Summary of Contents for Syrincs P6W
- Page 1 User manual...
- Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 09.02.2016 Issue 1...
-
Page 3: Table Of Contents
Table of contents Table of contents 1 General information about this manual 2 For your safety 3 Features 4 Installation 5 Technical specifications 6 Plug and connection assignment 7 Protecting the environment User manual P6W (Issue 1) 3 / 16... -
Page 4: General Information About This Manual
This warns of dangers that can result to faults during operation and/or considerable material damage. Environmental damage may also occur if the instructions are not followed. Symbols used General warning of a dangerous location Notice 4 / 16 User manual P6W (Issue 1) -
Page 5: For Your Safety
à Decrease the volume level immediately if you experience ringing in your ears or hearing impairment. If this is not possible, keep a greater distance or use sufficient ear protectors. User manual P6W (Issue 1) 5 / 16... - Page 6 Operating conditions This device has been designed for indoor use only. à To prevent damage, never expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and strong vibrations. 6 / 16 User manual P6W (Issue 1)
-
Page 7: Features
– Connection options: locking NL4 plug connector on front and back – Multiplex housing (black/grey) – Pole mount (2 × M20) – Suitable for set-up as cardioid array Optionally available accessories: – Transport casters User manual P6W (Issue 1) 7 / 16... -
Page 8: Installation
If you notice distortion during operation, either the amp or the speaker is over- loaded. This may permanently damage the amp or the speaker. Always reduce the volume as soon as you notice distortion. 8 / 16 User manual P6W (Issue 1) -
Page 9: Technical Specifications
Frequency range 36 Hz … 120 Hz (–3 dB) Dimensions (W × H × D) 590 mm × 550 mm × 680 mm Weight 45 kg 550 mm 590 mm 680 mm User manual P6W (Issue 1) 9 / 16... -
Page 10: Frequency Response
Technical specifications Frequency response 10 / 16 User manual P6W (Issue 1) -
Page 11: Plug And Connection Assignment
NL4 connection 1, + Signal 1 (in phase) 1, – Signal 1 (out of phase) 2, + Signal 2 (in phase) 2, – Signal 2 (out of phase) User manual P6W (Issue 1) 11 / 16... -
Page 12: Protecting The Environment
Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste dis- posal facility. 12 / 16 User manual P6W (Issue 1) - Page 13 Notes User manual P6W (Issue 1) 13 / 16...
- Page 14 Notes 14 / 16 User manual P6W (Issue 1)
- Page 15 Notes User manual P6W (Issue 1) 15 / 16...
