Academy of Model Aeronautics Fokker Eindecker E.III ARF Instructions For Final Assembly

A 380 size electric slowflyer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Product Part Number 128411
FOR YOUR INFORMATION
To make your modeling experience totally enjoyable, we recommend that you get experienced, knowledgeable help with
assembly and during your first flights. Your local hobby shop has information about flying clubs in your area whose
membership includes qualified instructors. If there is no hobby shop in your area, we recommend that you contact the
AMA at the address below. They will be able to help you locate a flying field near you.
The Wattage Fokker Eindecker E.III ARF is distributed exclusively by Global Hobby Distributors 18480 Bandilier Circle, Fountain Valley, CA 92728
All contents copyright © 2001, Global Hobby Distributors Version V1.0 September 2001
For more cool Wattage products visit our website at http://watt-age.globalhobby.com
INSTRUCTIONS FOR FINAL ASSEMBLY

Specifications:

Academy of Model Aeronautics
5151 East Memorial Drive
Muncie IN 47302-9252
(800) 435-9262
www.modelaircraft.org
Wing Area: 340 square inches
Wing Span: 42.25 inches
Length: 31.5 inches
Functions: Rudder, Elevator, Throttle
Power: 380 Motor w/Gear Box (included)
Radio: 3 Channel Micro System
