S250 Pro FPV Quadcopter Manual
www.spedix-rc.com
For age 14+ only. Rotating propellers may cause serious injury and damages!
Do not install propellers during setup procedures.
Check www.knowbeforeyoufly.org for drone safety.
Users in USA need register on FAA system:
Version: Naze V6 V1.1
！
WARNING
www.federaldroneregistration.com
S250 PRO
Features
Setup and Play.
Assembled and tested in factory.
Quick response in flight, durable and
light structure.
Latest Naze32 Rev6 flight controller
with 3 Flight modes.
DSM2/DSMX* compatible satellite
receiver with easy binding button.
700TVL FPV camera.
5.8GHz 200mW 40 channel video
transmitter with race band.
Integrated On Screen Display.
Powerful and durable 2204 motors.
BLHeli program speed controllers.
Green and Red LED lights on arms.
Programmable RGB LED lights on
tail.
*DSM2 and DSMX are trademarks of Horizon Hobby Inc.
The receiver installed in this aircraft is not a product of
Horizon Hobby Inc.
Online Video Instructions
Scan barcode or search
"Spedix S250 Pro Setup" on
YouTube to acsess video
instructions.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S250 Pro FPV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SPEDIX S250 Pro FPV

  • Page 1 Integrated On Screen Display. Powerful and durable 2204 motors. BLHeli program speed controllers. Green and Red LED lights on arms. S250 Pro FPV Quadcopter Manual Programmable RGB LED lights on tail. Version: Naze V6 V1.1 *DSM2 and DSMX are trademarks of Horizon Hobby Inc.

  • Page 2: Package Content

    Package Content S250 Pro Quad x1 Propellers x4 Receiver Cable x1 OSD-ISP OSD-SET Cable x1 Cable x1 Optional Equipment 6+ Channel 3S or 4S FPV monitor or goggle USB Cable Spektrum Radio 1500-1800mAh LiPo...

  • Page 3: Binding & Settings

    We have online video can start and control the quad properly. tutorials. Scan barcode on the right or search “Spedix S250 The quad itself has been programmed in the factory and is Pro Setup” on YouTube to not necessary to make changes of the parameters for The radio should set to watch video instructions.

  • Page 4: Installation And Testing

    Installation and Testing 6. Motor calibration Motors are calibrated in the factory. If they do not spin properly, then motors should be calibrated in Cleanflight to make the quad work properly. Follow the instructions in the software to complete calibration. Motor Sequence and Rotation 7.
  • Page 5 Video Transmitter and OSD Important: Antenna should be installed ！ before power on. Specifications of VTX Power: 200mW Frequency: 5.8 GHz 5.8G Hz 200mW 40 Channel Video Transmitter Channels: 40 Channels, ABEFR Bands Antenna: SMA 3dBi antenna Power: 7-24V input Size: 29x22x7.5mm Weight: 8.3g RP-SMA Connector...
  • Page 6 Electronics Connection of Electronic Components Main Control Board S250 has a flight controller based on Naze32 XT60 Connector 700TVL Rev6, integrated with power distribution board FPV Camera and MinimOSD. The flight controller is mounted upside down in the quad. Therefore in the Configuration section of Cleanflight, “Board and Sensor Alignment”...
  • Page 7 Assembly 1 Flight controller installation Arm assembly 5’or 6'Propeller 2204 Motor Camera instrallation M3x8 ARM Led Plate Landing Gear M2x8 M2x12 LED installation Video Transmitter installation...
  • Page 8 Assembly 2 Main Frame Assembly Discussion on YouTube Videos RC Groups...
