ENGINEER'S GUIDE
Congratulations! You've just purchased the most
technically advanced HO diesel locomotive ever
produced! This highly detailed model includes a
broader range of features than you'll find on any
other HO scale diesel, including smooth
performance from a 12-Volt 5-Pole Precision
Flywheel Equipped Skew-wound motor; and a
DCC-Ready plug-in receptacle for any DCC
receiver. If you're looking for modern motive
power that's accurately detailed, smooth running,
and a great deal of fun to operate, it doesn't get
any better than this.
PLEASE READ THE MANUAL BEFORE USE AND SAVE
WWW.MTHHOTRAINS.COM
Advertisement
Table of Contents
Related Manuals for MTHTrains F-3
Summary of Contents for MTHTrains F-3
- Page 1 M.T.H. HO Diesel Engine DCC Ready ENGINEER’S GUIDE Congratulations! You've just purchased the most technically advanced HO diesel locomotive ever produced! This highly detailed model includes a broader range of features than you’ll find on any other HO scale diesel, including smooth performance from a 12-Volt 5-Pole Precision Flywheel Equipped Skew-wound motor;...
-
Page 2: Table Of Contents
TABLE OF CONTENTS UNPACKING YOUR ENGINE Removing and Unwrapping Your Engine What Else is in the Box? PRODUCT OVERVIEW Getting to Know Your Engine Engine Diagram Removing the Body SET-UP Lubrication FEATURES AND OPERATION Analog DC (standard DC power pack) DCC Digital Command Control Alternate Lighting Supply Jumper Installing your DCC Decoder... - Page 3 Step 3: Apply increasing DC voltage until she starts up and pulls out! CAUTION: M.T.H. HO engines DO NOT OPERATE ON AC VOLTAGE. Applying AC power to your locomotive could cause permanent damage and will void your warranty. M.T.H. HO F-3 Diesel Engine...
-
Page 4: Unpacking Your Engine
The following items are packed with your engine. Engineer's Guide (1) You probably know that since you're reading it. ALT-L Pad Jumper (1) This is for the ALT-L pad on the MTH DCC Ready Engine Board M.T.H. HO F-3 Diesel Engine... -
Page 5: Product Overview
M.T.H. HO Engines, we could write a book. But, that's no fun. So, if you haven't already done so, flip to the Quick Start Guide and let's run your new engine!! M.T.H. HO F-3 Diesel Engine... -
Page 6: Engine Diagram
-You must first remove the front locomotive coupler in order to pull the body off of the chassis. -Remove the screw shown below -Then slighty pull the body outward of engine in order to slide the body off. -Re-assemble in reverse order. Remove the Screw M.T.H. HO F-3 Diesel Engine... -
Page 7: Set-Up
Don’t worry. We’ve taken care of the hard part for you. Your MTH DCC Ready engine already has the jumpers installed at the factory so all you have to do is set it on the rails, apply DC power and away you go. M.T.H. HO F-3 Diesel Engine... -
Page 8: Modes Of Operation
Reduce the throttle until the engine stops, flip the direction switch, and then increase the throttle again. Lighting Your model is equipped with a headlight and number board lights. In analog DC mode, lighting operation is fully automatic. M.T.H. HO F-3 Diesel Engine... -
Page 9: Alternate Lighting Supply Jumper
The tabs are labeled on the board – D_R = Ditch Right, D_L = Ditch Left, NUM = Number Board. Alternate Lighting Supply Number Board LED Pin 5 Pin 4 NMRA 8-Pin Pin 8 Pin 1 DCC Lighting Control for: Number Boards” M.T.H. HO F-3 Diesel Engine... - Page 10 This provides a secure, yet, quick and easy way to connect the added function wires from your DCC decoder using the existing LED's on your MTH engine. M.T.H. HO F-3 Diesel Engine...
- Page 11 Step 7: Re-install the engine's body and ensure that it is clipped fully onto the chassis. You should be able to pick up your model by the body if it's been installed properly M.T.H. HO F-3 Diesel Engine...
-
Page 12: Specifications
DCC - Digital Command Control (with user installed DCC Decoder) DCS - Digital Control System Default Addresses DCS DCC short DCC extended US PATENTS US 6,457,681 Oct. 2, 2002 US 6,619,594 Sept. 16, 2003 US 6,655,640 Dec. 2, 2003 M.T.H. HO F-3 Diesel Engine... -
Page 13: Care And Maintenance
The Number board lights are jumpers for the Number board not controllable from DCC lightslights to be active Motion Solution Check that you have removed the Motor spins at track voltage NMRA header jumper (both jumpers) M.T.H. HO F-3 Diesel Engine... -
Page 14: How To Order Parts
HOW TO ORDER PARTS Replacement parts are available directly from the M.T.H. Parts Department (order online: www.mth-railking.com, e-mail: parts@mth-railking.com; mail: 7020 Columbia Gateway Drive, Columbia MD 21046-1532, FAX: 410-381-6122). M.T.H. HO F-3 Diesel Engine... -
Page 15: Service & Warranty Information
All M.T.H. products purchased from an Authorized M.T.H. Retailer are covered by this warranty. See our Website www.mthtrains.com to identify an M.T.H. Retailer near you. M.T.H. products are warrantied for one year from the date of purchase against defects in material or workmanship, excluding wear items such as light bulbs, pick-up rollers, batteries, smoke unit wicks, and traction tires.
