Summary of Contents for Temperature alert TM-CELL400-Z
-
Page 1: Table Of Contents
Cellular Edition TM-CELL400-Z User Guide Table of Contents TM-CELL400-Z U ELLULAR DITION UIDE HARDWARE GUIDE ERIFYING IRELESS IGNAL ECEPTION ETTING IRST LERT ELLULAR DITION ACKS AND ONNECTORS HARGING THE ATTERY ATTERY URNING ON THE EVICE URNING OFF THE EVICE PERATING... -
Page 2: Hardware Guide
HANGING THE ATTERIES ROUBLESHOOTING Hardware Guide Cellular Edition At a Glance The Temperature@lert Cellular Edition is a remote environmental monitor that measures conditions such as temperature and humidity at its location every few minutes. Each sensor reading is transmitted via the mobile phone network to our 24/7 monitoring system and secure web site. If the temperature goes too high or too low, the system will call, email or text message you. -
Page 3: Setting Up Your First Alert
Temperature@lert Cellular Edition is primarily controlled via the Sensor Cloud website located at www.myalertlist.com. Log into www.myalertlist.com using the username and password you created when you purchased the device. To setup a temperature alert notification, follow these steps: 1. Click on the Devices tab and select Device List. -
Page 4: Cellular Edition Jacks And Connectors
Cellular Edition Jacks and Connectors On the side of the unit, you’ll find the majority of the connectors and jacks (see figure 2): Large Antenna – The GSM or CDMA swivel antenna is connected via a threaded SMA mount. Used to connect to the cellular network. -
Page 5: Battery Life
Battery Life When disconnected from external power the battery is expected to last between one to two days. Lower reading intervals will lower battery life. It’s recommend to set power alerts for AC power loss and low battery. Turning on the Device Connecting a unit that has been powered off to wall power will turn on the unit. -
Page 6: Operating Guidelines
http://www.youtube.com/watch?v=b3UhVPN4EGg Operating Guidelines Placement The unit should be placed indoors on a flat and level surface. The unit can be mounted vertically on a wall or other surface with screws or with industrial Velcro® tape. Adding ZPoint Wireless Sensors When you order your ZPoint wireless sensors from Temperature@lert, we will automatically associate them with your account. -
Page 7: Environment Considerations
Environment considerations. Device Operating Range: 5ºC to +45ºC (+41ºF to +113ºF) If placing the device in a refrigerated environment it is highly recommend keeping in a sealed FDA bag with desiccant. Otherwise condensation and build and damage the device. Ideally the device should be placed outside the fridge or freezer environment and have a sensor probe on the inside. -
Page 8: Zpoint Wireless Sensor
wireless communication is unavailable (for example if the ZPoint Cellular Edition is loses signal or a wireless sensor goes out of wireless range of the cellular edition), turning on store and forward will internally log the sensor readings on the regular interval. Once communication is restored, the logged data will be forwarded to the cloud and available for reporting and compliance purposes. -
Page 9: Turning On The Wireless Sensor
1. Press and hold the "on/off" button. All the lights will illuminate and after about 5 seconds the "status" light will start flashing. When the "status" light begins flashing release the "on/off" button.(Hold the button too long and the device will power off) 2. - Page 10 ZPoint wireless sensors that are not within range of a ZPoint Cellular Edition for an extended period of time will experience a decrease in battery life. If you are using the wireless sensors in those conditions, make sure you have low battery alarms setup. ZPoint Wireless Repeaters operate on a built-in lithium- ion rechargeable battery.
