This system contains:

LS 300/C Center Speaker;

Congratulations on your purchase and welcome to the AudioSource family of satisfied customers. Please take a few moments to re a d

this manual before you get started. Also, be sure to retain this document should you need to refer to it in the future .

The AudioSource System 300 Home Theater Speaker System is designed to accurately reproduce high fidelity music, including digital

signals. Movies and stereo TV broadcasts will sound more realistic, putting you in the center of the action. The LS 300/C center

channel speaker is video-shielded, allowing placement on top of your television. LS 300 speakers are provided for both the front

and surround channels, to provide a theater-like experience.

This manual is divided into two sections. The first provides information about the LS 300 speakers and the LS 300/C center speaker.

The next section concerns the SW 300 Powered Subwoofer.

Hooking Them Up

The five-way binding posts accommodate nearly any type of connector and up to 14-gauge wire. For bare wire, press the binding post

in to reveal the eye, thread the wire into the eye, and release the spring-loaded connector . For banana plugs, simply insert the plug

into the end of the connector.

When connecting the speakers, be sure to retain the correct polarity. Attach the wire from the +, red, or positive terminal on one

component to the +, red, or positive terminal on the corresponding component's speaker output terminals. The –, blackblack or

negative terminals must connect to the respective –, black or negative terminals. This is easy to do by observing the color, stripe,

or ribbing that appears on the wire.

Please note: If any parts of this system are missing or damaged, do not return to the store where you purchased this system. Please call AudioSource

directly at 800-HELP-115 (800-435-7115).

System 300

Home Theater Speaker System

LS 300 Compact Speakers (front left, front right, back left & back right speakers);

SW 300 Powered Subwoofer

LS 300 & LS 300/C

Owner's Manual
