Related Manuals for Grundig 43 VLE 5523 BN

Summary of Contents for Grundig 43 VLE 5523 BN

  • Page 1 43 VLE 5523 BN...

  • Page 2: Table Of Contents

    CONTENTS --------------------------------------------------------------------------------------------------------------- 5­ SET-UP­AND­SAFETY 24­ PICTURE­/SOUND­SETTINGS Picture settings 7­ GENERAL­INFORMATION Advanced picture settings Special features of your TV Sound settings Receiving digital channels 28­ TV­OPERATION­–­BASIC­­ Grundig SCR system FUNCTIONS Important notes on environmental protec- Switching on and off tion Selecting channels Notes on still images Selecting channels from lists 9­ PACKING­CONTENTS Selecting a preset AV channel Adjusting the volume Standart accessory Switching sound on/off Optional accessory Displaying information 10­ CONNECTION­AND­PREPARATION Freeze-frame Audio language Connecting the antenna and the power Subtitles adapter Zapping function Setting up or hanging Setting up with stand 30­...
  • Page 3 CONTENTS --------------------------------------------------------------------------------------------------------------- 41­ USB­OPERATION 54­ RESET­FUNCTIONS File formats Restoring the television to the default set- Connecting external data media tings Removing the external data media 55­ OPERATION­USING­EXTERNAL­ The media player DEVICES Settings in the USB setup menu DIGI LINK 44 Basic playback functions The DIGI LINK functions on your televi- Additional playback functions sion 46­ LANGUAGE­SETTINGS Device operation Switching the device to standby Opening the SETTINGS menu High definition HD ready Changing the menu language Connection options Changing the audio language Connecting external devices 47­ ACCESSIBLED­FUNCTIONS­ Using a DVD player, DVD r ecorder, video recorder or set-top box Changing the subtitle language Headphones and subtitle mode...
  • Page 4 CONTENTS --------------------------------------------------------------------------------------------------------------- Searching for digital terrestrial TV chan- nels manually Automatic service update Tuning analogue television c hannels Changing stored analogue c hannels Displaying signal information 74­ INFORMATION Service information for dealers Environmental note Note for the Product Package Cleaning the TV set Explanation of the symbols which may be present on back side of the television set Troubleshooting 77­ GLOSSARY 80­ INDEX 4­ ENGLISH...

  • Page 5: Set-Up­and­safety

    SET-UP­AND­SAFETY ­ - ---------------------------------------------------------------------------------- About­your­TV­set Safety WARNING W ith your TV set, you can receive and watch digital TV programmes over DVB-S, DVB-T Risk­of­electrical­accident and DVB-C, along with analogue TV. D o not open the TV set. Safety risk may arise The TV set can record programmes. For this and also the guarantee of the product can be feature you need a USB storage device, such void if the television set is opened. as an external hard drive (not included). Re- T he TV set can only be operated with the corded programmes can only be played on power cable or the AC/DC adapter supplied the same TV set. After the TV st is repaired, it with the product. is possible that recorded programmes may no D o not operate the TV set with a damaged longer be able to be played back. power cord/AC/DC adaptor (if supplied). Intended­use I f the plug on the TV set has an earthing con- tact, only insert the plug into a socket with an T he TV set is designed for use in dry rooms. earthing contact. U se the TV set with the supplied stand or P lug the TV set into the mains socket only after a suitable VESA bracket.
  • Page 6 SET-UP­AND­SAFETY ­ - ---------------------------------------------------------------------------------- Discolouration­of­furniture­due­to­rub- WARNING ber­feet Injuries­caused­by­falling­TV­set S ome furniture surfaces may discolour when Never place the TV set on an unstable surface. they come in contact with rubber. To protect The TV set may fall, causing serious injury, pos- furniture, you can place a sheet made o f glass sibly leading to death in isolated cases. or plastic under the stand. Do not use textile underlays or mats such as doilies. Observe the following precautions: O nly use the manufacturer’s recommended Environmental­information cabinets or stands. O nly use furniture that can safely support the Do not dispose of batteries in TV set. the household waste. Used bat- teries must be returned to retail M ake sure that the TV set does not protrude stores or public collection points. You help to beyond the dimensions of the furniture on protect the environment in this way. which it is resting. B e sure to dispose of packaging materials D o not place the TV set on tall furniture (such for your product separately according to the as kitchen cabinets, bookshelves) without guidelines of local authorities so that they...

  • Page 7: General­information

    T and DVB-C). Watching these channels and individual television programmes are – when the recording and playback functions are only provided by the broadcasting station – are possible with the appropriate CI module and also available in the electronic TV guide. a SmartCard. Ask your specialist dealer. You can connect various data media, such as T he range of channels available from the an external hard drive, a USB memory stick or public broadcasting institutions (ARD with Ein- a digital camera, to the USB socket. Using the sExtra, EinsFestival or ZDF with ZDF Info and file browser, you can then select and play the all third party broadcasters) are not encrypted file formats of your choice (for example, MP4, and can be received without a SmartCard. MP3 or JPEG data). Grundig­SCR­system Using the time shift function, you can quickly Y our TV supports SCR system (Satellite Chan- and easily pause a programme using the nel Router). If your antenna installation is remote control and resume it at a later stage. equipped with an Single Cable Distribution The programme is recorded in an external multiswitch, all television sets which are con- data medium. nected on this antenna can receive the televi- You can record any digital TV channels you sion channels stand-alone. choose. The TV channels are converted by the televi- sion and saved on an external data medium which is connected to the USB socket. The saved programmes can be called up and played from the archive on the external data medium at any time.

  • Page 8: Important Notes On Environmental Protec- Tion

    GENERAL­INFORMATION ­ - ------------------------------------------------------------------ Important­notes­on­environmen- Notes­on­still­images tal­protection Watching the same image for a long time on the screen may cause a still image remains The following information will help you to save feebly on the background. Feeble image(s) on resources – and money as well. the background is originated from LCD/LED If you are not using your television set for technology and does not require any action s everal days, you should pull out the mains under guarantee. To avoid such cases and/or plug for environmental and safety reasons. minimize the impact, you may observe the tips This way the television does not consume any below. electricity. Do not allow the same TV channel to stay on If the device is equipped with a power switch, the screen for a very long time. Channel logos switching it off using this switch will be suf- may cause this situation. ficient. The energy consumed by the television Do not allow the images, which are not full set is reduced to virtually 0 W. screen, to constantly stay on the screen; if not In standby mode, the television set uses very streamed in full screen format by the broad- little energy. However, it may be necessary caster, you can convert the images to full to leave the television set in standby mode screen by changing picture formats. for certain functions (for example automatic Higher brightness and/or contrast values will switch-on and switch-off and for timer func- lead this impact to appear faster; therefore, tions).

  • Page 9: Packing­contents

    PACKING­CONTENTS ­------------------------------------------------------------------------------- ­ S tandart­accessory ­ O ptional­accessory 1­ Easy-Use Remote Control Batteries for Easy-Use remote controls 2­ Stand Cleaning cloth 3­ Remote control 4­ Batteries for remote controls 5­ S crews and mounting instructions for stand 6­ Screws for VESA bracket 7­ Brief Instruction 9­ ENGLISH...

  • Page 10: Connection­and­preparation

    CONNECTION­AND­PREPARATION ­ - -------------------------------------- ­ C onnecting­the­antenna­and­the­power­adapter SERVICE SATELLITE ANT-IN Optic Out USB2 HDMI2 13/18V max. 500mA max. 50mA 1 To receive digital satellite channels (DVB-S/ ­ 3 Plug the power cord of the power adapter S2), connect the satellite antenna cable to into a wall socket. the a ntenna socket SATELLITE on the televi- Notes: sion set. Do not plug in the power adapter until you And/or have connected the external equipment and the antenna. 2a To receive terrestrial digital broadcasters (DVB-T) connect the cable for the rooftop Do not use an adapter plug or extension or indoor antenna (passive or active indoor lead which does not meet the applicable antenna with its own power supply) to the safety standards. Do not tamper with the...

  • Page 11: Setting Up Or Hanging

    CONNECTION­AND­PREPARATION ­ - -------------------------------------- ­ S etting­up­or­hanging S elect a location so that no direct sunlight falls on the screen. ­ S etting­up­with­stand T o mount the stand, refer to the installation instructions included. P lace the TV set on a hard, level surface. ­ P reparing­for­mounting­on­ the­VESA­bracket You will need: A pair of scissors, A crosstip screwdriver. Follow the installation instructions for the VESA bracket. 1­ Place the TV set in the film on a smooth surface with the screen facing down. 2­ Cut open the film on the back side using the scissors. 3­ Connect the required cables to the connec- tors on the TV set. See the “Connections” section in this manual. 4­ Tie the cables so they do not hang down onto the floor.

  • Page 12: Inserting Batteries Into The R Emote Control

    CONNECTION­AND­PREPARATION ­ - -------------------------------------- Inserting­batteries­into­the­ Environmental­note ­ r emote­control This symbol on recharge- able batteries/batteries or on the packaging indi- cates that the recharge- able battery/battery may not be disposed of with regular household rubbish. For certain r echargeable batteries/batteries, this symbol may be supplemented by a chemical symbol. Symbols for mercury (Hg) or lead (Pb) are provided if the rechargeable bat- teries/batteries contain more than 0.0005% mercury or more than 0.004% lead. Rechargeable batteries/batteries, including those which do not contain heavy metal, may not be disposed of with household waste. Always dispose of used batteries in accordance with local environmental r egulations. Make enquiries about the applicable dis- posal regulations where you live. 1­ Open the battery compartment by removing the lid. 2­ Insert the batteries (2 x 1.5 V micro, for example R03 or AAA). Observe the polar- ity marked in the bottom of the battery c ompartment. 3­...

  • Page 13: Overview

    OVERVIEW ­-------------------------------------------------------------------------------------------------------------- ­ C onnections­on­the­television­set SERVICE SERVICE SATELLITE ANT-IN Optic Out USB2 HDMI2 13/18V max. 500mA max. 50mA 13­ ENGLISH...

  • Page 14: Control Elements

    OVERVIEW ­-------------------------------------------------------------------------------------------------------------- SERVICE ­ C ontrol­elements Service only. AV­/­S-VHS S CART socket, audio/video input and output; S-VHS socket, audio/video input for S-Video camera using a SCART-S-VHS adapter cable; Component socket, audio/ video input (YUV signal) us- ing a SCART-YPbPr adapter cable. SATELLITE F or satellite antenna. Suit- able for single-cable GSCR system. ANT­IN F or antenna cable (terres- trial antenna, cable connec- tion or analogue antenna). Turning­the­TV­to­standby Optic­Out O ptical audio output. 1­ » /I«­Switches the television on and back For digital multichannel into standby mode. audio/video amplifier or AV receiver connections. ­...

  • Page 15: The Remote Control - Main Functions

    OVERVIEW ­-------------------------------------------------------------------------------------------------------------- ­ T he­remote­control­–­Main­functions Turns on and off the television set (stand-by) Switches on from standby mode; selects channels directly S witches between S elects the channel list (»All«, teletext and TV mode »FAV 1« to »FAV 4«) HDMI CEC Device List Exits TV guide Display information ­ Z apping function; Opens the main menu switches back one menu level in the menus Opens the channel list Opens the TV guide Opens the TOOLS menu Adjusts the volume Signal source S witches on from standby; Selects channel – in steps Muting Record, play, pause and stop (only digital television Next/previous image/ chap- channels) on/from an exter- ter, next/previous track nal data medium Picture formats Select subtitle Switches between...

  • Page 16: The Remote Control - All Functions

    OVERVIEW ­-------------------------------------------------------------------------------------------------------------- The­remote­control­–­­ All­functions  ­(red)­ Selects pages in teletext; (green) Selects/activates various functions  (yellow) in the menus.  (blue)  S witches to double character size in teletext; selects the previous title/previous picture in the Media Player. ­ R efreshes a teletext page; selects the next track/next picture in the Media Player. S tops scrolling through pages in t eletext; starts a fast reverse search in the Media Player. R eveals answers in teletext; starts a fast forward search in the Media Player. S tarts the recording (only for digital television channels, the recording is made on an external data medium). S tarts playing a programme from an external data medium;...

  • Page 17: Initial­set-Up

    INITIAL­SET-UP ­--------------------------------------------------------------------------------------------------- Initial­set-up­and­tuning­­ Selecting­language,­operating­ channels mode­and­country 1­ T he television set is equipped with automatic Switch on the television set from standby channel search, which searches for satellite with » «, »1…0« or »P+« or »P-«. channels (DVB-S/S2), terrestrial channels (DVB- – During initial set-up, the »Installation T), cable channels (DVB-C) and analogue chan- Guide« will be displayed. nels. Help:­ You start the search and the channels will be If this menu is not displayed, restore the stored into the different Program Tables. Follow- t elevision set to its default settings (see ing, you can sort the channels in the Program page 54). Tables. < > 2­ Select the menu language with » «, » «, » « or » « and press »OK« to confirm. Λ The­various­settings < >...

  • Page 18: Tuning The Channels From Satellite (Dvb-S

    INITIAL­SET-UP ­--------------------------------------------------------------------------------------------------- ­ ­ T uning­the­channels­from­ ­ A dvanced­installation satellite­(DVB-S/S2) 1­ In the »Source Setup« menu, in the »Con- nection Type« line, select the option »Satel- You have two options for tuning digital satellite < > lite« with » « or » «. channels. 2­ Select the line »Advanced Installation« with A T he easy installation, » « or » « and press »OK« to confirm. Λ w hich pre-configures all antenna settings for – T he menu appears. the satellite channels on Astra 19.2° East. B The advanced installation xx.xx.xxxx INSTALLATION c an be used if you wish to receive satellite 15:46 ANTENNA SETTINGS channels from various satellites. To do so, you...
  • Page 19 INITIAL­SET-UP ­--------------------------------------------------------------------------------------------------- 6­ Select the line »DISEqC Mode« with » « Note: or » «. Λ It is possible, that some TV channels (tran- Select »DiSEqC 1.0« or »DiSEqC 1.1« sponders) cannot be found. This is caused in a ccordance with the existing antenna by a change in satellite parameters made < > system with » « or » «. by the broadcaster, e.g. new channels have – D iSEqC 1.0 allows up to four satellites to been added. Set the »Network Search« be received simultaneously. option to »On«. – D iSEqC 1.1 allows up to 16 satellites to 11­ Start the scan with » « (red).  be received simultaneously. – T he »Results« menu appears, and the scan 7­ Select the line »LNB Selection« with »...

  • Page 20: Tuning Terrestrial Channels (Dvb-T)

    INITIAL­SET-UP ­--------------------------------------------------------------------------------------------------- Tuning­terrestrial­channels­­ Tuning­channels­from­the­cable­ (DVB-T) provider­(DVB-C) 1­ 1­ In the »Source Setup« menu, in the »Con- In the »Source Setup« menu, in the nection Type« line, select the option »Air« »Connection Type« line, select the option < > < > with » « or » «. »Cable« with » « or » «. 2­ Select the line »Scan Type« with » « or 2­ S elect the line »Scan Type« with » « or » «. » «. Λ Λ < > < > Use » « or »...

  • Page 21: Changing The Program Table For The Digi- Tal Channels

    INITIAL­SET-UP ­--------------------------------------------------------------------------------------------------- ­ C hanging­the­program­table­for­ ­ S electing­channel­lists the­digital­channels 1­ Open the menu with »MENU«. 2­ Select the »SOURCE SETUP« menu with Channels which are found using the scan are » « or » « and press »OK« to confirm. saved in the »PROGRAM TABLE«. Λ – T he »SOURCE SETUP« menu appears. You can delete channels which are not required from the programe table, you can change the 3­ Select the line »Programe Table« with » « order of channels within the programe table and or » « and press »OK« to confirm. Λ lock individual channels (Parental control). – T he menu »PROGRAM TABLE« appears. Important: You can also add channels to the favourites list; Programe table and favourites lists are in addition, you can change the order of chan- saved separately according to the different nels within the favourites list.
  • Page 22 INITIAL­SET-UP ­--------------------------------------------------------------------------------------------------- Deleting­channels­in­the­program­table Sorting­channels­in­the­program­table 1­ In the »PROGRAM TABLE« menu, select the (only satellite channels and digital television Edit mode by pressing » « (red). channels from the cable provider)  You can sort the order of the channels in the 2­ Select the t elevision channel to be deleted < > program table according different criteria. with » «, » «, » « or » « and press Λ » « (yellow) to delete.  1­ In the »PROGRAM TABLE« menu, select the Sort mode by pressing » « (blue).  Note: 2­ You can delete all channels with » « Select the sort criteria for satellite chan-  (blue). nels with »...
  • Page 23 INITIAL­SET-UP ­--------------------------------------------------------------------------------------------------- Creating­lists­of­favourites Sorting­channels­in­the­favourite­list You can save your favourite channels in up to You can change the order of channels in the four favourites lists (FAV 1 to FAV 4). f avourites list. Notes: 1­ In the »PROGRAM TABLE« menu, select the f avourites list »1« to »4«. Favourites lists must be created separately for all input sources (satellite, cable, air). 2­ Select the channel which should be moved < > You can select the favourites list by pressing with » «, » «, » « or » « and mark it Λ »FAV«. with » « (red).  1­ In the »PROGRAM TABLE« menu, switch 3­ Move the channel to its new position with < > over to the list view with » « (yellow).  »...

  • Page 24: Picture­/Sound­settings

    PICTURE­/SOUND­SETTINGS ­ - ---------------------------------------------------------- ­ ­ P icture­settings­ Advanced­picture­settings­ 1­ Open the menu with »MENU«. The “advanced picture settings” are in principal digital image improvements which, however, 2­ Select the menu item »PICTURE SETTINGS« should be only used when necessary when pic- with » « or » « and press »OK« to Λ ture quality and transmission is excellent. They confirm. may well improve the display with poor mate- – T he »PICTURE SETTINGS« menu appears. rial, but may adversely affect the display where transmission and picture quality are excellent. xx.xx.xxxx 15:46 PICTURE SETTINGS »Nois Reduction« – Reduces the visible snow by displaying the picture a little less sharply and creating a slight blurring. Basic Tuning Should therefore be used minimally with Picture Mode User good picture material.
  • Page 25 PICTURE­/SOUND­SETTINGS ­ - ---------------------------------------------------------- »Gamma« – This setting establishes which brightness value should be displayed for which digital transmission value. Most recordings are transmitted with a gamma value of 2.2 (all Windows PCs and newer PCs with a MAC operating system work with this, older MAC systems and transmis- sions without colour profile mostly operate with a gamma value of 1.8). »Dynamic Contrast« – The function dynami- cally and optimally adjusts the contrast for the respective picture content by analysing images and then altering this depending in a change in contrast. This increase the con- tract, however may also reduce the visible brightness levels in the picture. »Dynamic Backlight« – Here the device optimally adjusts the back lighting for the picture content by regulating the back lighting depending on the average picture brightness. If a picture has predominately dark areas, then the black level displayed is improved by downward adjustment of the back lighting (in this case the display of the dark areas is improved), and with predomi- nantly bright picture material the back light- ing is maximised in order to display these areas more brightly. »Backlight« – Manual setting for back light- ing (only active if dynamic back lighting is switched to “OFF”). This setting also directly impacts power consumption. 25­ ENGLISH...

  • Page 26: Sound Settings

    PICTURE­/SOUND­SETTINGS ­ - ---------------------------------------------------------- ­ S ound­settings­ ­ S tereo/two­channel­sound,­mono If the device receives two-channel-sound pro- 1­ Open the menu with »MENU«. grammes, e.g. a film with the original soundtrack 2­ Select the menu item »SOUND SETTINGS« on audio channel B (display: »Dual II«) and with » « or » « and press »OK« to Λ the dubbed version on sound channel A (dis- confirm. play: »Dual I«), you can select the audio chan- – T he »SOUND SETTINGS« menu appears. nel you prefer. If the device receives stereo or Nicam pro- xx.xx.xxxx grammes, it switches automatically to stereo SOUND SETTINGS 15:46 sound (display: »Stereo«). You can switch the sound to »Mono« if the ste- Volume reo sound quality is poor. Balance 1­ Select the line »Sound Type« with »...
  • Page 27 PICTURE­/SOUND­SETTINGS ­ - ---------------------------------------------------------- Soundeffects Exiting­the­setting 1­ This menu offers three preset sound effects (Mu- Press »MENU« to end the setting. sic, Natural and Speech) and one setting to be created by you (User). 1­ Select the line »Sound Preset« with » « or » «. Λ 2­ Select the sound effect »Music«, »Natural« < > or »Speech« by pressing » « or » «. Note: »User« option is active when »Sound mode« setting is selected as »Normal or »Spatial«. Automatic­volume Television stations broadcast at different vol- umes. The automatic volume limiting (AVL) func- tion means the volume is kept the same when you switch between channels. 1­ Select the line »AVL« with » « or » « and Λ < > select the option »On« with »...

  • Page 28: Tv­operation­-­Basic­functions

    TV­OPERATION­–­BASIC­FUNCTIONS ­--------------------------------- Switching­on­and­off Selecting­a­preset­AV­channel 1­ 1­ Press » «, »1…0« or »P+« or »P-« to Open the »Select Source« menu with switch on the television from standby mode. » «. < 2­ Press » « to switch the television to standby. 2­ Select an AV preset with » «, » «, » « or Λ > » « and press »OK« to confirm. Selecting­channels 3­ Use »1…0« to switch back to the television 1­ Press »1…0« to select presets directly. channel. 2­ Select television channels step by step with Adjusting­the­volume »P+« or »P-«. 1­ Adjust the volume with »+ –«. 3­ Open the channel list with »OK«, select the preferred television channel with »...

  • Page 29: Subtitles

    TV­OPERATION­–­BASIC­FUNCTIONS ­--------------------------------- Subtitles Various subtitles are available on digital televi- sion channels. This depends on the programme being broadcast. 1­ Open the selection menu with » «. 2­ Select the subtitles with » « or » « and Λ press »OK« to confirm. Zapping­function This function remembers the channel you are c urrently watching while you switch over to other ones (zapping). 1­ Press »1…0« or »P+«, »P–« to select the channel to be stored in the zapping memory and press »BACK­ < « to confirm. 2­ Press »1…0« or » «, » « to switch to Λ a nother television channel. 3­ Press »BACK­ < « to switch between the saved television channel and the last televi- sion channel viewed. 4­ End the function with »MENU«.

  • Page 30: Tv­operation­-­Additional­functions

    TV­OPERATION­–­ADDITIONAL­FUNCTIONS ­------------ Entering­the­switch-off­time­­ Audio­settings (sleep­timer) Various audio settings are available. In the »Sleep Timer« menu you can enter a time 1­ Open the Tools menu with »TOOLS«. for the television to switch off. After this time 2­ Select the menu item »Sound Preset« with has elapsed, the television switches to standby » « or » «. Λ mode. < 3­ Select the audio setting by pressing » « or 1­ Open the Tools menu with »TOOLS«. > » «. 2­ Select the line »Sleep Timer« with » « or – Y ou can change the »User« audio setting » «. Λ – see the “Soundeffects” chapter on page < > 3­...

  • Page 31: Changing The Picture Format

    TV­OPERATION­–­ADDITIONAL­FUNCTIONS ­------------ Changing­the­picture­format »Overscan­off«­format In this mode, HD pictures are not cropped by Basic setting is 16 : 9. the HDMI sockets or component sockets, and 1­ Select the picture format with » «. are displayed in their original size. This only – T he picture format (for example »16:9«) is applies in HDMI mode and for resolutions of displayed. 720p or above. – Y ou can choose between the following p icture formats: »Auto«­format The picture format is automatically switched to »16:9« for 16:9 programmes. The picture format is automatically switched to »4:3« for 4:3 programmes. »16:9«­and­»14:9«­formats For programmes in 4:3 format, the picture is stretched horizontally if the »16:9« format or »14:9« format is selected. The picture geometry is stretched horizontally. With actual 16:9 input sources (from a set- top box on the SCART socket) the picture fills the screen completely and with the correct g eometry. »4:3«­format The picture is shown in 4:3 format. »LetterBox«­format­ The letterbox format is especially suitable for programmes in 16:9 format.

  • Page 32: Electronic­tv­guide

    ELECTRONIC­TV­GUIDE ­--------------------------------------------------------------------------- Electronic­TV­guide The electronic TV guide provides an overview of all programmes that will be broadcast in the next week (for digital channels only). 1­ Press »GUIDE« to display the TV guide. Notes: Not all channels supply provide a detailed TV guide. Many broadcasters transmit the current schedule, but do not offer detailed descrip- tions. There are broadcasters which do not pro- vide any information at all. 2­ Press » « or » « to select a television Λ c hannel. – T oday's programmes on the television channel selected are displayed. 3­ Switch to the information about the current > programme with » «. Notes: Y ou can open and switch off the extensive programme information with »?«. Y ou can can added the selected broadcast to the memory timer by pressing »OK«. Y ou can record programmes by pressing »...

  • Page 33: Teletext­operation

    TELETEXT­OPERATION ­------------------------------------------------------------------------------ TOP­text­or­FLOF­text­mode Additional­functions 1­ Press »TXT« to switch on teletext. Skipping­the­waiting­time 2­ Select teletext pages directly with »1...0« While a page search is progressing, you can or step by step with » « and » «. Λ switch to the TV programme. Return to teletext page 100 with »?«. 1­ Enter the teletext page number with »1…0« Note: and then press » «. At the bottom of the screen there is an info – A s soon as the page is found, the page bar with red, green and – depending on the number is displayed. channel – yellow and blue panels. Similarly, 2­ Press » « to switch to the teletext page. the remote control also features buttons with different colours with which these pages can Enlarging­the­character­height be selected. If you have difficulty reading the text on the 3­ Go back a page with » « (red).  screen, you can increase the character height.

  • Page 34: Usb­recording

    USB­RECORDING ­------------------------------------------------------------------------------------------- ­ ­ I nformation­on­recording­and­ ­ P ossible­limitations­when­using­ playing­television­programmes an­external­data­medium Recording and playback of television pro- Depending on the broadcaster, you may experi- grammes is only possible with digital televi- ence various restrictions on some of the functions sion channels (DVB-S/S2, DVB-T and DVB-C). from some television channels. GRUNDIG­has­no­influence­on­ The digital television channels (DVB-S/S2, DVB-T and DVB-C) you are able to record and these­restrictions. playback also depends on the broadcaster. Recording a programme on the external data Recording and playback of programmes, medium can be disabled by the broadcaster. as well as the time shift function, can only be If the message »URI* protected! PVR func- carried out using an external data medium tion is blocked« appears on the screen, then (hard drive or USB stick). recording or timeshift is restricted (one record- ing possible) or disabled (recording not pos- Recordings can be made with most data me- sible) by the broadcaster. dia on the market. However, we cannot guar- * U RI = User right information (Copyright infor- antee operation for all data media. mation).

  • Page 35: Connecting External Data Media

    USB­RECORDING ­------------------------------------------------------------------------------------------- ­ C onnecting­external­data­media­ Notes: The USB1 socket of the television supplies Notes: a maximum power of 500 mA in accor- Before connecting the external data dance with USB specifications. External medium it is recommended to switch the hard disks which require more power may television to stand-by mode. therefore only be connected to the USB2­ Before removing the external data medium, of the television. the television must be switched to standby, If you use a network cable for external hard so that no data loss occurs. disks which have been connected to the Your television features two USB sockets, USB2 socket of the television, this network USB1 and USB2. cable must also be disconnected from USB2 is used to connect data m edia, which the power supply when the television is require an additional power supply. switched off. – for example, external hard disks. External data media may not be discon- nected from the television while files on the data medium are being accessed. ­ S ettings­for­USB­recording ­ S electing­the­menu 1­...
  • Page 36 USB­RECORDING ­------------------------------------------------------------------------------------------- Formatting­the­external­data­media Selecting­a­partition­on­the­external­ data­medium A new, external data media must be formatted before the recording. If the external data medium features several par- titions, select the partition you would like to use. 1­ Select the »Format Partation« line with » « or » « button and confirm with »OK« Λ 1­ Select the line »Partition« with » « or » «. Λ button. < 2­ Select the partition you wish to use with » « > 2­ To confirm the formatting operation press or » «. » « (green) button;  3­ Press »MENU« to end the setting. Safely­remove­disk to cancel formatting operation press » «  1­ Select the line »Safely Remove Disk« with (red) button.

  • Page 37: Recording Programmes

    USB­RECORDING ­------------------------------------------------------------------------------------------- ″Pausing”­time­shift­pro- Recording­programmes grammes You can record programmes. The data for these programmes is recorded on an external data You can pause the programme you are watch- medium and this archive is administered via the ing. This is a useful function, for example if the television. telephone rings while you are watching a film and you do not want to miss anything. You need 44 MB till 110 MB of memory capac- ity on the external data medium for A freeze-frame display of the last scene appears 1 minute recording time. on the screen and the programme is recorded in the time shift memory of the external data While recording, you can watch another pro- m edium. gramme from the archive. Note: Note: The external hard disk or the USB memory The external hard disk or the USB memory stick you connected to the TV should be stick you connected to the TV should be formatted by the TV before recording or formatted by the TV before recording or doing time shift. doing time shift. 1­ Press » « to pause the current programme. One-touch­programme­recording – T he picture is frozen, the time shift and the 1­...

  • Page 38: Presetting Programmes To Be Recorded

    USB­RECORDING ­------------------------------------------------------------------------------------------- Recording­a­programme­from­the­chan- Presetting­programmes­to­be­ nel­list recorded 1­ Open the »CHANNEL LIST« with »OK«..­using­the­electronic­TV­guide 2­ Select a television channel with » «, » «, Λ < > You can use data from the electronic TV guide » « or » « and press »OK« to confirm. for recording. 3­ Press »MENU« to exit the channel list. 20 programmes can be preset for the timer r ecording or as a reminder. 4­ Press » « to start recording. – I nformation on the recording is displayed: 1­ Press »GUIDE« to display channel informa- the recording symbol, the channel name, tion. the programme, the recording time and – T he electronic TV guide appears. the available memory space.
  • Page 39 USB­RECORDING ­------------------------------------------------------------------------------------------- ...­by­manual­data­entry Editing­recording­data­in­the­­ timer­menu You can preset up to 20 programmes for timer recording. You can edit the data for programmed timer r ecordings. 1­ Press »GUIDE« to display channel informa- tion. 1­ Select the timer menu by pressing – T he electronic TV guide appears. »GUIDE«, » « (yellow) and » « (blue)   in succession. 2­ Open the »MAKE SCHEDULE« menu by – T he »SCHEDULED EVENTS« menu ap- pressing » « (yellow) twice.  pears. 3­ Select the line »Type« with » « or » « Λ 2­ Select the title of the programme to be <...

  • Page 40: Playback

    USB­RECORDING ­------------------------------------------------------------------------------------------- Playback 5­ Select the programme you want with » « or » « and press » « (red) to start Λ  The recorded programmes – whether started p layback. manually or using the timer function – are stored – T he recording continues in the back- on the external data medium. ground. Selecting­a­programme­from­­ 6­ Press » « to end playback. the­archive 7­ Press » « to stop recording. 1­ Open the menu with »MENU«. Deleting­programmes­in­the­recording­ 2­ Select the menü item »USB RECORDING« list with » « or » « and press »OK« to Λ confirm. You can delete programmes from the recording list.

  • Page 41: Usb­operation

    USB­OPERATION ­-------------------------------------------------------------------------------------------- File­formats Audio­data Your television can play audio data in the for- Your television can work with the following file mats MP3, AAC. formats using the USB sockets: MP3 is the abbreviation for MPEG-1 Level 3 Video­data and is based on the MPEG-1 standard, which was developed by the MPEG (Motion Picture Special codecs for video compression and Expert Group). d ecompression provide more memory space without compromising the picture quality exces- AAC stands for Advanced Audio Coding and sively. was also developed by MPEG. AAC provides Your television plays video files in the formats better sound quality at an identical data rate. XVID, H.264/MPEG-4 AVC (L4.1, 4 reference These formats allow audio files to be recorded pictures), MPEG-4, MPEG-2, MPEG-1, MJPEG and played which sound as good as a CD, and MOV. while taking up only a fraction of the memory The following file name extensions are also space. supported: “.avi”, “mkv”, “.mp4”, “.ts”, “.mov”, File name extensions which are supported: “.mpg”, “.dat”, “.vob”,”.divx”. MP3, MP2, M4A, AAC. Format (codec) information is embedded within the file content and may differ depending on the MP3 files can be organised into folders and file extension. “.avi”, “.mkv” or “.divx” files con- s ubfolders, as on the computer. taining divx codec within are not playbacked.

  • Page 42: Connecting External Data Media

    USB­OPERATION ­-------------------------------------------------------------------------------------------- ­ C onnecting­external­data­media­ Before connecting the external data medium it is recommended to switch the television to stand- by mode. SERVICE Before removing the external data medium, SATELLITE ANT-IN Optic Out USB2 HDMI2 13/18V max. 500mA max. 50mA the television set must be switched to standby, so that no data loss occurs. Notes: The USB1 socket of the television set s upplies a maximum power of 500 mA in accordance with USB specifications. Exter- nal hard disks which require more power may therefore only be connected to the USB2 of the television set. If you use a network cable for external hard 1­ Press » «, »1…0« or »P+« or »P-« to disks which are connected to the USB2 switch on the television from standby mode. socket on the television, this network cable must also be disconnected from the power 2­ Connect the USB2 socket of the television supply when the television is switched off.

  • Page 43: The Media Player

    USB­OPERATION ­-------------------------------------------------------------------------------------------- The­media­player Settings­in­the­USB­setup­menu The media player displays video, audio and Selecting­the­menu p icture files stored on external data media. 1­ Press »My­Media« to select the external If an external data medium contains files in data medium. d ifferent formats, you can, when necessary, filter 2­ Open the menu with »MENU«. out the formats not required. 3­ Select the menu item »SOURCE SETUP« with » « or » « and press »OK« to Λ confirm. 19:10 I xx.xx.xxxx – T he »SOURCE SETUP« menu a ppears. VIDEO FILES Note: ROOT Photo Additional functions are explained in the Music f ollowing sections. Film Switching­on­automatic­preview If this function is switched on, a preview of the...

  • Page 44: Basic Playback Functions

    USB­OPERATION ­-------------------------------------------------------------------------------------------- Basic­playback­functions­ Notes: Use » « to select »Up Folder«, when you Λ 1­ Press »My­Media« to select the external would like to return to the last folder. data medium. Use »Root« (and then press »OK«) to return – T he media player appears. to the main folder. 2­ Select the file format (video files, audio files, It is possible that files which are actually picture files) with » « or » «. Λ supported do not function correctly in USB mode. This is because certain files are not 3­ Switch to the folder/file list with »OK«. recorded with standardised compression Notes: processes, although they feature the “right” If two USB data media are connected, file ending. select the desired data media with » « or If a video file features several audio tracks » « and open with »OK«. Λ (audio streams), you can switch these over USB data medium with several partitions is during playback in full screen mode with connected to the USB sockets, the letter for »...

  • Page 45: Additional Playback Functions

    USB­OPERATION ­-------------------------------------------------------------------------------------------- Additional­playback­functions Selecting­a­track­or­picture­in­steps­ (SKIP) Depending on the file format, the following 1­ During playback, select the next track/ a dditional functions are available: picture with » «. Selecting­chapters­files 2­ During playback, select the previous track/ (only video files) picture with » «. – P layback begins with the track or picture 1­ During playback, select the next chapter > you selected. with » «. 2­ During playback, select the previous chap- Selecting­a­certain­passage­for­ < ter with » «. playback Note: (video files only) You can also select chapters by entering the 1­ During playback, press »OK«. chapter number with »1...0«. 2­...

  • Page 46: Language­settings

    LANGUAGE­SETTINGS ­ - ---------------------------------------------------------------------------- Opening­the­SETTINGS­menu ­ C hanging­the­audio­language 1­ Open the menu with »MENU«. (only for digital television channels) You can define a primary and a secondary 2­ Select the menu item »SETTINGS« menu audio language. with » « or » « and press »OK« to Λ confirm. 1­ Select the line »Audio« with » « or » « Λ – T he »SETTINGS« menu appears. and press »OK« to confirm. – T he »Select Audio Language« menu a ppears. xx.xx.xxxx 15:46 SETTINGS < > 2­ Select the audio language with »...

  • Page 47: Accessibled­functions

    ACCESSIBLED­FUNCTIONS­ ­ ----------------------------------------------------------------- ­ C hanging­the­subtitle­language 6­ Select the line »Subtitle Mode« with » « or » « and then set the preferred option Λ and­subtitle­mode < »Off«, »Automatic« or »Basic« with » « or (only for digital television channels) > » «. You can switch the subtitles on and off, select 7­ Press »MENU« to end the setting. the subtitle language and allocate a second subtitle language. Audio­description­(Audio­sub- 1­ Open the menu with »MENU«. titles) 2­ Select the menu item »SETTINGS« menu Audio description is an additional audio chan- with » « or » « and press »OK« to Λ nel for visually-impaired persons. Descriptions confirm. are provided of activities, surroundings, changes – T he »SETTINGS« menu appears. of scene, gestures and actors' facial expressions.

  • Page 48: Date­and­time­settings

    DATE­AND­TIME­SETTINGS ­----------------------------------------------------------------- Opening­the­SETTINGS­menu ­ M anual­setting 1­ Open the menu with »MENU«. You can also set the difference in time manu- ally – for example, when the correct time is not 2­ Select the menu item »SETTINGS« menu detected automatically or does not correspond with » « or » « and press »OK« to Λ to local time for other reasons. confirm. 1­ Select the line »Time Adjustment« with » «, – T he »SETTINGS« menu appears. < then select the option »Manual« with » « > or » «. xx.xx.xxxx 15:46 – T he lines »Time Zone« and »Daylight Sav- SETTINGS ing« are active. 2­ Select the line »Time Zone« with » « and Language settings press »OK« to confirm.

  • Page 49: Timer­functions

    TIMER­FUNCTIONS ­ - -------------------------------------------------------------------------------------- Opening­the­SETTINGS­menu ­ S witch-on­timer 1­ Open the menu with »MENU«. In the »Auto On« menu you can enter a switch- on time for the television. After the preset time 2­ Select the menu item »SETTINGS« menu has elapsed, the television switches on from with » « or » « and press »OK« to Λ standby – at the preselected volume and the confirm. preselected television channel. – T he »SETTINGS« menu appears. 1­ Select the line »Auto On« with » « or » « Λ and press »OK« to confirm. xx.xx.xxxx 15:46 SETTINGS 2­ Select the line »Mode« with » « or » « Λ < >...

  • Page 50: Switch-Off Timer

    TIMER­FUNCTIONS ­ - -------------------------------------------------------------------------------------- Switch-off­timer In the »Auto Off« menu, you can enter a time for the television to switch off. After this time has elapsed, the television switches to standby mode. 1­ Select the line »Auto Off« with » « or » « Λ and press »OK« to confirm. 2­ Select the line »Mode« with » « or » « Λ < > and use » « or » « to set the preferred mode. 3­ Select the line »Set Hour« with » « or » « Λ and enter the time with »1…0«. 4­ Save the data with » « (green).  Note: You can abort the entry by pressing » «  (red).

  • Page 51: Parental­settings

    PARENTAL­SETTINGS ­ - -------------------------------------------------------------------------------- Opening­the­SETTINGS­menu ­ A uthorising­programmes 1­ Open the menu with »MENU«. There are films which may be wholly or partially unsuitable for children. 2­ Select the menu item »SETTINGS« menu These programmes contain information which with » « or » « and press »OK« to Λ marks the content or scenes with access levels of confirm. 4 to 18. You can select one of the access levels, – T he »SETTINGS« menu appears. thereby authorising playback. 1­ Select the line »Parental Guidance« with xx.xx.xxxx 15:46 > SETTINGS » « or » « and press » « to confirm. Λ 2­ Enter the PIN code »1234« with »1 ... 0«. < >...

  • Page 52: Locking Keys (Parental Lock)

    PARENTAL­SETTINGS ­ - -------------------------------------------------------------------------------- < > Locking­keys­(Parental­lock) 6­ Select the column »Lock« with » « or » « and press »OK« to lock the channel. When the key lock is activated, the buttons on 7­ Enter the PIN code »1234« with »1...0«. the television set do not function. – The channel is marked using »✔«. 1­ Select the line »Keypad Lock« with » « or > » « and press » « to confirm. Λ Note: To remove the lock, select the channel 2­ Enter the PIN code »1234« with »1...0«. again with » « or » «, press »OK« to Λ 3­ Activate (On) or deactivate (Off) the key confirm and then enter the PIN code 1 2 3 < > lock with » « or » «.

  • Page 53: Software­of­the­device

    SOFTWARE­OF­THE­DEVICE ­--------------------------------------------------------------- Opening­the­SETTINGS­menu Updating­software­ 1­ Open the menu with »MENU«. (for digital channels only) 1­ In the »SETTINGS« menu, select the line 2­ Select the menu item »SETTINGS« menu »Check For Updates updates« with » « or with » « or » « and press »OK« to Λ » « and press »OK« to confirm. Λ confirm. – A search for new software will be made – T he »SETTINGS« menu appears. and – if available – it will be installed. Note: xx.xx.xxxx 15:46 SETTINGS If a search for software updates should be made automatically, select the line »Auto OAD Update« with » « or » « and use Λ < > Language settings »...

  • Page 54: Reset­functions

    RESET­FUNCTIONS ­ - --------------------------------------------------------------------------------------- ­ ­ R estoring­the­television­to­the­ default­settings This function allows you to delete the channel lists and all custom settings. 1­ Open the menu with »MENU«. 2­ Select the menu item »SETTINGS« menu with » « or » « and press »OK« to Λ confirm. – T he »SETTINGS« menu appears. xx.xx.xxxx 15:46 SETTINGS Language settings English Menu Audio English Subtitle English Subtitle Mode Hard of Hearing Date and time settings Date &...

  • Page 55: Operation­using­external

    OPERATION­USING­EXTERNAL­DEVICES ­------------------------ DIGI­LINK Switching­off­the­external­device­ automatically Your television is equipped with If you switch your television to standby, the the DIGI LINK function. external device (if it is switched on) will also be This function uses the CEC switched to standby. (Consumer Electronics Control) DIGI LINK is always active on your television protocol. set. CEC allows external devices which are con- nected to the HDMI sockets by an HDMI cable Searching­for­and­activating­­ (e.g. DVD player) to be operated with a remote external­devices control. You can connect up to 11 devices with Prerequisite is that the devices connected sup- DIGI LINK functions to your television. port CEC. Read the operating manual for the 1­ Open the Tools menu with »TOOLS«. external device to find out how to activate the corresponding function. 2­ Select the menu item »CEC« with » « or » « and press »OK« to confirm. Λ The­DIGI­LINK­functions­on­your­ – T he »HDMI CEC Device List« appears. television 3­...

  • Page 56: Device Operation

    Source HDMI1 < > 1­ Press » «, use » «, » «, » « or » « to Λ select the preset »HDMI1« or »HDMI2« and DIGILINK press »OK« to confirm. Device Selection GRUNDIG 2­ Open the menu with »MENU«. Remote Control RC Passthrough 3­ Select the menu item »SOURCE SETUP« Device Standby with » « or » « and press »OK« to Λ confirm. – T he »SOURCE SETUP« menu appears. 4­ Select »Device Standby« with » « or »...

  • Page 57: High Definition Hd Ready

    OPERATION­USING­EXTERNAL­DEVICES ­------------------------ ­ H igh­definition­­ ­ HD­ready ­ C onnection­options Connect the corre- Which television socket(s) you connect your sponding input sources external devices to depends on the sockets (e.g. HDTV receiver the external device is equipped with and or HD-DVD player) to the signals which are available. the HDMI sockets (for Please note: With many external devices, digital HDTV sources). the resolution of the video signal must This ensures that you be adjusted to the input sockets of the can view digital HDTV p rogrammes, even if they television (see the operating manual of the are copy-protected (HDCP High Bandwidth external device). You can find out which Digital Content Protection), without encountering values you need to set by referring to the problems. guidelines in the sections about the various connection options. Do not connect any other equipment while the device is switched on. Also switch off the other equipment before connecting it. Do not plug in the power cord of the device until you have connected the external equipment and the antenna.

  • Page 58: Connecting External Devices

    OPERATION­USING­EXTERNAL­DEVICES ­------------------------ Connecting­external­devices Using­a­DVD­player,­ DVD­­ r ecorder,­video­recorder­­ ...­with­digital­audio/video­signals or­set-top­box Suitable devices: Digital satellite receivers, 1­ Switch on the external device and select the Playstation, BluRay player, DVD player/ function you wish to use. recorder, set-top box, notebook, PCs. < > 2­ Video signal: Digital video; resolution: stan- Press » «, use » «, » «, » « or » « to Λ dard 576p; HDTV 720p, 1080i, 1080p. select the preset for the input signal (»AV1«, Audio signal: digital audio (stereo, multi-chan- »S-VHS«, »HDMI1«, »HDMI2« or »Compo- nel compression, uncompressed). nent«) and press »OK« to confirm. Presets »HDMI 1« or »HDMI2«. Headphones 1­ Connect the HDMI1 or HDMI2 socket on the television and the corresponding Connecting­the­headphones HDMI socket on the external device using 1­ Plug the headphone jack (3.5 mm ø jack a standard HDMI cable (digital video and plug) into the headphone socket on the left...

  • Page 59: Hi-Fi System/Av Receiver

    OPERATION­USING­EXTERNAL­DEVICES ­------------------------ Hi-fi­system/AV­receiver Playing­the­audio­signal­via­the­­ HiFi­system Connecting­the­hi-fi­system/­ 1­ Connect the socket on the television to AV­receiver the corresponding socket of the AV receiver with an cable (digital audio signal). 1­ Connect the Optic­Out socket on the television to the corresponding socket of the Note: device with an optical digital cable (digital If this function is not activated, the audio audio signal). signal is transmitted to the HiFi system/ AV receiver (connected to 3.5 mm ø jack Setting­the­audio­format plug) into the headphone socket on the left You can select whether the audio signal output side of the television. via the Optic­Out socket should be in the PCM 1­ Open the menu with »MENU«. or AC2 format. 2­ Select the menu item »SOUND SETTINGS« 1­ Open the menu with »MENU«. with » « or » « and press »OK« to Λ 2­ Select the menu item »SOUND SETTINGS« confirm.

  • Page 60: Operation­with­a­common

    OPERATION­WITH­A­COMMON­INTERFACE ­-------------- SERVICE SATELLITE ANT-IN Optic Out USB2 HDMI2 13/18V max. 500mA max. 50mA ­ W hat­is­a­Common­Interface? ­ A ccess­control­for­CI­module­and­ smart­card Common Interface (CI) is an interface for DVB receivers. 1­ Open the menu with »MENU«. Encrypted channels can only be viewed 2­ Select the menu item »SOURCE SETUP« with a CA module suitable for the encryp- with » « or » « and press »OK« to Λ tion system and in conjunction with the confirm. c orresponding smart card. – T he »SOURCE SETUP« menu appears. The television set is equipped with a Com- 3­...

  • Page 61: Setting­further­channels

    ­ S ETTING­FURTHER­CHANNELS ­----------------------------------------------------- Update­for­digital­channels­from­ 7­ Select the line »Scan Mode« with » « or » «. Λ a­satellite­automatically < > Select the scan mode with » « or » « Satellite data changes frequently, new channels (for unencrypted channels, for encrypted are constantly being added. You should there- channels only, or both). fore perform an automatic search from time 8­ Select the line »Service Type« with » « or to time. » «. Λ This searches all transponders for new channels. < > Use » « or » « to select whether you want 1­ Open the menu with »MENU«. to search for television channels (TV) only, radio stations only (Radio) or both 2­ Select the menu item »SOURCE SETUP«...

  • Page 62: Searching For Digital Channels From A Satellite Manually On A Transponder

    SETTING­FURTHER­CHANNELS ­----------------------------------------------------- Searching­for­digital­channels­ ­ Service­Type­ < > Use » « or » « to select whether you want from­a­satellite­manually­on­a­ to search for television channels only (TV), transponder radio stations only ( Radio), or both (Radio If a certain channel cannot be found with + TV). automatic search, you can search it manually 6­ Start the scan with » « (red).  by manual search function. You must enter all – T he »Results« menu appears, and the scan parameters of the channel correctly. You can for TV channels begins. obtain the current transponder information from teletext page, satellite TV magazines or internet. Note: You can abort the search by pressing 1­ Open the menu with »MENU«. »MENU«. 2­ Select the menu item »SOURCE SETUP« 7­ Press »MENU« to end the setting. with »...

  • Page 63: Antenna Settings And Searching For Digital Channels From A Satel-Lite Automatically

    SETTING­FURTHER­CHANNELS ­----------------------------------------------------- Antenna­settings­and­searching­ 7­ Select the line »Scan Mode« with » « or » «. Λ for­digital­channels­from­a­satel- < > Select the scan mode with » « or » « lite­automatically (for unencrypted channels, for encrypted Notes: channels only, or both). The following description about the LNB set- 8­ Select the line »Service Type« with » « or tings premise a substantial expertise about » «. Λ the satellite systems. Ask your specialist < > Use » « or » « to select whether you want dealer. to search for television channels (TV) only, 1­ Open the menu with »MENU«. radio stations only (Radio) or both (Radio + TV). 2­ Select the menu item »SOURCE SETUP«...

  • Page 64: Antenna Settings, Scr System And Search- Ing For Digital Channels From A Satellite Automatically

    Λ 8­ Select the line »Service Type« with » « or »OK« to confirm. » «. Λ ­ LNB­Type­ < > Use » « or » « to select whether you want If your antenna system is equipped with a to search for television channels (TV) only, single-cable system multiswitch, use the op- radio stations only (Radio) or both tion »Grundig SCR«. Press »OK« and select (Radio + TV). < > the »Grundig SCR« option with » « or » «. 9­ Start the scan with » « (red).  Select the »LNB-Frequency High« line with – T he »Results« menu appears, and the scan » « and enter the frequency with »1...0« for TV channels begins. in five digits. Select the »LNB-Frequency Low« line with »...

  • Page 65: Antenna Settings For Diseqc 1.0/1.1And Searching For Digital Channels From A Satellite Automatically

    SETTING­FURTHER­CHANNELS ­----------------------------------------------------- Antenna­settings­for­DiSEqC­ Notes: When updating via the same satellites a 1.0/1.1­and­searching­for­digital­ security query is displayed at the start of a channels­from­a­satellite­auto- search. matically If the previously stored channels should Note: be retained in the channel list and the new channels found be added to it, then press The following description about the LNB set- » « (green). tings premise a substantial expertise about  If » « (red) is pressed, the saved channels the satellite systems. Ask your specialist  will be deleted from the current channel list. dealer. – T he »Results« menu appears, and the scan 1­ Open the menu with »MENU«. for channels begins. 2­ Select the menu item »SOURCE SETUP« – D epending on the number of channels re- with » « or » « and press »OK« to Λ ceived, this can easily take a few minutes.
  • Page 66 SETTING­FURTHER­CHANNELS ­----------------------------------------------------- If » « (red) is pressed, the saved channels ­ DISEqC­ M ode­  will be deleted from the current channel list. Based on the number of current satellite sys- – T he »Results« menu appears, and the scan tem, select the option »Off«, »DiSEqC 1.0« < > for channels begins. or »DiSEqC 1.1« with » « or » «. – D epending on the number of channels re- – » Off«: For satellite systems with single ceived, this can easily take a few minutes. antenna. – T he search is complete as soon as the – » DiSEqC 1.0« switch allows for receiving »PROGRAM TABLE« appears. from maximum four satellites at the same Note: time. < >...

  • Page 67: Searching For Channels From The Cable Provider Automatically

    SETTING­FURTHER­CHANNELS ­----------------------------------------------------- ­ S earching­for­channels­from­the­ 6­ Select the line »Cable Scan Type« with » « or » « and set the option »Quick« or »Full« Λ cable­provider­automatically < > with » « or » «. 1­ Open the menu with »MENU«. – T he search function »Quick« sets the channels according to the information 2­ Select the menu item »SOURCE SETUP« provided by your cable provide in the with » « or » « and press »OK« to Λ transmission signal. confirm. – I f the option »Full« is selected, the entire – T he »SOURCE SETUP« menu appears. frequency range will be scanned. The 3­ Select the line »Source« with »...

  • Page 68: Searching For Channels From The Cable Provider Manually

    SETTING­FURTHER­CHANNELS ­----------------------------------------------------- ­ S earching­for­channels­from­the­ ­ S earching­for­digital­terrestrial­ cable­provider­manually TV­channels­automatically 1­ 1­ Open the menu with »MENU«. Open the menu with »MENU«. 2­ Select the menu item »SOURCE SETUP« 2­ Select the menu item »SOURCE SETUP« with » « or » « and press »OK« to with » « or » « and press »OK« to Λ Λ confirm. confirm. – T he »SOURCE SETUP« menu appears. – T he »SOURCE SETUP« menu appears. 3­ 3­ Select the line »Source« with » « or » « Select the line »Source« with » «...

  • Page 69: Searching For Digital Terrestrial Tv Chan- Nels Manually

    SETTING­FURTHER­CHANNELS ­----------------------------------------------------- 6­ Select the line »Scan Typ« with » « or » « 5­ Select the line » Digital Manual Tuning« with Λ < > and set the option »DTV« with » « or » «. » « or » « and press »OK« to confirm. Λ – T he menu appears. 7­ Start the scan with » « (red).  6­ – A ll channel and favourites lists will be Enter the channel number directly with d eleted and compiled anew. »1...0«. – A fter the search is complete, the channels Note: found are displayed in the »Results« menu. After starting the scan, a security query will 7­ Press »MENU« to finish the setting.

  • Page 70: Tuning Analogue Television C Hannels

    SETTING­FURTHER­CHANNELS ­----------------------------------------------------- ­ ­ T uning­analogue­television­ 4­ Select the line »Automatic Channel Search« with » « or » « and press »OK« to Λ ­ c hannels confirm. This setting is only necessary if you cannot re- ceive any digital channels and you have not car- xx.xx.xxxx SOURECE SETUP ried out an analogue search during initial setup. 15:46 The television channels can be set directly or using the scan. Source Switching­the­television­to­­ a nalogue­ Automativ Channel Search reception Digital Manual Tuning Note: Analogue Manual Tuning Analogue channels can be selected if the Program Table option »Air« or »Cable« has been selected.

  • Page 71: Changing Stored Analogue C Hannels

    SETTING­FURTHER­CHANNELS ­----------------------------------------------------- Tuning­the­television­channels­by­enter- 6­ Press » « (blue) to save the setting.  ing­the­channel­numbers Note: 1­ Open the menu with »MENU«. If you wish to remedy other television chan- nels, repeat steps 4 to 6. 2­ Select the menu item »SOURCE SETUP« « or » « and press »OK« to with » Λ 7­ Press »MENU« to end the setting. confirm. – T he »SOURCE SETUP« menu appears. Changing­stored­analogue­ ­ c hannels 3­ Select the line » Analogue Manual Tuning« with » « or » « and press »OK« to Λ If channels were stored with the automatic chan- confirm. nel search while tuning the television channels, – T he menu appears. you can delete them. You can also store chan- nels in a different preset, change or enter the name of a channel as well as skip channels.

  • Page 72: Displaying Signal Information

    SETTING­FURTHER­CHANNELS ­----------------------------------------------------- Skipping­television­channels Displaying­signal­information You can highlight television channels to be (for digital channels only) skipped when you select with » « or » «. Λ 1­ Open the menu with »MENU«. S election is still possible using the number b uttons. 2­ Select the menu item »SOURCE SETUP« with » « or » « and press »OK« to Λ 1­ In the »PROGRAME TABLE« menu, switch confirm. over to the list view with » « (yellow).  3­ Select the line »Signal Information« with 2­ Select the preferred channel with » « » « or » « and press »OK« to confirm. Λ or » «. Λ – I nformation on the channel, network, <...

  • Page 73: Information

    INFORMATION ­------------------------------------------------------------------------------------------------- GRUNDIG­43­VLE­5523­BN Digital­reception­ranges Satellite Ku band: 10,700 MHz … 12,750 MHz Product­data­sheet Modulation: D VBS QPSK, DVBS2 QPSK, 8 PSK Energy­efficiency­class IF band: 950 MHz … 2150 MHz A+ Signal level: –25 dBm … –65 dBm Screen­diagonal Cable 108 cm/43 inch Overall band: 110 MHz … 862 MHz Power­consumption Modulation: 1 6 QAM, 32 QAM,64 QAM, Operation 53 W/100 W max. 128 QAM and 256 QAM Standby < 0.50 W Symbol rate: 4.0 Msym/s … 7.2 Msym/s Annual­power­consumption Terrestrial­(DVB-T) 77 kWh V HF/UHF-Band, bandwidth 7 MHz and Maximum­resolution 8 MHz 1920 × 1080...

  • Page 74: Service Information For Dealers

    INFORMATION ­------------------------------------------------------------------------------------------------- Service­information­for­dealers Note­for­the­Product­Package The product complies with the Packaging materials of your product are recy- following EU directives and clable. Please ensure that packaging materials regulations: of your product are disposed of separately in 2006/95/EC: Directive on accordance with the regulations set by the lo- the harmonisation of the laws cal authorities in order to have the packaging of Member States relating to designed for use materials included in the environmental friendly within certain voltage limits. recycling process. 2004/108/EC: Directive relating to electro- Cleaning­the­TV­set magnetic compatibility. 2009/125/EC: Ecodesign requirements Pull the power cord out of the mains socket. for energy-using products; Clean the appliance with a damp cloth and Implementing Reg (EC) No 642/2009: a mild detergent. Do not use any detergents Ecodesingn requirements for Televisions; containing alcohol, spirit, ammonia or scouring Implementing Reg (EC) No 278/2009: agent. Ecodesingn requirements for no-load condition Use a damp, soft cloth to clean the screen. Do electric power consuption and average active not use water with soap or detergent. efficiency of external power supplies. (for mod- els with AC/DC external adaptor) Explanation­of­the­symbols­ 2 010/30/EU: Directive on the indication by which­may­be­present­on­back­...

  • Page 75: Troubleshooting

    INFORMATION ­------------------------------------------------------------------------------------------------- Troubleshooting If the information provided below does not help, please consult an authorised GRUNDIG dealer. Please bear in mind that malfunctions can also be caused by external devices such as video record- ers or satellite receivers. Problem Possible­cause Remedy Screen lit (snow), but no Antenna cable Is the antenna cable connected? s tation visible No TV channel tuned Start a channel scan Insufficient contrast in The picture settings are not cor- Adjust the brightness, contrast or picture rect c olour setting Problem at station Try another channel Picture and/or sound dis- Interference from other devices Place the device in a different torted position Ghosting, reflection Channel setting Automatic or manual tuning/fine tuning Antenna Have antenna cable or system checked No colour Colour intensity too low Turn up the colour...

  • Page 76: Glossary

    GLOSSARY ­ - ------------------------------------------------------------------------------------------------------------- Depending on the television model. Dynamic­Backlight Here the device optimally adjusts the back Backligh lighting for the picture content by regulating the Manual setting for back lighting (only active if back lighting depending on the average pic- dynamic back lighting is switched to “OFF”). ture brightness. If a picture has predominately This setting also directly impacts power con- dark areas, then the black level displayed is sumption. improved by downward adjustment of the back lighting (in this case the display of the dark ar- Block­Noise­Reduction eas is improved), and with predominantly bright This function can only be selected with digital picture material the back lighting is maximised in order to display these areas more brightly. reception sources and AV presets. It reduces any interference from artefacts (pixel blocks) from DTS­TruSurround digital programmes due to MPEG compression (such as from DVB-T receivers and lower trans- DTS TruSurround is an advanced surround mission rates or DVD players). sound solution package that extracts and posi- tions the exact audio signals for an atmospheric Boot­loader­version surround sound experience using the built-in TV Boot loader is a software application that is speakers. To complete the audio experience, loaded by the device firmware from a bootca- post-processing and psychoacoustic methods are used which provide 3D audio playback in pable medium and then executed. The boot accordance with the video content - for optimis- loader then loads further parts of the operating ing bass and dialogue and delivering unified...
  • Page 77 GLOSSARY ­ - ------------------------------------------------------------------------------------------------------------- Film­mode Detects and processes feature films automati- Low Noise Block is located in the centre of a cally for all channel sources. This means you will parabolic antenna. always receive an optimal picture. It converts the satellite frequency from, for ex- This functions in the modi 480i, 576i and 1080i ample, 10.7 to 11.75 or 11.8 to 12.75 GHz to in TV playback and for other channel sources. the 950-2150 MHz range, thereby enabling the If the »Film mode« is switched on for pro- cable transmission using a coaxial cable and grammes without a feature film signal, minor more recently also with optical fibre and recep- problems such as picture freeze, defective sub- tion with a satellite receiver. titles or fine lines in the picture could occur. MEMC Firmware­version Improves the display of moving images through Firmware is the term used for software that is em- the additional computation of intermediate pic- bedded in a programmed chip (microcontroller). tures and is only available for devices from 32”. It is mostly stored in a flash memory, an EPROM It is displayed with a PPR of 400 (Picture Perfec- or an EEPROM. The firmware contains functions tion Rate). If the adjustment value is too high, for controlling the device. this may result in ghosting with poor transmission due to the incorrect computation of the interme- Gamma diate pictures. This setting establishes which brightness value should be displayed for which digital transmis- sion value. Most recordings are transmitted with MP3 is the abbreviation for MPEG-1 Level 3 a gamma value of 2.2 (all Windows PCs and...
  • Page 78 GLOSSARY ­ - ------------------------------------------------------------------------------------------------------------- Symbolrate This is the number of transmitted symbols in the digital transmission technology per time unit Timeshift You can pause the programme you are watch- ing. This is a useful function, for example if the telephone rings while you are watching a film and you do not want to miss anything. The programme is saved in the time¬shift memo- ry of the external data medium. A maximum of 60 minutes of the current programme can be recorded in the time shift memory. Transponder A transponder receives data on a satellite and then transmits it again. For example, an earth station can transmit data signals for television channels to a geostationary satellite, which sends this back to earth. Any suitable satellite antenna with visual contact to the satellite can receive the signal. USB-Recording Enables recording and playback of television programmes with digital television channels (DVB-S, DVB-T and DVB-C). This depends on the broadcaster. Recording and playback of programmes can only be carried out using an external data me- dium (hard drive or USB stick). Vibrant­Colour Increases the colour contrast and the contrast adjustment. This setting is mostly too strong for use with normal pictures and should only be used where necessary (low or off) otherwise nuances in the image can be suppressed. 78­ ENGLISH...

  • Page 79: Index

    Automatic switch-off(Auto Sleep)..50 Enlarging the character height..33 Automatic volume..27 Entering channel names (8 digit maximum)..72 Entering the switch-off time (sleep timer)..30, Balance..26 Environmental note..75 Basic playback functions..44 Equalizer..27 Explanation of the symbols which may be pres- ent on back side of the television set..75 Change the order of the channels in the pro- gram table..22 Changing stored analogue channels..71 Fast forward..45 Changing the audio language..46 File formats..41 Changing the headphone volume..58 Formatting the external data media..36 Changing the menu language..46 Freeze-frame..28 Changing the picture format..31 Changing the PIN code..52 Changing the program table for the digital Grundig SCR system..7 channels..21 Changing the subtitle languageand subtitle mode..47 Headphones..58 Cleaning the TV set..75 Hi-fi system/AV receiver..59 Connecting external data media..35, 42 High definition HD ready..57 Connecting external devices..58 Connecting the antenna and the power adapter..10 Image data..41 Important notes on environmental protection..8 79­ ENGLISH...
  • Page 80 INDEX ­ - --------------------------------------------------------------------------------------------------------------------------- Information on recording and playing television Revealing answers..33 programmes..34 Rotating pictures..45 Initial set-up and tuning television channels..17 Inserting batteries into the remote control..12 Safely remove disk..36 Inserting the CA module..60 Searching for and activating external devic- es..55 Locking keys (Parental lock)..52 Searching for digital television channels from a Locking menus..51 satellite manually..63 Locking television channels..52 Searching for digital terrestrial TV channels automatically..68 Searching for digital terrestrial TV channels Main menu of the file browser..43 manually..69 Manual setting..48 Searching for television channels from the cable provider automatically..67 Searching for television channels from the cable Normal text mode..33 provider manually..68 Note for the Product Package..75 Selecting a certain passage forplayback..45 Notes on still images..8 Selecting a partition on the external data medium..36 Selecting a preset AV channel..28 One-touch programme recording..37 Selecting a track or picture in steps (SKIP)..45 Optional accessory..9 Selecting channel lists..21 Selecting channels..28 Selecting channels from lists..28 Page hold..33...
  • Page 81 INDEX ­ - --------------------------------------------------------------------------------------------------------------------------- Software update (USB)..53 using the SCART socket (CVBS/RGB sig- Sorting channels in the favourite list..23 nal)..58 Sorting channels in the program table..22 Soundeffects..27 Video data..41 Sound settings..26 Volume..26 Special features of your TV..7 Split screen..33 Standart accessory..9 Watching a blocked television channel..52 Stereo/two channel sound, mono..26 What is a Common Interface?..60 Stereo width..26 with digital audio/video signals..58 Subtitles..29 S-Video signal..58 Switching off the external deviceautomati- Zapping function..29 cally..55 Zoom function..30 Switching on and off..28 Switching on automatic preview..43 Switching on the television automatically from standby..55 Switching sound on/off..28 Switching the device to standby..56 Switch-off timer..50 Switch-on timer..49 The DIGI LINK functions on your television..55 The file browser..43 The remote control – All functions..16 The remote control – Main functions..15 The various settings..17 TOP text or FLOF text mode..33 Troubleshooting..76 Tuning analogue television channels..70...
  • Page 82 Grundig Intermedia GmbH • Beuthener Strasse 41 • D–90471 Nürnberg...
