MTS Systems THIR-6780 Series Configuration Manual

1dimensional / 2dimensional
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
THIR-6780 Series
Configuration Barcode Menu
1dimensional / 2dimensional
Image Reader
12-Sep-28
st
1
edition

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the THIR-6780 Series and is the answer not in the manual?

Questions and answers

Related Manuals for MTS Systems THIR-6780 Series

Summary of Contents for MTS Systems THIR-6780 Series

  • Page 1 THIR-6780 Series Configuration Barcode Menu 1dimensional / 2dimensional Image Reader 12-Sep-28 edition...
  • Page 2 【Update Information】 Edition Date Update Contents edition 2012/ 9/28 New release...

  • Page 3: Table Of Contents

    Table of Contents COMMAND MANUAL USAGE NOTES ......................6 ABBREVIATIONS USED ............................ 6 1. COMMUNICATIONS SETUP .......................... 7 ・ Baud rate ..............................7 ・ Character Framing ............................ 8 ・ RS/CS Control ............................9 ・ Header ..............................9 ・ Terminator ...............................10 2.
  • Page 4 ・ Code39 Start / Stop Transmit ........................32 ・ Code128 ..............................32 ・ GS1-128(EAN128) ..........................32 ・ Codabar Setup ............................33 ・ Codabar ST/SP Character Case.......................33 ・ Codabar Start / Stop transmission ......................34 ・ ITF Setup..............................34 ・ ITF Digits Setup ............................35 ・ Code93 ..............................35 ・...
  • Page 5 ・ Autosense Mode............................54 Enable / Disable autosense mode......................54 Autosense Mode timeout ..........................55 Decode Time out ............................56 Pointer in Autosense mode ..........................57 Autosense sensitivity ...........................57 Prohibit Same Symbol decoding in Auto Detection mode................58 Same Symbol Prohibition duration in Auto Detection Mode ................58 Cropping Image area ...........................59 Quick Setting with Function Button .......................60 3.2 S...
  • Page 6 ・ Caps Lock Setting ............................87 ・ Setting for Uppercase/Lowercase Conversion ...................87 ・ HID Status ...............................89 7. USB DEVICE TYPE ............................90 Initiate USB interface type switch ......................91 Select interface type..........................91 Save Settings ............................91...

  • Page 7: Command Manual Usage Notes

    Introduction The configuration barcodes provided in this manual offer instant setup off the various scanner settings, E.G., serial communication baud rate, enabling and disabling barcodes. Note: Default values in this guide are indicated by the notation “(*)”. Note: Barcodes may also be referred to as “symbols”. This manual may use either or both conventions. Please read the operation Manual of this reader carefully to ensure correct use of the equipment.

  • Page 8: Communications Setup

    1. Communications Setup（serial interface） ・Baud rate To set the Baud rate to match the baud rate setting of the host device, scan the appropriate symbol below. 1200[bps] 2400[bps] 4800[bps] 9600[bps](*) 19200[bps] 38400[bps] 57600[bps] 115200[bps]...

  • Page 9: Character Framing

    ・Character Framing To set the combination setting of Data Bits ,Parity and Stop Bits to match those settings of the Host device, scan the appropriate symbol below. 7 bits/Odd/Stop bit 1 7 bits/Odd/Stop bit 2 7 bits/Even/Stop bit 1 7 bits/Even/Stop bit 2 8 bits/None/Stop bit 1 (*) 8 bits/None/Stop bit 2 8 bits/Odd/Stop bit 1...

  • Page 10: Rs/Cs Control

    ・RTS/CTS Hardware Handshaking To Enable or Disable RTS/CTS Hardware Handshaking (RTS/CTS H/H) to the Host device, scan the appropriate symbol below. Disable RTS/CTS H/H (*) Enable RTS/CTS H/H ・Suffix character A prefix character may be appended to the head of scan data for use in data editing. To set the prefix character, scan the appropriate symbol below.

  • Page 11: Terminator

    ・Suffix character A suffix character may be appended to the end of scan data for use in data editing. To set the Suffix character, scan the appropriate symbol below. None [EX] [CR][LF] (*) [EX][CR] [CR] [CR][TAB] [TAB][CR] [TAB] Save Settings (Write into Flash ROM)

  • Page 12: Symbol Setup

    2. Symbol Setup 2.1 Common Setup ・All Symbologies To Enable or Disable to decode symbols for all symbolories, scan the appropriate symbol below. Note: To enable only a select number of symbologies, it is advised to disable all symbologies first and enable only the symbology type(s) needed.

  • Page 13: Center Reading Mode

    ・Center Reading Mode To Enable or Disable to read symbols located at the central part of the field of view only, scan the appropriate symbol below. Disable Center Reading (*) Enable Center Reading...

  • Page 14: Reading Digit Length

    ・Symbol Length To decode symbols with a specific length range for each symbology, this setting must be set through the serial command DIGIT=ab,c-d[CR] below. Command Format: DIGIT=ab,c-d[CR] a = code character A: Code39 C: Code128 d: DataMatrix e: Composite, RSS E: UPC/JAN/EAN F: Codabar G: Code93 I: ITF...

  • Page 15: Maximum Decodable Symbols Per Trigger Input

    ・Maximum decodable symbols per trigger input The image reader can decode multiple symbols (up to four symbols) in a single image with a single pull of the trigger. To set the maximum number of symbols to be decoded for a single trigger input, scan the appropriate symbol below.

  • Page 16: Set The Output Order For Multiple Symbol Reading

    ・Output order for multiple symbols reading To set the output order (transmitting data order) for multiple symbols reading, scan several symbols in the proper sequence below. Unless otherwise specified, if an error occurs during a scanning sequence, just re-scan the correct parameter. [Procedure] (1) Set the maximum number of symbols to be decoded for a single trigger input.

  • Page 17: Select The Output Number To Be Programmed

    ・Output sequence number to be programmed To set the output sequence number to be programmed, scan the appropriate symbol below. Output 1 Output 2 Output 3 Output 4 ・Select the item to be set To set the item to be set, scan the appropriate symbol below. Symbol length First character Second character...
  • Page 18 ・Addition of Symbology Identifier (AIM Code Identifiers) A Symbology Identifier specifies the type of symbology of a scanned symbol. If this function is enabled, Symbol Identifier is added before the decoded data. To Enable or Disable this function, scan the appropriate symbol below. <Symbol Information Character>...

  • Page 19: Additional Symbol Information (Optional Data)

    Additional Symbol Information (Optional Data) An optional single character (henceforth “Front Character”) corresponding to the type of symbology of the decoded symbol may be inserted before the decoded data. And similarly another optional character (henceforth “End Character”) may be inserted after the decoded data. [Procedure] (1) Enable or Disable to activate each Front Character and End Character setting respectively.
  • Page 20 Setup Front Character Setup Front Character for Codabar for ITF Setup Front Character Setup Front Character for PDF417 for MaxiCode Setup Front Character Setup Front Character for QR-Code for EAN128 Setup Front Character Setup Front Character for Code93 for GS1 Databar Setup Front Character Setup Front Character for Composite...

  • Page 21: Setup Add Optional Symbol Data At End

    Enable/Disable End Character To Enable or Disable End Character, scan the appropriate symbol below. Enable Disable End Character (*) End Character Setup Optional End character To enter Setup procedure of End character, scan the appropriate symbol below. Setup End Character Setup End Character for Code39 for Code128...
  • Page 22 Setup End Character Setup End Character for QR-Code for GS1-128 Setup End Character Setup End Character for GS1 Databar for Code93 Setup End Character Setup End Character for Composite for Customer Barcode(Japan Post Code) Setup End Character for AztecCode...

  • Page 23: Additional Function Of Optional Data For Prefix Or Suffix

    Additional Optional Single Data An optional single character (henceforth “Front Data”) regardless to the type of symbology of the decoded symbol may be inserted before the decoded data. And similarly another optional character (henceforth “End Data”) may be inserted after the decoded data. [Procedure] (1) Enable or Disable to activate each Front Data and End Data setting respectively.

  • Page 24: Setups Suffix Data

    Enable/Disable End Data To Enable or Disable End Data, scan the appropriate symbol below. Disable End Data (*) Enable End Data Enter Setup procedure of End Data To enter Setup procedure of End Data, scan the symbol below. Setup End Data Save Settings (Write into Flash ROM)

  • Page 25: Control Character

    ・Control Code A control code contained in a symbol may be changed to another form and then transmitted, i.e. the control code may be changed into the ASCII code enclosed in the parenthesis ( [ , ] ) and then transmitted. Example：[SX]1234[EX] ==>...

  • Page 26: Transform Optional Character From Gs Output

    Transmit Group Separator [FNC1] Group Separator [FNC1] may be substituted to another single character. This function is available for GS-128, GS1 Databar only. Default Setting Value：GS( 0x1D ) Setting Procedure is below to set this single character substituted for Group Separator [FNC1], [Procedure] The user has to follow the procedures in order otherwise the setup will be ignored.

  • Page 27: Character Code

    Character Code The Character Code is used to set the following functions: Set the Multiple symbols reading sort information Add Symbol Information Data Add optional data Transform optional character from GS Character Set UPPER DATA Note: Scanners set to use the HID interface cannot output the data in the gray section.

  • Page 28: Character Data

    Character Data To input Character Data first, scan the upper data symbol, followed by the lower data symbol. The same symbols can be used for both upper and lower data.
  • Page 29 Save Settings (Write into Flash ROM)

  • Page 30: Symbol Type

    ・Symbology Type To select the symbology types to dedode, scan the appropriate symbol below. Not specified (*) Code39 Code128 Codabar JAN/EAN/UPC PDF417 QR-Code DataMatrix MaxiCode...

  • Page 31: Confirm / Cancel Multiple Reading Setting

    GS1-128 Postal GS1 Databar Composite Code Code93 Aztec Code ・Confirm / Cancel multiple reading setting When setting of output order for multiple symbols reading is completed, scan the “Confirm” symbol to accept the changes or “Cancel” to revert back to the previous settings. Confirm Cancel Save Settings...

  • Page 32: Symbol Reading Setup

    2.2. Symbol Reading setup Code39 Code39 symbol reading Check Digit (C/D) verification: Modulus 43 To select the Code39 reading, scan the appropriate symbol below. Read Code39 Read Code39 No C/D check (*) Check C/D Transmit C/D Read Code39 Read Code39 Check C/D No C/D check No C/D transmission...

  • Page 33: Code39 Start / Stop Transmit

    ・Code39 Start / Stop Transmit To Enable or Disable the transmission of ST/SP characters at the head and the end of the read data, scan the appropriate symbol below. Transmit No transmission of Code39 ST/SP (*) Code39 ST/SP Code128 To Enable or Disable to decode Code128 symbol, scan the appropriate symbol below. Enable Code128 decoding (*) Disable Code128 decoding GS1-128(EAN128)

  • Page 34: Codabar Setup

    ・Codabar Setup Enable / Disable CODABAR symbol decoding, Check Digit verification and transmission. C/D Verification: Modulus 16 To select tCodabar reading, scan the appropriate symbol below. Read Codabar Read Codabar No C/D check (*) Check C/D Transmit C/D Read Codabar Disable Codabar decoding Check C/D No C/D Transmit...

  • Page 35: Codabar Start / Stop Transmission

    Codabar Start / Stop transmission To Enable or Disable the transmission of the Codabar ST/SP characters, scan the appropriate symbol below Transmit Codabar ST/SP (*) No Codabar ST/SP transmission ・ITF Setup Enables / Disables ITF (Interleaved 2 of 5) symbol decoding, Check Digit verification and transmission.

  • Page 36: Itf Digits Setup

    ・ITF Digits Setup Set the amount of accepted number of digits for ITF symbols. The number of digits includes C/D. To set up the number of digits for ITF symbols, scan the appropriate symbol below. 2 digits 4 digits 6 to 2047 digits (*) Code93 To Enable or Disable Code93 symbol for decoding, scan the appropriate symbol below.

  • Page 37: Setting The Application Identifier

    Setting the Application Identifier Output the Application Identifier of GS1-128 and GS1 Databar by enclosed in the parenthesis. Outputs without parentheses ( Output directly ) if there are any defects in decoding data format.. To set the Application Identifier outputting type, scan the appropriate symbol below. Output directly (*) Output with additional parentheses Example: 010498702825577917080400104ZA38M...

  • Page 38: Composite

    Composite To Enable or Disable Composite symbol for decoding, scan the appropriate symbol below. Disable Composite Symbol decoding (*) Enable Composite Symbol decoding ・JAN/EAN/UPC Setup To Enable or Disable JAN/EAN/UPC symbol for decoding, scan the appropriate symbol below. Enable JAN/EAN/UPC decoding (*) Disable JAN/EAN/UPC decoding JAN/EAN/UPC (Standard) Check Digit Transmission To select the JAN-13/EAN-13 (Standard) C/D transmission, scan the appropriate symbol below.

  • Page 39: Jan/Ean Shortened Check Digit Transmission

    JAN/EAN (Shortened) Check Digit Transmission To select the JAN-8/EAN-8 (Shortened) C/D transmission, scan the appropriate symbol below. JAN-8/EAN-8 (Shortened) JAN-8/EAN-8 (Shortened) Transmit C/D (*) No C/D transmission UPC-A Check Digit Transmission To select the UPC-A C/D transmission, scan the appropriate symbol below. UPC-A Transmit C/D (*) UPC-A Disable C/D Transmission UPC-E Check Digit Transmission...

  • Page 40: Upc-A Number System Transmission

    UPC-A Number System transmission To Enable or Disable UPC-A Number System transmission, scan the appropriate symbol below. Transmit UPC-A No transmission of UPC-A Number System (*) Number System UPC-E Number System Transmission To Enable or Disable UPC-E Number System transmission, scan the appropriate symbol below. Transmit UPC-E No transmission of UPC-E Number System (*)

  • Page 41: Upc-E Format Conversion

    UPC-E Format Conversion To Enable or Disable the conversion UPC-E codes to UPC-A format, scan the appropriate symbol below. Format Conversion No Format Conversion to UPC-A (*) UPC Output Digits To Enable or Disable the conversion of adding A zero(0) to the beginning of the data when UPC 12 digits symbol read , scan the appropriate symbol below.

  • Page 42: Datamatrix Setup

    ・DataMatrix Setup Enable / Disable DataMatrix decoding and set reading parameters. Supports ECC200 Symbology only. To select DataMatrix reading, scan the appropriate symbol below. Enable DataMatrix decoding Enable DataMatrix decoding Shape: Square Shape: Square Marking: Dark on Light (*) Marking: Light on Dark Enable DataMatrix decoding Shape: Square Marking: Dark on Light &...

  • Page 43: Datamatrix Cell Size

    DataMatrix Cell Size To select the reading cell size for Data Matrix codes, scan the appropriate symbol below. Normal Cell Size (*) Small Cell Size Smaller Cell Size Save Settings (Write into Flash ROM)

  • Page 44: Maxi Code Setup

    ・Maxi Code Setup Enable / Disable MaxiCode decoding and set the mode. To select Maxi Code reading, scan the appropriate symbol below. Enable MaxiCode decoding Enable MaxiCode decoding All Modes (*) Mode 0 Enable MaxiCode decoding Enable MaxiCode decoding Mode 1 Mode 2 Enable MaxiCode decoding Enable MaxiCode decoding...

  • Page 45: Transmission Of Primary

    Transmission of Primary To Enable or Disable the data transmission for decoding primary of Maxi Code (primary only), scan the appropriate symbol below. Enable primary transmission (*) Disable primary transmission PDF417 To Enable or Disable PDF417 symbol for decoding, scan the appropriate symbol below. Enable PDF417 decoding (*) Disable PDF417 decoding Save Settings...

  • Page 46: Qr Code Setup

    ・QR Code Setup Enable / Disable QR-Code decoding and set the marking type. To select QR Code reading, scan the appropriate symbol below. Enable QR Code decoding Enable QR Code decoding Marking: Dark on Light (*) Marking: Light on Dark Enable QR Code decoding Disable QR Code decoding Marking: Dark on Light &...

  • Page 47: Customer Barcode(Japan Post Code)

    Customer Barcode(Japan Post Code) To Enable or Disable Customer Barcode (Japan Post Code) symbol for decoding, scan the appropriate symbol below. Disable Customer Barcode (*) Enable Customer Barcode decoding To Enable or Disable the reading of incomplete Customer Barcode symbol, scan the appropriate symbol below.

  • Page 48: Aztec Code

    Aztec Code Enable / Disable Aztec Code decoding and set the marking type. To select Aztec Code reading, scan the appropriate symbol below. Enable Aztec Code decoding Enable Aztec Code decoding Marking: Dark on Light (*) Marking: Light on Dark Enable Aztec Code decoding Disable Aztec Code decoding Marking: Dark on Light and Light on Dark...

  • Page 49: Operational Setup

    3. Operational Setup General Operational Setup Writes Setup Values To save all current settings into the device’s non-volatile flash memory, scan the symbol below. Save Settings (Write Flash ROM) Restore factory default settings To return all settings to their default states, scan the symbol below. Restore Factory Default Settings...

  • Page 50: My Settings

    My Settings The scanner can register multiple separate configurations in non-volatile memory. This function should be utilized when multiple types of marking technologies needed to be read. Registration of My Setting To register the configuration into My setting, scan the appropriate symbol below. Register the configuration into My setting 1 Register the configuration into My Setting 2 Load registered My Settings...

  • Page 51: Buzzer Setup

    Buzzer setup To Enable or Disable the buzzer indicator, scan the appropriate symbol below. Enable Buzzer (*) Disable Buzzer Vibration To Enable or Disable the vibrator indicator, which indicates successful decoding, scan the appropriate symbol below. Enable Vibrator (*) Disable Vibrator Save Settings (Write into Flash ROM)

  • Page 52: Continuous Reading Interval Mode

    Continuous Reading Mode Do not trigger read while the reader is on continuous reading mode. Autosense mode should be disabled when using the continuous reading mode. Setting for Continuous Reading Mode To Enable or Disable Continuous Reading Mode, scan the appropriate symbol below. Enable Continuous Reading Mode Disable Continuous Reading Mode Save Settings...

  • Page 53: Continuous Reading Mode Interval

    Continuous Reading Mode Interval To set the interval time between successive scans in continuous reading mode, scan the appropriate symbol below. Interval: 0 s (*) Interval: 1 s Interval: 2 s Interval: 3 s Interval: 4 s Interval: 5 s Interval: 6 s Interval: 7 s Interval: 8 s...

  • Page 54: Prohibit Same Symbol Decoding In Continuous Reading Mode

    Prohibit Same Symbol decoding in Continuous Reading Mode To Enable or Disable reading of the same symbol when in continuous reading mode, scan the appropriate symbol below. Disable Same Symbol prohibition (*) Enable Same Symbol Prohibition Same Symbol prohibition duration in Continuous Reading Mode To set the Prohibit Duration time for same symbol reading in Continuous Reading Mode, scan the appropriate symbol below.

  • Page 55: Autosense Mode

    ・Autosense Mode To Enter or Escape Autosense mode, scan the appropriate symbol below. Note: Autosense mode is invalid while in Continuous Reading Mode. Continuous Reading Mode needs to be disabled before enabling Autosense mode. Enter Autosense Mode Escape Autosense Mode Save Settings (Write into Flash ROM)

  • Page 56: Autosense Mode Timeout

    Autosense Mode timeout To set the duration time limit (Time out ) to read symbol after detecting a label coming in, scan the appropriate symbol below. Time out: 1s Time out: 2s Time out: 3s (*) Time out: 4s Time out: 5s Time out: 6s Time out: 8s Time out: 10s...

  • Page 57: Decode Time Out

    Decode Time out When the scanner cannot decode the symbol within the limited time, it will stop decoding. This mode needs the setting of maximum timeout time . Increasing the setting time when the symbol data size is large and needs extra time to decode. Decreasing the setting time when the data size is small that takes shorter time to decode.

  • Page 58: Pointer In Autosense Mode

    Pointer in Autosense mode Enable / Disable the pointer while in Autosense mode. Note: The pointer will blink during decode, regardless of this setting,. To Enable or Disable the pointer blinking, scan the appropriate symbol below. Enable pointer (*) Disable Pointer Autosense sensitivity Set the sensitivity of Autosense mode.

  • Page 59: Prohibit Same Symbol Decoding In Auto Detection Mode

    Prohibit Same Symbol decoding in Auto Detection mode. To Enable or Disable Same Symbol prohibition in Auto Detection mode, scan the appropriate symbol below. Enable Same Symbol prohibition (*) Disable Same Symbol prohibition Same Symbol Prohibition duration in Auto Detection Mode To set the prohibited time for same symbol reading in Auto Detection mode, scan the appropriate symbol below.

  • Page 60: Cropping Image Area

    Cropping Image area Set the image cropping area. Note: Vertical 25% and horizontal 25% is an invalid setting, all other combinations are possible. To set the image cropping area size in Auto Detection mode, scan the appropriate symbol below for Horizontal size and Vertical size respectively.

  • Page 61: Quick Setting With Function Button

    This setting prevents the change of the mode of the operation when the operation mode is configured incorrectly. Note: Please refer to the operation manual of THIR-6780 series for quick setting 1 and 2. To set the function button, scan the appropriate symbol below.

  • Page 62: Setting Camera Control

    3.2 Setting Camera Control Enable/Disable AGC (auto gain control) of the internal-camera. “Enabled AGC”: the camera gain is adjusted automatically whenever scanner reads symbol. “Disabled AGC”: when the “Disable AGC” (below) is scanned, the camera gain is held at just its gain value. To Enable or Disable AGC, scan the appropriate symbol below.

  • Page 63: Preset Mode Setting

    Preset Mode setting The scanner has the function of Preset Mode function that is used for verification of the decoded data. The scanner compares the decoded data with the preset data (Registered data) and will output only if the data is matched regardless of its symbology type. Preset Mode has two modes, Preset Mode 1 and Preset Mode2.

  • Page 64: Preset Mode 2

    ・Preset Mode 2 This mode would registered the preset data by using the barcode menu or serial commands. Both for the perfect matching and partial matching are available on data verification. The preset data can be also stored into the non-volatile memory. To set Preset Mode 2, scan the symbol (Preset data 2 ) below and follow the procedure below.

  • Page 65: Setting For Digits

    Setting for Digits To decode symbols with a specific length range for each symbology, this setting must be set through the serial command DIGIT=ab,c-d[CR] below. To enable the partial match verification, transmit the serial command (SET=PRENa ) from the host computer.

  • Page 66: Example Of Preset Data

    Example of Preset data Example 1: Compare with preset "12345" and read data. Result example： 12345 Match 1234 NOT match 012345 NOT match ●Preset data by barcode menu Scan the adequate symbols in following sequence. 1) Scan the “Preset Mode 2” symbol. 2) Scan the “Set preset Data”...

  • Page 67: Transmitting Preset Status

    ●Preset barcode menu It is not capable to setup only barcode menu. ●Setup by Sending Command Send serial commands to the scanner from host computer as following sequence. 1) PREM=2[CR] 2) SET=PRED??ALFA????[CR] 3) SET=PREN10[CR] 4) WSETS[CR] Transmitting Preset Status Output the current preset setting status. To output the status, read the barcode menu of preset status transmission below.

  • Page 68: Diagnosis

    4. Diagnosis Output the Decode Time The actual time consumed during symbol decoding, (starting with the SYNC ON event), can be appended to the output data in the serial interface output. Added Decode Time NOT Added Decode Output Example 1912345678907(0238ms)[CR] Format <Header>•<read data><aaaa>ms•<Terminator>...

  • Page 69: Output Actual Reading Statistics

    Output Actual Reading Statistics A statistical report of actual reading quality based on decode time can be output through the serial interface. The report contains minimum, maximum and average times for OK reads and Bad reads, and also the total count of SYNC events, OK reads and Bad reads. The report covers the time period since the last read barcode menu of Clear Decode Time, Output Reads Count, or else since power ON.

  • Page 70: Output Actual Reading Statistics2

    ・Output Actual Reading Statistics2 The report of an actual reading which is based on the numbers of decodes attempts (shortest / longest / average decoding time and reading time can be output) after the power activation. The data will be erased when the scanner is turned off or when the bar code "Erase decoding time and reading time"...

  • Page 71: Output Of Bar Code Position Information

    ・Output of Bar Code Position Information Set the output for the position information of decoded symbol. a)Barycentric coordinates Output the central coordinate of the decoded symbol. The origin coordinate is the upper left (000,000) on the display. (Output example) 100000000990703(+312,+255) (Output format) <Header>•<read data>(abbb,accc)•<Terminator>...

  • Page 72: Reference 4 Coordinate Position Of Each Symbol

    Reference 4 Coordinate Position of Each Symbol 1 dimensional barcode 2 dimensional barcode MaxiCode QRCode PDF417 DataMatrix...

  • Page 73: C) Output Of Both Geometrical Center And 4 Corner Coordinates

    c) Output of Both Geometrical Center and 4 Corner Coordinates Data of the geometrical center coordinates and 4 corner coordinates are both output to the serial interface with the read data. The origin coordinate is the upper left (000,000) on the display. (Output example) 100000000990703(+140,+326)(+269,+011)(+455,+086)(+386,+270)(+198,+199) Format...

  • Page 74: Setting Reference

    5. Setting Reference Output the current setting of the reader (status). ・Status1 Save Settings (Write into Flash ROM) Transmit Status 1 (Output example) ******** STATUS ******** THIR-XXXX SHUTT=1 (0:1/60 1:1/125 2:1/250 3:1/500 4:1/1000) (5:1/2000 6:1/4000 7:1/6000 8:1/8000) GCV=6 (1-11) AGC_ENABLE:1 (0:disable 1:enable) LIGHT=1 (0,2:OFF 1,3:ON) LABELTX=0 (0:through 1:[HEX]) ILLUM=1 (0:OFF 1:IN 2:EX 3:BOTH 4:LEAVE EX ON) SYMBOLTX=0 (0:only data 1:add symbol information to data)
  • Page 75 SYMBOLTX= Prefixed Symbol Information 0: Not Add Prefix Symbol Information 1: Add Prefix Symbol Information keep decoding: Continuous Reading Mode 0 Dark on Light Mode 1 Continuous Reading Mode contintvl= Continuous Reading Interval Mode (Second) 0 - 9 : ０Second－９Second １Second GOUTMODE=_ Image Output Mode...

  • Page 76: Status 2

    ・Status 2 Save Settings (Write into Flash ROM) Transmit Status 2 Output Example ******** STATUS ******** THIR-XXXX RSCS=0 (0: OFF 1: ON) C39SS=0 (0: not trans. 1: trans.) CODASS=1 (0: not trans. 1: trans.) CODACS=1 (0: small 1: capital) SEPA=2 (0:non 1:&...
  • Page 77 CODACS= Codabar ST/SP Character 0:Lower Case Letter 1:Upper Case Letter SEPA=_ Separator Setting UPCTX=_ Output Digits of UPC Code 0:12 digits 1:13 digits E128GS=_ Transmit Control Character [GS] 0:Not Transmit 1:Transmit mode Reading Mode Reading Minimum Digits (1-2047) Reading Maximum Digits (1-2047) start Start Edit Digits (1-2047) length...
  • Page 78 DataMatrix: Read DataMatrix (mode) 0 Disable 1 Read, Square, Dark on Light label 2 Read, Square, Light on Dark label 3 Read, Square, Dark on Light & Light on Dark label 5 Read, Square & Rectangle, Dark on Light label 6 Read, Square &...
  • Page 79 EAN128: Read GS1-128 (mode) 0: Disable 1: Read RSS: Read GS1 Databar (mode) 0: Disable 1: Read Code93: Read Code93 (mode) 0: Disable 1: Read Composite: Read Composite (mode) 0: Disable 1: Read AztecCode: Read AztecCode (mode) 0: Disable 1 Read, Dark on Light label 2 Read, Light on Dark label 3 Read, Dark on Light &...

  • Page 80: Status 3

    ・Status 3 Save Settings (Write into Flash ROM) Transmit status 3 Output Example ******** STATUS ******** THIR-XXXX LABELS=1 (1-4:labels) OUTFORM=0 (0:no check 1:digit 2:chara 3:symbol) CheckNo. digit chara1 chara2 symbol check[1] : check[2] : check[3] : check[4] : XYTX=0 (0:non 1:add(x,y)) TXWAIT=1000 (1000-2500,step10) ********* END ********** THIR-XXXX Description of Status 3...

  • Page 81: Status 4

    ・Status 4 Save Settings (Write into Flash ROM) Transmit status 4 (Output example) ******** STATUS ******** THIR-XXXX ILLUMINT=50,70 ( 0-80, 0-100 ) FNCBTN=1 ( 0:disable(all) 1:enable(switch) 2:enable(all) ) SENDCHAR=¥0D ( ¥00~¥FF ) SENDIMG=1 ( 1:Full 2:1/2 3:1/4 4:1/8 ) MODE=0 0:normal 1:image-out DECODELIM=1000 100-10000 step10 DTTX=0 0:non 1:add(****ms) MIRROR=0 0:normal 1:mirror...
  • Page 82 SENDCHAR= Output data when the function button is pressed (Available only when the function button is set to the character string output) ¥0D ( ¥00~¥FF ) *up to 2 characters are settable. (Example: ¥0D¥OA) SENDIMG=_ Output image size when the function button is pressed (Available only when the function button is set to the image output) 1: Full 2: 1/2...
  • Page 83 DMSIZE= Cell size of DataMatrix 0: Default cell size 1: Small cell size 2: Smaller cell size VERIFY= Prohibition of continuous reading same symbol 0: Normal Continuous Reading 1: Prohibit continuous reading same symbol VWAIT= Prohibition duration of continuous reading same symbol 1.5secs Values between 1～20(0.5 sec～10 sec) GRVAREA= Center reading mode 0: Disable...

  • Page 84: Status Img

    ・Status IMG Check the reading area cropping status. Save Settings (Write into Flash ROM) Transmit status IMG (Output example) ******** STATUS ******** THIR-XXXX IMODE=0 PX=0 PY=0 WX=752 WY=480 CAPX=0 ( 0:100%, 1:75%, 2:50%, 3:25% ) CAPY=0 ( 0:100%, 1:75%, 2:50%, 3:25% ) IMGSEL=1 ( 0:captured image 1:decoded image ) ********* END ********** THIR-XXXX (Description of status IMG)

  • Page 85: Image Area Definition

    Image Area Definition The origin point is located on the upper left of the image when the image transmitting area is specified. Origin Point (0,0) (PX,PY)

  • Page 86: Status "Lf

    ・Status “LF” Save Settings (Write into Flash ROM) Transmit status LF (Output example) ******** STATUS ******** THIR-XXXX LFMODE=0 (0:OFF 1:ON) LFMOVELIM=2 (0:1000ms 1:2000ms 2:3000ms 3:4000ms 4:5000ms 5:6000ms 6:8000ms 7:10000ms) LFDECLIM=2(x500mS 1-20 ) LFPOINTER=1 (0:OFF 1:ON) VSENS=2 (0-4) LFVERIFY=1 (0:OFF 1:ON) LFVWAIT=6(x500mS 1-20 ) LFINTVL=0 (0-5000ms) ********* END ********** THIR-XXXX (Description of status LF)

  • Page 87: Setting For Hid Type Only

    6. Setting for HID Type Only Setting of special function for HID type (Human Interface Device), describe at below. Data Transmission Interval Setting for data transmission interval time (Note) -Reactivate the scanner after reading “Save the Setting” barcode to reflect the setting of the data transmission interval time.

  • Page 88: Keyboard Selection

    Keyboard Selection 1) Select Japanese or English keyboard from the bar code below and save the setting. 2) Reactivate the scanner to reflect the setting. Select Japanese Keyboard Select English Keyboard ・Caps Lock Setting Sets Caps lock convert. Capslock OFF Capslock ON Capslock AUTO Output example)

  • Page 89: Setting For Uppercase/Lowercase Conversion

    ・Setting for Uppercase/Lowercase Conversion Converted alphabets can be output if there are alphabets in the output data. No conversion Uppercase conversion Lowercase conversion Uppercase/lowercase conversion Output example) Output data：AaBbCc Setting Result Scanner Setting Output No Conversion AaBbCc Uppercase Conversion AABBCC Lowercase Conversion aabbcc Uppercase/Lowercase...

  • Page 90: Hid Status

    ・HID Status Display the HID status information. Save Setting Transmit HID Status (Write Flash ROM) (Output example) ******** STATUS ******** THIR-XXXX HIDDELAY=1 (0:0ms 1:10ms 2:20ms 3:30ms 4:3ms 5:5ms 6:7ms) HIDKEYTYPE=0 (0:JIS 1:ISO) HIDCAPS=0 (0:OFF 1:ON 2:AUTO) STRCONV=0 (0:OFF 1:UPPER 2:LOWER 3:EXCHANGE) ********* END ********** THIR-XXXX (Description of Status HID) HIDDELAY= Data transmitting interval (ms)

  • Page 91: Usb Device Type

    7. USB Device Type This function switches the type of USB device when connected to a Windows computer. Available interface types: -USB Virtual COM (VCOM) Image Reader -Human Interface Device (HID) Image Reader [How to switch between device types] -Settings for both of reader and computer is necessary. 1) How to switch VCOM type into HID type How to change reader setting 1.

  • Page 92: Initiate Usb Interface Type Switch

    Initiate USB interface type switch Enable Switching Select interface type VCOM Image Reader HID Image Reader Save Settings Save Settings...
  • Page 93 ［Memorandum］...
  • Page 94 ［Memorandum］...
  • Page 95 ［Memorandum］...
