Pacific PTV3606 Service Manual

Color television receiver
Hide thumbs Also See for PTV3606:
Table of Contents

Advertisement

Quick Links

PTV3606
SERVICE MANUAL
COLOR TELEVISION RECEIVER
ORIGINAL
MFR'S VERSION A
Design and specifications are subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PTV3606 and is the answer not in the manual?

Questions and answers

Summary of Contents for Pacific PTV3606

  • Page 1 PTV3606 SERVICE MANUAL COLOR TELEVISION RECEIVER ORIGINAL MFR’S VERSION A Design and specifications are subject to change without notice.
  • Page 2 PTV3606 SERVICE MANUAL COLOR TELEVISION RECEIVER ORIGINAL MFR’S VERSION A Design and specifications are subject to change without notice.

  • Page 3: Servicing Notices On Checking

    SERVICING NOTICES ON CHECKING 1. KEEP THE NOTICES As for the places which need special attentions, they are indicated with the labels or seals on the cabinet, chassis and parts. Make sure to keep the indications and notices in the operation manual. 2.

  • Page 4: Table Of Contents

    SERVICING NOTICES ON CHECKING ... HOW TO ORDER PARTS ... IMPORTANT ... CONTENTS ... GENERAL SPECIFICATIONS ... DISASSEMBLY INSTRUCTIONS 1. REMOVAL OF ANODE CAP ... 2. REMOVAL AND INSTALLATION OF FLAT PACKAGE IC ... SERVICE MODE LIST ... CONFIRMATION OF HOURS USED ... WHEN REPLACING EEPROM (MEMORY) IC ...

  • Page 5: General Specifications

    GENERAL SPECIFICATIONS G - 1 S ystem Color System Speaker Sound Output PAL60Hz G - 2 Tu nin g Broadcasting System S ystem Tuner and Receive CH Intermediate Frequency Preset CH Stereo/Dual TV Sound Tuner Sound Muting G - 3 P o w e r Power Source Power Consumption...
  • Page 6 GENERAL SPECIFICATIONS G - 8 OSD Language G - 9 Clock and Sleep Timer Timer On/Off Timer Wake Up Timer Timer Back-up (at Power Off Mode) G - 1 0 Remo t e Unit Control Glow in Dark Remocon Format Custom Code Power Source Total Keys...
  • Page 7 GENERAL SPECIFICATIONS VM Circuit Full OSD Unitext Fastext Top Text Premiere Comb Filter Auto CH Memory Auto Set Up Stable Sound FBT Leak Test Protect Hotel Lock Power ON Memory G - 1 2 Accessories Owner's Manual Remote Control Unit Rod Antenna Loop Antenna U/V Mixer...
  • Page 8 GENERAL SPECIFICATIONS G - 1 7 Material G - 1 8 Environment Content Material Dimensions W x D x H(mm) Description of Origin Gift Box Material Dimensions W x D x H(mm) Design Description of Origin Drop Test Height (cm) Container Stuffing Cabinet Cabinet Front...

  • Page 9: Removal Of Anode Cap

    1. REMOVAL OF ANODE CAP Read the following NOTED items before starting work. After turning the power off there might still be a potential voltage that is very dangerous. When removing the Anode Cap, make sure to discharge the Anode Cap's potential voltage.

  • Page 10: Removal And Installation Of Flat Package Ic

    REMOVAL AND INSTALLATION OF FLAT PACKAGE IC REMOVAL Put the Masking Tape (cotton tape) around the Flat Package IC to protect other parts from any damage. (Refer to Fig. 2-1.) NOTE Masking is carried out on all the parts located within 10 mm distance from IC leads.
  • Page 11 INSTALLATION Take care of the polarity of new IC and then install the new IC fitting on the printed circuit pattern. Then solder each lead on the diagonal positions of IC temporarily. (Refer to Fig. 2-5.) Soldering Iron Solder temporarily Supply the solder from the upper position of IC leads sliding to the lower position of the IC leads.

  • Page 12: Service Mode List

    This unit provided with the following SERVICE MODES so you can repair, examine and adjust easily. To enter the Service Mode, press both set key and remote control key for more than 2 seconds. Set Key Remocon Key VOL. (-) MIN VOL.

  • Page 13: When Replacing Eeprom (Memory) Ic

    WHEN REPLACING EEPROM (MEMORY) IC If a service repair is undertaken where it has been required to change the MEMORY IC, the following steps should be taken to ensure correct data settings while making reference to TABLE 1. Enter DATA SET mode by setting VOLUME to minimum. While holding down VOLUME button on front cabinet, press key 6 on remote control for more than 2 seconds.

  • Page 14: Before Making Electrical Adjustments

    BEFORE MAKING ELECTRICAL ADJUSTMENTS Read and perform these adjustments when repairing the circuits or replacing electrical parts or PCB assemblies. CAUTION • Use an isolation transformer when performing any service on this chassis. • Before removing the anode cap, discharge electricity because it contains high voltage.
  • Page 15 2-7: HORIZONTAL POSITION Receive the monoscope pattern. Using the remote control, set the brightness and contrast to normal position. Activate the adjustment mode display of Fig. 1-1 and press the channel button (08) on the remote control to select "H POSI(50)". Press the VOL.
  • Page 16 2-14 : Confirmation of Fixed Value (Step No.) Please check if the fixed values of the each adjustment items are set correctly referring below. FUNCTION AGC GAIN R CUTOFF G CUTOFF B DRIVE V POSI 50/60 BRIGHT MAX BRIGHT MIN TINT SHARP CONT MAX...

  • Page 17: Purity And Convergence Adjustments

    PURITY AND CONVERGENCE ADJUSTMENTS NOTE Turn the unit on and let it warm up for at least 30 minutes before performing the following adjustments. Place the CRT surface facing east or west to reduce the terrestrial magnetism. Turn ON the unit and demagnetize with a Degauss Coil. 3-1: STATIC CONVERGENCE (ROUGH ADJUSTMENT) Tighten the screw for the magnet.

  • Page 18: Electrical Adjustment Parts Location Guide (Wiring Connection)

    ELECTRICAL ADJUSTMENTS 4. ELECTRICAL ADJUSTMENT PARTS LOCATION GUIDE (WIRING CONNECTION) CD803 J701 CP101 CP803A VR420 FB401 VR401 TU001 W812 CP401 CRT PCB S501A S801B TP023 J801 CP806 CP803B CP1001 MAIN PCB SPEAKER AC IN...

  • Page 19: Block Diagram

    CH UP CH DOWN VOL UP MICON W/T.TEXT IC IC101 OECF009A VOL DOWN OSD_R A_MUTE OSD_G OS101 KEY IN OSD_B OSD_FB REMORT Q510, Q511 POWER P.CON SW. POWER FAIL OSC IN RESET IC IC102 PST3231NR OSC_OUT RESET 9V REG. IC V-SYNC IC503 KIA7809API H-SYNC...
  • Page 20 D410 R421 D414 R429 D604 CD803A C418 CP803A C634 C417 R703 R408 D709 C408 W045 W823 W074 W075 R122 C003 CP001 W058 W081 TU001 PRINTED CIRCUIT BOARDS MAIN/CRT (INSERTED PARTS) SOLDER SIDE HS501 HS402 Q501 Q401 W011 FB401_1 C507 W068 C443 C524 R511...

  • Page 21: Printed Circuit Boards

    R1004 R1006 C1004 C1002 IC102 R106 R105 R132 Q103 R104 R103 C1009 PRINTED CIRCUIT BOARDS MAIN/CRT (CHIP MOUNTED PARTS) SOLDER SIDE R141 R140 R142 R618 R143 IC199 Q403 R115 Q615 C201 C121 C104 Q616 R648 C112 R623 C102 Q605 R219 C108 C109 R217 R508...
  • Page 22 R104 R103 R102 R101 2.2K 1.2K MICON W/T.TEXT IC IC101 KEY_IN R120 POWER FAIL 4.7K C140_1 R117 FORTHD VCR 2 220P B FORTHD VCR 1 C141_1 0.1 F EMERGENCY C108 R152 22P CH 4.7K OSC_IN X101 100CT4R013 4MHz OSC_OUT ON_TIMER C109 22P CH P4.6/PWM6...
  • Page 23 L206 0.27uH 0.001 FROM POWER P.CON+8V P.CON+5V TO SOUND AMP AUDIO_OUT FROM/TO MICON/TUNER RF_AGC PROTECT NOTE: THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE CHROMA/SIF/VIF/21PIN SCHEMATIC DIAGRAM (MAIN PCB) SIF BUFFER Q204 2SC2412K C629...
  • Page 24 FROM CHROMA/SIF/VIF/21PIN AUDIO_OUT FROM POWER FROM DEFRECTION SOUND+B FROM MICON/TUNER A_MUTE NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED NOTE: THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.
  • Page 25 FROM/TO CHROMA/SIF/VIF/21PIN R.OUT G.OUT B.OUT VAMP V-DRIVE IC IC401 TDA8174A V_OUT ABCL H_OUT 14.5 23.0 12.0 FROM MICOM/TUNER R406 PROTEC PROTECT 6.8K 1/4W Q403 KRC102SRTK HS401 763WSAA013 T401 ETH09K14BZ H.OUTPUT 27.0 Q401 TT2140LS-YBC11 FROM POWER H.DRIVE Q402 HS402 2SC1627_Y 763WSA0017 P.CON+8V H.DRV+B TO SOUND AMP/FRONT AV...
  • Page 26 TH501_1 W851 B59104-T80-B10 DEGAUSS COIL D503 L503 8R140018 RM11C-EIC CP502 A1561WV2-2P COIL LINE FILTER L501 0R7A223F24Y D504 RM11C-EIC AC230-240V_50Hz CD501 06444801 S501A BROWN BLUE R501 S501B 1.5M 1/2W BLUE BROWN F501 50T040H T4A_L_250V NC NC FH501 FH502 EYF-52BC EYF-52BC SW501 ESB92S22B L502 W5T29X7.5X19...

  • Page 27: Micon/Tuner

    MICON/TUNER 0.5 s 1.00V 10ms 1.00V 20 s 1.00V 20 s 1.00V 50 s 100mV WAVEFORMS 50 s 100mV 50 s 100mV 50 s 0.50V 0.2ms 1.00V 0.2ms 1.00V NOTE: The following waveforms were measured at the point of the corresponding balloon number in the schematic diagram.

  • Page 28: Waveforms

    20 s 1.00V 20 s 100mV 20 s 1.00V 20 s 1.00V 20 s 1.00V WAVEFORMS 10ms 1.00V 20 s 200mV SOUND AMP/FRONT AV 500us 500mV DEFLECTION/CRT 10ms 1.00V 10ms 10.0V NOTE: The following waveforms were measured at the point of the corresponding balloon number in the schematic diagram.
  • Page 29 20 s 20 s WAVEFORMS NOTE: The following waveforms were measured at the point of the corresponding balloon number in the schematic diagram.

  • Page 30: Mechanical Exploded View

    MECHANICAL EXPLODED VIEW L503 V801 101E 101C 101B 101A J801 PCB110 (CRT PCB ASS'Y) FB401 101G 101F 101D TU001 PCB010 (MAIN PCB ASS'Y) SP1001...

  • Page 31: Mechanical Replacement Parts List

    MECHANICAL REPLACEMENT PARTS LIST REF. NO. PART NO. A3M421I720 CABINET,FRONT ASSY 101A 701WPJC340 CABINET,FRONT 101B 713WPAA048 GUIDE,REMOCON 101C 713WPAA111 GLASS LED 101D 735WPA0396 SPEAKER,HOLDER 101E 735WPBA808 BUTTON,FRAME 101F 8995034000 CORD CLIP UL CO. 101G 725000A063 SHEET,PC A3M421I740 CABINET,BACK ASS'Y 752WSAA006 PLATE,SHIELD 752WSAA008 SHIELD,CASE 752WSAA013 SHIELD,LID 722575A004...

  • Page 32: Electrical Replacement Parts List

    ELECTRICAL REPLACEMENT PARTS LIST REF. NO. PART NO. DESCRIPTION RESISTORS ! R411 R3X28A151J R.METAL OXIDE ! R418 R3X28B6R8J R,METAL OXIDE ! R424 R3X181181J R,METAL OXIDE ! R429 R635815R6J R,FUSE ! R447 R635U2680J R,FUSE ! R501 R002T2155J ! R502 R3X181221J R,METAL OXIDE ! R503 R63581R22J R,FUSE...
  • Page 33 ELECTRICAL REPLACEMENT PARTS LIST REF. NO. PART NO. DESCRIPTION MISCELLANEOUS CF201 1012T6R014 FILTER,CERAMIC TRAP CF202 102E239R5B FILTER SAW CF204 1012T04101 FILTER,CERAMIC TRAP CP001 069W01001A CONNECTOR PCB SIDE CP101 069X160379 CONNECTOR PCB SIDE CP401 069S450089 CONNECTOR PCB SIDE CP502 069S420110 CONNECTOR PCB SIDE CP801 069W01001A CONNECTOR PCB SIDE CP1001...
  • Page 34 M3M4-21I SPEC.NO. U353551 O/R NO.
  • Page 35 SERVICING NOTICES ON CHECKING 1. KEEP THE NOTICES As for the places which need special attentions, they are indicated with the labels or seals on the cabinet, chassis and parts. Make sure to keep the indications and notices in the operation manual. 2.

  • Page 36: Mechanical Replacement Parts List

    SERVICING NOTICES ON CHECKING ... HOW TO ORDER PARTS ... IMPORTANT ... CONTENTS ... GENERAL SPECIFICATIONS ... DISASSEMBLY INSTRUCTIONS 1. REMOVAL OF ANODE CAP ... 2. REMOVAL AND INSTALLATION OF FLAT PACKAGE IC ... SERVICE MODE LIST ... CONFIRMATION OF HOURS USED ... WHEN REPLACING EEPROM (MEMORY) IC ...

  • Page 37: General Specifications

    GENERAL SPECIFICATIONS G - 1 S ystem Color System Speaker Sound Output PAL60Hz G - 2 Tu nin g Broadcasting System S ystem Tuner and Receive CH Intermediate Frequency Preset CH Stereo/Dual TV Sound Tuner Sound Muting G - 3 P o w e r Power Source Power Consumption...
  • Page 38 GENERAL SPECIFICATIONS G - 8 OSD Language G - 9 Clock and Sleep Timer Timer On/Off Timer Wake Up Timer Timer Back-up (at Power Off Mode) G - 1 0 Remo t e Unit Control Glow in Dark Remocon Format Custom Code Power Source Total Keys...
  • Page 39 GENERAL SPECIFICATIONS VM Circuit Full OSD Unitext Fastext Top Text Premiere Comb Filter Auto CH Memory Auto Set Up Stable Sound FBT Leak Test Protect Hotel Lock Power ON Memory G - 1 2 Accessories Owner's Manual Remote Control Unit Rod Antenna Loop Antenna U/V Mixer...
  • Page 40 GENERAL SPECIFICATIONS G - 1 7 Material G - 1 8 Environment Content Material Dimensions W x D x H(mm) Description of Origin Gift Box Material Dimensions W x D x H(mm) Design Description of Origin Drop Test Height (cm) Container Stuffing Cabinet Cabinet Front...

  • Page 41: Removal Of Anode Cap

    1. REMOVAL OF ANODE CAP Read the following NOTED items before starting work. After turning the power off there might still be a potential voltage that is very dangerous. When removing the Anode Cap, make sure to discharge the Anode Cap's potential voltage.

  • Page 42: Removal And Installation Of Flat Package Ic

    REMOVAL AND INSTALLATION OF FLAT PACKAGE IC REMOVAL Put the Masking Tape (cotton tape) around the Flat Package IC to protect other parts from any damage. (Refer to Fig. 2-1.) NOTE Masking is carried out on all the parts located within 10 mm distance from IC leads.
  • Page 43 INSTALLATION Take care of the polarity of new IC and then install the new IC fitting on the printed circuit pattern. Then solder each lead on the diagonal positions of IC temporarily. (Refer to Fig. 2-5.) Soldering Iron Solder temporarily Supply the solder from the upper position of IC leads sliding to the lower position of the IC leads.

  • Page 44: Service Mode List

    This unit provided with the following SERVICE MODES so you can repair, examine and adjust easily. To enter the Service Mode, press both set key and remote control key for more than 2 seconds. Set Key Remocon Key VOL. (-) MIN VOL.

  • Page 45: When Replacing Eeprom (Memory) Ic

    WHEN REPLACING EEPROM (MEMORY) IC If a service repair is undertaken where it has been required to change the MEMORY IC, the following steps should be taken to ensure correct data settings while making reference to TABLE 1. Enter DATA SET mode by setting VOLUME to minimum. While holding down VOLUME button on front cabinet, press key 6 on remote control for more than 2 seconds.

  • Page 46: Electrical Adjustments

    BEFORE MAKING ELECTRICAL ADJUSTMENTS Read and perform these adjustments when repairing the circuits or replacing electrical parts or PCB assemblies. CAUTION • Use an isolation transformer when performing any service on this chassis. • Before removing the anode cap, discharge electricity because it contains high voltage.
  • Page 47 2-7: HORIZONTAL POSITION Receive the monoscope pattern. Using the remote control, set the brightness and contrast to normal position. Activate the adjustment mode display of Fig. 1-1 and press the channel button (08) on the remote control to select "H POSI(50)". Press the VOL.
  • Page 48 2-14 : Confirmation of Fixed Value (Step No.) Please check if the fixed values of the each adjustment items are set correctly referring below. FUNCTION AGC GAIN R CUTOFF G CUTOFF B DRIVE V POSI 50/60 BRIGHT MAX BRIGHT MIN TINT SHARP CONT MAX...
  • Page 49 PURITY AND CONVERGENCE ADJUSTMENTS NOTE Turn the unit on and let it warm up for at least 30 minutes before performing the following adjustments. Place the CRT surface facing east or west to reduce the terrestrial magnetism. Turn ON the unit and demagnetize with a Degauss Coil. 3-1: STATIC CONVERGENCE (ROUGH ADJUSTMENT) Tighten the screw for the magnet.
  • Page 50 ELECTRICAL ADJUSTMENTS 4. ELECTRICAL ADJUSTMENT PARTS LOCATION GUIDE (WIRING CONNECTION) CD803 J701 CP101 CP803A VR420 FB401 VR401 TU001 W812 CP401 CRT PCB S501A S801B TP023 J801 CP806 CP803B CP1001 MAIN PCB SPEAKER AC IN...

  • Page 51: Block Diagram

    CH UP CH DOWN VOL UP MICON W/T.TEXT IC IC101 OECF009A VOL DOWN OSD_R A_MUTE OSD_G OS101 KEY IN OSD_B OSD_FB REMORT Q510, Q511 POWER P.CON SW. POWER FAIL OSC IN RESET IC IC102 PST3231NR OSC_OUT RESET 9V REG. IC V-SYNC IC503 KIA7809API H-SYNC...

  • Page 52: Printed Circuit Boards Main/Crt

    D410 R421 D414 R429 D604 CD803A C418 CP803A C634 C417 R703 R408 D709 C408 W045 W823 W074 W075 R122 C003 CP001 W058 W081 TU001 PRINTED CIRCUIT BOARDS MAIN/CRT (INSERTED PARTS) SOLDER SIDE HS501 HS402 Q501 Q401 W011 FB401_1 C507 W068 C443 C524 R511...
  • Page 53 R1004 R1006 C1004 C1002 IC102 R106 R105 R132 Q103 R104 R103 C1009 PRINTED CIRCUIT BOARDS MAIN/CRT (CHIP MOUNTED PARTS) SOLDER SIDE R141 R140 R142 R618 R143 IC199 Q403 R115 Q615 C201 C121 C104 Q616 R648 C112 R623 C102 Q605 R219 C108 C109 R217 R508...
  • Page 54 R104 R103 R102 R101 2.2K 1.2K MICON W/T.TEXT IC IC101 KEY_IN R120 POWER FAIL 4.7K C140_1 R117 FORTHD VCR 2 220P B FORTHD VCR 1 C141_1 0.1 F EMERGENCY C108 R152 22P CH 4.7K OSC_IN X101 100CT4R013 4MHz OSC_OUT ON_TIMER C109 22P CH P4.6/PWM6...
  • Page 55 L206 0.27uH 0.001 FROM POWER P.CON+8V P.CON+5V TO SOUND AMP AUDIO_OUT FROM/TO MICON/TUNER RF_AGC PROTECT NOTE: THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE CHROMA/SIF/VIF/21PIN SCHEMATIC DIAGRAM (MAIN PCB) SIF BUFFER Q204 2SC2412K C629...
  • Page 56 FROM CHROMA/SIF/VIF/21PIN AUDIO_OUT FROM POWER FROM DEFRECTION SOUND+B FROM MICON/TUNER A_MUTE NOTE:THE DC VOLTAGE AT EACH PART WAS MEASURED NOTE: THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME WITH THE DIGITAL TESTER WHEN THE COLOR BROADCAST OF PRINTING AND SUBJECT TO CHANGE WITHOUT NOTICE WAS RECEIVED IN GOOD CONDITION AND PICTURE IS NORMAL.
  • Page 57 FROM/TO CHROMA/SIF/VIF/21PIN R.OUT G.OUT B.OUT VAMP V-DRIVE IC IC401 TDA8174A V_OUT ABCL H_OUT 14.5 23.0 12.0 FROM MICOM/TUNER R406 PROTEC PROTECT 6.8K 1/4W Q403 KRC102SRTK HS401 763WSAA013 T401 ETH09K14BZ H.OUTPUT 27.0 Q401 TT2140LS-YBC11 FROM POWER H.DRIVE Q402 HS402 2SC1627_Y 763WSA0017 P.CON+8V H.DRV+B TO SOUND AMP/FRONT AV...
  • Page 58 TH501_1 W851 B59104-T80-B10 DEGAUSS COIL D503 L503 8R140018 RM11C-EIC CP502 A1561WV2-2P COIL LINE FILTER L501 0R7A223F24Y D504 RM11C-EIC AC230-240V_50Hz CD501 06444801 S501A BROWN BLUE R501 S501B 1.5M 1/2W BLUE BROWN F501 50T040H T4A_L_250V NC NC FH501 FH502 EYF-52BC EYF-52BC SW501 ESB92S22B L502 W5T29X7.5X19...

  • Page 59: Micon/Tuner

    MICON/TUNER 0.5 s 1.00V 10ms 1.00V 20 s 1.00V 20 s 1.00V 50 s 100mV WAVEFORMS 50 s 100mV 50 s 100mV 50 s 0.50V 0.2ms 1.00V 0.2ms 1.00V NOTE: The following waveforms were measured at the point of the corresponding balloon number in the schematic diagram.

  • Page 60: Sound Amp/Front Av

    20 s 1.00V 20 s 100mV 20 s 1.00V 20 s 1.00V 20 s 1.00V WAVEFORMS 10ms 1.00V 20 s 200mV SOUND AMP/FRONT AV 500us 500mV DEFLECTION/CRT 10ms 1.00V 10ms 10.0V NOTE: The following waveforms were measured at the point of the corresponding balloon number in the schematic diagram.
  • Page 61 20 s 20 s WAVEFORMS NOTE: The following waveforms were measured at the point of the corresponding balloon number in the schematic diagram.

  • Page 62: Mechanical Exploded View

    MECHANICAL EXPLODED VIEW L503 V801 101E 101C 101B 101A J801 PCB110 (CRT PCB ASS'Y) FB401 101G 101F 101D TU001 PCB010 (MAIN PCB ASS'Y) SP1001...

  • Page 63: Mechanical Replacement Parts List

    MECHANICAL REPLACEMENT PARTS LIST REF. NO. PART NO. A3M421I720 CABINET,FRONT ASSY 101A 701WPJC340 CABINET,FRONT 101B 713WPAA048 GUIDE,REMOCON 101C 713WPAA111 GLASS LED 101D 735WPA0396 SPEAKER,HOLDER 101E 735WPBA808 BUTTON,FRAME 101F 8995034000 CORD CLIP UL CO. 101G 725000A063 SHEET,PC A3M421I740 CABINET,BACK ASS'Y 752WSAA006 PLATE,SHIELD 752WSAA008 SHIELD,CASE 752WSAA013 SHIELD,LID 722575A004...

  • Page 64: Electrical Replacement Parts List

    ELECTRICAL REPLACEMENT PARTS LIST REF. NO. PART NO. DESCRIPTION RESISTORS ! R411 R3X28A151J R.METAL OXIDE ! R418 R3X28B6R8J R,METAL OXIDE ! R424 R3X181181J R,METAL OXIDE ! R429 R635815R6J R,FUSE ! R447 R635U2680J R,FUSE ! R501 R002T2155J ! R502 R3X181221J R,METAL OXIDE ! R503 R63581R22J R,FUSE...
  • Page 65 ELECTRICAL REPLACEMENT PARTS LIST REF. NO. PART NO. DESCRIPTION MISCELLANEOUS CF201 1012T6R014 FILTER,CERAMIC TRAP CF202 102E239R5B FILTER SAW CF204 1012T04101 FILTER,CERAMIC TRAP CP001 069W01001A CONNECTOR PCB SIDE CP101 069X160379 CONNECTOR PCB SIDE CP401 069S450089 CONNECTOR PCB SIDE CP502 069S420110 CONNECTOR PCB SIDE CP801 069W01001A CONNECTOR PCB SIDE CP1001...
  • Page 66 M3M4-21I SPEC.NO. U353551 O/R NO.
