Summary of Contents for Strategic Vista SG250
- Page 1 5” 4-CHANNEL B&W OBSERVATION SYSTEM MODEL SG250, SG251 & SG254 FOR MORE INFORMATION WWW.STRATEGICVISTA.COM Before operating the system, please read this manual thoroughly and retain it for future reference!!! Rev 03/03 - 1...
-
Page 2: Important Safety Instructions
CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Explanation of two Symbols The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT SAFEGUARDS All the safety and operating instructions should be read before the appliance is operated and retained for future reference. 1. HEED WARNINGS - All warnings on the appliance and in the operating instructions should be adhered to. 2. -
Page 4: Table Of Contents
System. This system has the capability of connecting up to four cameras, allowing you to view up to four locations. The PIR Motion Sensor camera included with some of the SG250 series models provides motion alarm sensing function to alert the user of camera activity. Other features integrated with this system include: two way audio, recording the picture to any VCR and sequential or full screen viewing. - Page 5 MONITOR CONTROLS – FRONT PANEL 1) On/Off Power Switch – Pressing this switch will turn the monitor ON/OFF. (Note: ensure this switch is set to the OFF position prior to plugging into an electrical outlet). 2) Volume Control – Adjust this button to control the volume sound. 3) Brightness Control –...
- Page 6 MONITOR CONTROLS – BACK PANEL 1) AC Input Jack – Power source to the monitor. Connect one end to the monitor; the other end to an electrical outlet. 2) VCR Audio Out – Use with A/V cables (not supplied) to connect to a recording device (eg. Time Lapse VCR). 3) VCR Video Out –...
- Page 7 WIRED CAMERA INSTALLATION 1. Attach the stand base to the wall or ceiling where you want to install the camera. Locate a wall stud or ceiling joist and secure bracket using the supplied mounting screws. 2. Attach the camera to the stand and firmly tighten the swivel. 3.
-
Page 8: Monitor
OPERATION CONNECTING MONITOR TO A VCR Monitor RCA Cables (not included) Connections Connect the supplied audio/video cable from the back of the monitor to the Audio/Video In of the VCR. Did You Know? You have the option of connecting this system to a Time Lapse VCR. A time lapse VCR provides you multiple recording options allowing you to record up to 40 days using a standard T120 tape. -
Page 9: Optional Accessories
OPTIONAL ACCESSORIES The following accessories are available to add to your existing system. CABLE TIME LAPSE VCR NIGHTVISION Weatherproof Night vision Extends viewing length Used to record key events. accessory. Allows you to from Camera to monitor. Select From a 40 hour real see in the dark up to 35-40 Available In 65, 100 and time or 960 Hour time... -
Page 10: Specifications
800 mA Operating Temperature 14º F to + 122º F (-10ºC to + 50 ºC) Weight 3 Lbs. SYSTEM INCLUDES SG250 (INCLUDES) 5” B&W Monitor AC Adapter English, French and Spanish Owners Manual SG251 (INCLUDES) 5” B&W Monitor AC Adapter 1 –...
