Page 1: Table Of Contents
Contents CPS 9768 06/2015 Welcome Dimensions & Technical Instructions for Use Specifications a. Diagram of outside including a. Short Penguin top plate b. Woody b. Diagram inside including door c. Hungry Penguin c. Warnings & Pre-lighting d. Fat Penguin checks e. - Page 2 A very warm welcome and croeso to your new chilli penguin stove The charter of the penguin We guarantee that your stove is good quality and well made We guarantee that your stove will give you years of warm and efficient heating...
-
Page 3: Short Penguin
2 a. Stove Dimensions - Short Penguin 2 a.Technical Specifications - Short Penguin Tested to EN 13240 and BS3841-2:1994 as intermittent burning appliance Item Wood Smokeless fuels Fuel type Nominal Output 5.0kW 4.8kW Total Energy Efficiency % 81.9 72.7... - Page 4 efficient and fabulous 2.b Stove Dimensions - Woody 2.bTechnical Specifications - Woody Tested to EN 13240 and BS3841-2:1994 as intermittent burning appliance Item Wood Smokeless fuels Fuel type Nominal Output 5.0kW 5.0kW Total Energy Efficiency % Flue gas g/s Co content @13% 02 0.19% 0.21% Mean Flue gas temp.
-
Page 5: Hungry Penguin
does it all 2.c Stove Dimensions - Hungry Penguin 2.cTechnical Specifications - Hungry Penguin Tested to EN 13240 and BS3841-2:1994 as intermittent burning appliance Item Wood Smokeless fuels Fuel type Nominal Output 5.0kW 5.0kW Total Energy Efficiency % Flue gas g/s Co content @13% 02 0.19% 0.21%... -
Page 6: Fat Penguin
big, fat & beautiful 2.d Stove dimensions - Fat Penguin 2.d Technical Specifications - Fat Penguin Tested to EN 13240 and BS3841-2:1994 as intermittent burning appliance Item Wood Smokeless fuels Fuel type Nominal Output 5.0kW 5.0kW Total Energy Efficiency % Flue gas g/s Co content @13% 02 0.19%... -
Page 7: High And Mighty
smug as a sausage 2.e Stove dimensions - High and Mighty 2.e Technical Specifications - High and Mighty Tested to EN 13240 and BS3841-2:1994 as intermittent burning appliance Item Wood Smokeless fuels Fuel type Nominal Output 5.0kW 5.0kW Total Energy Efficiency % Flue gas g/s Co content @13% 02 0.19%... -
Page 8: Penguin
simply awesome 2.f Stove Dimensions - Penguin 8 2.f Technical Specifications – Penguin 8 Tested to EN 13240 and BS3841-2:1994 as intermittent burning appliance Item Wood Smokeless fuels Fuel type Nominal Output 8.0kW 8.0kW Total Energy Efficiency % Flue gas g/s Co content @13% 02 0.19% 0.21%... -
Page 9: Penguin 8 With Oven
smoking hot 2.g Stove Dimensions - Penguin 8 with Oven ( plinth and side panels included ) 2.g Technical Specifications Tested to EN 13240 and BS3841-2:1994 as intermittent burning appliance Item Wood Smokeless fuels Fuel type Nominal Output 8.0kW 8.0kW Total Energy Efficiency % Flue gas g/s Co content @13% 02... -
Page 10: Installation Instructions
The clip in boiler option on all our stoves is not approved for use in smoke control areas. The general principle to be observed in an Exempt chilli penguin stove is that the air controls cannot be completely closed, allowing a permanent air supply to the fire chamber.This means that fuel burns more efficiently, thereby emitting less harmful... -
Page 11: Fitting A Smoke Control Kit
administrations for those countries. Separate legislation, the Clean Air (Northern Ireland) Order 1981, applies in Northern Ireland. Therefore it is a requirement that fuels burnt or obtained for use in smoke control areas have been "authorised" in Regulations and that appliances used to burn solid fuel in those areas (other than "authorised" fuels) have been exempted by an Order made and signed by the Secretary of State or Minister in the devolved administrations. -
Page 12: Plinth Clamp
vents are required for all sizes of stoves, this can apply to new extensions as well. This will depend on the air leakage (air permeability) of your property.Your HETAS installer should be able to guide you on your particular property. In addition a stove should not be fitted in a room with an appliance such as extractor fan, ceiling fan or tumble drier, it will affect the draw of the stove and could lead to fumes entering the room. -
Page 13: Rear Flue Box
(a rear swept bend or T-junction with cap would be required). All other models; the Short, Woody and Penguin 8 would need the rear flue box. The rear flue box allows you to flue out of the rear of the stove, the flue pipe then goes vertically up the chimney. - Page 14 3.j Base Heat Shield The temperature at the base of a stove will affect the type of hearth required, see “hearth requirements”. If a constructional hearth is required but is not possible, then a base heat shield can be fitted underneath the stove. This reduces the hearth temperatures and allow the stoves to be installed onto a superimposed (12mm) hearth.
- Page 15 Non Combustible Walls Diagrams illustrating the minimum distances to combustible walls. The Woody is illustrated, but non combustible distances are the same for all models 3 k.MINIMUM DISTANCES TO NON COMBUSTIBLE WALLS (ie. stone/brick) model rear sides above All models 50mm 100mm 150mm...
-
Page 16: Distances To Combustible Walls
3.l Clearance to combustible walls Diagram illustrating the minimum distances to combustible surfaces Short 400mm Woody/Penguin 8 350mm Rear Fat/Hungry/H&M 250mm Short /Hungry 500mm Side Fat /Woody 400mm Pen 8 350mm H&M 250mm 3.l MINIMUM DISTANCES TO COMBUSTIBLE WALLS model... -
Page 17: Chimney
3.n Chimney and Access for sweeping Existing chimney Must comply with all current building regulations height 4.5 metres Non Exempt Lined with 150mm diameter class 1 liner with 125mm stove pipe + (no smoke control adaptor kit fitted) Exempt models Lined with 150mm diameter class 1 liner where possible, where not, 125mm flue is permitted A flue way must not be shared with other appliances... -
Page 18: Instructions For Use
4.a Instructions for use Diagram of the outside of the stove When you look at your penguin, smile, because it’s looking back at you Grate:the cast iron grill that sits on the base of the fire chamber, the castellated edge can be seen through the glass fire door... - Page 19 Stove levelling bolts: bolts on each leg used to level the stove during installation Primary air control knob: stainless steel knob on the LH side of the stove as you face it. It controls the flow of air underneath the fire Secondary air control knob: stainless steel knob on the RH side of the stove as you face it (fully out it will protrude 10mm further than the other knob).
- Page 20 4 c. Warnings and Pre-lighting checks Chilli penguin stoves will not be responsible for any damage caused to the stove due to either the incorrect installation of the stove or the incorrect use of the stove, including the use of the wrong fuels. We strongly recommend the use of a qualified and experienced installer.
-
Page 21: Simple Guide
4.d Simple guide to your first fire We recommend the goldilocks and the three bears method; small fire, medium fire, hot fire read this manual and all warnings prepare a kindling fire carefully •scrunch up newspaper and place kindling over the top, light the fire, close •the 3 most important points are the stove door •a= air control... -
Page 22: Principles Of Combustion
A list can be found at http://smokecontrol.defra.gov.uk/fuels.php. If in any doubt contact your Chilli Penguin stockist. These fuels burn most effectively when air is introduced beneath the fuel bed – up draught. -
Page 23: The Environment
Your Chilli Penguin Stove has been designed to burn solid fuel suitable for closed appliances and wood with high efficiency. It is not advised to try and keep a wood fire in overnight. -
Page 24: Instructions For Use With Wood
Instructions for use with wood Making a fire We recommend scrunched up paper with kindling arranged in a tepee shape around it. Some people put a firelighter in the middle. Light the paper or firelighter. Once the kindling is burning gradually increase the size of log until the fire is established The air controls Pull both controls out to open fully and swing the boost disc up (the RH knob will... -
Page 25: Instructions For Use With Smokeless Fuels
4.h Instructions for use with Authorised smokeless fuels Making a fire Solid fuels can be more difficult to light in a cold stove – especially when damp. We recommend scrunched up paper with kindling arranged in a tepee around it, some people put a firelighter in the middle. - Page 26 Safety Always use the glove provided when opening the doors of the stove. Your stove has not been designed to run with the door open, it should therefore be kept shut except when refuelling is carried out . love your penguin 4 i.
-
Page 27: Routine Checks And Cleaning
looking after your penguin 5. Stove maintainance 5 a. Routine checks and cleaning As required Stove surface should be cleaned with a soft brush or lint free cloth when cold, some people use a vacuum cleaner attachment. Ash pan should be emptied daily when using smokeless fuel, if this is done while the stove is still warm, use glove and tool provided. -
Page 28: Trouble Shooting
i. Preparing the surface a.Remove all rust: sandblasting, sanding or grinding. IF YOU APPLY ON TOP OF RUST the paint will adhere to the rust and fail . A new stove /flue should arrive rust free, this will only be relevant if you are renovating an old stove. b. - Page 29 Rubbing a penguin’s belly 5 c. Keeping your stove glass clear To maintain clear glass there are 2 factors correct and dry fuel (see section on principles of combustion) correct use of air controls (see section instructions for use with wood/solid fuel) As a general rule the hotter the fire the clearer the glass will be.
- Page 30 5 f. Fire Brick (vermiculite brick) Replacement The vermiculite bricks which line the fire chamber will need replacing over time, they are a perishable item. They are a pressed board, not a ceramic brick so it should be treated with care. They insulate the stove allowing it to burn more efficiently and protect the steel body from the heat of the stove.
- Page 31 Reach into the fire chamber with your other hand to receive the grate, support the grate on the stove while you find a comfortable 2 handed hold Tilt the grate onto an angle which will allow it to exit the door Manoeuvre carefully out of the stove, usually the lower corner castellations first, then manoeuvre the rest of the castellated edge To re install it, follow the same steps in reverse, then replace the ash pan...
- Page 32 never shoot a penguin 5 i. Trouble Shooting Problem Possible cause Remedial Action Fuel is damp Ensure fuel is dry Cannot get fuel to Fire has been Load smaller amounts of fuel at a time – be patient! stay alight smothered Insufficient air Air boost disc has been closed before...
- Page 33 6. 7 Year Guarantee Chilli penguin stoves’ guarantee covers the materials listed plus the construction and workmanship.The assembly, installation and operation of the stove, because they do not come under our direct control, are not included in this guarantee. You are advised to take these matters up with your stove supplier or accredited installation engineer.
