LMD-2708
PORTABLE 7" LCD MONITOR AND DVD PLAYER
ACCESSORY:
1 x AC to DC Adapter
1 x Remote Control with battery (CR2025)
1 x Instruction Manual
1 x Audio/Video Cable
1 x Cigarette Lighter Adapter
1 x Earphone
1 x Rechargeable Battery
PDF created with FinePrint pdfFactory Pro trial version
http://www.fineprint.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LMD-2708 and is the answer not in the manual?

Questions and answers

Summary of Contents for AWA LMD-2708

  • Page 1 LMD-2708 PORTABLE 7" LCD MONITOR AND DVD PLAYER ACCESSORY: 1 x AC to DC Adapter 1 x Remote Control with battery (CR2025) 1 x Instruction Manual 1 x Audio/Video Cable 1 x Cigarette Lighter Adapter 1 x Earphone 1 x Rechargeable Battery PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com...
  • Page 2: Cautions And Warnings

    INTRODUCTION Thank you for choosing the 7” portable DVD player. Please read the entire instruction manual supplied with this product prior to using. The documen- tation will assist you in installing the system properly to obtain the best equipment performance. Please save this manual for later use. CAUTIONS AND WARNINGS 1 Placement To prevent fire or electric shock, do not expose this appliance to rain or...
  • Page 3 order to protect the environment,please dispose the battery properly. Do not use the unit in temperatures higher than 104 degrees Fahrenheit or 40 degrees Celsius. 4 Disassemble Do not attempt to disassemble the cabinet. There is a risk of electric shock and/or exposure to Laser Radiation.
  • Page 4: Powering And Installation

    POWERING AND INSTALLATION 1. Powering the system indoors Plug one end of the AC to DC adapter into the DC jack on the side of the main unit, then plug the other end into the 110~240V AC power outlet. 2. Powering the system in a car Plug one end of the cigarette lighter adapter into the DC jack on the unit, then plug the other end into the cigarette lighter socket.
  • Page 5 2. DVD 1) Menu Button:Open and close DVD menu. 2) Up/Down/Left/Right/OK Buttons:Used to highlight and confirm selections. 3) Open Button:Open the DVD compartment. 4) Previous Button:Skip to the previous titles,chapters,or tracks. 5) Screen Mode Button:Switch between 4:3 and 16:9 display ratio. 6) Pause Button:Still the picture.
  • Page 6 3. RIGHT 1) Power On/Off Switch 2) Brightness Up/Down Control:Adjust the brightness. 3) Volume Up/Down Control:Adjust the volume. 4) Earphone Jack 1:Insert earphone for private listening.the speaker mute. 5) Earphone Jack 2:Insert earphone. 6) E-Port:Connect a TV tuner or game pad with AV IN mode. 7) AV In/Out Switch:Set to OUT to use internal DVD player and IN for an external AV device.
  • Page 7: Remote Control View

    REMOTE CONTROL VIEW 1) Setup:Press to access the SETUP menu screen. 2) Up:Turn to UP. 3) Previous:Skip to the previous titles, chapters,or tracks. 4) Enter: Use to confirm selections on a menu screen. 5) Left/REW: Turn to LEFT and Scan backward at 2,4,8,16,32 times speed.
  • Page 8 SETUP 1. General Setup Page 1) With no disc inside the player, press ‘SETUP’ to display the Main screen of the Setup Menu on the screen and “General Setup Page” appears. At the same time, “ ” is highlighted. Press ‘SETUP’ again to exit the Setup Menu and the unit will resume it’s last playback mode.
  • Page 9 c). Screen Saver *On: Enables screen saver *NOTE: The DVD player will enter the Screen Saver mode after approximately five minutes if the same image remains on the screen.*Off: Disables screen saver (off) d). Last Memory *On: The unit will return to the last position on the disc. *Off: The unit will not return to the last position on the disc.
  • Page 10 3. Password With no disk inside the player, press SETUP to enter the Setup menu. button to select “Password Setup Page” and is Press the highlighted. Press ENTER to enter the password page.Press ENTER twice to enter the Password Change Page. Input theOld Password or the Default Password, the New Password, and Confirmed the New Password.
  • Page 11 d) Parental Select ‘Parental’ by pressing the button in the preference page. And Press to enter the sub menu. Select the parental level you desire using button for discs with lock- out function or multiple rating levels. These are listed from the lowest level (1 Kid Safe) to the highest level (8 Adult).
  • Page 12: Connecting To Other Equipment

    CONNECTING TO OTHER EQUIPMENT 1. AV Out Connecting with a TV or another monitor a. Slide the AV In/Out switch to Out. b. Connect one end of the supplied audio/video cable’s black (1/8” stereo plug) plug into the unit’s DVD’s AV jack, and connect the other end to the AUDIO INPUT jacks on your TV or Monitor through an optional RCA cable(white = left channel, red = right channel, Yellow = Video).
  • Page 13: Specifications

    SPECIFICATIONS Compatible DISC: DVD/CD/MP3/JPEG Signal system: Panel size: 7 inch Audio S/N: Better than 60 dB Dynamic range : Better than 85 dB Power source: DC 9V Operating temperature: 5~35°C Weight : 0.615 kg Dimensions (W x D x H): 7.87 X 5.92 X1.34 inches 200 x 150.5 x 34 mm -EN-13- PDF created with FinePrint pdfFactory Pro trial version...
  • Page 14: Troubleshooting

    TROUBLE SHOOTING No sound or distorted sound? Make sure your DVD is connected properly.Make sure all cables are securely inserted into the appropriate jacks. Can’t advance through a movie? You can’t advance through the opening credits and warning information that appears at the beginning of movies because the disc is programmed to prohibit that action.
  • Page 15 IR sensor inoperative? 1. Verify that the batteries in the remote are fresh. 2. Verify that the remote sensor eye is not obstructed. 3. Verify that the infrared transmitter is affixed over thesensor eye of the component to be controlled. Disc won’t play? 1.
  • Page 16 This symbol on the product or in the instructions means that your electrical and electronic equipment should be disposed at the end of its life separately from your household waste.There are separate collection systems for recy- cling in the EU.For more information, please contact the localauthority or your retailer where you purchased the product.
