- Page 1 ® OPERATION AND MAINTENANCE MANUAL BSD-1000 BSD-1200 LOW VOLTAGE METAL ASSEMBLY SCREW DRIVER WWW.KILEWS.COM.CN KILEWS ELECTRIC TOOLS（SHANGHAI）CO., LTD. No.367, 2nd Xinjian Road, Xuhang Town, Jiading District, Shanghai 201808 China Tel: 86-21-59556022 Fax: 86-21-59553779 OSH-D10E...
-
Page 2: Specifications
BSD-1200 Series NOTICE Metal Assembly Screwdrivers are designed for installing threaded fasteners in light industrial and appliance manufacturing applications. KILEWS is not responsible for customer modification of tools for applications on which KILEWS was not consulted. WARNING Important safety information enclosed. -
Page 3: General Safety Rules
BSD-1200 Series 1. General Safety Rules Read all instructions Failure to follow all instructions listed below may result WARNING! in electric shock fire and/or serious injure. The term “power tool” in all of the warning listed below refer to your mains operated (corded) power tool or battery operated (cordless) power tool. - Page 4 BSD-1200 Series g) If devices are provided for the connection of dust extraction and collection facilitys, ensure these are connected and properly used. Use of these devices can reduce dust related hazards. 4) Power tool Use and Care a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
- Page 5 BSD-1200 Series 2. Operations Cautions 1) Whenever changing a bit, make certain the Power Switch is in the “ OFF “ position and tool is unplugged. 2) Do not allow chemicals such as acetone, benzene, thinner, trichloroethylene ketone, or other similar chemicals to come in contact with the screwdriver housing as damage will result.
- Page 6 BSD-1200 Series 3. Specifications MODEL BSD-1000 BSD-1200 32VDC Input voltage(DC) Rated input 0.5-7 2-15 Kgf.cm Bit torque 0.44-6.10 1.68-13.01 Lbf.in 0.05-0.69 0.19-1.47 Torque Adjustment Step less Unloaded Rotation Speed 1000 1000 (R.p.m) ±10% Machine 1.4~2.6 2.0-4.0 Metal assembly screw(mm) screw Tapping 1.4~2.0...
-
Page 7: Description Of Operation
BSD-1200 Series 4. Description of Operation Attaching / detaching bit and bit type Push up the holder clamp by finger tip, and it will be unlocked. Thus, the bit can be freely attached and detached (single finger notion type) select such a bit whose shank is equal to the size shown below. - Page 8 BSD-1200 Series CAUTION 1. Also in reverse rotation, the clutch is turned off in such manner as in normal rotation, stopping the motor running. Accordingly, when the screw tightened at a large torque, set it to a higher torque scale.
- Page 9 BSD-1200 Series 7. Servicing Maintenance and Inspection: 1. The screw driver must be operated in top condition. one day working hour must be not more than eight hours. 2. Periodically check for wear of motor carbon brush, one day for eight hours use is normal, replace it after every five to six months.
- Page 11 BSD-1000LA/B/C/AD , BSD-1200LA/B/C/AD PARTS NO PARTS NAME-E Q'ty NO PARTS NO PARTS NAME-E Q'ty 1 AA50001-2 CORD 26 GH20241 GEAR PLANET 2 CJ20011 SUSPENSION RING 27 GG20271 GEAR SEAT 3 CB15021 HOUSING-UNDERSIDE 28 G20101 GEAR OF CENTER 4 CA15101 HOUSING-UPSIDE...
- Page 13 BSD-1000LD , BSD-1200LD PARTS NO PARTS NAME-E Q'ty NO PARTS NO PARTS NAME-E Q'ty 1 AA50001-2 CORD 24 GK20231 “C” RING 2 CJ20011 SUSPENSION RING 25 GI20251-1 IRON WASHER 3 CB15021 HOUSING-UNDERSIDE 26 GH20241 GEAR PLANET 4 CA15101 HOUSING-UPSIDE 27 GG20271-G...
-
Page 14: Parts Name
® BSD-32P PARTS No. PARTS NAME. Q.TY P11013 HOUSING 32V 40W FOR BSD-32P EG50101-14 PCB POWER SUPPILY FOR BSD-32P A10105-3 CORD 2C× 1.5m... - Page 15 KILEWS ELECTRIC TOOLS（SHANGHAI）CO., LTD. E-mail:service@kilews.com.cn http://www.kilews.com.cn...
