SPEED LIMIT RC
Pivoted canopy
Retractable landing gear
Adopt the folding wingspan
SPEED LIMIR RC
reserve the right to modify the specification or
printing errors without prior notice.
F-4U
CORSAIR
A R/C model airplane is not a toy and is not suitable for flyer under 14 years old.
Read the instructions carefully before any use.
If you are a beginner, it is necessary to let an experienced airplane pilot assist you.
WWW.SPEEDLIMITRC.COM
Advertisement
Table of Contents
Related Manuals for Speed Limit RC F4U CORSAIR
Summary of Contents for Speed Limit RC F4U CORSAIR
- Page 1 SPEED LIMIT RC F-4U CORSAIR Pivoted canopy Retractable landing gear Adopt the folding wingspan A R/C model airplane is not a toy and is not suitable for flyer under 14 years old. Read the instructions carefully before any use. If you are a beginner, it is necessary to let an experienced airplane pilot assist you.
-
Page 2: Meaning Of The Icons
F-4U SPEED LIMIT RC Instruction Manual Meaning of the icons. Only use genuine accessories as replacmente for damaged parts. WARNING!:this symbol indicates where caution is essential to Accessories avoid injury to yourself or others . 7.Do not attempt to catch the PROHIBITED: this symbol points out actions that you should NOT do to avoid possible damage or accidents. - Page 3 F-4U SPEED LIMIT RC Instruction Manual Tail wheel installation: (4~11) Need a servo with 300mm line and big torsion, to control the tail wheel, infix to the fourth channel of the receiver. Length:1273mm Radio:12CH RC Brushless ESC:50A Wingspan:1600mm 12×Digital metal 17g servo Wing area：47.27d㎡...
-
Page 4: Left And Right
F-4U SPEED LIMIT RC Instruction Manual Left and right fuselage pasting: (12~14). Middle wing installtion: Flap servos installation as follows: (23~32) Need a positive servo and a reverse servo,both with 50mm line , and a 450mm Y wire, connect these two serve and the Y wire infix to the sixth channel of the receiver. - Page 5 F-4U SPEED LIMIT RC Instruction Manual Retracts installation as follows : (33~34) Need twelve 2.5x8mm screws, use for fixing the retracts. The installation of servos extension lines in aileron and folding wing as follows: (42~46) Need six 450mm extension lines.
- Page 6 F-4U SPEED LIMIT RC Instruction Manual Middle wing and fuselage connecting as follows:(55~57) Need four 3X54 screws, use for fixing the middle wing. Retract covers installtion as follows :(47~54). Outside of main wing installation: ( 1 ) Aileron servos installation as follows :...
- Page 7 F-4U SPEED LIMIT RC Instruction Manual Aileron horn and push rod installation :(70~72). ( 2 ) Folding wing servos installation as follows :(63~69) Connecting the servos with folding wing controller,then infixing the folding wing controller to the seventh channel of receiver.
-
Page 8: Horizontal Tail Installation
F-4U SPEED LIMIT RC Instruction Manual Vertical fin installation as follows :(89~97). Horizontal tail installation as follows :(81~88). Need a servo with 50mm line and a 600mm Y line to control the rudder, vertical Need a positive servo with 50mm line to install in the slot of right horizontal tail. -
Page 9: Power Package
F-4U SPEED LIMIT RC Instruction Manual Cowling installation as follows :(104~110). Need two 2X20 screws, to fixing the cowling Power package installation follows :(98~103). Need a 5060 model motor with 5KG tensile force, and a 50A ESC. WWW.SPEEDLIMITRC.COM... - Page 10 F-4U SPEED LIMIT RC Instruction Manual Propeller installation as follows :(111~115). Canopy installation as follows (116~131). WWW.SPEEDLIMITRC.COM...
- Page 11 F-4U SPEED LIMIT RC Instruction Manual Decal pasting as follows :(132~145). Bomb installation as follows :(146~157). WWW.SPEEDLIMITRC.COM...
- Page 12 F-4U SPEED LIMIT RC Instruction Manual Receiver installation as follows :(163~179). Decorating parts installation as follows :(158~162). WWW.SPEEDLIMITRC.COM...
- Page 13 F-4U SPEED LIMIT RC Instruction Manual Battery installation as follows (180~181). Energize and test all function whether work normal: (182~186). WWW.SPEEDLIMITRC.COM...
- Page 14 F-4U SPEED LIMIT RC Instruction Manual CG Debugging :(187). F-4U Installation finished:(188~189). rotary. WWW.SPEEDLIMITRC.COM...
