- Page 1 Instruction Manual • Please read the instructions carefully before using. • Please keep the user’s guide where it is easily accessible. • Design and product development may be upgraded without a public notice. www.versapers.nl...
- Page 2 Important safeguards When using electrical appliances, basic safety precautions should always be followed including the following as described below: Read all instructions. To protect against risk of electrical shock, do not put the main body (motor) in water or any other liquid. Close supervision is necessary when any appliance is used by or near children.
-
Page 3: Table Of Contents
Please refer to the user’s guide when you are having technical difficulties or are unsure of the usage of this product. Versapers is not liable for any damages or injuries that may occur due to the lack of understanding of the user’s guide. -
Page 4: Contents Of The Box
Contents of the box Hopper Squeezing screw Base Cleaning brush Yellow Strainer White Strainer more pulp less pulp Pusher Container (2) Top set Important Spinning brush Important: As shown below, the hopper edge must point to ‘CLOSE’ sign on the base in order for the machine to operate properly. -
Page 5: Safety Precautions
Safety precautions Please read carefully before using. Please follow the instructions to avoid injuries. Warning signs Warning: violating this sign may lead to serious injury or even death. Caution: violating this sign may lead to serious damage to the product. Warning Example: (danger in health) - Page 6 Warning Do not disassemble the base. Stop use when the electrical Please consult with repair cord is damaged or loose. technician for trouble shooting. Do not put any unknown Keep the base dry at all times. substance into the machine. Keep away from children or any Do not disassemble any parts personnel who are not familiar...
- Page 7 Caution Do not remove the hopper Should the squeezing screw jam, while operating. put in reverse for 2-3 seconds. Then try operating again. Do not disassemble the top set Do not use anything other than while operating. the pusher. Do not use more than Do not submerge the motor 30 minutes continuously.
-
Page 8: Assembly Instruction – Type 1
Assembly instructions – Type 1 Bowl Hopper Arrow on the hopper Red dot on the Base bowl Assemble the bowl on the base. 1 Make sure the bowl is all the way into the shaft of the base. 2 Twist the bowl to close Red dot on Rode stip Assemble the hopper onto the bowl. -
Page 9: Assembly Instruction - Type 1
Assembly instruction – Type 2 Place the strainer into the spinning brush. Strainer Spinning brush Place the strainer + spinning brush into Red dot on the bowl. the strainer Make sure the red dot on the strainer and the red dot on the bowl are aligned. Red dot on the bowl Push the squeezing screw into the strainer... -
Page 10: Assembly Instruction - Type 2
Assembly instruction – Type 2 Assemble the hopper onto the bowl. 1 Make sure the arrow on the hopper and the red dot on the bowl are aligned. 2 Twist the hopper clockwise to lock it on the bowl. Arrow on the hopper Red dot on the bowl... - Page 11 Assembly instruction – Type 1, 2 Now connect the power cord. Place a container under the pulp ejection and one under the juice ejection. Yellow rubber pad Underneath the bowl, there is a yellow rubber pad which allows all the juice to only discharge from the fresh juice ejection exit.
-
Page 12: How To Use The Slow Juicer
How to use the Versapers slow juicer The machine has three (3) settings. ‘ON’ starts the motor, start making juice. ‘REV’ is reverse. Only use when something is stuck and you need to unclog. ‘OFF’ is at the center position. -
Page 13: Warning While Operating
Take special care with the ON/OFF switch. Remove any You could damage the Versapers by hard seeds from fruits hard seeds. like cherries, apricots, peaches, olives, dates etc. Seeds of a watermelon, apples or pears do not form any problem. It is best to remove the pits of citrus fruit like lemons and oranges if you can but they will not damage the product. -
Page 14: How To Disassemble And Clean
How to disassemble and clean Turn the machine ‘OFF’ and Use the brush to clean unplug the electric cord. thoroughly after operating. Twist the hopper to unlock by grabbing the two ejections. Make sure the arrow is aligned with the open sign before pulling o the bowl. -
Page 15: Before Requesting For Repair Service
- Check if the power cord has been plugged in correctly. does not operate. - Check if the assembly has been done correctly - Call the store where you have bought the Versapers The juice does not discharge - Check if the rubber pad has been installed correctly. - Page 16 Product speci cations Product speci cations Product name Versapers Slow Juicer Model name Emotion Voltage 230 V Frequency 50 Hz Power consumption 150 W 80 rpm Electrical cord length 140 cm Motor Single Phase Induction Weight 5.2 kg Width 17,3 cm...
- Page 17 For the latest information on your product, tips and recipes, please visit our website www.versapers.nl We especially like to hear what you think about the Versapers. Please share with us your thoughts at our online forum and learn from what other Versapers users have said about the Versapers.
- Page 18 Customer Service Netherlands: www.versapers.nl...
