TechLine BAL-10 Instruction Manual

I N S T R U C T I O N M A N U A L
D I G I TA L S C A L E F O R P E R S O N A L U S E
B A L - 1 0 / B A L - 2 0
Be f ore u s i n g th e p ro d u c t re a d t he in st r uc ti o ns c a re f ul l y
IMPORTANT:
1) Do not operate this appliance near explosives, flammable fumes or where oxygen is
being administered.
2) Do not subject the scale to sudden shock, dust and water.
3) The surface of the scale can be slippery when wet.
4) Always weigh at the same time preferably without cloth and before breakfast.
5) If the scale will not be used on a regular basis, remove the battery to prevent possible
damage due to chemical leakage. If battery leaks remove it carefully. Be sure to protect
your hands from touching the liquid.
6) Do not dispose off the battery in an incinerator as they may explode. Place it in the
appropriate bin for recycled material.
7) This product is intended for household use only and not for commercial or industrial
use.
S P E C I F I CATI O N S
Modelo Modelo BAL-10 BAL-10
Model BAL-10/BAL-20
Visor Digital • Cristal Líquido Visor Digital • Cristal Líquido Até 4 dígitos Até 4 dígitos
LCD Display Up to 4 digits
Faixa de Medição Faixa de Medição Até 180 Kg (330 Lb) Até 180 Kg (330 Lb)
Capacity Range Up to 180 Kg
Alimentação Alimentação 2 baterias de lítio 3v (CR2032) inclusas* 2 baterias de lítio 3v (CR2032) inclusas*
Power Source 1 lithium battery CR 2032 (1x3V) included
Precisão Precisão Pode apresentar 1% de oscilação de seu peso total Pode apresentar 1% de oscilação de seu peso total
Accuracy It may show 1% difference of your total weight
Sensor Sensor Equipado com sensor de alta precisão Equipado com sensor de alta precisão
Sensor Equipped with high precision sensor
Plataforma Plataforma Vidro temperado Vidro temperado
Platform Tempered safety plate glass
Chave de conversão de peso Chave de conversão de peso Para alterar de Kg à Lb. Abaixo do compartimento das baterias Para alterar de Kg à Lb. Abaixo do compartimento das baterias
Weight converter To alter from Kg to Lb ( below battery compartment)
Interruptor Interruptor Liga / Desliga automático Liga / Desliga automático
Switch Auto-on and Auto-off
Indicadores Indicadores Excesso de peso e bateria fraca Excesso de peso e bateria fraca
Indicators Overload and Low Battery
* Note: The battery included is for demonstrative use. Please change it when the display
reads "LO".
4
US I NG TH E SCALE
1) Turn the scale over to its backside and open the battery cover carefully.
2) Remove the insulation sheet from the battery contact before using.
3) Set Kg (kilogram) or Lb (pound) on the switch button under the scale.
4) Place the scale on a hard, dry, and flat surface for best accuracy. Very soft, deep pile
carpets or rugs may affect accuracy.
5) Gently step on the scale with parallel feet. Wait until the scale is processing your
weight. Do not lean against any support while the scale is processing the result. For best
results, always use the scale at the same time of the day and at the same position.
Remark: When using the scale for the first time or each time you change the battery,
do not consider the first weighing. Please step off the scale to wait for the scale to auto-
off and then repeat step (5). Your second time weighing will be the correct one.
6) When you step off the scale it will automatically switch off. If no weighing is carried out
while zero is being displayed, the scale will automatically switch itself off after approxima-
tely 6 seconds.
7) Overload: When the scale is overloaded (more than 180 kg / 396 Lb) the display will
show "ERR".
LI TH I U M BAT TE RY
To change:
1) Turn the scale over to its backside and open the battery cover carefully.
2) Remove the battery.
3) Install 1 new lithium battery into its compartment.
4) Ensure "+" sign of the battery is facing up and close the cover.
5) Replace the battery whenever the display reads "LO".
* Note: The battery included is for demonstrative use. Please change it when the display
reads "LO".
6) Remove the battery if the scale is not used for a long period.
7) Dispose off the old battery in appropriate bin for recycled materials.
CAR E A N D MA I NTE NANCE
1) Wipe the scale with a soft cloth with mild detergent. Do not use abrasive or liquid
cleansers and never leave the scale in humid places. Do not allow water to get inside the
scale.
2) Store and transport the scale in its own package.
3) This scale contains electronic parts. Therefore use it carefully: do not drop it, kick it nor
jump on it.
4) Do not store the scale near chemical products nor heaters.
5) This scale is an extremely sensitive device; therefore to save the battery do not leave
any heavy object on it.
5
