Summary of Contents for Keebox SFE05
- Page 1 Quick Installation Guide Guía de instalación rápida 5-Port 10/100 Fast Ethernet Switch SFE05 8-Port 10/100 Fast Ethernet Switch SFE08...
-
Page 2: Table Of Contents
Contents Español 1. Antes de iniciar 2. Instalación del Hardware 3. LED Technical Specifications Troubleshooting Quick Installation Guide - KEEBOX SFE05/SFE08 Version 05.14.2010 Version 05.13.2009... -
Page 3: Antes De Iniciar
Inspeccione visualmente el conector de alimentación de corriente DC para comprobar que está conectado al adaptador de corriente Compruebe que existe una correcta regulación de la temperatura y una ventilación adecuada alrededor del conmutador No coloque objectos pesados encima del conmutador Guía de Instalación Rápida - KEEBOX SFE05/SFE08 Español... -
Page 4: Instalación Del Hardware
Instalación del Hardware 1. Conecte el adaptador de alimentación al SFE05/SFE08 y luego a una toma de corriente. 2. Conecte un cable de red RJ-45 CAT 5, 5e o 6 del PC a un puerto Ethernet disponible en el SFE05/SFE08. -
Page 5: Led
Verde (Sólido): Conexión para los puertos 100Mbps Verde (intermitente): La conexión tiene actividad Ámbar (Sólido): Conexión para los puertos 10Mbps Ámbar (intermitente): la conexión tiene actividad Si no está iluminado: No se detecta nada en el puerto Guía de Instalación Rápida - KEEBOX SFE05/SFE08 Español... -
Page 6: Technical Specifications
Troubleshooting Technical Specifications SFE05 SFE08 IEEE 802.3 10Base-T; IEEE 802.3u 100Base-TX; Standards IEEE 802.3x Flow Control Ethernet: Cat. 3,4,5, up to 100m Network Media Fast Ethernet: Cat. 5, 5e, 6 up to 100m Ethernet: 10Mbps/20Mbps (half/full-duplex) Data Rates Fast Ethernet: 100Mbps/200Mbps (half/full-duplex) - Page 7 Troubleshooting 1. After connecting the Switch to a power outlet, the LEDs do not turn on. Check the connection of the external power adapter to the SFE05/SFE08 and the power outlet. 2. Check that the power outlet is receiving power.
- Page 8 AC/DC Power Adapter, Cooling Fan, and Power Supply carry a 1 year warranty If a product does not operate as warranted during the applicable warranty period, KEEBOX shall reserve the right, at its expense, to repair or replace the defective product or part and deliver an equivalent product or part to the customer. The repair/replacement unit's warranty continues from the original date of purchase.
- Page 9 Certifications This equipment has been tested and found to comply with FCC and CE Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received. Including interference that may cause undesired operation.
- Page 10 Copyright © 2010 KEEBOX. All Rights Reserved.
