Installation, Operation & Maintenance
Instructions
Please leave this instruction booklet with the owner as it contains
important guarantee, maintenance and safety information
Read this manual carefully before commencing installation.
This manual covers the following products.
Jet 55-45
Pt. No. 46587
50 Hz
Jet 80-45
Pt. No. 46588
CE compliant product
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Stuart Jet 55-45
Summary of Contents for Stuart Jet 55-45
- Page 1 Please leave this instruction booklet with the owner as it contains important guarantee, maintenance and safety information Read this manual carefully before commencing installation. This manual covers the following products. Jet 55-45 Jet 80-45 Pt. No. 46587 Pt. No. 46588...
-
Page 2: Table Of Contents
(after initial priming) installations using the optional suction hose/ footvalve assembly. This pump set must not be used for any other application without the written consent of Stuart Turner Limited and in particular, must not be connected directly to the mains water supply. -
Page 3: Checklist
CHECKLIST IMPORTANT: With the pump removed from its packaging check for any damage prior to installation. If any damage is found contact Stuart Turner Ltd within 24 hours of receipt. Fig. 1 Item Description Qty Item Description Pump Handle screws... -
Page 4: Important Facts - Read Before Commencing Installation
1 IMPORTANT FACTS: READ BEFORE COMMENCING PUMP INSTALLATION A. Water storage capacity. 1.11 The cold water storage capacity must be sufficient to meet the flow rates required by the pumped equipment and any other water using fittings and appliances, which may be operated simultaneously. 1.12 Ensure the pump is primed as described in the priming section before starting, damage to the shaft seal will result otherwise. -
Page 5: Location
2 LOCATION - GENERAL 2.11 Access: For emergencies and maintenance the pump must be easily accessible. 2.12 Protection: The pump must be located in a dry position, frost free and protected from freezing, particularly when installed in a loft (not recommended). 2.13 Ventilation: Ensure an adequate air flow to cool the pump. - Page 6 2 LOCATION - PUMP MOUNTED BELOW WATER SOURCE Fig. 2 2.24 Water supply: Must be made via a tank connector offering a dedicated supply direct to the pump. Cont ... - 6 -...
- Page 7 Fig. 3 2.25 Self Priming: Jet 55-45 and 80-45 pumps are capable of self priming the suction hose assembly, providing a footvalve and strainer (not supplied) is always used for this type of installation. The Jet pump can be used in a suction lift installation providing the height of lift is no greater than maximum permitted (Fig.
-
Page 8: Electrical Installation
3 ELECTRICAL INSTALLATION / EARTHING 3.11 Regulations: The electrical installation must be carried out in accordance with the current national electrical regulations and installed by a qualified person. 3.12 Safety: In the interests of electrical safety a 30 mA residual current device (R.C.D. -
Page 9: Wiring Diagram
MOTOR BLACK CAPACITOR 230 V, 1 phase supply connected via a three pin plug. Jet 55-45 and Jet 80-45 Fig. 4 3.19 Fuse: The following fuse size should be used with the appropriate pump: Model Fuse Size (AMPS) All Models Cont ... -
Page 10: Commissioning
4 COMMISSIONING 4.11 System Flushing: The pipework system should be flushed out prior to the pump being connected to ensure any contaminants/chemical residues and foreign bodies are removed from elsewhere in the system. 4.12 Water Supply: Always ensure that water storage capacity is adequate to meet the demand. - Page 11 Jet 55-45 and Jet 80-45 Plug Fig. 5 4.17 For Further Technical Support: Phone the Stuart Turner PumpAssist team on +44 (0) 800 31 969 80. Our staff are trained to help and advise you over the phone. Cont ...
-
Page 12: Maintenance
5 MAINTENANCE 5.11 No routine maintenance is required but provision should be made for easy access to the pump to allow for repairs due to normal wear and tear. 5.12 Disconnect electrical supply before working on pump. 5.13 Turn off water supplies to the pump and release pressure by opening outlets before attempting maintenance. -
Page 13: Technical Specification
Although these pumps are self priming we recommend a footvalve/strainer is used if a suction lift is required. 6.11 Noise: The equivalent continuous A-weighted sound pressure level at a distance of 1 metre from the pump does not exceed 73 dB(A) for Jet 55-45 or 76 dB(A) for Jet 80-45. - 13 -... -
Page 14: Trouble Shooting
Check fuse (see fuse section). Check circuit breaker is set. Check wiring connections. Pump jammed. If motor ‘Buzzes’ switch off power and contact Stuart Turner. Integral motor thermotrip Wait for thermotrip to auto-reset and check that duty activated. point and run time is within specification (see technical specification). -
Page 15: Guarantee
Installers – Register with Stuart Turner and move up to Approved Installer status We receive thousands of enquiries every month from people seeking a Stuart Turner installer and by registering your details with us, we can offer consumers the opportunity to quickly locate an installer in their area. -
Page 16: Declaration Of Conformity
BS EN 61000-4-2, BS EN 61000-4-3, BS EN 61000-4-4, BS EN 61000-4-5, BS EN 61000-4-6, BS EN 61000-4-11 1999/519/EC BS EN 62233 2011/65/EU IT IS HEREBY CERTIFIED THAT THE STUART ELECTRIC MOTOR DRIVEN PUMP AS SERIAL NUMBER BELOW, COMPLIES WITH THE ESSENTIAL REQUIREMENTS OF THE ABOVE E.E.C. DIRECTIVES. RESPONSIBLE PERSON AND MANUFACTURER... - Page 17 Note: Ensure retained rubber seal is fitted in adaptor Adaptor locking ring Link cable (pre-fitted) Adaptor lower (pre-fitted) Jet pump Stuart Turner Ltd, Henley-on-Thames, Oxfordshire RG9 2AD ENGLAND Tel: +44 (0) 1491 572655, Fax: +44 (0) 1491 573704 info@stpumps.co.uk www.stuart-turner.co.uk Issue No. 3914/1-01...
-
Page 18: Operating Instructions
Water Pump Automatic Control Unit OPERATING INSTRUCTIONS Specifications Input voltage 230 V Maximum working pressure 10 bar Frequency 50-60 Hz Maximum water temperature rating Max current (resistive) Maximum ambient temperature rating Enclosure rating IP65 Connection 1 " male (G 1) - Page 19 UNIT INSTALLATION If the column of water between It is advisable to the pump and the highest connect the unit outlet tap exceeds 10 mts, the unit to the system by cannot be installed directly means of a flexible on the pump, but it has to hose to reduce noise be raised until the column of and vibration.
- Page 20 WIRING DIAGRAMS FOR CONNECTING THE UNIT WARNINGS: The electrical installation must be carried out in accordance with the current national electrical regulations and installed by a competent person. Before starting work on the electrical installation ensure the power supply is isolated.
- Page 21 After rectification of the failure that has caused the blockage, the system is restarted by pressing the “Restart” button. Stuart Turner Ltd, Henley-on-Thames, Oxfordshire RG9 2AD ENGLAND Tel: +44 (0) 1491 572655, Fax: +44 (0) 1491 573704 info@stpumps.co.uk...
