Planet HTS-1000P User Manual

10-inch touch screen home automation controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
10-inch Touch Screen Home
Automation Controller
HTS-1000P

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HTS-1000P and is the answer not in the manual?

Questions and answers

Summary of Contents for Planet HTS-1000P

  • Page 1 10-inch Touch Screen Home Automation Controller HTS-1000P...
  • Page 2 Further, PLANET reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation to notify any person of such revision or changes.
  • Page 3 Do not dispose of WEEE as unsorted municipal waste and have to collect such WEEE separately. Revision User’s Manual of PLANET 10-inch Touch Screen Home Automation Controller Model: HTS-1000P Rev: 1.00 (August, 2015) Part No. EM-HTS-1000P_v1.0...

  • Page 4: Table Of Contents

    10-inch Touch Screen Home Automation Controller HTS-1000P Table of Contents Chapter 1. Product Introduction ..............5 1.1 Package Contents ................5 1.2 Overview.....................5 1.3 Specifications..................8 Chapter 2. Hardware Interface..............10 2.1 Physical Descriptions................ 10 2.2 Default Setting .................. 11 Chapter 3. Configuration................12 3.1 Introduction ..................

  • Page 5: Chapter 1. Product Introduction

    1.2 Overview Wall-mounted Touch Panel Makes Home System Control Easy PLANET HTS-1000P is a 10-inch Touch Screen Home Automation Controller, which is the command center of the Home Monitoring and Automation Systems, providing users with quick, consistent access to every device in the connected home. A simple user interface enables customers to easily arm and disarm their system;...
  • Page 6 10-inch Touch Screen Home Automation Controller HTS-1000P Keep an Eye on Home with Touch Screen You can view cameras around your home on touch screen. Keep an eye on your kids and pets, screen visitors at your entranceway and view activity occurring around the interior or exterior of your home whenever and wherever you want.
  • Page 7 Energy and Cost Saving on Every Room You can also check the current energy consumption in your home within the configuration interface of the HTS-1000P with the HAC-1000 Control Gateway. Manage these energy-saving devices such as power meter switches, power switches and dimmer switches to help you reduce energy consumption and thus save expenses on utilities.

  • Page 8: Specifications

    10-inch Touch Screen Home Automation Controller HTS-1000P AEC (Acoustic Echo Cancellation) Technology Acoustic Echo Cancellation (AEC) technology is adopted in PLANET’s HDP-1100PT Door Phone and HTS-1000P Touch Screen to enable to minimize the sound signal distortion, thus guaranteeing the best-in-class sound quality. 1.3 Specifications Product...
  • Page 9 10-inch Touch Screen Home Automation Controller HTS-1000P General 12V DC, 1.5A Power Requirements IEEE 802.3af Class 3 Operating Temperature -10 ~ 40 degrees C Operating Humidity 0 ~ 90% (non-condensing) Weight 620g Dimensions (W x D x H) 258 x 163 x 24 mm...

  • Page 10: Chapter 2. Hardware Interface

    Volume (+/–) Tab (+/–) SD/SDHC (void) Interface Description Volume (+/–) Press to adjust the volume. Tab (+/–) Press to select the next (+) or previous (–) item. Home Press to display the HTS-1000P Home Menu. SD/SDHC Future Feature 10 -...

  • Page 11: Default Setting

    Please RJ45 (LAN Socket, PoE ) use Cat5 cable to connect the HTS-1000P to an Ethernet network switch or hub. ONLY use one power source, either from DC or from 802.3af Power over Ethernet.

  • Page 12: Chapter 3. Configuration

    10-inch Touch Screen Home Automation Controller HTS-1000P Chapter 3. Configuration Your control pad is ready to use in your home with door phone and control gateway. Please take a few minutes to read through this guide to familiarize yourself with the steps required to...

  • Page 13: Network Setting

    10-inch Touch Screen Home Automation Controller HTS-1000P Parameters Description The date and temperature of a location where the control pad has been set. The time of a location where the control pad has been set. The visibility of a location where the control pad has been set.
  • Page 14 10-inch Touch Screen Home Automation Controller HTS-1000P Quick click 7 times in the red box area to switch to TCP/IP setting page. Click “Ethernet” to “ON” click “Ethernet configuration” networking. Select “Static IP” and fill out the information of IPs and then click “Save”.
  • Page 15 10-inch Touch Screen Home Automation Controller HTS-1000P Now you can get the date weather information your location. Parameters Description This address is a unique number that identifies a computer or device IP address on the WAN or LAN. These numbers are usually shown in groups separated by periods, for example, 192.168.1.166.

  • Page 16: Settings

    10-inch Touch Screen Home Automation Controller HTS-1000P 3.3 Settings Here you can configure all the functions of control pad. 3.3.1 Gateway Fill out the IP of control gateway to connect with gateway. Click “Gateway” button. Click magnifying glass to search the IP of gateway.

  • Page 17: Z-Wave Devices

    10-inch Touch Screen Home Automation Controller HTS-1000P Control pad found an IP of gateway. Click the IP to join. The default gateway port is 5000, and user name and password are both admin. 3.3.2 Z-Wave devices Before configuring the “Control Panel”, we need to include Z-Wave device first, because without Z-Wave device, we cannot select any device from the control panel.
  • Page 18 10-inch Touch Screen Home Automation Controller HTS-1000P Click the “Include New Device” button to add Z-Wave device. When message of “Waiting for user action”, you can press the match button on Z-Wave devices. If a device is added successfully, it will show...

  • Page 19: Intercom

    10-inch Touch Screen Home Automation Controller HTS-1000P When message of “Waiting for user action”, you can press the match button on Z-Wave devices to exclude device. 3.3.3 Intercom After configuring this part, you can communicate with door phones via control pad.
  • Page 20 10-inch Touch Screen Home Automation Controller HTS-1000P Control pad found the IP of door phone and click the IP to join. Name the door phone and the account and password of door phone are both admin. The default SIP ID is 2001.

  • Page 21: Control Panel

    10-inch Touch Screen Home Automation Controller HTS-1000P 3.3.4 Control Panel After configuring this part, you can control Z-Wave devices and scenes via control pad. Click the “Control Panel” button. Click three-line button on the upper right corner and click “Add Panel”.
  • Page 22 10-inch Touch Screen Home Automation Controller HTS-1000P Click hold seconds to select the device or scene. Select a device. Select a device. Go back to the main page click “Control” button. 22 -...

  • Page 23: Scene

    10-inch Touch Screen Home Automation Controller HTS-1000P You can control scenes and devices here. 3.3.5 Scene After including Z-Wave devices into gateway, you can create different scenes with this function. You can set scenes to control your devices. Click the “Scene” button.
  • Page 24 10-inch Touch Screen Home Automation Controller HTS-1000P Select one device to add in the device list. Select one device. Click the “Plus” button to add device. Select status device (ON or OFF). 24 -...

  • Page 25: Upgrading

    10-inch Touch Screen Home Automation Controller HTS-1000P Click “All Scenes” to check the scene. 3.3.6 Upgrading When control pad has a new firmware, just click the Upgrading button to enable to upgrade automatically. Click “Upgrading” button. Control will download latest firmware automatically.

  • Page 26: Janitor

    10-inch Touch Screen Home Automation Controller HTS-1000P Click “OK” to replace the old one. Click “Install” to install the new firmware. 3.3.7 Janitor This function is to contact janitor via IP address. The janitor side can use IP phone. Click the “Janitor” button.

  • Page 27: Ip Cameras

    10-inch Touch Screen Home Automation Controller HTS-1000P Fill out the IP of janitor. Click the “Janitor” button communicate with janitor. 3.3.8 IP Cameras You can add 12 cameras in the control pad, monitoring 4 cameras on the same page. It helps to enhance the security of home automation.
  • Page 28 10-inch Touch Screen Home Automation Controller HTS-1000P Click three-line button on the upper right corner and click “Add Cam”. Click magnifying glass to search the IP of camera. Control pad will search the cameras. Select one camera to join. 28 -...
  • Page 29 10-inch Touch Screen Home Automation Controller HTS-1000P Fill out the command line and MAC address of camera automatically. Camera name: Name the camera. IP address: Complete IP address must contain IP address command. Account and password: The default account and...
  • Page 30 10-inch Touch Screen Home Automation Controller HTS-1000P Select the camera. Added successfully. Go back to the main page click “Camera” button. You can monitor the camera. 30 -...

  • Page 31: Triggers

    10-inch Touch Screen Home Automation Controller HTS-1000P 3.3.9 Triggers When Z-Wave devices have triggered, you could set a scene to run this function. Click “Trigger” button. Click “Create Trigger”. Trigger: Name this trigger. Device: Select a Z-Wave device. Mode: Select “Arm” to enable alarm when it has triggered.

  • Page 32: Activating Code

    10-inch Touch Screen Home Automation Controller HTS-1000P 3.3.10 Activating Code This function is for the control pad to communicate with Cloud Bell App via smart phone. Click the “Activate Code” button. check activate code here. This is for Cloud Bell App to...
  • Page 33 10-inch Touch Screen Home Automation Controller HTS-1000P To scan the activate code on control pad. Go back to the main page click “Contacts” button. will accounts when activate code is scanned. Click the “Call” button to contact those users via Cloud Bell App.

  • Page 34: Location Setting

    10-inch Touch Screen Home Automation Controller HTS-1000P 3.3.11 Location Setting The control pad will show the weather and time information of your location. Click “Location Setting” button. Key-in the city and click the “Search” button. Select the correct city name.
  • Page 35 10-inch Touch Screen Home Automation Controller HTS-1000P Go back to the main page and you will see the information location that you set. 35 -...

  • Page 36: Appendix A: Troubleshooting & Frequently Asked Questions

    10-inch Touch Screen Home Automation Controller HTS-1000P Appendix A: Troubleshooting & Frequently Asked Questions Features Can control pad wirelessly connect Yes, it can. to router? The frequency is different between Z-Wave and ZigBee. ZigBee is 2.4GHz and Z-Wave is about 900MHz.
