Summary of Contents for Observer AWSC35
- Page 1 Wireless Outdoor Security Camera ACCESSORY Compatible with ALC AWS3155 and AWS3266 Video Surveillance Systems Model AWSC35 User Guide Please read these instructions completely Wireless Made Simple. before operating this product.
-
Page 3: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..............2 INTRODUCTION......................5 System Contents .......................5 Getting to Know Your Camera ...................6 INSTALLATION ......................7 Installation Tips ......................7 Night Vision ........................7 Installing the Camera(s) ....................8 Camera Pairing ......................10 Turning the Camera On or Off ..................12 Additional Features ....................12 MAINTENANCE ...................... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS PRODUCT SAFETY: When used in the directed manner, this unit has been designed and manufactured to ensure your personal safety. Improper use of this product can result in potential electrical shock or fire hazards. Please read all safety and operating instructions carefully before installation and use, and keep these instructions handy for future reference. - Page 5 IMPORTANT SAFETY INSTRUCTIONS Recycling and Disposal Information: • Do not dispose of electronic devices or any of their components in your municipal trash collection. • Consult your local waste management authority or a recycling organization like Earth911.com to find an electronics recycling facility in your area. WARNING: STRANGULATION HAZARD: Infants have STRANGLED in power cords.
- Page 6 IMPORTANT SAFETY INSTRUCTIONS Ventilation - Slots and openings in the case are provided for ventilation to ensure reliable operation of the product and to protect it from overheating. These openings must not be blocked or covered. The openings should never be blocked by placing the video equipment on a bed, sofa, rug, or other similar surface.
-
Page 7: Introduction
Antenna Camera Bracket Wireless Outdoor Security Camera ACCESSORY Compatible with ALC AWS3155 Video Surveillance System Model AWSC35 Quick Start Guide Please read these instructions completely Wireless Made Simple. before operating this product. AC Adapter Extension Cable Quick Start Guide x 1... -
Page 8: Getting To Know Your Camera
INTRODUCTION Getting to Know Your Camera FRONT Mounting Socket Cover Mounting Socket Power Status Link Status REAR Antenna Connector Power Pigtail — 6 —... -
Page 9: Installation
INSTALLATION Installation Tips WARNING: Weatherproof, IP66 rated cameras are suitable for outdoor installation. However, if possible, it is recommended to install in a location that provides some shelter from the elements, such as beneath roof eaves. • Before you install the camera, plan where and how it will be positioned, and where you will route the cable that connects the camera to the power adapter. -
Page 10: Installing The Camera(S)
INSTALLATION Installing the Camera(s) If not mounting, but just using on a flat surface (desk, table, etc.), skip to step 4. Secure the multi-position camera bracket to a stable surface, ceiling or wall using the three screws. If needed, three anchors are also included. - Page 11 INSTALLATION Installing the Camera(s) Screw Antenna clockwise into rear of camera. Connect one end of an AC adapter to the camera’s power pigtail and plug the other end of the adapter to a 120 volt AC (standard indoor) power outlet. TIP: A 6 foot power extension cable is included for your camera setup if needed.
-
Page 12: Camera Pairing
INSTALLATION Camera Pairing When you add a new camera to your system, you have to “introduce” the camera and monitor to each other so they can communicate. Tap the Pop-Up Menu tab to access the Menu options. Motion Tap the icon to enter the status SCAN... - Page 13 INSTALLATION Camera Pairing Follow steps 1 through 3 on the previous page to access the System Setup. Tap Camera Setup to access the Camera Setup screen. Tap Pairing. Tap the camera image you want to pair. A processing icon displays for a 60 second countdown.
-
Page 14: Turning The Camera On Or Off
INSTALLATION Turning the Camera On or Off After adding a camera, it will automatically be active (On) in this setting. To turn the camera on or off, perform the following: Follow steps 1 through 3 on page 10 to access the System Setup. Tap Camera Setup to access the Camera Setup screen. -
Page 15: Maintenance
Upgrading the Firmware The latest firmware and how to install the firmware will be available under the Observer category on our support page at www.ALCWireless.com/support/. -
Page 16: Troubleshooting
TROUBLESHOOTING If you have any trouble with your system, try these simple steps which should handle most common issues. Problem Possible Solution Screen lock may be on. Tap the Power button to unlock the screen. Make sure the camera’s power is on. Make sure the monitor has enough charge / connect it to No Image. - Page 17 TROUBLESHOOTING Problem Possible Solution Screen lock may be activated, tap the power button to Live screen has no icons. unlock the screen. Turn off the monitor and restart. If power button does not System has locked up. respond, use a pin to press the reset button located on the side of the monitor.
-
Page 18: Product Specifications
PRODUCT SPECIFICATIONS Camera Communication Range ............500 ft (164 yards) in open space Camera Resolution Single Camera ................480 x 272 Camera Resolution Multiple Camera ................. 320 x 240 Operating Temperature ...............14°F ~ 122°F (-10°C ~ 50°C) Operating Voltage ....................DC 5V, 1A Current Consumption .................. -
Page 19: Warranty
WARRANTY One-Year Limited Warranty Important: Evidence of original purchase is required for warranty service. Atoms Labs LLC (“ALC”) ELEMENTS OF WARRANTY: ALC warrants, if properly installed and used thereafter in strict accordance with the use and care guidelines provided in the instructions manual, the Product shall be free from manufacturing defects in material and workmanship for one (1) year from the documented date of purchase. - Page 20 WARRANTY ONE-YEAR LIMITED WARRANTY IMPORTANT: Evidence of original purchase is required for warranty service. LEGAL REMEDIES: This limited warranty gives you specific legal rights, and you may also have other WARRANTOR: Atoms Labs LLC (“ALC”) ELEMENTS OF WARRANTY: The ALC warranty covers the product for one (1) year rights which vary from state to state.
- Page 21 Wireless Made Simple. ALCWireless.com 020116_v1.0...
- Page 22 Wireless Made Simple. ALCWireless.com...
