Summary of Contents for Embest LCD8000-97C
- Page 1 LCD8000-97C Operation Guide Embest Technology http://www.embest-tech.com...
-
Page 2: Table Of Contents
Connecting to MarS Board ....................2 Hardware Connections ..................2 Software Configurations ..................3 Connecting to SABRE Lite ....................5 Hardware Connections ..................5 Software Configurations ..................6 Technical Support and Warranty ..................9 Copyright © 2013 Embest Technology LCD8000-97C Operation Guide... -
Page 3: Product Overview
LCD8000-97C is a 9.7-inch capacitive touch-screen developed by Embest Technology for use with MarS Board – a supper ARM DIY platform and SABRE Lite. LCD8000-97C has a LVDS interface and supports a resolution of up to 1024x768 and a 260,000 colors. Its multi-touch screen brings better experience to the users of MarS Board and SABRE Lite. -
Page 4: Connecting To Mars Board
Using LCD8000-97C on MarS Board 1. Hardware Connections 1） Use the Mini HDMI cable provided with the product to connect the LVDS interface on MarS Board to the Mini HDMI interface on LCD8000-97C as shown below; Connection between MarS Board and LCD8000-97C Figure 1 2）... -
Page 5: Software Configurations
1） The latest images and source code for Linux and Android on MarS Board have been able to support LCD8000-97C; Please visit to download them; 2） Please refer to Chapter 4 in the User Manual of MarS Board to update Linux/Android images on the board;... - Page 6 LDB-XGA,if=RGB666 fbmem=10M vmalloc=400M androidboot.console=ttymxc1 saveenv Note: At present, the touch screen of LCD8000-97C only support single point touch on Linux system 5） Reboot MarS Board again and then you can see LCD8000-97C working properly. Copyright © 2013 Embest Technology...
-
Page 7: Connecting To Sabre Lite
Using LCD8000-97C on SABRE Lite 1. Hardware Connections 1） Use the LVDS cable provided with the product to connect the Mini HDMI interface on LCD8000-97C to the LVDS and IIC interfaces on SABRE Lite as shown below; Connections between SABRE Lite and LCD8000-97C Figure 3 2）... -
Page 8: Software Configurations
U-Boot 2009.08 (Nov 13 2013 - 11:06:28) CPU: Freescale i.MX6 family TO1.2 at 792 MHz Temperature: 42 C, calibration data 0x5764fd69 mx6q pll1: 792MHz mx6q pll2: 528MHz mx6q pll3: 480MHz Copyright © 2013 Embest Technology LCD8000-97C Operation Guide... - Page 9 MX6Q SABRELITE U-Boot > 4） Execute the following instructions to set the display mode for the 9.7-in LVDS LCD; setenv bootargs console=ttymxc1,115200 init=/init rw video=mxcfb0:dev=ldb, LDB-XGA,if=RGB666 fbmem=10M vmalloc=400M androidboot.console=ttymxc1 saveenv Copyright © 2013 Embest Technology LCD8000-97C Operation Guide...
- Page 10 Embest Technology Note: At present, the touch screen of LCD8000-97C only support single point touch on Linux system 5） Reboot SABRE Lite again and then you can see LCD8000-97C working properly. Copyright © 2013 Embest Technology LCD8000-97C Operation Guide...
-
Page 11: Technical Support And Warranty
Embest Technology Technical Support and Warranty Technical Support Embest Technology provides its product with one-year free technical support including: Providing software and hardware resources related to the embedded products of Embest Technology; Helping customers properly compile and run the source code provided by Embest Technology;... - Page 12 4） Please contact technical support if there is any repair request. Note: Embest Technology will not take any responsibility on the products sent back without the permission of the company. Copyright © 2013 Embest Technology...
-
Page 13: Contact Information
Fax Number: +86-755-25616057 Email Address: market@embedinfo.com Company Information Company Website: http://www.armkits.com http://www.embest-tech.com Company Address: Tower B 4/F, Shanshui Building, Nanshan Yungu Innovation Industry Park, Liuxian Ave. No. 1183, Nanshan District, Shenzhen, Guangdong, China (518055) Copyright © 2013 Embest Technology LCD8000-97C Operation Guide...
