DIRTY HANDS 104609 Operation Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

950 Watts

/1200Watts

/2000Watts

(104609)

(104610)

(104611)

PORTABLE INVERTER GENERATORS

MODELS #104609, #104610 and #104611

Operation Manual

This safety alert symbol identifies important safety messages in

this manual. Failure to follow this important safety information

may result in serious injury or death.

Part # 104827

Table of Contents

Need help?

Do you have a question about the 104609 and is the answer not in the manual?

Questions and answers

Summary of Contents for DIRTY HANDS 104609

Page 1: Operation Manual
/2000Watts (104609) (104610) (104611) PORTABLE INVERTER GENERATORS MODELS #104609, #104610 and #104611 Operation Manual This safety alert symbol identifies important safety messages in this manual. Failure to follow this important safety information may result in serious injury or death. Part # 104827...
Page 2 For Service or Questions Call 1-877-487-8275 720-287-5182 www.dirtyhandtools.com Dirty Hand Tools® is a brand of 1100 W 120th Ave, Suite 600 Westminster, CO 80234 • 720-287-5182...
Page 3: Table Of Contents
Table of Contents Important Safety Information .............4 Components ...................7 Operation Precautions ..............8 Operation ..................9 Maintenance .................12 Troubleshooting ................16 Storage ..................17 Warranty and Specifications .......... Back Cover...
Page 4: Important Safety Information
Important Safety Information WARNING WARNING: Read and thoroughly understand all instructions and safety information before operating this portable power generator. Failure to do so may cause serious injury or death. Do not allow anyone to operate this portable power generator who has not read this manual.
Page 5: General Safety
Important Safety Information General Safety Failure to follow warnings, cautions, assembly and operation instructions in the Operation Manual may result in serious injury or death. DANGER USING A GENERATOR INDOORS CAN KILL YOU IN MINUTES Exhaust contains carbon monoxide which is a poison DANGER that you cannot see or smell.
Page 6 Important Safety Information • Never run the engine in an enclosed area or without proper ventilation as the exhaust from the engine contains carbon monoxide, which is an odorless, tasteless, and deadly poisonous gas. • Fill the gasoline tank outdoors with the engine off and allow the engine to cool completely.
Page 7: Components
Components The portable power generator is assembled at the factory. Illustrated below are the operational controls and maintenance components of the inverter generator. Part Description Economy Control Switch Engine ON/OFF Switch Fuel Tank Spark Plug Cover Muffler Carrying Handle Choke Lever AC Pilot Light Overload Indicator Light Oil Warning Light...
Page 8: Operation Precautions
Operation Precautions Sensitive electronic equipment, including but not limited to audio/video equipment, television sets, computers, and printers, can be operated on this inverter type generator, However, if the plugged in product operates abnormally or unusually slow, immediately stop using the generator as a power source.
Page 9: Operation
Operation WARNING ADD OIL TO THE GENERATOR BEFORE OPERATION. 1. Place the portable power generator on a level surface. Check the oil level with the dipstick (see Figure 3). Do not screw in the oil filler cap when checking oil level. 2.
Page 10 Operation Starting the Generator 1. Remove all connected devices. 2. Open the fuel tank air vent to the “OPEN” position. 3. Turn the fuel On/Off lever to the “ON” position. 4. Turn the engine switch to the “ON” position 5. Press the primer bulb 5 - 6 times. 6.
Page 11 Operation Overload Indicator Light The total combined load through the outlet on the generator must not exceed the rated maximum power of the unit. Calculating Power Draw Power draw can be calculated by multiplying volts and amps. The resulting number is wattage.Never exceed the rated maximum wattage for the generator or outlet.
Page 12: Maintenance
Maintenance WARNING BEFORE PERFORMING ANY MAINTENANCE PROCEDURE STOP THE ENGINE, WAIT FIVE (5) MINUTES TO ALLOW ALL PARTS TO COOL. Disconnect the spark plug wire, keeping it away from the spark plug. Regular maintenance is the way to ensure the best performance and long life of your machine.
Page 13 Maintenance REMOVE Engine Oil Replacement SCREWS 4 PLACES 1. Place the machine on a level surface and warm up the engine for several minutes. Then stop the engine and turn the fuel On/Off switch to “OFF””. Turn the fuel tank cap air vent clockwise.
Page 14 Maintenance SPARK PLUG ACCESS COVER WARNING TO PREVENT SERIOUS INJURY FROM ACCIDENTAL STARTING TURN THE ENGINE POWER SWITCH TO THE “OFF” POSITION. Wait for the engine to cool, and remove the spark plug wire before performing any inspection, maintenance, or cleaning. Spark Plug Maintenance: Figure 8 1.
Page 15 Maintenance Cleaning the Fuel Tank Filter 1. Remove the fuel tank cap and filter (see Figure 11). 2. Clean the filter with solvent. If damaged, replace. 3. Wipe the filter clean and insert it. FUEL TANK WARNING FUEL FILTER TIGHTEN TANK CAP SECURELY Figure 11 Muffler Screen Avoid touching the engine and muffler while they are still hot...
Page 16: Troubleshooting
Troubleshooting WARNING BEFORE PERFORMING ANY MAINTENANCE PROCEDURE STOP THE ENGINE, WAIT FIVE (5) MINUTES TO ALLOW ALL PARTS TO COOL. Disconnect the spark plug wire, keeping it away from the spark plug. PROBLEM SOLUTION The engine will not start. • Fuel On/Off Switch not ON. •...
Page 17: Storage
Storage 1. Wait for the engine to cool, then clean the engine with a clean cloth. 2. When the generator is to be stored for longer than 20 days, prepare the engine for storage by emptying the fuel tank and draining all fuel lines. Clean out area around spark plug and remove.
Page 18 Notes...
Page 19 Notes...
Page 20: Warranty And Specifications
Record the information below for future reference. Model No. Serial No. Date of Purchase Place of Purchase Specifications SKU/Part No. 104609 104610 104611 Description 950W Inverter Generator 1200W Inverter Generator 2000W Inverter Generator Peak Wattage...

This manual is also suitable for:

104610 104611
