Portable Generator
model number 055-0361-0 | contact us: 1.866.523.5218
IMPORTANT:
Instruction
Read and follow all safety rules and operating
Manual
instructions before using this product.

Advertisement

Table of Contents
loading

Summary of Contents for Yardworks 055-0361-0

  • Page 1 Portable Generator model number 055-0361-0 | contact us: 1.866.523.5218 IMPORTANT: Instruction Read and follow all safety rules and operating Manual instructions before using this product.
  • Page 2 | contact us: 1.866.523.5218 055-0361-0 SPECIFICATIONS KNOW YOUR GENERATOR ASSEMBLY OPERATION SAFETY AND MAINTENANCE EXPLODED VIEW (PRODUCT) PARTS LIST (PRODUCT) EXPLODED VIEW (ENGINE) PARTS LIST (ENGINE) WIRING DIAGRAM TROUBLESHOOTING WARRANTY...
  • Page 3 | contact us: 1.866.523.5218 055-0361-0 Starting Watts 4200 Running Watts 3500 AC Voltage 120 V Phase Single Frequency 60 Hz Fuel Capacity 5 gal (19 L) Gross Weight 142 lb 14 oz (64.8 kg) Net Weight 129 lb 6 oz (58.7 kg) Length 24 1/2”...
  • Page 4 | contact us: 1.866.523.5218 055-0361-0 1. Fuel Tank 2. Battery 3. Fold–away Handle 4. Power Panel 5. Never–flat Wheels 6. Fuel Valve 7. Recoil Starter 8. Air Filter KNOW YOUR GENERATOR Before attempting to assemble or operate your generator, please become familiar with the major parts and components.
  • Page 5 | contact us: 1.866.523.5218 055-0361-0 Battery Switch Circuit Breakers Power Meter and Fuel Life Meter Remote Reset Light and Button 12 V Charger Outlet L5-30R Outlet 5-20R Duplex (2) Ground Choke 10. Engine Switch KNOW YOUR GENERATOR Familiarize yourself with the power panel outlets and switches before operation.
  • Page 6 | contact us: 1.866.523.5218 055-0361-0 INSTALL THE WHEEL KIT 1. Before adding fuel and oil, tip the generator on its side. 2. Slide the wheel pin roll (#65) through the wheel (#64) from the outside. 3. Slide the pin roll through the mount point on the frame.
  • Page 7 | contact us: 1.866.523.5218 055-0361-0 ADD ENGINE OIL The recommended oil type is 10W-30 automotive oil. 1. Place the generator on a flat, level surface. 2. Remove oil fill cap/dipstick to add oil. 3. Add up to 0.6 qt (0.6 L) of oil and replace oil fill cap/dipstick. DO NOT OVERFILL.
  • Page 8 | contact us: 1.866.523.5218 055-0361-0 ADD FUEL Use clean, fresh, regular unleaded fuel with a minimum octane rating of 87 and an ethanol content of less than 10% by volume. DO NOT mix oil with fuel. Clean the area around the fuel cap.
  • Page 9 | contact us: 1.866.523.5218 055-0361-0 GENERATOR LOCATION NEVER operate the generator inside any building including garages, basements, crawlspaces, sheds, enclosure or compartment, including the generator compartment of a recreational vehicle. Please consult your local authority. In some areas, generators must be registered with the local utility.
  • Page 10 | contact us: 1.866.523.5218 055-0361-0 WIRELESS REMOTE Wireless remote starting is only possible within 78’ (24 m) of the generator. Do not attempt to adjust the carburetor choke. The remote system will automatically close and open the choke.
  • Page 11 | contact us: 1.866.523.5218 055-0361-0 CONNECTING ELECTRICAL LOADS Let the engine stabilize and warm up for a few minutes after starting. Plug in and turn on the desired 120 V AC single phase, 60 Hz electrical loads. DO NOT connect 3-phase loads to the generator.
  • Page 12 | contact us: 1.866.523.5218 055-0361-0 POWER METER AND FUEL LIFE METER The power and fuel life meter are located on the front of the operator’s panel and shown as Item #3 on page 5. The meter is divided into two separate displays. The LCD display on top shows the voltage [U], frequency [H], running time [R], total time, and remaining fuel run time [F].
  • Page 13 | contact us: 1.866.523.5218 055-0361-0 IMPORTANT SAFETY INFORMATION WHEN SERVICING THE GENERATOR: ∙ Disconnect the spark plug wire and place it ∙ Read this manual thoroughly before where it cannot contact the plug. operating your generator. Failure to ∙...
  • Page 14 | contact us: 1.866.523.5218 055-0361-0 DO NOT USE THE GENERATOR IF: WHEN STARTING THE GENERATOR: ∙ Electrical output is lost. ∙ DO NOT attempt to start a damaged ∙ Equipment sparks, smokes or emits generator. flames. ∙ Make certain that the gas cap, air filter, ∙...
  • Page 15 | contact us: 1.866.523.5218 055-0361-0 STORAGE AND MAINTENANCE The owner/operator is responsible for all periodic maintenance. Tampering with the factory set governor will void your warranty. Improper maintenance will void your warranty. Maintenance, replacement, or repair of emission control devices and systems may be performed by any non-road engine repair establishment or individual.
  • Page 16 | contact us: 1.866.523.5218 055-0361-0 Air Filter 1. Remove the snap-on cover holding the air filter to the assembly. 2. Remove the foam element. 3. Wash in liquid detergent and water. Squeeze thoroughly dry in a clean cloth.
  • Page 17 | contact us: 1.866.523.5218 055-0361-0 Maintenance Schedule Follow the service intervals indicated in the following maintenance schedule. Service your generator more frequently when operating in adverse conditions. Every 8 hours or daily Check oil level Clean around air intake and muffler...
  • Page 18 | contact us: 1.866.523.5218 055-0361-0 Generator Maintenance 1. Make certain that the generator is kept clean and stored properly. Only operate the unit on a flat, level surface in a clean, dry operating environment. DO NOT expose the unit to extreme conditions, excessive dust, dirt, moisture or corrosive vapours.
  • Page 19 | contact us: 1.866.523.5218 055-0361-0 Generator Battery This product is equipped with an automatic battery charging circuit. The battery will receive charging voltage when the engine is running. The battery will maintain a proper charge if the unit is used on a regular basis (about once every two weeks). If it is used less frequently, the battery should be connected to a trickle charger (not included) or battery maintainer (not included) to keep the battery properly charged.
  • Page 20 | contact us: 1.866.523.5218 055-0361-0...
  • Page 21 | contact us: 1.866.523.5218 055-0361-0 Item Description Drawing Engine, Teal 3145c 27.601.99 Rotor Assembly, Al, Ø119 x 90 mm, THD<15% 124.191000.18 Flange Bolt M8 x 227 2.08.103 Washer Ø8 1.96.08 Lock Washer Ø8 1.7244.08 Stator Assembly, Al, Ø190 x 90 mm,THD<15% 124.191200.18 Stator Cover 124.191002.02...
  • Page 22 | contact us: 1.866.523.5218 055-0361-0 Item Description Drawing Washer Ø24 x Ø6.5 x 1.5 2.03.004 Flange Bolt M6 x 20 1.5789.0620 Reversal Valve 24.070800.00 Hole, Breather Tube 24.070030.00 Pipe, Reversal Valve, 670 mm 122.070014.03 Seal Ring 122.070036.00 Fuel Level Sensor, 135 mm 122.070035.00...
  • Page 23 | contact us: 1.866.523.5218 055-0361-0 Item Description Drawing Jacket, Wire 152.200013.01 Red Wire, Battery, 190 mm 5.1900.010 Black Wire, Battery, 190 mm 5.1900.011 Motor Mount 2 122.201200.02 Lock Nut M6, Flange 1.6177.1.06 Lock Washer Ø6, Toothed 1.862.06 Flange Bolt M6 x 12 1.5789.0612...
  • Page 24 | contact us: 1.866.523.5218 055-0361-0 Item Description Drawing Screw/Washer Assembly M5 x 14, Black 1.9074.4.0514.1 Bolt M5 x 14, Green 1.5783.0514.3 Nut M5, Green 1.6170.05.3 Washer Ø5, Green 1.97.1.05.3 Lock Washer Ø5 1.862.05 30 Amp Circuit Breaker, Push Button 5.1210.930...
  • Page 25 | contact us: 1.866.523.5218 055-0361-0 This Page Intentionally Left Blank.
  • Page 26 | contact us: 1.866.523.5218 055-0361-0...
  • Page 27 | contact us: 1.866.523.5218 055-0361-0 Item Description Drawing Flange Bolt M6 × 8 1.5789.0608 Cover, Recoil Starter, Black 419c 22.061100.00.30 Spring, Recoil Starter 21.061005.00 Rope Ø5 × 1550 2.10.003 Reel, Recoil Starter 21.061001.01 Spring, Ratchet 45.060003.00 Starter Ratchet, Steel 45.060002.00...
  • Page 28 | contact us: 1.866.523.5218 055-0361-0 Item Description Drawing Air Guide, Right Side 27.080600.01 Stud Bolt M6 × 90 2.01.003 Crankcase 27.030100.01 Oil Level Sensor 21.127000.02 Cylinder Head, 224cc 26.010100.01 Connecting Rod 27.050200.00 Crankshaft 27.050100.00 Bearing 6205 1.276.6205 Gasket, Crankcase Cover 24.030008.00...
  • Page 29 | contact us: 1.866.523.5218 055-0361-0 Item Description Drawing Ring, Second Piston 27.050302.00 Ring, First Piston 27.050301.00 Gasket, Cylinder Head 27.030009.01 Dowel Pin Ø10 × 14 2.04.003 Valve, Intake 23.040002.02 Valve, Exhaust 23.040006.02 Air Shroud, Cylinder 27.080200.00 Spark Plug F6RTC 2.15.002(F6RTC)
  • Page 30 | contact us: 1.866.523.5218 055-0361-0 Item Description Drawing Seal Strip, Crankcase Cover, Short 27.030013.01 Flange Bolt M8 × 40 2.08.123 Flange Bolt M10 × 65 2.08.121 Flange Bolt M6 × 29 1.5789.0629 Dowel Pin Ø8 × 10 2.04.005 Starter Motor Assembly 27.125100.00...
  • Page 31 | contact us: 1.866.523.5218 055-0361-0 This Page Intentionally Left Blank.
  • Page 32 | contact us: 1.866.523.5218 055-0361-0...
  • Page 33 | contact us: 1.866.523.5218 055-0361-0 Problem Cause Solution Generator will not start. No fuel. Add fuel. Faulty spark plug. Replace spark plug. Unit loaded during start up. Remove load from unit. Generator will not start. Low oil level.
  • Page 34 (120) days from the date of retail purchase. Made in China. Imported by Yardworks Canada Toronto, Canada M4S 2B8 YARDWORKS CANADA will not be liable for incidental or consequential loss or damage.
  • Page 35 • Failure to follow the recommended starting procedures and guidelines for fuel and oil usage as specified in the operating manual. Yardworks™ recommends fuel that is a minimum of 87 octane. Do not use fuel with more than 10 percent ethanol such as E15 or E85 fuel. Damage to the engine caused by ethanol-blended fuels is not covered under the warranty of the product.
