Made by NARVI Oy Finland
Aito AK-47 / AK-57 / AK-57K
GB
Installation, use and service instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AK-47 and is the answer not in the manual?

Questions and answers

Summary of Contents for Aito AK-47

  • Page 1 Made by NARVI Oy Finland Aito AK-47 / AK-57 / AK-57K Installation, use and service instructions...
  • Page 2: Table Of Contents

    Heating Cleaning and maintenance General cleaning Replacement of sauna heater stones Soot fire Warranty Lay-out scheme of AK-47 Lay-out scheme AK-57 and AK-57K Stone sets AK-47 Kerkes ceramic stones AK-57 Kerkes ceramic stones AK-57K Kerkes ceramic stones Olivine stone sets...
  • Page 3: General Information

    Aito AK-47 / AK-57 / AK-57K Thank you for having chosen our heat storing Aito sauna heater. To make the most of your sauna heater please read the manual carefully before you start installing and using it. 1.1 General information Aito sauna heater is the traditional heat storing sauna heater, which lets you enjoy steam in its truest form.
  • Page 4: Sauna Heater Stones

    1.3 Sauna heater stones The sauna heater is delivered with extremely durable ce- AK-47 / AK-57 / AK-57K ramic sauna heater stones, which reduce the time of heat- ing and also the firewood consumption is half less than...
  • Page 5: Installation

    A. Install the raising element (includes ready-installed insulation and a stainless steel inner layer). Only for model AK-57K. When assembling a sauna heater AK-47 or AK-57, skip this part and continue with the next step. A. Place the ash drawer A.
  • Page 6: Top Cover

    2.5 Top cover Do not complete the first layer fully before the first heating. During heating add stones in places that start glowing first. The first layer functions as an adjustment layer. To reduce excessive draught add stones in the first layer. The amount of stones is sufficient when some are left over.
  • Page 7: Masonry Connection And Flue Connection

    B. Connect the connective flue with the sauna heater with the tightening bracket. A connective flue delivered with Aito sauna heater can also be provided with enamel-lined extension pipes. Extensions: 400 mm, 600 mm or 1000 mm. Yrittäjäntie 14, FI-27230 Lapland • Phone: +358 0207 416 740 • Fax: +358 0207 416 743 • www.narvi.fi...
  • Page 8: Heating

    To prevent soot The sauna heater is ready for the bathing procedure when problems, AITO sauna heater should always be heated so the first “löyly” has been thrown, the opening pan and the hot that the lower halves of the upper stones glow red.
  • Page 9: Cleaning And Maintenance

    Removal of ash after each heating improves burning ef- ficiency and prolongs the life-time of the grate. Pursuant to consumer protection legislation Aito sauna For easy maintenance of the enamel-lined sauna heater heaters’ warranty period is one year.
  • Page 10: Lay-Out Scheme Of

    2210-393 Rockwool panel (between the covers) Cast iron cover 2210-746 2210-387 Stone set AK-47, 90 kg 5524 Small tetra-stones (black case) Top cover 60 mm balls (white box) (includes insulation wool protected 80 mm balls (white box) with a stainless steel inner layer)
  • Page 11: Lay-Out Scheme Ak-57 And Ak-57K

    8. Lay-out scheme Masonry connection 2210-394 AK-57 and AK-57K Connective flue 60°, enamel-lined 5334 AK-57 and AK-57K are generally the same, except the fact that model 57K is equipped with a raising element installed Tightening bracket 2210-395 between the bottom and top cover. Fastening 2210-391 Valve at the fastening Steam hatch 2220-224...
  • Page 12: Stone Sets

    9. Stone sets 9.1 AK-47 Kerkes ceramic stones 9.2 AK-57 Kerkes ceramic stones Stone Package sauna Stone Package sauna heater heater 1 x 20 kg, white Ball 100 mm 10 kg case 10 kg Ball 100 mm 20 kg Ball 80 mm...
