth defects, or other
reproductive harm.
Ÿ
This product contains chemicals known to
the State of California to cause cancer, birth
defects, or other reproductive harm.
Manual # P80109005L -
!
Date:2007/05/08

Advertisement

loading
Need help?

Need help?

Do you have a question about the M3207ALP and is the answer not in the manual?

Questions and answers

Summary of Contents for MEMBERS PARK M3207ALP

  • Page 1 OPERATOR'S MANUAL Liquid Propane Gas (LPG) Grill Model M3207ALP Natural Gas (NG) Grill Model M3207ANG WARNING Grill Information Center: Ÿ Failure to comply with these instructions could Call us first if you have any problem with result in a fire or explosion that could cause this product.

  • Page 2: Table Of Contents

    Table of Contents WARNING Primary Safety Warnings ......1-3 Pre-Assembly Instructions ......3 Do not store spare LP cylinder Part Diagrams and Lists ......4-10 within 10 feet (3m) of this appliance. Assembly Instructions......11-16 Do not store or use gasoline or Use &...

  • Page 3: Pre-Assembly Instructions

    Pre-Assembly Instructions For Your Safety WARNING WARNING For safe operation ensure the Gas Valve Assem- Failure to comply with these instructions could bly Orifice is inside the Burner Tube before using result in a fire or explosion that could cause your grill.
  • Page 4 Hardware Pack Parts List for Models M3207ALP & M3207ANG PART # PART DESCRIPTION QTY PURPOSE OF PART P06002016A Hardware Pack For use in assembly (For LPG model only) P06002017A Hardware Pack For use in assembly (For NG model only) S112G03061 Phillips Head Screw 3/16"x3/8"...
  • Page 5 Hardware Pack for Models M3207ALP & M3207ANG Phillips Head Screw Phillips Head Screw Phillips Head Screw Flange Nut 3/16" 1/4" x 1/2" 3/16" x 3/8" 1/4" x 1-3/16" Qty. 4 (LPG model) Qty. 16 Qty. 10 (LPG model) Qty. 4 Qty.
  • Page 6 Parts Diagram for Models M3207ALP & M3207ANG Parts Diagram for Models M3207ALP & M3207ANG 50 46 48 49 76 74 68(NG Only) (LPG Only)
  • Page 7 Parts List for Models M3207ALP & M3207ANG DESCRIPTION PART# Lid Ass embly Y0110045 Temperature Gauge P00601061A Lid Handle P00205069B Protective Pad P05518002I Cooking Rack/Secondary P01516003A Cooking Grid P01604014A Cooking Grid P01604015A Burner/Main P02008024A Infrared Burner P02005004A Infrared Burner Electrode Assembly Y0320011 Savor Plates®...
  • Page 8 Parts List for Models M3207ALP & M3207ANG DESCRIPTION PART# Electric Ignitor, 5-port P02502218C Side Burner Lid P01127004B Side Burner Frame P01104010A Side Burner Body P02301015B Side Burner Pot Support P00805010A Side Burner P02002012A Side Burner Electrode P02614007C Control Knob for Side Burner...
  • Page 9 Parts List for Models M3207ALP & M3207ANG DESCRIPTION PART# Cart Panel Bracket-B, Right Rear P03342006A Door Hinge Bracket, Left Lower P03302023A Door Hinge Bracket, Right Lower P03302024A Cas ter, 2.5 in., with Brake P05110006D Door Handle P00201001C Door, Left P04302036A...
  • Page 10 Y0250089 Rotisserie Assembly Parts Diagram Y0250089 Rotisserie Assembly Parts List PART# DESCRIPTION P05508004E Rot. Handle P05508092F Rot. Bushing Rot. Thumbscrew 3/8"x1/2" S196G06084 Rot. Collar P05508091F P05508146F Rot. Spit P05508090F Rot. Holding Fork Rot. Motor Bracket P03307028A Rot. Motor/AC P07101008B S112G10124 Rot.

  • Page 11: Assembly Instructions

    Assembly Instructions Remove all packed components. Use the parts list to check that all necessary parts have been included. Assemble the gas grill on a protective work surface to avoid scratching grill surfaces. Inspect your grill for damage as you proceed. Do not assemble or operate your grill if it appears damaged.
  • Page 12 Install Door Handles, Cart Spice Basket and Door (two Bas- kets for NG model) Intall the Door Handles to Doors using 4 of 3/16"x1/4" Phillips Head Screws. Install the Cart Spice Basket to Cart Bottom Shelf using 4 of M4 x 10 Self-Tapping Screw. Insert Bottom Left Door Hinge into Bottom Left Door Hinge Bracket.
  • Page 13 Install Side Shelf Brackets Attach the Side Shelf Bracket (RR) to the Rear of Right Bowl Panel. Attach the Side Shelf Bracket (RF) to the Front of Right Bowl Panel. Tighten securely by using 1/4” x 1/2” Phillips Head Screws. Repeat for Left Side Shelf Brackets installing.
  • Page 14 Install Side Burner Connection Hose Push back Sleeve of the Socket. See Figure A. Insert Plug then release Sleeve. See Figure B. Push Plug until sleeve snaps forward locking the Plug into the Socket. See Figure C. Push the Side Burner Hose into hose holder. Figure A PLUG SOCKET...
  • Page 15 Install Regulator Assembly (For NG model only) Install NG Regulator Assembly to Right Cart Side Panel using 2 of 3/16” x 1/4” Phillips Head Screws. Place the NG regulator into the hole on Right Cart Side Panel. Tighten securely using Brass Nut found in the NG Regulator.
  • Page 16 Install Ignitor Battery Unscrew Ignitor Cap from Control Panel. Place supplied AA battery into the Ignitor Slot with positive pole facing you. Ignitor Cap Position the Cap and Spring over the AA battery and tighten onto Control Panel. AA Battery With the assistance of another person, perform this Electrode Check before proceeding.

  • Page 17: Use & Care Instructions

    USE AND CARE INSTRUCTIONS CORRECT LP GAS TANK USE Use of alcohol or drugs may impair the ability to assemble and operate the appliance. LP Gas grill models are designed for use with a standard 20 lb. Liquid Propane Gas (LP Gas) tank, Keep fire extinguisher readily accessible.
  • Page 18 USE AND CARE INSTRUCTIONS LP Gas Model only: NOTE about LP Gas Tank Exchange Programs Ÿ Secure a 20lb LP Gas Tank to Gas Grill Many retailers that sell grills offer you the option of replacing your empty LP Gas tank through an ex- Turn your LP Gas Tank Valve clockwise to the change service.
  • Page 19 USE AND CARE INSTRUCTIONS LP Gas Model only: Check all connections for LP Gas Leaks Connect Regulator with Hose to your LPG Tank Never test for leaks with a flame. Prior to first use, at the beginning of each season, or every time Turn all Burner Valves to the OFF position.
  • Page 20 USE AND CARE INSTRUCTIONS Natural Gas Model only: Figure 1 Connecting Natural Gas To Your Grill Connect the Swivel nut of the 12' Natural Gas Swivel nut Hose, 12 ft./ NG Horizontal fitting Hose to the horizontal fitting of NG Regulator as shown in Fig.
  • Page 21 USE AND CARE INSTRUCTIONS Grill Lighting Instructions Burner Control Knobs on Control Panel Before each use, check all hoses for cracks, nicks, cuts, burns or abrasions. If a hose is damaged in any way, do not use your grill before replacing the hose with an authorized part from the Parts List.

  • Page 22: Lighting Instructions

    USE AND CARE INSTRUCTIONS Troubleshooting Manually Lighting Your Grill By Paper Match If the grill fails to light : To light your gas grill by match, insert a match into the Turn gas off at source and turn Control Knobs to OFF. Lighting Stick and follow steps 1 through 6 of the Grill Wait at least 5 minutes for gas to clear, then retry.
  • Page 23 USE AND CARE INSTRUCTIONS CORRECT ROTISSERIE USE WARNING Read all instructions before initial use. IMPORTANT: When using electrical appliances, basic To protect against electrical shock, do not immerse safety precautions should always be used. electrical cord, plugs or motor in water or expose to The Rotisserie Motor is set for 120V, 60Hz AC current.

  • Page 24: Rotisserie Instruction

    Rotisserie Instructions 1. Remove all components from the carton. Attach the Motor Bracket on the outside of the left grill bowl panel. Align the two holes of the Bracket with the holes on the grill bowl. Tighten securely using two Screws #10-24x3/4" UNC, Plain Washers and Nuts provided.
  • Page 25 Install the AC (alternating current) Rotisserie Motor onto the Motor Bracket as shown below. Be sure the Motor attaches to the Bracket with the electrical cord down. This installation insures that once the Spit is inserted into the Motor it will also rest securely into the slot of your grill bowl. Rotisserie M otor Motor Bracket Rotisserie Spit must rest securely...

  • Page 26: Cleaning And Maintenance

    ® Replace Savor Plates and Cooking Grids. CLEANING AND MAINTENANCE Reconnect the gas source and observe the Proper care and maintenance will keep your grill in top Burner flame for correct operation. operating condition and prolong its life. Follow these Cleaning Exterior Surfaces: cleaning procedures on a timely basis and your grill will stay clean and operate with minimum effort.
  • Page 27 CLEANING THE BURNER TUBES AND BURNER PORTS To reduce the chance of FLASHBACK FIRE you must Regardless of which Burner cleaning procedure you clean the Burner Tubes as follows at least once a month use, we recommend you also complete the following in summer and fall or whenever spiders are active in your steps to help prolong Burner life.
  • Page 28 Cooking Instructions Burn-Off Before cooking on your gas grill for the first time, you Lid to be open. This method is ideal for searing, should "burn off" the grill to eliminate any odor or grilling, deep frying and whenever you want foods to foreign matter.
  • Page 29 Guide to Rotisserie Cooking Guide to Smoking Slow Cooking with a Rotisserie Preparing to Smoke Rotisserie cooking produces foods that are moist, Smoking gives food a distinctive, delicious flavor. You will flavorful and attractive. The rotisserie system is most find a variety of wood chips available for use in smoking commonly used for cooking meat or poultry and is grilled foods.
  • Page 30 OPTIONAL GRILL ACCESSORIES Cast-Iron Cooking Pan with Lid This cast iron pan conducts heat wonderfully and cooks evenly, making this the ideal accessory for baking and roasting on your new grill. Prepare pizza, potatoes, stew, corn bread and des- serts. Can be used in place of 1 grid and Flame Tamer or use on...
  • Page 31 Question: Question: Sometimes I hear a humming sound coming from my Can I convert my grill from one fuel type to another in regulator. What causes this? And - My grill has a low other words from LPG to NG or vice versa? flame and sometimes will not light.
  • Page 32 Cooking Grids before and after each cookout. Use a Question: brush to apply a thin layer of cooking oil or vegetable The Regulator and Hose supplied with my gas grill shortening onto each Cooking Grid. We do not does not fit the older LP Gas tank I’ve used for suggest spray type oils unless they are specified for years.
  • Page 33 Grand Hall Limited Warranty Grand Hall Enterprise Co., Ltd. will warrant to the ORIGINAL PURCHASER of this gas grill that it will be free of defects in material and workmanship for set periods below from the date of purchase when used under normal outdoor use and correct assembly: Full Warranty on Grill –...
