Summary of Contents for Phyhome FHL104C

  • Page 1: User Manual

    FHL104C User Manual www.phyhome.com FHL104C EPON OLT User Manual...

  • Page 2: Preface

    MAC address table, QoS, ACL, IGMP, performance, alarm and pipe network module command. About this Document FHL104C EPON OLT User Manual mainly introduces the product description, positioning, installation, operation, specific functional characteristics and configuration method, product use matters needing attention in the process of etc.. It suits for product technical support personnel and people who use the product .

  • Page 3: Conventions

    FHL104C User Manual www.phyhome.com Conventions The following symbol format and keyboard combination may be found in this document, they are defined as follows: Format Conventions Format Meaning Command key words Remain unchanged in the command have to Bold input completely...
  • Page 4 Instructions: Provides additional information to emphasize or supplement important points of the main text. Noun convention Here means FHL104C System,including switches and other devices connected on the link port, the main exchange processing module. Here means PON Protocol Processing module and PON port.

  • Page 5: Abbreviations

    FHL104C User Manual www.phyhome.com Abbreviations Access Control List Call Detail Record CVLAN Customer VLAN Destination Address Dynamic Bandwidth Allocation EPON Ethernet Passive Optical Network Forward Error Correction IGMP Internet Group Management Protocol LLID Logical Link Identifier Line Process Unit Medium Access Control...

  • Page 6: Table Of Contents

    FHL104C User Manual www.phyhome.com Contents Preface ..............................2 Related Documentation....................... 2 About this Document........................2 Conventions ..........................3 Abbreviations ..........................5 1. Description ............................9 1.1Product description......................... 9 1.1.1 Product positioning..................... 9 1.1.2 Product features ......................9 1.1.3 Structure features ..................... 10 1.1.4 Index parameter......................
  • Page 7 FHL104C User Manual www.phyhome.com 4.2.7 ONT remote restart ....................32 4.2.8 ONT multicast configuration..................32 4.2.9 Encryption and FEC switches................. 32 5.QINQ service description and configuration................. 33 5.1QinQ service Introduction ....................33 5.2QinQ service configuration ....................33 6. Multicast service introduction and configuration ............... 35 6.1 Multicast service introduction.....................
  • Page 8 FHL104C User Manual www.phyhome.com 13.1 User add ..........................44 13.2 User query .......................... 44 13.3 User delete ......................... 44 14. System upgrade and backup....................44 14.1 Introduction to system upgrade ..................44 14.2 System upgrade......................... 45 14.2.1 Environmental construction .................. 45 14.2.2 Software upgrade ....................

  • Page 9: Description

    GEPON port and four Cu / light combo uplink port, with a total access to 256 ONU.FHL104C follow IEEE 802.3 standards, by reference to the requirements to achieve the China Telecom EPON Technology and support 1GEPON access business, and Shenzhen City PHYHOME Electronics Co., Ltd.

  • Page 10: Structure Features

    1.1.3 Structure features 1U standard case, the size of the 440mm (W) 44mm x (H) x 170 (D) FHL104C Front Panel View Figure 2-2 The components and functions of the front panel are described as follows: (1) RST: Restart button...

  • Page 11: Index Parameter

    FHL104C User Manual www.phyhome.com providing the service.Access can automatically adapt to the direct network cable and cross network cable. (9) SFP1-SFP4:1000BASE-LX/SX Ethernet optical interface, supports 1.25Gbps single mode and multi-mode SFP optical module. State Explain Power System state normal operation condition...
  • Page 12 FHL104C User Manual www.phyhome.com item Description atmos 86 to 106 kpa Dust particle size Diameter>5μm, <3*104pcs/m3 Refrigerati Left fixed 2 fans, right into the wind, the left side of the wind Heat dissipation noise Electromagnetic compatibility GB 9254-1998 Class A...

  • Page 13: Typical Networking

    FHL104C User Manual www.phyhome.com item Description Received optical power -28 to –6dBm @BER<1×10-12 Please refer to "LED display Other I/F specifications" 1.1.5 Typical networking Typical multi service access network: High-rise buildings, the number of single building users around 200: Low density cell:...
  • Page 14 FHL104C User Manual www.phyhome.com Radio and television EPON+ EOC Safe city...
  • Page 15 FHL104C User Manual www.phyhome.com Village Project Smart home...

  • Page 16: Functiona Description

    FHL104C User Manual www.phyhome.com 1.2 functional description 1.2.1GEPON access function  EPON standard Fully comply with IEEE802.3ah standards, fully compatible with China Telecom EPON equipment technical requirements V3.0.  Maximum spectral ratio 1: 64.  Bandwidth setting Through the SLA setting, the bandwidth of the ONU can be configured (which can be configured with a minimum guaranteed bandwidth and maximum effort bandwidth).

  • Page 17: Data Service And Forwarding

    FHL104C User Manual www.phyhome.com its port (port isolation and port loop back detection, etc.).  ONU isolation By default, the ONU is physically isolated. After the P2P mode is turned on, the ONU can communicate with each other in the same PON port.

  • Page 18: Management And Maintenance

    FHL104C User Manual www.phyhome.com bandwidth and priority three parameters. An LLID of the same priority through the historical traffic statistics to ensure that service fairness and the QoS of the network through the guaranteed bandwidth to achieve.  Priority control (QOS) The device supports IEEE802.lp agreement marks priorities to achieve the priority...

  • Page 19: Installation And Landing

    9600 , data bits 8 bits, no parity , stop bit is 1, without the flow control . Connected to equipment, terminal will be as output: ************************************************************* * PHYHOME Software Platform (version 1.11) * Copyright 2010-2015 FH-NET OPTOELECTONIC LTD. *...

  • Page 20: Local Login Via Telnet

    OLT. 2.2.3 Remote login via Telnet FHL104C support with the management of the channel, you can let the host to manage through the OLT upstream port . The OLT device is equipped with no IP, which needs to be manually configured within the IP.

  • Page 21: Management Of Olt Through Network Management Software

    3 Command line interface and view 3.1 Command line interface FHL104C OLT equipment provides a series of configuration commands and command line interfaces to the user to configure and manage the EPON system:  Command hierarchical protection, to ensure that the user is not authorized to invade FHL104C.

  • Page 22: Command Line View

    FHL104C User Manual www.phyhome.com The user of the login system is divided into 2 levels, respectively, with the command level, the access level of the user can use the access level commands, privileged users can use all the commands. 3.3 Command line view Each command line view is based on different configuration requirements, there are connections and differences between them.

  • Page 23: Command Line Feature

    FHL104C User Manual www.phyhome.com exit button to exit config view, enter end retreat to view . Host (config) # interface pon 1/1 Host(config-pon-1/1)# Host(config-pon-1/1)## exit  Entry / exit onu view: in the config view input int onu slotid/portid:branchid (slotid/portid:branchid:1/<1-4>: <1-64>) can enter the onu view to configure the ONU;...
  • Page 24 FHL104C User Manual www.phyhome.com the device configuration. 3.4.1.1 Complete help 1) In any view, type <? >, the user terminal screen displays all the commands and their simple descriptions of the view. Host (config-vlan-2) # Clear screen description Vlan description...

  • Page 25: Command Line History Command

    FHL104C User Manual www.phyhome.com screen, which lists all the commands at the beginning of the string. Host (config) # in inband Inband interface interface Enter ethernet configuration mode 2) Type a command, and then a string is followed by <?>the user's terminal screen, which lists all the key words in the beginning of the string.

  • Page 26: Command Line Editing Features

    FHL104C User Manual www.phyhome.com All the commands the user type in , if it pass the syntax check , it will be executed correctly , or report the error message to the user, and the common error message is shown in table 3-2.

  • Page 27: Pon Service Description And Configuration

    . Authorization is refers to the standard definition, through what way to uniquely identify a ont and distribution ONUID.FHL104C support for MAC address, logic ID , MAC address + logical ID three authorization. Authorization policy mainly authorized manually and automatically authorize.

  • Page 28: Pon Configuration

    DBA template is a service bandwidth template, which is based on the ONT configuration of a class template. The QINQ template is a service template for FHL104C, which defines the VLAN, priorities, and ETH types of service flows. 4.2 PON configuration 4.2.1 Global parameter configuration...

  • Page 29: Service Template Configuration

    FHL104C User Manual www.phyhome.com authorization.  View configuration results: Config mode, enter the command Host(config)# show authorize-mode Host(config)# show authorize-policy all To view the status of the authorization mode and authorization policy. 4.2.2 service template configuration The system supports 100 DBA templates, each template is identified by the...

  • Page 30: Vlan Configuration

    FHL104C User Manual www.phyhome.com If the rule is the same as the operating rules, the rule will cover the previously configured rule. If you need to remove the template, type no qinq-profile or no dba-profile. 4.2.3 VLAN Configuration  OLT VLAN configuration VLAN configuration contains create, delete and ETH port VLAN add, delete.

  • Page 31: Ont Binding Template

    FHL104C User Manual www.phyhome.com 00:15:20:88:89:90 -------------ONT authorization The lifting of the authorization operation also means that ONT will be removed, the ONT's resources will be released, and the service will be interrupted. Host (config-pon-1/1) #no authorize-onu auth-id 1 ---------- lift ONT authorization 4.2.5 ONT binding template...

  • Page 32: Ont Remote Restart

    FHL104C User Manual www.phyhome.com ONT Ethernet port VLAN configuration support configuration VLAN mode and VLANID. VLAN mode is commonly used in TAG mode and TRUNK mode. Host(config-onu-1/1:1)#ethernet-port 1 vlan-mode tag Host(config-onu-1/1:1)#ethernet-port vlan-tag ------vlan tag model Host(config-onu-1/1:1)#ethernet-port 2 vlan-trunk -------vlan trunk model Host(config-onu-1/1:1)#ethernet-port 2 vlan-trunk vid 20 4.2.7 ONT remote restart...

  • Page 33: Qinq Service Description And Configuration

    5.1QinQ service Introduction FHL104C use service templates to define the service model, namely QinQ profile. In QinQ template can create up to 32 rule, each rule defines a service model. Such as VLAN transparent transmission, VLAN switch, and a VLAN tag add is QinQ business.
  • Page 34 FHL104C User Manual www.phyhome.com Host(qinq-profile-10)#profile-name qinq Host(qinq-profile-10)#rule 1 add-svlan 200 cvlan 100 ------inlayer vlan 100,outlayer vlan 200 Host(config)# interface pon 1/1 Host(config-pon-1/1)#bind qinq-profile qinq -------PON port bind QINQ template When the QINQ template rule is created, it can be added to the outer VLAN.

  • Page 35: Multicast Service Introduction And Configuration

    6.1 Multicast service introduction Multicast is a communication to multiple recipients simultaneously to transmit data, now widely used in IP video on demand service .FHL104C achieve the basic multicast service functions, including IGMP V2, IGMP Snooping, IGMP proxy, and VLAN-based Multicast.

  • Page 36: Multicast Configuration

    - added program, the system will automatically send report packets, the program flow to the OLT upstream. FHL104C currently only supports V1 IGMP and IGMPV2, for the time being not processed V3 IGMP packets. It does not support the multicast version number of the configuration system.

  • Page 37: Upstream Port Configuration

    7. Upstream port configuration 7.1Upstream port mode FHL104C uplink port for 4*1GE combo interface. The same port number of Ethernet and SFP optical interface cannot use at the same time . Considering the FHL104C product positioning and uplink port currently does not implement adaptive function.

  • Page 38: Olt Storm Suppression

    Multicasting refers to the destination MAC address of the first byte of the lowest 1 message, the access layer equipment common multicast message multicast packets and STP protocol, routing protocol message.FHL104C can detect such message and according to the configuration inhibition, to save bandwidth, network protection role.

  • Page 39: Unknown Unicast Suppression

    1 and MAC address is not all f or 0 message. For unicast packets, FHL104C will lookup 2 layer forwarding table according to the message of MAC address, if we can find the out port, normal packet forward to the other side, if you can't find out port, it is identified as unknown unicast.

  • Page 40: Ont Distal Batch Upgrade Configuration

    FHL104C User Manual www.phyhome.com batch update version of ONT. Batch remote upgrade can solve the maintenance costs, improve the maintenance efficiency. Batch upgrading function is realized according to the CTC criteria, for the loader to OLT and OLT loading to ONT , and program activated three step.ONT program...

  • Page 41: Ont Program Loading

    FHL104C User Manual www.phyhome.com the program need to upgrade should be put in the corresponding directory. 9.2.2 ONT program loading Execute the ONT program in the config mode: Host(config)# ftp download A.B.C.D Remote ftp server ip address ------------server IP address...

  • Page 42: View Bulk Upgrade Status

    FHL104C User Manual www.phyhome.com upgrade. Host(config)# active onu 1/1:all After the activation of the ONT program, ONT will automatically restart from the new software. 9.2.3 View bulk upgrade status At each stage of the ONT upgrade process can be viewed by the following...

  • Page 43: Alarm And Statistics

    FHL104C User Manual www.phyhome.com 12. Alarm and statistics 12.1 Alarm configuration and query In the config mode, enter the alarm to enter alarm mode. This mode support alarm configuration of open, shut off the switch, support adjustment of the alarm level, support configuration trap report switch, alarm history query support.

  • Page 44: User Management

    13. user management 13.1 User add Users of FHL104C are divided into the root, admin and guest, root own all authority, admin hold operator management authority, guest can only query, may not modify. System has three user default, root/root admin / admin. guest/guest.

  • Page 45: System Upgrade

    FHL104C User Manual www.phyhome.com password are correct, the target file existence. all the file types the specific details can be upgraded of FHL104C OLT devices are as follows: OS file: FHL104C program file, which contains the main control unit module and service control module.

  • Page 46: Software Upgrade

    FHL104C User Manual www.phyhome.com User name" enter a user name, according to the requirements of users; "home " directory" to upgrade version stored in the directory, the "change password" password, with the user need. Then click "done". To this FTP server set up to complete.

  • Page 47: Configuration File Backup And Load

    14.3 Configuration file backup and load 14.3.1 Configuration file backup FHL104C configuration divided into start and run configurations two. Boot configuration is also called system startup when loading the configuration file, file name is startup.cfg, run configuration, is after the successful launch of the system,...

  • Page 48: Load Profile

    FHL104C User Manual www.phyhome.com configuration. OLT before the host is normal. Host(config)# ftp upload 192.168.1.100 test test startup.cfg 14.3.2Load profile After the backup configuration file, users can edit the configuration file , save, and then reload it to the device. Loading a configuration file to the OLT and need to perform upgrade command to ensure that the configuration file at the next reboot to work , and then restart the system.

  • Page 49: Snmp Configuration

    Please use this operation carefully in the current use. 15.SNMP configuration FHL104C provides MIB interface, can be through the NMS equipment management and maintenance. Before the OLT is managed by the gateway, the SNMP parameters are required to be configured on the OLT.
