Assembly, Use and Care
Thank You!
You have purchased the highest quality professional broadcast spreader available on the market today. The
Model 2000 is the accumulated refinement of proven performance and will provide you with years of trouble-
free service. In the event you should have any questions or comments, please call our professional support staff.
1-800-225-2639
Our toll-free number is
Before You Begin . . .
To assemble your new
spreader, we highly
recommend
that you read
all instructions
thoroughly, familiarize yourself
with the assembly and
components, and verify that all parts are
included in this package.
You Will Need . . .
The following tools:
•
/
" and
/
" and
3
/
", open-end wrenches (or an
1
7
2
16
8
adjustable wrench)
• Pliers
• Phillips head screwdriver
• Grease gun
Professional Rotary Spreader
(U.S. Only)
Advertisement
Table of Contents
Summary of Contents for Andersons Model2000
-
Page 1: Before You Begin
Professional Rotary Spreader Assembly, Use and Care Thank You! You have purchased the highest quality professional broadcast spreader available on the market today. The Model 2000 is the accumulated refinement of proven performance and will provide you with years of trouble- free service. - Page 2 Assembly Place the bent end of the main shutoff connecting rod Turn the spreader upside-down. Place the wheels on through the hole in the lever and secure it with a cotter the axle with the longer portion of the hubs facing inward. Secure the drive wheel A (right side) to the axle using the pin on the right side.
- Page 3 Assembly continued Grease Fittings Using a grease gun, lubricate the grease fittings on the axle bearing housings and gear carrier. Apply a small amount of grease to the gear teeth. Install the two gearbox cover halves and secure with the three retainer clips. Insert the screen inside the hopper and secure it with factory installed clips.
- Page 4 Operation HOW TO USE 1) Check product bag for rate setting (letter), cone setting (number), and swath width. The rate setting is achieved Rate Control Plate by loosening the rate control knob and sliding the rate control plate to the desired letter. The cone setting is Helical Cone used to control spread pattern and is adjusted by rotating the index tab on the orange helical cone to...
- Page 5 Calibration Instructions calibration depth Calibration Key Pointer “E” Position Rate Control Plate Your professional spreader has been factory calibrated. For best results, occasionally check calibration and adjust if necessary. 1) Set the rate control plate to the “E” position. 8) Slide the rate control plate to the right until it comes in contact with the protruding end of the rate control 2) Push the main shutoff lever to the OPENposition.
- Page 6 Parts Diagram - Model 2000 Optional Deflector Kit (Used for side spread pattern shut off.) (includes 2, 3, 7-13) (includes 4-6, 13)
- Page 7 Ordering Parts See diagram for assistance in identifying specific parts. For parts orders, call 1-614-559-2705. (Note: Sales of parts for Andersons spreaders are handled by PSB Company.) IMPORTANT: When ordering replacement parts, always provide the following information: 1) Part number (DO NOT use key numbers when ordering parts. ALWAYS use part numbers.)
- Page 8 Your comments and questions are always welcome - please call our Helpline: 1-800-225-2639 (U.S. Only) Or Visit Our Website At . . . www.andersonsturf.com www.andersonsturf-intl.com The Andersons, Inc. 480 W. Dussel Drive Maumee, OH 43537 USA *ASP8099_Manual-L11...
