Packard Bell dot M/A Series
Service Guide
Service guide files and updates are available
on the ACER/CSD web; for more information,
please refer to
http://csd.acer.com.tw
PRINTED IN TAIWAN
Downloaded from LpManual.com Manuals

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DOTMA-111G16i and is the answer not in the manual?

Questions and answers

Related Manuals for Packard Bell DOTMA-111G16i

Summary of Contents for Packard Bell DOTMA-111G16i

  • Page 1 Packard Bell dot M/A Series Service Guide Service guide files and updates are available on the ACER/CSD web; for more information, please refer to http://csd.acer.com.tw PRINTED IN TAIWAN Downloaded from LpManual.com Manuals...
  • Page 2 Revision History Please refer to the table below for the updates made to this service guide. Date Chapter Updates Downloaded from LpManual.com Manuals...
  • Page 3 Copyright Copyright © 2009 by Acer Incorporated. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of Acer Incorporated.
  • Page 4 Conventions The following conventions are used in this manual: Denotes actual messages that appear SCREEN MESSAGES on screen. NOTE Gives bits and pieces of additional information related to the current topic. WARNING Alerts you to any damage that might result from doing or not doing specific actions.
  • Page 5 Preface Before using this information and the product it supports, please read the following general information. This Service Guide provides you with all technical information relating to the BASIC CONFIGURATION decided for Acer's "global" product offering. To better fit local market requirements and enhance product competitiveness, your regional office MAY have decided to extend the functionality of a machine (e.g.
  • Page 6 Downloaded from LpManual.com Manuals...

  • Page 7: Table Of Contents

    Your Packard Bell Notebook tour ........
  • Page 8 Table of Contents Removing the VGA Board ......... .63 Removing the LAN Board .
  • Page 9 FRU (Field Replaceable Unit) List Packard Bell dot M/A Exploded Diagrams ....... .146 Main Assembly .
  • Page 10 Table of Contents Downloaded from LpManual.com Manuals...

  • Page 11: System Specifications

    Chapter 1 System Specifications Features Below is a brief summary of the computer’s many features: Operating System • Genuine Windows® XP Home (Service Pack 3) • Genuine Windows Vista™ Platform • AMD Athlon™ 64 Processor L110 • Cache size:512KB, Frequency:1.2G (No P-state) •...

  • Page 12: Privacy Control

    • LAN: 10/100 Mbps Fast Ethernet • WPAN: Bluetooth® 2.0 or 2.1+EDR • WWAN: GSM/GPRS/EDGE/(WCDMA) (for 3G models) Privacy control • Kensington lock slot Dimensions and Weight • 286 (W) x 203 (D) x 29 (H) mm • 1.3 kg (2.86 lbs.) with 3-cell battery pack •...

  • Page 13: System Block Diagram

    System Block Diagram X'TAL 14.318MHz HOST 200MHz CHARGER LED D/B PCIE 100MHz ISL88731 CLOCK GENERATOR WLAN/3G SW USB 48MHz +3VPCU Silego:SLG84605TTR BT SW 3V/5V +3V_S5 AMD S1g1 Thermal Sensor IDT:ICS951462 DDRII-SODIMM1 DDR II 667 MHz REF 14.318MHz ISL6237 G781 WLAN/WiMax LED +3VSUS Channel A HTREF 66MHz...

  • Page 14: Your Packard Bell Notebook Tour

    Your Packard Bell Notebook tour After learning about your computer features, let us show you around your new computer. Front View Icon Item Description Acer Crystal Eye Web camera for video communication. Webcam Microphone Internal microphone for sound recording. Display screen Also called Liquid-Crystal Display (LCD), displays computer output.

  • Page 15: Closed Front View

    Icon Item Description Power button/ Turns the computer on and off while indicating the indicator computer’s power status. Closed Front View Icon Item Description Bluetooth Enables/disables the Bluetooth function. communication switch 3G/Wireless LAN Enables/disables the 3G/Wireless LAN communication switch Left View Icon Item Description...

  • Page 16: Rear And Base View

    Multi-in-1 card Accepts Secure Digital (SD), MultiMediaCard reader (MMC), Memory Stick (MS), Memory Stick PRO (MS PRO), xD-Picture Card (xD). Note: Push to remove/install the card. Only one card can operate at any given time. Microphone-in Accepts input from external microphones. jack Headphones/ Connects to line-out audio devices...

  • Page 17: Indicators

    Icon Item Description Ventilation slots Vents enable the computer to stay cool, even after and/or cooling fan prolonged use. Note: Do not cover or obstruct the cooling vents. Memory Houses the computer's main memory. compartment Battery lock Locks the battery in position. 3G SIM card slot Accepts a 3G SIM card for 3G connectivity (only for certain models).

  • Page 18: Touchpad Basics

    TouchPad Basics The following items show you how to use the TouchPad: • Move your finger across the TouchPad (1) to move the cursor. • Press the left (2) and right (3) buttons located beneath the TouchPad to perform selection and execution functions.

  • Page 19: Using The Keyboard

    Using the Keyboard Your Packard Bell dot Series has a close-to-full-sized keyboard and an embedded numeric keypad, separate cursor, lock, function and special keys. Lock Keys and embedded numeric keypad The keyboard has three lock keys which you can toggle on and off.

  • Page 20: Windows Keys

    Windows Keys The keyboard has two keys that perform Windows-specific functions. Description Windows key Pressed alone, this key has the same effect as clicking on the Windows Start button; it launches the Start menu. It can also be used with other keys to provide a variety of functions: <...

  • Page 21: Hot Keys

    Hot Keys The computer employs hotkeys or key combinations to access most of the computer's controls like screen brightness and volume output. To activate hotkeys, press and hold the <Fn> key before pressing the other key in the hotkey combination. Hotkey Icon Function...

  • Page 22: Special Keys

    Special Keys You can locate the Euro symbol and the US dollar sign at the upper-center and/or bottom-right of your keyboard. The Euro symbol Open a text editor or word processor. Hold <Alt Gr> and then press the <5> key at the upper-center of the keyboard. NOTE: Some fonts and software do not support the Euro symbol.

  • Page 23: Hardware Specifications And Configurations

    Hardware Specifications and Configurations Processor Item Specification CPU type AMD Athlon™ 64 Processor L110 CPU package 638-pin lidless micro PGA package. Core Logic • North Bridge-RS690E • South Bridge SB600 Chipset • Mobile Intel® US15W Express Chipset Features • Cache size: 512 KB, Frequency:1.2G (No P-state) •...
  • Page 24 Item Specification Features • Support PCI bus at 33MHz • Supports four SATA ports, complying with the SATA 1.0a specification • 5 OHCI and 1 EHCI Host controllers to support 10 USB ports, • audio • 4 Independent output stream(DMA). •...
  • Page 25 Item Specification Media data transfer rate (Mbytes/sec max) DC Power Requirements Voltage 5V ±5% 5V ±5% 5V ±5% 5V ±5% 5V ±5% tolerance Item Specification Vendor & Model Toshiba Toshiba Name WD1600BEVT WD2500BEVT MK1655GSX MK2555GSX Capacity (GB) Bytes per sector Data heads Drive Format Disks...
  • Page 26 Item Specifications Typical Power Consumption 2.85 (watt) Weight (without inverter) 255g 225g 255g 255g Physical Size (mm) 268 (L) x 268 x 161.5 x 268.0 x 161.5 268.0 x 161.5 161.5 (W) Electrical Interface LVDS LVDS LVDS LVDS Viewing Angle (degree) Horizontal (Right) / (Left) 45/45 45/45...
  • Page 27 Item Specification Internal & external keyboard work simultaneously Features • Supports Application keys for Windows XP version Mini Card Item Specification Number Supported Features • 1 for 3G (full size) • 1 for WLAN (half size) Camera Item Specifications Vendor and model Chicony CNF9011 Liteon 09P2SF001 SuyinCN0316-S30C-...
  • Page 28 Item Specification Specification Specification Specification Modulation DQPSK, DBPSK and CCK Schemes Channel Number • 1---11 channels for active channels • 12---13 channels for passive channels Data Rate 11Mbps with fall back rates of 5.5, 2, and 1Mbps Media Access CSMA/CA with ACK Protocol Transmitter Output 18dBm typically...

  • Page 29: System Utilities

    Chapter 2 System Utilities BIOS Setup Utility The BIOS Setup Utility is a hardware configuration program built into your computer’s BIOS (Basic Input/ Output System). Your computer is already properly configured and optimized, and you do not need to run this utility. However, if you encounter configuration problems, you may need to run Setup.

  • Page 30: Information

    Information The Information screen displays a summary of your computer hardware information. P h o e n i x B I O S S e t u p U t i l i t y Information M a i n Security B o o t Exit...

  • Page 31: Main

    Main The Main screen allows the user to set the system time and date as well as enable and disable boot option and recovery. P h o e n i x B I O S S e t u p U t i l i t y Information M a i n Security...

  • Page 32: Security

    Security The Security screen contains parameters that help safeguard and protect your computer from unauthorized use. P h o e n i x B I O S S e t u p U t i l i t y Information M a i n Security B o o t...
  • Page 33 Setting a Password Follow these steps as you set the user or the supervisor password: Use the ↑ and ↓ keys to highlight the Set Supervisor Password parameter and press the Enter key. The Set Supervisor Password box appears: S e t S u p e r v i s o r P a s s w o r d E n t e r N e w P a s s w o r d C o n f i r m N e w P a s s w o r d Type a password in the “Enter New Password”...
  • Page 34 Changing a Password Use the ↑ and ↓ keys to highlight the Set Supervisor Password parameter and press the Enter key. The Set Password box appears. S e t S u p e r v i s o r P a s s w o r d E n t e r C u r r e n t P a s s w o r d E n t e r N e w P a s s w o r d C o n f i r m N e w P a s s w o r d...

  • Page 35: Boot

    Boot This menu allows the user to decide the order of boot devices to load the operating system. Bootable devices includes the USB diskette drives, the onboard hard disk drive and the DVD drive in the module bay. P h o e n i x B I O S S e t u p U t i l i t y Information M a i n Security...

  • Page 36: Exit

    Exit The Exit screen allows you to save or discard any changes you made and quit the BIOS Utility. P h o e n i x B I O S S e t u p U t i l i t y Information Main Security...

  • Page 37: Bios Flash Utility

    BIOS Flash Utility The BIOS flash memory update is required for the following conditions: • New versions of system programs • New features or options • Restore a BIOS when it becomes corrupted. Use the Phlash utility to update the system BIOS flash ROM. NOTE: If you do not have a crisis recovery diskette at hand, then you should create a Crisis Recovery Diskette before you use the Phlash utility.

  • Page 38: Dos Flash Utility

    DOS Flash Utility Perform the following steps to use the DOS Flash Utility: Copy the flash utilities to the bootable diskette. Press F2 during boot to enter the Setup Menu. Select Boot Menu to modify the boot priority order, for example, if using USB HDD to Update BIOS, move USB HDD to position 1.
  • Page 39 In flash BIOS, the message Please do not remove AC Power Source displays. If the AC adapter is not plugged in the following message appears. Plug in the AC adapter and rerun the Phlash utility if the above message appears. If the AC adapter is connected, the following screen appears.

  • Page 40: Winflash Utility

    WinFlash Utility The Winflash utility consists of two files: • ZA8_3101.WPH (BIOS ROM file) • WinPhlash2.0.3.4 (BIOS windows flash tool) Perform the following steps to use the WinFlash Utility: Double click the WinFlash executable (WinPhlash2.0.3.4) to run the program. In the Specify New BIOS file field, enter the BIOS ROM file name and path. IMPORTANT:Be sure the AC power is plugged in.

  • Page 41: Remove Hdd/Bios Password Utilities

    Remove HDD/BIOS Password Utilities This section provides you with details about removing HDD/BIOS password methods: Removing HDD Password: If you key in the wrong HDD password three times, an error code is generated. To reset the HDD password, perform the following steps: On a different machine, run the HDD_PW.EXE file along with the error code generated.
  • Page 42 Removing BIOS Passwords: If you key in the wrong Supervisor password three times, an error code is generated and system is disabled. To unlock the BIOS, perform the following steps: On a different machine, run the BIOS_PW.EXE file along with the error code generated. For example: bios_pw 14452 0 Four ASCII strings are generated as output.

  • Page 43: Machine Disassembly And Replacement

    Chapter 3 Machine Disassembly and Replacement This chapter contains step-by-step procedures on how to disassemble the notebook computer for maintenance and troubleshooting. Disassembly Requirements To disassemble the computer, you need the following tools: Wrist grounding strap and conductive mat for preventing electrostatic discharge •...

  • Page 44: General Information

    General Information Pre-disassembly Instructions Before proceeding with the disassembly procedure, make sure that you do the following: Turn off the power to the system and all peripherals. Unplug the AC adapter and all power and signal cables from the system. Place the system on a flat, stable surface.

  • Page 45: External Module Disassembly Process

    External Module Disassembly Process NOTE: The product previews seen in the disassembly procedures may not represent the final product color or configuration. External Modules Disassembly Flowchart Turn off system and peripherals power Disconnect power and signal cables from system Remove Battery Remove Lower Covers...

  • Page 46: Removing The Battery Pack

    Removing the Battery Pack Turn the computer over. Slide the battery lock/unlock latch to the unlock position. Slide and hold the battery release latch to the release position (1), then slide out the battery pack from the main unit (2). Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 47: Removing The Hard Disk Drive Module

    Removing the Hard Disk Drive Module See “Removing the Battery Pack” on page 36. Loosen the three captive screws in the HDD Cover. Lift the HDD cover up to remove. Chapter 3 Downloaded from LpManual.com Manuals...
  • Page 48 Remove the single screw securing the HDD Module in place. Step Size Quantity Screw Type HDD Module M2*3 Slide the HDD in the direction of the arrow to disconnect the HDD from the interface connector. Chapter 3 Downloaded from LpManual.com Manuals...
  • Page 49 Lift the hard disk drive module out of the bay. NOTE: To prevent damage to device, avoid pressing down on it or placing heavy objects on top of it. Remove the four screws (two each side) securing the hard disk to the carrier. Step Size Quantity...

  • Page 50: Removing The Dimm Module

    Removing the DIMM Module See “Removing the Battery Pack” on page 36. Loosen the two captive screws in the Memory Cover. Lift the Memory cover up to remove. Chapter 3 Downloaded from LpManual.com Manuals...
  • Page 51 Push out the release latches on both sides of the DIMM socket to release the DIMM module. Remove the DIMM module. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 52: Removing The Wlan Board

    Removing the WLAN Board See “Removing the Battery Pack” on page 36. Loosen the two captive screws in the 3G Cover. Lift the 3G cover up to remove. NOTE: The 3g card is also located under this cover. Chapter 3 Downloaded from LpManual.com Manuals...
  • Page 53 Disconnect the Antenna cables from the WLAN Board. NOTE: Cable placement is White to the MAIN terminal (right) and Black to the AUX terminal (left). Remove the single screw securing the WLAN Board in place. Step Size Quantity Screw Type WLAN Board M2*3 Chapter 3...
  • Page 54 Remove the WLAN Board from the Mainboard. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 55: Removing The 3G Board

    Removing the 3g Board See “Removing the Battery Pack” on page 36. Loosen the two captive screws in the 3G Cover. Lift the 3G cover up to remove. NOTE: The WLAN card is also located under this cover. Chapter 3 Downloaded from LpManual.com Manuals...
  • Page 56 Disconnect the Antenna cables from the 3g Board. NOTE: Cable placement is Yellow to the MAIN terminal (right) and Blue to the AUX terminal (left). Remove the two screws securing the 3g Board in place. Step Size Quantity Screw Type 3g Board M2*3 Remove the 3g Board from the Mainboard.

  • Page 57: Main Unit Disassembly Process

    Main Unit Disassembly Process IMPORTANT: Cable paths and positioning may not represent the actual model. During the removal and replacement of components, ensure all available cable channels and clips are used and that the cables are replaced in the same position. NOTE: The product previews seen in the disassembly procedures may not represent the final product color or configuration.

  • Page 58: Removing The Keyboard

    Removing the Keyboard See “Removing the Battery Pack” on page 36. Turn the computer rightside up and open the lid to the full extent. Unlock the four securing latches by pressing down with a suitable plastic tool. IMPORTANT: The use of metal tools may damage the outer casing. Use plastic tools where available. Lift the Keyboard away from the Upper Cover as shown.
  • Page 59 Disconnect the FFC and remove the Keyboard. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 60: Removing The Hinge Covers

    Removing the Hinge Covers See “Removing the Battery Pack” on page 36. Remove the two screws securing the hinge covers. Step Size Quantity Screw Type Hinge Cover M2*10 Pull the Hinge Covers away from the Upper Cover as shown. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 61: Removing The Upper Cover

    Removing the Upper Cover See “Removing the Hinge Covers” on page 50. Remove the 11 screws securing the Upper Cover to the Lower Cover. Step Size Quantity Screw Type Upper Cover M2*6 (Red callouts) Upper Cover M2*4 (Cyan callouts) Turn the computer over and disconnect the following cable from the Mainboard. Chapter 3 Downloaded from LpManual.com Manuals...
  • Page 62 Release the locking latch and disconnect the FFC as shown. Remove the eight securing screws from the Upper Cover. Step Size Quantity Screw Type Upper Cover M2*4 (red callout) Chapter 3 Downloaded from LpManual.com Manuals...
  • Page 63 Starting at the front the cover, pry apart the Upper and Lower Covers as shown. Working along the front and to the right, pry apart the covers as shown. Lift the upper cover up and rotate it leftwards along the left hinge until the hinge is cleared, then lift the cover away.

  • Page 64: Removing The Button Board

    Removing the Button Board IMPORTANT: The TouchPad Board cannot be removed individually. To replace the TouchPad Board, replace the entire Upper Cover. See “Removing the Upper Cover” on page 51. Open the locking latches and disconnect the two FFCs from the Button Board as shown. Remove the two screws securing the button board to the Upper Cover.
  • Page 65 IMPORTANT: Ensure that the FFCs are disconnected before attempting to remove the Button Board. Slide the Button Board out from under the securing tabs in the Upper Cover as shown. Open the FFC locking latch and disconnect the FFC from the TouchPad connector. Pull the Mainboard FFC through the cover as shown.

  • Page 66: Removing The Led Board

    Removing the LED Board See “Removing the Upper Cover” on page 51. Open the locking latch and disconnect the FFC from the LED Board. Remove the two screws securing the LED Board to the Lower Cover. Step Size Quantity Screw Type LED Board M2*3 Chapter 3...
  • Page 67 Lift the LED Board from the Lower Cover. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 68: Removing The Bluetooth Module

    Removing the Bluetooth Module See “Removing the Upper Cover” on page 51. Disconnect the cable from the Bluetooth Module. Lift the Bluetooth Module, left side first, to remove it from the Lower Cover. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 69: Removing The Card Reader Board

    Removing the Card Reader Board See “Removing the Upper Cover” on page 51. Open the locking latch and disconnect the FFC from the Card Reader Board. Remove the two screws securing the Card Reader Board to the Lower Cover. Step Size Quantity Screw Type...
  • Page 70 Tilt the board up as indicated and remove the board from the Lower Cover, left side first to release the I/O ports. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 71: Removing The Speaker Module

    Removing the Speaker Module See “Removing the LED Board” on page 56. See “Removing the Card Reader Board” on page 59. Disconnect the Speaker cable from the Mainboard. Remove the three screws securing the Speakers to the Lower Cover. Step Size Quantity Screw Type...
  • Page 72 Lift the right and left side speakers out from the Lower Cover as shown. Remove the Speaker cables from the cable channels. Ensure that the cable is free from all cable clips. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 73: Removing The Vga Board

    Removing the VGA Board See “Removing the Card Reader Board” on page 59. Remove the single screw securing the VGA Board to the Lower Cover. Step Size Quantity Screw Type VGA Board M2*3 Lift the VGA Board left side first and turn it over to expose the VGA cable. IMPORTANT: Do not remove the board from the Lower Cover;...
  • Page 74 Flip the VGA board over, disconnect the cable from the VGA Board, and remove the board from the Lower Cover. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 75: Removing The Lan Board

    Removing the LAN Board See “Removing the Upper Cover” on page 51. Lift the adhesive strip securing the LVDS cable in place and disconnect the cable from the Mainboard. Open the FFC locking latch and disconnect the LAN Board cable from the Mainboard. Remove the LAN Board from the Lower Cover as shown.
  • Page 76 Disconnect the FFC cable from the LAN Board by pulling on the cable tab as shown. NOTE: The FFC Cable connector to the LAN board does not have a locking latch. NOTE: Reconnect the FFC cable to the mainboard if not immediately replacing the LAN board to prevent misplacing the FFC.

  • Page 77: Removing The Lcd Module

    Removing the LCD Module See “Removing the VGA Board” on page 63. See “Removing the LAN Board” on page 65. See “Removing the Card Reader Board” on page 59. Lift the adhesive strip securing the LVDS cable in place and disconnect the cable from the Mainboard. Remove the Antenna cables from the cable channel on the Lower Cover as shown, all the way to the hinge well.
  • Page 78 Remove the two screws on the rear of the Lower Cover securing the LCD Module to the computer. Step Size Quantity Screw Type LCD Module M2*3 IMPORTANT: Ensure that the LCD cables are free from all cable clips before removing the LCD Module. Using both hands, lift the LCD Module away from the Lower Cover.

  • Page 79: Removing The Hinge Wells

    Removing the Hinge Wells See “Removing the LCD Module” on page 67. Slide the two hinge wells out of the Lower Cover as indicated. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 80: Removing The Mainboard

    Removing the Mainboard See “Removing the Upper Cover” on page 51. Open the locking latch and disconnect the LED Board FFC from the Mainboard. Disconnect the Bluetooth cable from the Mainboard. Open the locking latch and disconnect the Card Reader FFC from the Mainboard. Chapter 3 Downloaded from LpManual.com Manuals...
  • Page 81 Remove the three screws securing the Mainboard to the Lower Cover as indicated. Step Size Quantity Screw Type Mainboard M2*3 Tilt the assembly onto its side so you are able to access the underneath of the mainboard. Lift the Mainboard right side first to release the I/O ports and separate the board from the Lower Cover. Reach through the HDD bay opening and unplug the VGA cable from the main board.

  • Page 82: Removing The Rtc Battery

    Removing the RTC Battery IMPORTANT: Follow local regulations for disposal of all batteries. See “Removing the Mainboard” on page 70. Disconnect the RTC Battery as shown. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 83: Removing The Thermal Module

    Removing the Thermal Module See “Removing the Mainboard” on page 70. Remove the adhesive and disconnect the fan power cable from the Mainboard. Remove the five screws securing the Thermal Module to the Mainboard. Step Size Quantity Screw Type Thermal Module M2*3 Chapter 3 Downloaded from LpManual.com Manuals...
  • Page 84 Using both hands, lift the Thermal Module clear of the Mainboard. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 85: Removing The Cpu

    Removing the CPU See “Removing the Thermal Module” on page 73. Using a flat blade screw driver, rotate the CPU screw 90° clockwise to release the CPU from the socket. Lift the CPU clear of the socket. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 86: Lcd Module Disassembly Process

    LCD Module Disassembly Process IMPORTANT: Cable paths and positioning may not represent the actual model. During the removal and replacement of components, ensure all available cable channels and clips are used and that the cables are replaced in the same position. NOTE: The product previews seen in the disassembly procedures may not represent the final product color or configuration.

  • Page 87: Removing The Lcd Bezel

    Removing the LCD Bezel See “Removing the LCD Module” on page 67. Starting from the inside top edge, pry the bezel away from the panel. Continue moving along the top, prying the bezel away from the LCD Module. If necessary, use a plastic pry to release the corners of the bezel.

  • Page 88: Removing The Camera Board

    Removing the Camera Board See “Removing the LCD Bezel” on page 77. Disconnect the cable from the Camera Board as shown. Remove the Camera Board from the LCD Module. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 89: Removing The Lcd Panel

    Removing the LCD Panel See “Removing the Camera Board” on page 78. Lift the Microphone Module upward to detach the adhesive holding it in place. Remove the four screws securing the LCD Panel to the LCD Module Step Size Quantity Screw Type LCD Panel M2*2...
  • Page 90 Lift the LCD Panel out of the LCD Module front edge first. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 91: Removing The Lcd Brackets And Fpc Cable

    Removing the LCD Brackets and FPC Cable See “Removing the LCD Panel” on page 79. Remove the four securing screws (two each side) from the LCD Brackets. Step Size Quantity Screw Type LCD Brackets M2*3 Turn the LCD panel over on a clean surface. Chapter 3 Downloaded from LpManual.com Manuals...
  • Page 92 Lift the LCD Cable to detach the adhesive securing the cable to the LCD Panel. Carefully lift the adhesive tape securing the cable connector to the LCD Panel. Hold the adhesive tape clear of the LCD Panel and disconnect the LCD cable as shown. Remove the cable from the LCD Panel.

  • Page 93: Removing The Antennas

    Removing the Antennas See “Removing the LCD Panel” on page 79. Carefully pry up the right Antenna pad, as shown, and remove the pad from the LCD Module. IMPORTANT: A strong adhesive is used to secure the Antenna pad in place. Take care not to bend the pad during removal.
  • Page 94 IMPORTANT: A strong adhesive is used to secure the Antenna pad in place. Take care not to bend the pad during removal. Remove the cable from the cable channel. Ensure that the cable is free from all cable clips. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 95: Lcd Module Reassembly Procedure

    LCD Module Reassembly Procedure Replacing the Antennas Remove the protective covering on the left and right Antenna pads. Place the Antenna pads in the LCD Module and press down to secure the adhesive in place. IMPORTANT: be sure the cables pass behind the shielding material as shown. Run the left side cable down the side and along the lower edge of the LCD Module using all the available cable clips.
  • Page 96 NOTE: The LCD Module appears as shown when the Antennas are replaced correctly. Ensure that the Antennas run through the hinge well as shown to avoid trapping when the LCD Panel is replaced. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 97: Replacing The Lcd Cable And Brackets

    Replacing the LCD Cable and Brackets Insert the LCD Cable into the panel connector Secure the connector by replacing the adhesive as shown. strip as shown. Press down to secure the adhesive. Run the LCD cable along the panel as shown. Press down to secure the adhesive. replace the four screws (two each side) securing the LCD Brackets to the LCD Panel.

  • Page 98: Replacing The Lcd Panel

    Replacing the LCD Panel Replace the LCD Panel top edge first as shown. Lower the Panel in to the LCD Module, ensuring the LCD cables are not trapped between the panel and the casing. Ensure the cables and Antennas pass through the hinge wells as shown. Press down to secure the adhesive holding the Microphone in place.

  • Page 99: Replacing The Camera Board

    Replace the two securing screws. Replacing the Camera Board Align the locating slots on the Camera Module with the locating pins on the LCD Module. Place the Camera Module in the LCD Module and press down to secure it in place. Connect the Camera cable as shown.

  • Page 100: Replacing The Lcd Bezel

    Replacing the LCD Bezel Replace the bezel bottom edge first as shown. Ensure that the cables are not trapped between the bezel and LCD Module and pass through the hinge wells. Press down around the edges of the bezel until there are no gaps between the covers. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 101: Main Module Reassembly Procedure

    Main Module Reassembly Procedure Replacing the CPU Insert the CPU into the socket. IMPORTANT: be sure to align the pins correctly with the marker on the CPU. Failure to do will likely result in permanent damage to teh CPU. NOTE: If replacing only the CPU, make sure to follow the instrucitons for cleaning and replacing thermal pads as described in “Replacing the Thermal Module”...
  • Page 102 Place the pads as shown. Place the Thermal Module onto the Mainboard and insert the screws in order from 1 to 5.. Step Size Quantity Screw Type Thermal Module M2*3 Chapter 3 Downloaded from LpManual.com Manuals...
  • Page 103 Connect the fan power cable to the Mainboard and replace the adhesive. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 104: Replacing The Rtc Battery

    Replacing the RTC Battery IMPORTANT: Follow local regulations for disposal of all batteries. See “Removing the Mainboard” on page 70. Disconnect the RTC Battery as shown. Replacing the Mainboard Turn the assembly and Mainboard onto its side and connect the mainboard to the VGA cable as shown. Insert the main board into the lower cover port-edge first.
  • Page 105 Replace the three screws to secure the Mainboard to the Lower Cover as indicated. Step Size Quantity Screw Type Mainboard M2*3 Connect the Card Reader FFC to the Mainboard and close the locking latch. Chapter 3 Downloaded from LpManual.com Manuals...
  • Page 106 Connect the Bluetooth cable to the Mainboard. Connect the LED Board FFC to the Mainboard and close the locking latch. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 107: Replacing The Hinge Wells

    Replacing the Hinge Wells Slide the two hinge wells into the Lower Cover as indicated. Replacing the LCD module Using both hands, lift the LCD Module away from the Lower Cover. Remove the two screws on the rear of the Lower Cover securing the LCD Module to the computer. Step Size Quantity...
  • Page 108 IMPORTANT: Ensure that the LCD cables are free from all cable clips before removing the LCD Module. Insert the Antenna cables into the cable channel on the Lower Cover as shown. NOTE: If replacing the LAN card, skip the next step. Connect the LVDS cable to the Mainboard and adhire the adhesive strip to secure the LVDS cable in place.

  • Page 109: Replacing The Lan Board

    Replacing the LAN Board Connect the FFC cable to the LAN Board by pushing the cable into the connector shown. NOTE: The FFC Cable connector to the LAN board does not have a locking latch. If the LVDS cable is still connected, lift the adhesive strip securing the LVDS cable in place and disconnect the cable from the Mainboard.

  • Page 110: Replacing The Vga Board

    Connect the LAN Board cable to the Mainboard and close the FFC locking latch. Connect the LVDS cable to the Mainboard and adhire the adhesive strip to secure the LVDS cable in place. Replacing the VGA Board Connect the cable from the VGA Board and flip the board over. Chapter 3 Downloaded from LpManual.com Manuals...
  • Page 111 Insert the CRT Board left side first into the Lower Cover. Replace the single screw to secure the VGA Board to the Lower Cover. Step Size Quantity Screw Type CRT Board M2*3 Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 112: Replacing The Speaker Module

    Replacing the Speaker Module Insert the Speaker cable into the cable channel. Ensure that the cable passes through all cable clips. Place the right and left side speakers into the Lower Cover as shown. Chapter 3 Downloaded from LpManual.com Manuals...
  • Page 113 Replace the three screws to secure the Speakers to the Lower Cover. Step Size Quantity Screw Type Speaker Module M2*3 Connect the Speaker cable to the Mainboard. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 114: Replacing The Led Board

    Replacing the LED Board Place the LED Board into the Lower Cover. Replace the two screws to secure the LED Board to the Lower Cover. Step Size Quantity Screw Type LED Board M2*5 Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 115: Replacing The Bluetooth Module

    Connect the LED Board FFC to the LED Board and close the locking latch. Connect the LED Board FFC to the Mainboard and close the locking latch. Replacing the Bluetooth Module Insert the Bluetooth Module, right side first, into Lower Cover so that it is held by the tab. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 116: Replacing The Card Reader Board

    Connect the cable to the Bluetooth Module. Press on the adhesive strip to attach the cable to the Lower Cover. Connect the Bluetooth cable to the Mainboard. Replacing the Card Reader Board Place the board into the Lower Cover, right side first so the I/O ports align with the openings in the lower cover.
  • Page 117 Replace the single screw to secure the Card Reader Board to the Lower Cover. Step Size Quantity Screw Type Card Reader M2*3 Board Connect the FFC to the Mainboard and close the locking latch. Connect the FFC to the Card Reader Board and close the locking latch. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 118: Replacing The Button Board

    Replacing the Button Board IMPORTANT: The TouchPad Board cannot be removed from the Upper Cover. To replace the TouchPad Board, replace the entire Upper Cover. Push the FFC through the cover as shown. Connect the FFC to the TouchPad connector and close the FFC locking latch. Slide the button board under the securing tabs in the Upper Cover as shown.

  • Page 119: Replacing The Upper Cover

    Replace the two screws to secure the TouchPad Bracket to the Upper Cover. Step Size Quantity Screw Type TouchPad M2*3 Bracket Connect the two FFCs to the Button Board and close the locking latches as shown. Replacing the Upper Cover Place the Upper Cover into the Lower Cover left corner first.
  • Page 120 Lightly press the edges of the cover in place to connect it to the lower cover., Replace the eight securing screws to the Upper Cover. Step Size Quantity Screw Type Upper Cover M2*4 (red callout) Chapter 3 Downloaded from LpManual.com Manuals...
  • Page 121 Connect the following cable to the Mainboard. Connect the FFC and close the locking latch as shown. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 122: Removing The Hinge Covers

    Turn the computer and replace the eleven screws securing the Upper Cover to the Lower Cover. Step Size Quantity Screw Type Upper Cover M2*6 (Red callouts) Upper Cover M2*4 (Cyan callouts) Removing the Hinge Covers Connect the Hinge Covers to the Upper Cover as shown. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 123: Replacing The Keyboard

    Replace the two screws to secure the hinge covers. Step Size Quantity Screw Type Hinge Cover M2*10 Replacing the Keyboard Turn the computer rightside up and open the lid to the full extent. Holding the keyboard on edge, insert the Keyboard FFC and secure the latch as shown. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 124: Reassembling External Modules

    Place the Keyboard into the Upper Cover bottom edge first, taking care to align the mounting tabs. Press the keyboard into place in the four indicated points. An audible click indicates the keyboard is in place. Reassembling External Modules Replacing the WLAN Board Insert the WLAN Board into the Mainboard.
  • Page 125 Replace the single screw to secure the WLAN Board in place. Step Size Quantity Screw Type WLAN Board M2*3 Connect the Antenna cables to the WLAN Board. NOTE: Cable placement is Black to the MAIN terminal (right) and White to the AUX terminal (left). Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 126: Replacing The 3G Module

    Replacing the 3G Module Insert the 3g Board into the Mainboard. Replace the two screws to secure the WLAN Board in place. Step Size Quantity Screw Type 3g Board M2*3 Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 127: Replacing The Dimm Module

    Connect the Antenna cables to the 3g Board. NOTE: Cable placement is Yellow to the MAIN terminal (right) and Blue to the AUX terminal (left). Replacing the DIMM Module Insert the DIMM module at an angle then push down into place until the latches on the sides click into place.
  • Page 128 Replace the four screws (two each side) to secure the hard disk to the carrier. Step Size Quantity Screw Type HDD Carrier M3*3 Place the hard disk drive module into the bay. NOTE: To prevent damage to the device, avoid pressing down on it or placing heavy objects on top of it. Slide the HDD in the direction of the arrow to connect the HDD to the interface connector.

  • Page 129: Replacing The Lower Covers

    Replace the single screw to secure the HDD Module in place. Step Size Quantity Screw Type HDD Module M2*3 Replacing the Lower Covers Insert the HDD cover into the Lower Cover. Chapter 3 Downloaded from LpManual.com Manuals...
  • Page 130 Insert the Memory cover into the Lower Cover. Insert the 3G cover into the Lower Cover. Tighten the seven captive screws in the HDD, Memory, and 3G Covers. Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 131: Replacing The Battery Pack

    Replacing the Battery Pack Turn the computer over. Slide the battery lock/unlock latch to the unlock position. Slide and hold the battery release latch to the release position (1), then slide the battery pack into the main unit (2). Slide the battery lock/unlock latch to the lock position. Chapter 3 Downloaded from LpManual.com Manuals...
  • Page 132 Chapter 3 Downloaded from LpManual.com Manuals...

  • Page 133: Troubleshooting

    Chapter 4 Troubleshooting Common Problems Use the following procedure as a guide for computer problems. NOTE: The diagnostic tests are intended to test only Acer products. Non-Acer products, prototype cards, or modified options can give false errors and invalid system responses. Obtain the failing symptoms in as much detail as possible.

  • Page 134: Power On Issue

    Power On Issue If the system doesn’t power on, perform the following actions one at a time to correct the problem. Do not replace non-defective FRUs: Start Start Start Swap AC /Battery Swap AC /Battery Check Check to try to try AC/Battery AC/Battery Power on...

  • Page 135: No Display Issue

    No Display Issue If the Display doesn’t work, perform the following actions one at a time to correct the problem. Do not replace non-defective FRUs: START Replace LCD LCD Module OK? Panel and Go to No Power Cable Power On ? troubleshooting step Reconnect...

  • Page 136: Random Loss Of Bios Settings

    If the computer boots correctly, add the devices one by one until the failure point is discovered. Reseat the memory modules. Remove the drives (see “Disassembly Process” on page 34). If the Issue is still not resolved, see “Online Support Information” on page 161. Abnormal Video Display If video displays abnormally, perform the following actions one at a time to correct the problem.

  • Page 137: Lcd Failure

    If the Issue is still not resolved, see “Online Support Information” on page 161. LCD Failure If the LCD fails, perform the following actions one at a time to correct the problem. Do not replace non- defective FRUs: Start Start Swap Swap Check LCD...

  • Page 138: Built-In Keyboard Failure

    Built-In Keyboard Failure If the built-in Keyboard fails, perform the following actions one at a time to correct the problem. Do not replace non-defective FRUs: Start Keyboard properly Disconnect and connected? reconnect Keyboard functioning? Replace Keyboard Replace mainboard Chapter 4 Downloaded from LpManual.com Manuals...

  • Page 139: Touchpad Failure

    TouchPad Failure If the TouchPad doesn’t work, perform the following actions one at a time to correct the problem. Do not replace non-defective FRUs: Start Start Re-assemble the Re-assemble the Check M/B T/P Check M/B T/P T/P FFC to M/B T/P FFC to M/B Check Check...

  • Page 140: Internal Speaker Failure

    Internal Speaker Failure If the internal Speakers fail, perform the following actions one at a time to correct the problem. Do not replace non-defective FRUs: Start Start Re-assemble the Re-assemble the Check M/B SPK Check M/B SPK SPK cable to M/B SPK cable to M/B cable cable...

  • Page 141: Internal Microphone Failure

    Remove and recently installed hardware or software. Restore system and file settings from a known good date using System Restore. If the issue is not fixed, repeat the preceding steps and select an earlier time and date. 10. Reinstall the Operating System. 11.

  • Page 142: Hdd Not Operating Correctly

    Select the microphone type from the list and click Next. Follow the onscreen prompts to complete the test. If the Issue is still not resolved, see “Online Support Information” on page 161. HDD Not Operating Correctly If the HDD does not operate correctly, perform the following actions one at a time to correct the problem. Disconnect all external devices.

  • Page 143: Usb Failure (Right Up/Down Side)

    USB Failure (Right up/down side) If the rightside USB port fails, perform the following actions one at a time to correct the problem. Do not replace non-defective FRUs: Start Start Re-assemble the Re-assemble the Check USB/B to Check USB/B to USB/B cable to M/B USB/B cable to M/B M/B cable...

  • Page 144: Intermittent Problems

    Intermittent Problems Intermittent system hang problems can be caused by a variety of reasons that have nothing to do with a hardware defect, such as: cosmic radiation, electrostatic discharge, or software errors. FRU replacement should be considered only when a recurring problem exists. When analyzing an intermittent problem, do the following: Run the advanced diagnostic test for the system board in loop mode at least 10 times.

  • Page 145: Post Code Reference Tables

    POST Code Reference Tables These tables describe the POST codes and components of the POST process. Code Beeps POST Routine Description Verify Real Mode Disable Non-Maskable Interrupt (NMI) Get CPU type Initialize system hardware Initialize chipset with initial POST Set IN POST flag Initialize CPU registers Enable CPU cache Initialize caches to initial POST va...
  • Page 146 Code Beeps POST Routine Description POST device initialization Check ROM copyright notice 2-1-2-3 Check video configuration against CMOS Initialize PCI bus and devices Initialize all video adapters in system QuietBoot start (optional) Shadow video BIOS ROM Display BIOS copyright notice Display CPU type and speed Initialize EISA board Test keyboard...
  • Page 147 Code Beeps POST Routine Description Initialize Extended BIOS Data Area Test and initialize PS/2 mouse Initialize floppy controller Determine number of ATA drives (optional) Initialize hard-disk controllers Initialize local-bus hard-disk controllers Jump to UserPatch2 Build MPTABLE for multi-processor boards Install CD ROM for boot Clear huge ES segment register Fixup Multi Processor table Search for option ROMs.
  • Page 148 Code Beeps POST Routine Description Initialize notebook docking (optional) Initialize notebook docking late Force check (optional) Extended checksum (optional) Unknown interrupt Code Beeps For Boot Block in Flash ROM Initialize the chipset Initialize the bridge Initialize the CPU Initialize system timer Initialize system I/O Check force recovery boot Checksum BIOS ROM...

  • Page 149: Jumper And Connector Locations

    Chapter 5 Jumper and Connector Locations Top View Item Description Item Description LVDS connector Speaker connector LAN connector I/O Board Connector Keyboard connector LED board connector Touchpad connector Bluetooth connector Chapter 5 Downloaded from LpManual.com Manuals...

  • Page 150: Bottom View

    Bottom View Item Description Item Description CN10 CN17 DDR Connector CN11 CRT/B Connector Battery connector CN12 RTC Battery Connector DC-in CN13 SATA Connector JSIM1 SIM card connector CN14 RS690E CN15 WL Connector GDDR CN16 3G Connector CPU Socket Chapter 5 Downloaded from LpManual.com Manuals...

  • Page 151: Clearing Password Check And Bios Recovery

    Clearing Password Check and BIOS Recovery This section provide you the standard operating procedures of clearing password and BIOS recovery for Aspire one. Aspire one provides one Hardware Open Gap on the main board for clearing the CMOS, and one Hotkey for enabling BIOS Recovery.

  • Page 152: Bios Recovery By Crisis Disk

    Peel back the Wireles LAN Card mylar and short the G2 pad. Reconnect the RTC battery and reassemble the unit. BIOS Recovery by Crisis Disk BIOS Recovery Boot Block: BIOS Recovery Boot Block is a special block of BIOS. It is used to boot up the system with minimum BIOS initialization.
  • Page 153 To use the Crisis USB key, do the following: Plug USB storage into USB port. Press Fn + ESC button then plug in AC power. The Power button flashes orange once. Press Power button to initiate system CRISIS mode. When CRISIS is complete, the system auto restarts with a workable BIOS. Update the latest version BIOS for this machine by regular BIOS flashing process.
  • Page 154 Chapter 5 Downloaded from LpManual.com Manuals...

  • Page 155: Fru (Field Replaceable Unit) List

    FRU (Field Replaceable Unit) List This chapter gives you the FRU (Field Replaceable Unit) listing in global configurations of Packard Bell dot M/A Series. Refer to this chapter whenever ordering for parts to repair or for RMA (Return Merchandise Authorization).

  • Page 156: Packard Bell Dot M/A Exploded Diagrams

    Packard Bell dot M/A Exploded Diagrams Main Assembly Item Description Part Number Left Hinge Cover Right Hinge Cover Keyboard Upper Cover Mainboard LED Board Lower Cover HDD Door Memory Door VGA Card Hinge Well I/O Board MiniPCI Door Chapter 6...

  • Page 157: Lcd Assembly

    LCD Assembly Item Description Part Number LCD Bezel LCD Bracket_L LCD Panel Camera LCD Cover LCD Bracket_R Chapter 6 Downloaded from LpManual.com Manuals...

  • Page 158: Packard Bell Dot M/A Series Fru List

    Packard Bell dot M/A Series FRU List CATEGORY QUANTA DESCRIPTION ACER PN. ADAPTER ZG5 ADP 19V 1.58A 30JH BA 90~264V S.P AP.03001.001 ZG5 ADP 19V PA-1300-04AC 90~264V S.P AP.03003.001 ZG5 ADP19V1.58A HP-A0301R3 S.P AP.0300A.001 BATTERY ZG8 BATT LI,UM09A71 3S1P 2.2A S.P BT.00307.013...
  • Page 159 CATEGORY QUANTA DESCRIPTION ACER PN. SD DUMMY CARD ZA3(EBZA3013,REV3A) CABLE ZB1 PWR CORD US S/P 27.TAXV7.001 ZR1 PWR CORD (5-KAF2166) S/P 27.TATV7.001 ZA8 CABLE BLUETOOTH(3.3V,5/8P,1A)S.P ZA8 CABLE CARDREAD(41MM,28P,1A)5V S.P ZA8 CABLE FFC LED (35MM,12P,1A)5V S.P ZA8 CABLE FFC LAN (48MM,12P,1A)5V S.P ZA8 CABLE LCD 11.6(30/40/5/4P,1A)3V SP Chapter 6 Downloaded from LpManual.com Manuals...
  • Page 160 CATEGORY QUANTA DESCRIPTION ACER PN. CASE/COVER/BRACKET ASSEMBLY ZA8 TOP CASE WIFI RED ASSY S.P ZA8 TOP CASE 3G-WIFI RED ASSY S.P ZA8 TOP CASE WIFI BK ASSY S.P ZA8 TOP CASE 3G-WIFI BK S.P ZA8 BASE CASE 3G-WIFI-BT BK S.P ZA8 BASE CASE WIFI-BT BK ASSY S.P ZA8 BASE CASE 3G-WIFI-BT RED S.P ZA8 BASE CASE WIFI-BT RED ASSY S.P...
  • Page 161 CATEGORY QUANTA DESCRIPTION ACER PN. ZA5 HINGE-R(FBZA5002,REV3A)S.P 33.WDP07.00 ZA5 TOP-HINGE-CAP-L S.P 42.WDP07.00 ZA5 TOP-HINGE-CAP-R S.P 42.WDP07.00 HDD/HARD DISK DRIVE ZG8 HDD(160G)HTS545016B9A300 0A70421 S.P KH.16007.024 ZK2 HDD(160G) ST9160310AS 9EV132-188 S.P KH.16001.034 Z06 HDD(160G) MK1655GSX-EUL S.P KH.16004.006 SA1 HDD(160G) WD1600BEVT-22ZCT0 S.P KH.16008.022 Z06 HDD(250G)ST9250315AS 9HH132-188 S.P KH.25001.016 Z06 HDD(250G) MK2555GSX-EUL S.P...
  • Page 162 CATEGORY QUANTA DESCRIPTION ACER PN. ZA5 K/B(ARAB-EN)BLACK S.P KB.I110G.002 ZA5 K/B(BELGIUM) BLACK S.P KB.I110G.003 ZA5 K/B(BRAZIL)BLACK S.P KB.I110G.004 ZA5 K/B(CHINA) BLACK S.P ZA5 K/B(DANISH) BLACK S.P KB.I110G.007 ZA5 K/B(FRENCH) BLACK S.P KB.I110G.009 ZA5 K/B(GERMAN)BLACK S.P KB.I110G.010 ZA5 K/B(GREEK)BLACK S.P KB.I110G.011 ZA5 K/B(HUNGARIAN)BLACK S.P KB.I110G.012 ZA5 K/B(ITALIAN)BLACK S.P...

  • Page 163: Screw List

    CATEGORY QUANTA DESCRIPTION ACER PN. ZA8 MB (UMA/WO CPU,3G/SAM SPM)S.P ZA8 MB (UMA/WO CPU/HYNIX SPM)S.P MEMORY Z01 RAM 1G 667MHZ HYMP112S64CP6-Y5 S.P KN.1GB0G.01 ZY2 RAM(1GB) DDR2 M470T2864QZ3-CE6 S.P KN.1GB0B.01 ZG8 RAM(1G)DDR2 EBE11UE6AESA-6E-F S.P KN.1GB09.010 ZY2L RAM(1G) NT1GT64UH8D0FN-3C S.P KN.1GB03.026 ZD1 RAM(2G)DDR2 HYMP125S64CP8-Y5 S.P KN.2GB0G.00 Z06 RAM(2GB)DDR2 M470T5663EH3-CE6 S.P KN.2GB0B.01...

  • Page 164: Model Definition And Configuration

    BT/6L/5R/CB_bg_0.3D_BAG_GEk_AR61 DOT_M/A.AC/ DOTMA- EMEA Middle East LU.BCC0Y.004 DOTMA-112G16i EM VHB32DTME2 UMACkk 1*2G/160/ 112G16i BT/6L/5R/CB_bg_0.3D_BAG_GEk_AR61 DOT_M/A.AC/ DOTMA- EMEA Middle East LU.BCC0B.003 DOTMA-111G16i EM AOXPHGDTME2 UMACkk 1*1G/ 111G16i 160/BT/6L/5R/CB_bg_0.3D_BAG_GEk_AR61 DOT_M/ A.AC/001 DOTMA- EMEA Spain LU.BCC0Y.003 DOTMA-112G16i VHB32DTES1 UMACkk 1*2G/160/6L/ 112G16i 5R/CB_bg_0.3D_BAG_GEk_ES31 DOT_M/A.SP/700 DOTMA-...
  • Page 165 Extra Acer Part No Memory 1 HDD 1(GB) Card Reader Chip S2.BCE0Y.001 AAL110 NLED11.6WXGAG SO1GBII6 N160GB5.4KS 5 in 1-Build in S2.BCF0B.001 AAL110 NLED11.6WXGAG SO1GBII6 N160GB5.4KS 5 in 1-Build in Wireless Wireless Country Acer Part No Bluetooth Battery Vista LAN1 Code LU.BCC0B.004 3rd WiFi BG 3rd WiFi BG...
  • Page 166 Acer Part No A cover UPC Code EAN Code Accessory LU.BCC0B.004 Black IMR 884483812226 4712842835820 PackardBell 11inch Netbook Bag black LU.BCC0Y.005 Black IMR 884483812202 4712842835806 PackardBell 11inch Netbook Bag black LU.BCC0Y.004 Black IMR 884483812196 4712842835790 PackardBell 11inch Netbook Bag black LU.BCC0B.003 Black IMR 884483812219...

  • Page 167: Test Compatible Components

    Appendix B Test Compatible Components This computer’s compatibility is tested and verified by Acer’s internal testing department. All of its system ® ® functions are tested under Windows XP Home, Windows XP Pro environment. Refer to the following lists for components, adapter cards, and peripherals which have passed these tests. Regarding configuration, combination and test procedures, please refer to the Gateway LT Series Compatibility Test Report released by the Acer Mobile System Testing Department.

  • Page 168: Windows Xp Environment Test

    Windows XP Environment Test BRAND Type Description Qualcomm Gobi2000 Qualcomm Gobi2000 Adapter DELTA Adapter DELTA 30W 19V 1.7x5.5x11 Black ADP-30JH BA LF HIPRO Adapter HIPRO 30W 19V 1.7x5.5x11 Black HP-A0301R3 B1LF LITE-ON Adapter LITE-ON 30W 19V 1.7x5.5x11 Black PA-1300-04AC LF Audio Codec Realtek ALC272X...
  • Page 169 BRAND Type Description AAL110 CPU AMD Athlon L110 PGA 1.2G 512K single core HGST N160GB5.4KS HDD HGST 2.5" 5400rpm 160GB Falcon B HTS543216L9SA00 SATA LF F/W:C40C HGST N160GB5.4KS HDD HGST 2.5" 5400rpm 160GB HTS545016B9A300 Panther B SATA LF F/W:C60F HGST N250GB5.4KS HDD HGST 2.5"...
  • Page 170 BRAND Type Description SAMSUNG SO1GBII6 Memory SAMSUNG SO-DIMM DDRII 667 1GB M470T2864QZ3- CE6 LF SAMSUNG SO2GBII6 Memory SAMSUNG SO-DIMM DDRII 667 2GB M470T5663EH3- CE6 LF 128*8 0.055um SAMSUNG SO512MBII6 Memory SAMSUNG SO-DIMM DDRII 667 512MB M470T6464QZ3-CE6 LF Modem External USB External USB Lite+LSI modem Lite+LSI modem Chipset...

  • Page 171: Online Support Information

    Appendix C Online Support Information This section describes online technical support services available to help you repair your Acer Systems. If you are a distributor, dealer, ASP or TPM, please refer your technical queries to your local Acer branch office. Acer Branch Offices and Regional Business Units may access our website. However some information sources will require a user i.d.
  • Page 172 Appendix C Downloaded from LpManual.com Manuals...

  • Page 173: Index

    Index Numerics CRT Board Removing 3G Cover CRT Cable Removing 70, 94 Removing Antennas DIMM Module Removing 40, 117 Removing Replacing Display display hotkeys Battery Pack 36, 121 Removing BIOS Euro Key ROM type vendor External Module Disassembly Version Flowchart 19–27 BIOS Utility Advanced...
  • Page 174 Microphone Jumper and Connector Locations Removing Top View Replacing Model Definition Keyboard 48, 113 Removing No Display Issue Keyboard Failure num lock on indicator LAN Board 65, 99 Removing ODD Failure LCD Bezel Removing Online Support Information Replacing LCD Brackets Removing Panel Replacing...
  • Page 175 Built-in KB Failure Internal Microphone Internal Speakers LCD Failure No Display Other Failures Power On Touch Pad Undetermined Problems Upper Cover 51, 109 Removing USB Failure (Rightside) utility 19–27 BIOS volume hotkeys Windows 2000 Environment Test WLAN Board 42, 114 Removing Downloaded from LpManual.com Manuals...
  • Page 176 Downloaded from LpManual.com Manuals...

This manual is also suitable for:

Dotma-112g16iDotma-112g25i

Table of Contents
