- Page 1 BW3451R 4.3” LCD Portable Wireless Baby Monitoring System For more exciting new products please visit our website: Australia: www.uniden.com.au...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This manual contains important information about this product’s operation. If you are installing this product for others, you must leave this manual or a copy with the end user. When using your equipment, always follow basic safety precautions to reduce the risk of fire, electric shock and injury to persons, including the following: • This equipment is NOT waterproof. - Page 3 • Clean only with a dry cloth. Failure to follow the instructions in this operating manual will void the warranty. Uniden assumes no liability for damages to property or injury to persons caused by improper handling or failure to comply with these safety...
-
Page 4: Table Of Contents
MONITOR INSTALLATION ........................7 CAMERA INSTALLATION ........................7 BAsIC oPeRAtIon .................... 8 WIRELESS CAMERA ........................... 8 WIRELESS MONITOR ..........................10 LCD Display ............................... 13 UsInG tHe BW3451R ..................15 Viewing Modes ............................15 sYsteM MenUs ....................16 SYSTEM ...............................16 Date/Time .................................17 Brightness ................................. 17 Format Storage ...............................18... - Page 5 NIGHT LIGHT ............................34 LULLABIES ..............................34 USING THE INTERCOM ...........................35 CAMERA PAIRING ............................35 MAINTAINING YOUR SYSTEM ....................... 35 tRoUBLesHootInG ..................36 sPeCIFICAtIon ................... 37 one-YeAR LIMIteD WARRAntY ..............39...
-
Page 6: What's In The Box
Screws & Anchors • If any item is missing or damaged, contact your place of purchase immediately. Never use damaged products! • Need help? Get answers at our website: www.uniden.com.au for Australian model All trademarks are registered trademarks of their respective owners. -
Page 7: Installation
InstALLAtIon MonItoR InstALLAtIon 1. Place the monitor in a location with clear reception from your camera(s). 2. If you are using the monitor as a stand-alone unit, flip out the stand on the back of the monitor and extend the antenna. Connect an AC adaptor to the power input on the side of the receiver. -
Page 8: Basic Operation
BAsIC oPeRAtIon WIReLess CAMeRA... - Page 9 Item What it does Light sensor: Measures light intensity on the camera side. Lens: Camera lens. Microphone: Receives sounds for the area near the camera, and transmits sound from the camera to the monitor. Temperature sensor: Detects temperature at camera side and displays it on the monitor LCD.
-
Page 10: Wireless Monitor
WIReLess MonItoR NOTE: RESET button on back of monitor. Item What it does Antenna: Receives video and audio signals from the camera. POWER: Turns the monitor on and off. Please note, if connected to the charge/ethernet cradle, the monitor cannot be powered off using the POWER switch. - Page 11 ▲Vol: • Increase speaker volume. • In Menus: Scroll up. • In Lullaby: Increase volume. • In Zoom: Scroll up. • In Video Playback - Pause or playback. CH◄: • In Menus: Scroll left. • In Zoom: Scroll left. • In Live view: Switch between available cameras. • In Video Playback - Fast reverse. ▼Vol: • Decrease speaker volume. • In Menus: Scroll down. • In Lullaby: decrease volume. • In Zoom: Scroll down. • In Video Playback - Stop playback. CH►: • In Menus: Scroll right. • In Zoom: Scroll right. • In Live view: Switch between available cameras • In Video Playback - Fast forward. Joy Stick: • Press down - To select a menu or accept a setting • Move Up/Down/Left/Right - To pan and tilt the camera. (Live and Zoom view) PLAY RECORD: Access video files. Microphone: Receives sound and transmits it to the camera, when the TALK button is pressed and held.
- Page 12 DC 5V: Connects the DC 5V power adaptor to the monitor. Charge LED • Green = Battery is fully charged. • Orange = Battery is almost charged. • Red = Battery is charging. If the monitor becomes unplugged from the adaptor, this LED turns off. LULLABY SKIP: Skips to the next lullaby in the series. See page 34 for details.
-
Page 13: Lcd Display
LCD Display Cam 1 21°C REC063020-1.AVI Item Icon What it does Signal Indicator (displays in full screen mode only). The number of bars in the signal indicator shows the strength of the signal received from the camera. One or no bars indicates the signal is poor, and 4 bars indicate a very strong signal. - Page 14 New Record Indicator. This flashing icon indicates when a new video record is available. Temperature indicator (displays in full screen mode 21°C only). Displays the temperature on the camera side. Night light indicator (displays in full screen mode only). Displays when the night light is turned on. (See page 34) Battery level.
-
Page 15: Using The Bw3451R
UsInG tHe BW3451R Viewing Modes Live view displays live images from the cameras in the following modes: • Quad mode: Monitor displays video from all cameras on a single screen in 4 quadrants. Any channel that does not have a camera is blank. • Single mode: Monitor displays video from one camera at a time. -
Page 16: System Menus
sYsteM MenUs Press MENU/BACK to access system menus. Use the navigating buttons to navigate up (▲Vol), down (▼Vol ), left (CH◄), and right (CH►) in the menus, then press JOY STICK (OK) to confirm a setting. Use CH► or CH◄ to focus on the 5 different system menu selections on the clothesline. • System • Power Save • Camera • Record • Alert sYsteM Move the focus to the System option and press JOY STICK (OK) to access the seven System options: • Date/Time... -
Page 17: Date/Time
Date/Time This option allows you to set the system date and time. The display format is Year.Month.Day Hour:Minute 1. From the System menu, select Date/Time and press JOY STICK (OK). The Date/Time screen displays. 11 30 10 30 2. Press ▲Vol or ▼Vol to increase/decrease the number for that setting. 3. -
Page 18: Format Storage
Format Storage Turning on Format Storage allows you to delete the files on your microSD card. (Default = No) 1. From the System menu, select Format Storage and press JOY STICK (OK). The Format Storage screen displays. 2. Press ▲Vol or ▼Vol to toggle between accepting or canceling the microSD card reformat. 3. Press JOY STICK (OK) to save the setting and return to the main System options. -
Page 19: Language
Language This option allows you to select the system’s display language from English, Español, or Français. (Default = English) 1. From the System menu, select Language and press JOY STICK (OK). The Language screen displays. 2. Press ▲Vol or ▼Vol to select a language. 3. Press JOY STICK (OK) to save the setting and return to the main System options. -
Page 20: Temperature Alert Range
Temperature Alert Range Your BW3451R measures the ambient room temperature around the camera. If the temperature falls outside of a preset range, the system alerts you. Temp. alert range lets you set that range. [Default = Low Temperature: 16°C ; High Temperature: 25°C; Off] 1. From the System menu, select Temp. alert range and press JOY STICK (OK). -
Page 21: Alert
ALeRt An alert triggers when either the temperature or the cameras go out of range. This option allows you to set the alert volume. There are 6 levels available. [Default = Zero (Mute)] 1. From the main menu selections, select Alert and press JOY STICK (OK). The Alert Volume screen displays. 2. Press CH► or CH◄ to adjust the volume. 3. Press JOY STICK (OK) to save the selection and return to the main menu selections. -
Page 22: Record
ReCoRD This option allows you to set the parameters for your recorded files. The RECORD options are: • Quality • Record Time • VOX • Overwrite Quality This option allows you to choose between a high or low resolution recording quality. (Default = Low 320 x 240) 1. -
Page 23: Vox
Record Time This option allows you to select how long the camera will record when the VOX sensitivity function is activated. (Default = 30 secs.) 1. From the Record menu, select Record Time and press JOY STICK (OK). The Record Time screen displays. 2. Press ▲Vol or ▼Vol to select a recording time block. 3. Press JOY STICK (OK) to save the selection and return to the main RECORD options. -
Page 24: Overwrite
2. Press ▲Vol or ▼Vol to toggle between Yes and No to activate or deactivate this feature. 3. Press JOY STICK (OK) to save the selection and return to the main RECORD options. Please use well-known brands of microSD cards to avoid operation errors. The BW3451R supports up to 32GB microSD cards. -
Page 25: Camera
CAMeRA This option allows you to pair the monitor with cameras (up to 4 cameras supported) to turn on/off individual camera. The cameras are still powered on but no longer visible to the monitor. 1. From the main menu selections, select Camera and press JOY STICK (OK). 2. -
Page 26: On/Off
2. Press ▲Vol or ▼Vol to select the camera you want to pair, then press JOY STICK (OK). The monitor prompts you to press the PAIR button on the bottom of the camera within 30 seconds. 3. Press PAIR button on the bottom of the camera within 30 seconds. 4. That camera’s video displays on the monitor when pairing is successful. # Pair the cameras to the monitor before mounting them. -
Page 27: Power Save
PoWeR sAVe Activating the Power Save feature turns off the LCD after two minutes of inactivity. Be sure that VOX is activated. However (see page 23), if VOX is deactivated, press any button on the monitor to turn the LCD back on. This option allows you to enable or disable this function. (Default = Off) Voice Activation (VOX) will turn the LCD back on. -
Page 28: Special Features
FeAtURes ReMote VIeWInG VIA APP You can use the Uniden Baby Watch app to remotely view the system. 1. Connect the AC adaptor to the power port on the cradle and the power outlet. 2. Connect the cradle to the router using the ethernet cable (provided). - Page 29 13. The Add Device screen displays with the UID code in the field. Enter the default password, 000000, and tap Save or OK. The Device List screen displays. Tap on the image to get Live View. The following will NOT work, when the BW3451R system is being viewed remotely: - Auto-Scan - Quad view...
-
Page 30: Live View
Live View From the Device List screen, tap on the snapshot view to display the Live View. In Live View, swipe across the screen to pan and tilt the camera. Icon/Option Function Tap on this icon to view the saved snapshots. Tap to take a snapshot in Live View. -
Page 31: Advanced Settings
Advanced settings Password Uniden strongly recommends changing the default password to a more personalised one. After your device displays on your Device List screen, tap on the icon to access the Edit Device screen. Tap on the Advanced Setting option to display the Advanced Setting screen below. - Page 32 Video Quality On the Advanced Setting screen, tap the option, Video Quality, to select the resolution of the video. The option available are: Max, High, Medium, Low, Min. About Device On the Advanced Setting screen, tap the option, About Device, to view the model name and firmware version.
-
Page 33: Recording Video
ReCoRDInG VIDeo You can manually record video to a microSD card (not included). The BW3451R supports up to 32GB microSD card. The system records video in 10 minute blocks; however, you can manually stop recording at any time. # During recording, only TALK and Manual Record is active. All other buttons are disabled. -
Page 34: Viewing Recorded Video On Your Computer
ZOOM again to return to normal view. nIGHt LIGHt You can control the BW3451R night light using the NIGHT LIGHT button on the top of the monitor. However, to control it from the monitor, you must place that camera in full screen mode. -
Page 35: Using The Intercom
3. Press LULLABY SKIP to skip to Lullaby #2. The system plays Lullaby #2 then repeats it. 4. Press LULLABY SKIP to skip to Lullaby #3. The system plays Lullaby #3 then repeats it. 5. Press LULLABY SKIP to skip to Lullaby #4. The system plays Lullaby #4 then repeats it. -
Page 36: Troubleshooting
tRoUBLesHootInG If you have problems with the system, there is often a quick and simple solution. Please try the following: There is no picture • checking all connections to the camera. Make sure from the camera the adaptor is plugged in. • making sure that the cameras and monitor are both • making sure that the camera is in range of the monitor. -
Page 37: Specification
sPeCIFICAtIon GENERAL Camera Monitor Operating Frequency Range 2.400 ~ 2.4835GHz TX Power 15dBm RX Sensitivity –81dBm Type of Spread Spectrum Used FHSS Type of Modulation Used GFSK Communication Range 150ms Line of Sight CAMERA Image Sensor Type Manufacturer/ Model # 1/6.5” Color CMOS Image sensor Effective Pixel 640 x 480 Image Processing... - Page 38 MONITOR Display Size/Type 4.3” TFT LCD Resolution 480 x 272 Power Requirement 5.0VDC +/–5% Power Consumption 350mA Max (Normal) 700mA Max (Charging) Operating Temperature Range –10°C ~ 40°C (14°F ~ 104°F) Operating Humidity Range Within 80% Relative Humidity Battery Life 4.5 hours Housing Material Plastic...
-
Page 39: One-Year Limited Warranty
(“Uniden Aust”) . Terms of Warranty Uniden Aust warrants to the original retail purchaser only that the BW3451R (“the Product”), will be free from defects in materials and craftsmanship for the duration of the warranty period, subject to the limitations and exclusions set out below. - Page 40 (such as a legible copy of the sales docket) to Uniden. Please refer to the Uniden website for address details. You should contact Uniden regarding any compensation that may be payable for your expenses incurred in making a warranty claim.
- Page 44 ©2015 Uniden Australia Pty Ltd Printed in PRC...
