Ex.2 When there are 3 effective digits (such as in high precision metal film resistors). 5.62k 562 x 10 5621 RN1/4PC 5 6 2 1 CONTRAST TABLE VSX-D909S/KU/CA, VSX-909RDS/HY, VSX-909RDS/HV and VSX-909RDS-G/HY are constructed the same except for the following: Part No. Ref. Mark Symbol and Description Remarks...
Page 3
VSX-909RDS, VSX-909RDS-G 3 7 63 1515 0 Part No. Ref. Symbol and Description Remarks Mark VSX-D909S VSX-909RDS VSX-909RDS VSX-909RDS-G /KU/CA PACKING SECTION P3- 4 Remote Control Unit AXD7278 AXD7258 AXD7258 AXD7279 P3- 9 Packing Case AHD7883 AHD7887 AHD7887 AHD7888...
Page 4
(HY Type Only) (HV Type Only) AC Power Cord No.3 IBZ30P100FCC FRONT PANEL SECTION No.5 AC Power Cord Screw ABA1193 BBT30P080FCC : VSX-909RDS-G ABA1193 Only BBT30P080FZK : VSX-909RDS Side Escutheon R Teminal Screw Rear Panel Shield Case Under Base No.6...
VSX-909RDS, VSX-909RDS-G 3 7 63 1515 0 CONTRAST OF PCB ASSEMBLIES EXTERNAL IN ASSY AWX7413 and AWX7398 are constructed the same except for the following : Part No. Mark Symbol and Description Remarks AWX7398 AWX7413 C1101- C1106 Not used...
VSX-909RDS, VSX-909RDS-G 3 7 63 1515 0 MAIN CONTROL ASSY AWX7710 and AWX7708 are constructed the same except for the following : Part No. Mark Symbol and Description Remarks AWX7708 AWX7710 IC102 BU4052BCF Not used IC109 NJM4558MD Not used...
VSX-909RDS, VSX-909RDS-G 3 7 63 1515 0 SP / PS ASSY AWX7691 and AWX7689 are constructed the same except for the following : Part No. Mark Symbol and Description Remarks AWX7689 AWX7691 IC3001 Not used AEK7007 Q3501 Not used...
VSX-909RDS, VSX-909RDS-G 3 7 63 1515 0 DISPLAY ASSY AWX7702 and AWX7700 are constructed the same except for the following : Part No. Mark Symbol and Description Remarks AWX7700 AWX7702 IC7051 TC7W53FU Not used IC7401 Not used BU1923 Q7053...
Page 9
VSX-909RDS, VSX-909RDS-G 3 7 63 1515 0 DSP ASSY AWX7633 and AWX7632 are constructed the same except for the following : Part No. Mark Symbol and Desacription Remarks AWX7633 AWX7632 Not used IC9041 NJM4558MD Not used IC9071 PM4007A Not used...
VSX-909RDS, VSX-909RDS-G 3 7 63 1515 0 RF/DIGITAL IN ASSY AWX7638 and AWX7642 are constructed the same except for the following : Part No. Mark Symbol and Description Remarks AWX7642 AWX7638 CN1250 Not used KM250MA3 1200 Not used VEF1040...
VSX-909RDS, VSX-909RDS-G 3 7 63 1515 0 Line Voltage Selection Line Voltage can be changed by the following modification: 1. Disconnect the AC power cord. Y6001 Y6002 2. Remove the cover. 3. Change the connection wire from TRANS 1 ASSY (Terminal No.
VSX-909RDS, VSX-909RDS-G 3 7 63 1515 0 3. SCHEMATIC DIAGRAM 3.1 EXTRA IN, A-PINJACK and CONNECTION ASSYS EXTRA IN ASSY CN1101 (AWX7413) JA1101-JA1103 ( AKB7095 ) A-PINJACK ASSY (AWX7412) JN1016: AKB7120 CN1001 JN1015: AKB7048 L 13942296513 JA1011-JA1013 : AKB7048...
Page 13
VSX-909RDS, VSX-909RDS-G 3 7 63 1515 0 Note : When ordering service parts, be sure to refer to "EXPLODED VIEWS and PARTS LIST" or "PCB PARTS LIST" CONNECTION ASSY (AWX7347) UPC4570C CN1302 CN1301 UPC4570C CN103 UPC4570C CN1353 CN1351 L 13942296513...
Page 14
VSX-909RDS, VSX909RDS-G 3 7 63 1515 0 3.2 MAIN CONTROL ASSY (1/3) : The power supply is shown with the marked box. CN906 52045-0545 CN7005 1SS355 1SS355 L 13942296513 CN941 : AKB7075 JA911 : DKB1045 u163 CN1353 1/3F http://www.xiaoyu163.com...
Page 15
VSX-909RDS, VSX-909RDS-G 3 7 63 1515 0 : AUDIO SIGNAL ROUTE : AUDIO SIGNAL ROUTE (PHONO) 1/3 F : AUDIO SIGNAL ROUTE (LD) : AUDIO SIGNAL ROUTE (TUNER) MAIN CONTROL ASSY : AUDIO SIGNAL ROUTE (TV) : AUDIO SIGNAL ROUTE (CD)
Page 16
VSX-909RDS, VSX909RDS-G 3 7 63 1515 0 3.3 MAIN CONTROL ASSY (2/3) 2/3 F MAIN CONTROL ASSY ( AWX7710 ) C165 C166 100p UPC4570HA UPC4570HA 100p C155 C155 100p UPC4570G2 100p L 13942296513 C156 UPC4570G2 100p u163 C176 C175...
Page 17
VSX-909RDS, VSX-909RDS-G 3 7 63 1515 0 : The power supply is shown with the marked box. : AUDIO SIGNAL ROUTE 1SS355 1SS355 CN501 L 13942296513 CN105 103 or 113 (2/3) 103 or 113 (1/3) 103 or 113 (3/3)
Page 19
VSX-909RDS, VSX-909RDS-G 3 7 63 1515 0 : The power supply is shown with the marked box. 3/3 F CN7001 MAIN CONTROL ASSY (AWX7710) CN904 L 13942296513 CN905 u163 CN108 CN701 CN5003 3/3F http://www.xiaoyu163.com...
Page 22
VSX-909RDS, VSX909RDS-G 3 7 63 1515 0 3.6 TRANS 2-1, DIODE and SP/PS ASSYS CAUTION : FOR CONTINUED PROTECTION AGAINST RISK OF FIRE. REPLACE ONLY WITH SAME TYPE NO. 49102.5 MFD, BY LITTELFUSE INC. FOR IC4501, IC4502 (AEK7014). DIODE ASSY...
Page 23
VSX-909RDS, VSX-909RDS-G 3 7 63 1515 0 HA HE SP/PS ASSY (AWX7691) CN3101 CN3102 L 13942296513 CN5001 3004 CN5002 u163 CN3003 http://www.xiaoyu163.com...
Page 24
VSX-909RDS, VSX909RDS-G 3 7 63 1515 0 3.7 REGULATOR, TRANS 1 and TRANS 2-2 ASSYS REGULATOR ASSY (AWX7310) CN5001 52147-0810 3004 CN5002 L 13942296513 TRANS 1 ASSY 5501 (AWX7316) LN4SB60-4003 C5501 0.47/100 R5501 TRANS 2-2 ASSY u163 CAUTION : FOR CONTINUED PROTECTION AGAINST RISK OF FIRE.
Page 25
VSX-909RDS, VSX-909RDS-G 3 7 63 1515 0 : AUDIO SIGNAL ROUTE CN5003 3/3 F CN108 CN5004 1/3 F CN104 L 13942296513 CN5008 3/3 F CN920 3/3 F CN901 CN5005 u163 CN5006 CN5007 CN9801 CN9802 http://www.xiaoyu163.com...
VSX-909RDS, VSX-909RDS-G 3 7 63 1515 0 4. REMOTE CONTROL UNIT [AXD7258, AXD7279] 4.1 CONTRAST OF MISCELLANEOUS PARTS NOTES : ÷ Parts marked by “ NSP ” are generally unavailable because they are not in our Master Spare Parts List.
