- Page 1 SELCO A/S M2500 Installation Manual M2500 Engine Controller Installation Manual Revision: 23-04-2012 Page 1...
-
Page 2: Table Of Contents
SELCO A/S M2500 Installation Manual Contents Preface ............................4 Installation ........................... 5 Terminal Connections ........................6 Inputs ............................7 Power Supply ........................... 7 Mode/ Control Inputs ....................... 7 4.2.1 Connection of Mode Selector Switch .................. 8 4.2.2 Remote Start (terminal 8) ..................... 9 4.2.3 Remote Stop (terminal 9) ..................... - Page 3 SELCO A/S M2500 Installation Manual Alarm Outputs ........................20 5.3.1 Connection of alarm outputs ....................21 5.3.2 Common Alarm (terminal 46) ................... 21 5.3.3 Shutdown (terminal 47) ..................... 21 5.3.4 Cable break (terminal 48) ....................21 5.3.5 CAN (terminal 49) ......................21 5.3.6 REF3 (terminal 50) ......................
-
Page 4: Preface
1 Preface The M2500 - Engine Controller is designed for control and monitoring of marine engines. Together with the optional M2600 - Shutdown Unit the M2500 - Engine Controller forms a complete alarm, control and protective safety system for marine engines. -
Page 5: Installation
M2500 Installation Manual 2 Installation The M2500 is designed for flush mounting to the front panel of the switchboard. It is secured by 6 mounting brackets which are supplied with the M2500. The panel cut out dimension is 138mm x 210mm... -
Page 6: Terminal Connections
SELCO A/S M2500 Installation Manual 3 Terminal Connections USB interface for configuration and RS485 Modbus read out of alarm log Outputs for Primary and back-up indication of engine state power supply (e.g. to PMS) Inputs for activation of operation Control... -
Page 7: Inputs
SELCO A/S M2500 Installation Manual 4 Inputs 4.1 Power Supply Redundant Power Supply (2x 24V DC, -30 % / +30 %) Alarm in case any power supply fails (common alarm + display text). Primary supply will not be monitored during cranking, as the battery voltage will drop during this process. -
Page 8: Connection Of Mode Selector Switch
The local mode input is considered active when connected to COM, inactive when open. When active the M2500 will be in local mode. This means start and stop are only available from the push buttons on the front panel. The remote start and stop terminals are disabled. The LOCAL LED on the front panel will be lit. -
Page 9: Remote Start (Terminal 8)
LED will be lit continuously. If the engine does not start the M2500 will initiate a stop procedure and a Start Fail Alarm. The red ALARM LED on the front panel will be lit. The alarm text “START FAILURE” will be shown on the display. -
Page 10: Override (Terminal 10)
Crank Disconnect signal the M2500 will deactivate the crank output after a start attempt. If the M2500 looses this signal without a stop procedure, the ALARM LED will be lit and a Tacho Fail Alarm will be displayed. -
Page 11: Com (Terminal 13)
The magnetic pick-up is connected as follows: For use of magnetic pick-up the DIP switches 3 and 4 on the rear side of M2500 must be in OFF position. The DIP switches are placed between the RS485 and CAN connectors on the rear side of M2500. -
Page 12: Connection Of Pnp Pick-Up
The NPN pick-up is connected as follows: For use of PNP pick-up the DIP switch 3 on the rear side of M2500 must be in ON position, DIP switch 4 must be in OFF position. The DIP switches are placed between the RS485 and CAN connectors on the rear side of M2500. -
Page 13: Digital Sensor Inputs
SELCO A/S M2500 Installation Manual 4.4 Digital sensor inputs Description Remark Sensor input for digital sensor 1 Digital input 1 Digital input 2 Sensor input for digital sensor 2 Digital input 3 Sensor input for digital sensor 3 Digital input 4... -
Page 14: Connection Of A Normally Closed Sensor Without Cable Monitoring
SELCO A/S M2500 Installation Manual 4.4.2 Connection of a normally closed sensor without cable monitoring The following example shows the Connection of a normally closed sensor without cable monitoring. The sensor is considered active when open, inactive when connected to COM. -
Page 15: Connection Of A Normally Closed Sensor With Cable Monitoring
SELCO A/S M2500 Installation Manual 4.4.4 Connection of a normally closed sensor with cable monitoring The following example shows the connection of a normally closed sensor with cable monitoring. The sensor is considered active when open, inactive when connected to COM. -
Page 16: Analogue Inputs (Terminals 27 To 34)
The analogue sensor inputs are for generating alarms and shutdowns. In case the input signal is below 3mA or above 25mA the M2500 will generate a sensor fail alarm. Cable Error LED will be lit. Delay times can be programmed for alarms and shutdowns. -
Page 17: Outputs
SELCO A/S M2500 Installation Manual 5 Outputs All outputs are relay contacts. 5.1 Engine Status Outputs Description Type Rating Ready/ Not Ready NO Relay Start warning NO Relay Engine Running NO Relay Cool down NO Relay REF1 Common reference for engine status outputs 5.1.1 Connection of Engine Status Outputs... -
Page 18: Ready (Terminal 36)
M2500 will trip the C/B. The engine will continue running for the duration of the cool down time. After expiration of the cool down time the M2500 will stop the engine. The cool down time can be configured. Cool Down only applies to remote mode and only for normal stops. -
Page 19: Engine Control Outputs
SELCO A/S M2500 Installation Manual 5.2 Engine Control Outputs Description Type Rating Auxiliary lubrication pump NO Relay Crank NO Relay Circuit breaker trip NO Relay Air intake valve NO Relay Common reference for the control REF 2 outputs 5.2.1 Connection of Engine Control Outputs Following example shows the connection of an external relay for the C/B trip signal: 5.2.2 Auxiliary Lubrication Pump (terminal 41) -
Page 20: Crank (Terminal 42)
5.2.3 Crank (terminal 42) Normally Open Relay output. This is the start output of the M2500. It activates for each start attempt and remains active until either the engine has fired or the crank time has expired or a stop command has been activated at the M2500. -
Page 21: Connection Of Alarm Outputs
SELCO A/S M2500 Installation Manual 5.3.1 Connection of alarm outputs Following example shows the connection of an external relay for signaling a shutdown to an external alarm system: 5.3.2 Common Alarm (terminal 46) Normally Open Relay output. This output becomes energized for each alarm and shutdown. -
Page 22: Digital Outputs
SELCO A/S M2500 Installation Manual Digital Outputs Rating Description Type Digital Output 1 NO Relay (start fail in default config) Digital Output 2 NO Relay (stop fail in default config) Digital Output 3 NO Relay Digital Output 4 NO Relay... -
Page 23: Digital Outputs Out 1 To Out 12 (Terminals 51 To 62)
SELCO A/S M2500 Installation Manual 5.4.2 Digital Outputs Out 1 to Out 12 (terminals 51 to 62) Normally Open Relay output. These are programmable alarm and shutdown outputs. It is also possible to program these outputs to activate with any of the alarms generated from the analogue measurements. -
Page 24: Run/ Stop Solenoid (Terminal 66 And 67)
This is especially important in case the stop solenoid is not activated directly by the M2500 output but by an intermediate relay, that typically requires a much lower current to activate than the stop solenoid. - Page 25 This is especially important in case the fuel valve is not activated directly by the M2500 output but by an intermediate relay, that typically requires a much lower current to activate than the fuel valve.
-
Page 26: Siren Relay
SELCO A/S M2500 Installation Manual 5.6 Siren Relay Description Type Rating Relay contact in de-energized position REF 5 Reference contact of alarm relay Relay contact in energized position The siren relay is typically used for connection of a siren. It is normally energized. -
Page 27: Communication
SELCO A/S M2500 Installation Manual 6 Communication 6.1 CAN J1939 Bus The M2500 can communicate directly with the engine ECU by CAN bus, SAE J1939 for a maximum distance 250m. 6.1.1 CAN J1939 Connector: Pin 1: CAN H Pin 2:... -
Page 28: Rs485 Modbus
SELCO A/S M2500 Installation Manual 6.1.3 RS485 MODBUS M2500 includes an RS485 interface MODBUS RTU communication. RS485 Connector: Pin 1: RS485 A Pin 2: RS485 B Pin 3: RS485 COM The RS485 Modbus is to be terminated on both ends with a 120Ω resistor. -
Page 29: Functional Description
In remote mode (terminal 5 connected to com) Start and stop is only available from the REMOTE START (terminal 08) and REMOTE STOP (terminal 09) terminals. Provided the engine is ready for remote start (Not Ready LED on the front panel of M2500 is off) the start procedure works as follows:... - Page 30 SELCO A/S M2500 Installation Manual Remote Stop flowchart: Engine Running Fuel Vanve Remote Stop Command Fuel Vanve Cool Down Run C/B Trip Cool Down Cool Down Time expired? Engine Stop Stop Procedure Stop Solenoid Stop Time expired? Stop Fail Engine...
-
Page 31: Alarm Monitoring
The alarm monitoring is always active regardless of Local or remote mode. Note: Alarms are abnormal conditions that will be indicated and logged by the M2500, but they will not stop the engine. Alarms can be set to continuous monitoring (regardless if the engine is running or not) or conditional monitoring (only monitored if the engine is running). -
Page 32: Alarm Flowchart
SELCO A/S M2500 Installation Manual 7.2.1 Alarm flowchart: Engine Running Fuel Vanve Alarm input activated? Override activated AND Alarm marked for override? Alarm marked Monitoring for blocking? delay expired? Running Fuel Valve Not Ready Common Alarm Alarm Procedure Alarm Relay de-... -
Page 33: Shutdown Monitoring
The shutdown monitoring is always active regardless of Local or remote mode. Note: Shutdowns are abnormal conditions that will be indicated and logged by the M2500 and they will stop the engine. Shutdowns can be set to continuous monitoring (regardless if the engine is running or not) or conditional monitoring (only monitored if the engine is running). -
Page 34: Shutdown Flowchart
SELCO A/S M2500 Installation Manual 7.3.1 Shutdown flowchart: Engine Running Fuel Vanve Shut Down input activated? Override activated AND Shutdown marked for override? Shutdown Monitoring marked for delay expired? blocking? Not Ready C/B trip Air Intake Common Alarm Shut Down... -
Page 35: Specification
