Summary of Contents for Seeed GroveXBee Carrier
-
Page 1: User Manual
Grove - XBee Carrier User Manual Release date： 2015/9/22 Version： Wiki: http://www.seeedstudio.com/wiki/index.php?title=Bee_Stem Bazaar:http://www.seeedstudio.com/depot/Grove-XBee-Carrier-p- 905.html... -
Page 2: Document Revision History
Document Revision History Revision Date Author Description Sep 22, 2015 Jiankai.li Create file... -
Page 3: Table Of Contents
Contents Document Revision History · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 2 1. - Page 4 Under the supervision of Seeed Technology Inc., this manual has been compiled and published which covered the latest product description and specification. The content of this manual is subject to change without notice.
-
Page 5: Introduction
1. Introduction The Grove - XBee Carrier is a Wireless Sensor Network (WSN) base board designed for Bee series and Grove units. It is primarily suitable for standalone Bee Nodes like RFBee, Wifi Bee RFBee Wifi which have ATMega328 onboard and XBee (Zigbee) modules. It is compatible with XBee Bluetooth Bee . -
Page 6: Features
2. Features Bees Compatible Receptacle Two Grove Connectors Two Grove Place Holders LEDs for PWR, Charge Indication and UART transmission. Power Switch Reset Button... -
Page 7: Application Ideas
3. Application Ideas Wifi Bee Wireless Sensor Network with Standalone Bee Node like As a configuration aid for Bees using FT232RL. Charger for Lithium Ion Cells using on-board charge controller. As a FT232RL based 3.3v USB-UART. -
Page 8: Cautions
4. Cautions Insert the Bees in the proper direction. Use the Bee outline on the silk-screen. -
Page 9: Specification
5. Specification Item Typical Unit Voltage Charge Controller CN3063 CHARGER (Charging Voltage for LiPo Battery) 4.4V to 6V (as per CN3063 Spec) Low Noise and Micropower type. Suitable for 3.3V LDO Battery Application. I/O Logic 3.3V Logic... -
Page 10: Interface Function
6. Interface Function U2: RT9167A_33PB IC, 3.3V LDO Lownoise Micropower Regulator U3: CN3083 IC, Charger controller for Lithium batteries (charging using solar panel) U4: FT232RL IC, USB to serial UART interface... -
Page 11: Usage
7. Usage When using an RFBee, the following pinouts of ATmage168 on RFBee apply for using the Arduino IDE. Pin 5 is the Grove connector for I/O - Yellow wire. Pin 6 is the Grove connector for I/O - White wire. Pin 16 may need to be driven low to provide enough power to the I/O Grove [via mosfet. - Page 12 Wifi Bee RFBee Nodes - WiFi Bee Grove - XBee Carrier The following image illustrated the connection of Any Groves can be connected to the Grove sockets provided. The programming of WiFi Bee's onboard AtMega328P is carried by connecting to PC through USB port.
- Page 13 Working with Bee Modules This section is about those Bee modules which do not have a MCU pre-programmed with Arduino bootloader. They mostly act just like a wireless trans-receiver. These Bee Modules like Bluetooth Bee, etc.. can communicated with PC as well. In this case, Grove - XBee Carrier acts as a carrier for these Bees providing necessary power, communication interface with PC through FT232RL USB to UART.
-
Page 14: Programming
Bluetooth Bee Bluetooth Bee Commands For more information on using , consult the documentation Programming Test code for use with an XBee Carrier & an RF Bee Turns on PD5 (eg: grove relay) on for one second, then off for one second, repeatedly. void setup() // initialize the digital pin as an output [Pin 5 is the Grove connector for I/O pinMode(5, OUTPUT);... -
Page 16: Resources
Resources Grove - XBee Carrier Eagle Files Grove - XBee Carrier PDF schematics file CN3063 RT9167A_33PB ... -
Page 17: Support
9. Support forum wish If you have questions or other better design ideas, you can go to our to discuss.
