Summary of Contents for Marquis M G 1 9 3 2
- Page 1 MARQUIS GALAXY SERIES M G 1 9 3 2 M G 1 9 1 8 S M G 1 9 1 5 M M G 1 9 2 8 U s e r ’ s G u i d e...
-
Page 3: Important Safety Instructions
CONTENTS MG1932 MG1932 Specifications MG1928 MG1928 Specifications MG1918S MG1918S Specifications MG1915S MG1915S Specifications MG1915M MG1915M Specifications i l p MG-AF MG-SMAF IMPORTANT SAFETY INSTRUCTIONS The MG Series loudspeakers covered by this manual are not intended for fixed installation in outdoor or high moisture environments. - Page 4 Integral rigging hardware, a dual angle pole socket and an accessory array frame provide for a variety of mounting and suspension options. DIMENSIONAL DRAWINGS FOR MG1932 MARQUIS GALAXY Transducer Technology U.S. PATENT 5,748,760 Single...
-
Page 5: Specifications
SPECIFICATIONS MG1932 - 12”, TWO-WAY, LINE ARRAY LOUDSPEAKER SYSTEM " 2 n i l Frequency Range (-10 dB) 57 Hz - 20 kHz Frequency Response (±3 dB) 75 Hz - 20 kHz 0° 5° c i t y l l c t i Crossover Frequency: 1.2 kHz... - Page 6 INTRODUCTION TO THE MG1928 The MG1928 - the smaller version of the MG1932 is a light-weight, compact, 8”, two-way line-array speaker system system designed for use in arrays of up to six units. MG1928 is the ideal choice when line-array perfor- mance is needed but the venue size doesn't call for the very long-throw characteristics of larger line-arrays.
- Page 7 SPECIFICATIONS MG1928 - 8”, TWO-WAY, LINE-ARRAY SPEAKER " 8 n i l Frequency Range (-10 dB): 70Hz -20kHz Frequency Response (±3 dB): 87Hz - 19kHz 0° 5° c i t , ) l y l l c t i Crossover Frequency: 2.0 KHz Power Rating (Continuous / Program / Peak)
- Page 8 INTRODUCTION TO THE MG1918S The MG1918S is a compact, single, 18" direct radiating subwoofer intended for use in suspended arrays or ground-supported applications. The suspension system is designed for full compatibility with the MG1932 line-array speaker system and the MG-AF array frame. DIMENSIONAL DRAWINGS FOR MG1918S （29.5）...
- Page 9 Follow all applicable local ordinances. Attachment of the loudspeaker to supporting structure should be referred to a qualified professional. NL4 ±1 NL4 ±2 Marquis Galaxy ® Equipped with Differential Drive Transducer Technology U.S. PATENTS: 5,748,760, 6,768,806, 6,847,726, 6,774,510 and D483,743.
- Page 10 INTRODUCTION TO THE MG1915S The MG1915S a very compact single 15" direct radiating subwoofer is intended as companion subwoofer for the MG1928. The suspension system is designed for full compatibility with the MG1928 Line Array System and with the MG-SMAF array frame. The M20 mounting plate allows for utilization of the adjustable pole mount SS4-BK.
- Page 11 Follow all applicable local ordinances. Attachment of the loudspeaker to supporting structure should be referred to a qualified professional. NL4 ±1 NL4 ±2 Marquis Galaxy ® Equipped with Differential Drive Transducer Technology U.S. PATENTS: 5,748,760, 6,768,806, 6,847,726, 6,774,510 and D483,743.
- Page 12 INTRODUCTION TO THE MG1915M The MG1915M is a dedicated, compact and lightweight, 15", two way touring-class floor monitor, with only a 375 mm (14.75 in) stage height and JBL’s latest neodymium-magnet transducers. A 380 mm (15 in) 2265H patented Differential Drive woofer handles 800 watts (continuous) and delivers ®...
- Page 13 FUNCTIONAL BLOCK DIAGRAM HIGH FREQ IN / THRU PASSIVE FREQ MODE Marquis Galaxy ® Marquis Galaxy Transducer Technology U.S. PATENTS: 5,748,760, 6,768,806, ® Equipped with Differential Drive 6,847,726, 6,774,510 and D483,743.
-
Page 14: Frequency Response
AMPLITUDE SHADING AMPLITUDE SHADING Amplitude shading is a technique that allows the coverage pattern of a loudspeaker array to be shaped by adjusting the relative acoustic output of some of the devices in the array. Most often, array shading involves only the mid and high-frequency sections of the array. - Page 15 ARRAY CONFIGURATION SELECTOR (ACS) Below is an example of applying the ACS in a three-speaker array. In this particular configuration, the ACS on the top speaker is set at +3 dB, the middle speaker at 0 dB, and the bottom speaker -3 dB. +3 dB 0 dB -3 dB...
- Page 16 DEPLOYING THE SYSTEM The MG1932 is a flexible speaker system that can be deployed in ground-supported or suspended applications. The following information will help you set up your MG1932 system safely and effectively. POLE AND TRIPOD SAFETY WARNINGS! When using stands or poles, be sure to observe the following precautions: •...
- Page 17 DUAL MG1932 / MG1928 Unlike most conventional speakers, the MG1932 / MG1928 is designed so that a pair of speakers may be safely mounted onto a pole or tripod stand. For most applications, the forward socket of the dual angle pole socket will be used. This will tilt the lower of the two speakers at a 15°...
-
Page 18: Inspection And Maintenance
SUSPENSION SAFETY WARNINGS! Correct use of all rigging hardware is required for secure system suspension. Careful calculations should always be performed to ensure that all components are used within their Maximum Load Limit before the array is suspended. Never exceed the maximum recommended load ratings. Prior to suspending the system, an expert, trained and experienced in flying speaker systems should be consulted. - Page 19 MAXIMUM ARRAY SIZE There are two variations of the MG array frame. The MG-AF is for suspension of MG1918S and MG1932. The MG-SMAF is solely intended for use with the MG1928 and MG1915S. Before suspending an MG array, determine which version of the array frame you have and consult the table below to determine the maximum number of speakers that may be safely suspended.
- Page 20 SUSPENSION IN PERMANENT INSTALLATIONS For permanent installation applications an MG array may be suspended using M10 eyebolts. Only load-rated, forged shoulder eyebolts are to be used. A kit consisting of three (3) forged shoulder eyebolts is available from JBL Professional as part number 229-00009-01. Suspension of the MG array must employ both top attachment points.
- Page 21 INTRODUCTION TO THE MG-AF The MG-AF is an array frame designed to be used for suspension of the MG1932 and MG1918S loudspeaker systems. The optional array frame kit includes the following items: • 1 x center frame • 2 x side arms •...
- Page 22 INTRODUCTION TO THE MG-SMAF The MG-SMAF is an array frame designed to be used for suspension of the MG1928 and MG1915S loudspeaker systems. The optional array frame kit includes the following items: • 1 x frame • 2 x quick release pins •...
- Page 23 JBL WARRANTY The JBL Warranty on professional loudspeaker products will follow the warranty policy implemented in China market. Please refer to the warranty card for details.
- Page 24 JBL Professional 8500 Balboa Blvd. Part Number:5069690 03/2016 Northridge, CA 91329 USA...
