User's Manual

for

American Telecom 6001S

for use with

Service by SunRocket

6001S

Compatible only with SunRocket Service

Expandable, Digital Cordless

Internet Telephone

To enjoy all the benefits of this product, please review

the information contained in this manual.

Table of Contents

Need help?

Do you have a question about the 6001S and is the answer not in the manual?

Questions and answers

Summary of Contents for American Telecom 6001S

Page 1 User’s Manual American Telecom 6001S for use with Service by SunRocket 6001S Compatible only with SunRocket Service Expandable, Digital Cordless Internet Telephone To enjoy all the benefits of this product, please review the information contained in this manual.
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safety Instructions ...................3 Safety Instructions for Handset Battery Pack..............3 FCC Statement.........................4 Package Includes (Parts List) ...................4 Handset and Base Layouts ....................5 LCD Display........................6 Getting Started.........................7 Basic Operation .......................9 Answering Calls.......................9 Making Calls......................11 Call Waiting / Call Waiting ID ..................12 Conference Calls......................12 Redial ..........................12 Muting the Handset Microphone..................13...
Page 3: Important Safety Instructions
There is a danger of explosion if the battery is incorrectly replaced. Use only an approved battery pack in the handset of your 6001S Cordless Telephone. To reduce the risk of fire or injury, always do the following when replacing, discarding, or charging battery, when handling the batteries, be careful not to short the battery with conducting materials such as rings, bracelets, and keys.
Page 4: Fcc Statement
FOR HANDSET UNIT: GP60AAAH3BMX 3.6V 600mAh GPI INTERNATIONAL LIMITED CONTAINS NICKEL-METAL HYDRIDE BATTERY. BATTERY MUST BE RECYCLED OR DISPOSED OF PROPERLY Do not dispose of the battery in a fire. The cell may explode. Check with local codes for possible special disposal instructions. Do not open or mutilate the battery.
Page 5: Handset And Base Layouts
Handset and Base Layouts Key pad (0-9; *; #) Message Waiting Indicator (LED) Start/End Calls Cancel Clear/Delete Volume _/ Scroll _ Flash/Speakerphone Intercom Voice Mail Redial/Pause Program Repeat Dial Volume _ / Scroll _ Directory Info. Display (LCD) Last Call Return...
Page 6: Lcd Display
Message Waiting/In Use Indicator Page Handset Charge Indicator LCD Display...
Page 7: Getting Started
1. Caller ID Time 2. Caller ID Date 3. Ringer OFF icon (displayed when user turns the ringer off) 4. Low battery icon (displayed only if battery voltage is low) 5. Key lock icon (displayed when user locks the keypad) 6.
Page 8 Snap the bracket into place on the back of the base. Connect the power supply to a live outlet. Make sure the outlet is not controlled by a switch. Plug the adaptor into a power outlet near your equipment that is easily accessible.
Page 9: Basic Operation
Basic Operation When you plug the Ethernet cable into your router for the first time the 6001S will contact SunRocket over your internet connection. The start of service may be delayed for up to 3 minutes as the internal firmware in the device is upgraded.
Page 10 The time/date information shown is generated by SunRocket. The time/date information is shown in the first line. 10:20 6/01 SOMEBODY 987-654-3210 The caller ID information may be blocked by the caller. The handset will display calls with blocked name/numbers as indicated below: Private number: SMITH PRIVATE NUMBER...
Page 11: Making Calls
SOMEBODY Calls with blocked name in caller ID is shown as: TALK 1:32:56 PRIVATE NAME TALK 1:32:56 UNKNOWN NAME The number ‘1:32:56’ represents the elapsed time of your call in hours, minutes and seconds. Key entries during a call will replace the number/name in the second line, and the digits are left-truncated in case the entered number exceeds 16 digits.
Page 12: Call Waiting / Call Waiting Id
as well as display ‘OUT OF SERVICE’. Call Waiting / Call Waiting ID Call Waiting When you receive a Call Waiting alert tone in the earpiece (or Handset Speakerphone), the ‘waiting’ call can be answered by pressing the FLASH key. Pressing FLASH clears the second line in the display. If the ‘waiting’...
Page 13: Muting The Handset Microphone
in the event redial memory is empty. Press TALK to dial the displayed number. -OR- Press TALK and listen for dial tone. Now, press REDIAL to scroll through the list of recently dialed numbers. Dial the displayed number by pressing PROG. Muting the Handset Microphone It is possible to mute the microphone during a conversation by pressing the CLEAR/DEL key.
Page 14: Intercom
Intercom To place an intercom call to another handset: 1. Press Int button SELECT INTERNAL HANDSET #2 2. Use the UP _ / DOWN _ keys to scroll through the available handsets and select the desired one, or select CALL ALL to call all handsets. 3.
Page 15: Caller Id Call Log
Caller ID Call Log All incoming calls with a valid Caller ID provided phone number are stored in the phone’s call log. Please note, this call log is separate from the call log provided within your SunRocket account. Name and time/date information are also stored in the phone’s call log if the service provider sends it.
Page 16: Phone Book
By selecting PROG, the phone displays “CALL LOG EMPTY” for 5 seconds and returns to main menu after deleting. By selecting CANCEL, the phone returns to the call log. _ Storing the Caller ID information displayed into the Phone Book by pressing the PROG key. Before the name and number is transferred to the Phone Book, you can edit the number and name.
Page 17 Names are entered using the numerical keys. Characters are generated by multiple key presses (see the table below). The cursor moves to the next position if another numerical key is pressed or by pressing the _ key. The last entered character is deleted by pressing CLEAR or _. The entire name is cleared with a long CLEAR key press.
Page 18 continue searching using the UP/DOWN keys. ROBERT 9898327822 1) Press TALK to dial the number. TALK 0:00:01 9898327822 Editing a Phone Book entry: 1) Press PROG to enter the menu; press _ to put PHONE BOOK on the top line of the display; press PROG again;...
Page 19: Volume
9876543210 3) Press PROG STORE NAME 4) Enter the desired name. A name has to be entered otherwise an audible alert is given and the phone returns to the ‘STORE NAME’ display. STORE NAME SOMEBODY 5) Press PROG. Your new entry has been stored. The screen returns to: >STORE RECALL Press CANCEL twice to return to the idle screen.
Page 20: Ring Pattern
RING PATTERN Ringing is switched off by adjusting the ring volume to zero. A "Ringer OFF" icon is shown in the display during idle mode. The default ring volume is 3. Ring Pattern The ring pattern of an incoming call is changed by the following key sequence: 1) Press PROG.
Page 21: Key Lock
KEY CLICK 4) Enable key click by pressing 1 or _, or disable key click by pressing 0 or DOWN. KEY CLICK 5) Press PROG to confirm the setting. The display will return to: >KEY CLICK KEY LOCK Note: 1) Key Click is ON by default and 2) Key Click is disabled when the key lock is ON. Key Lock It is possible to lock the handset keypad.
Page 22: Language
The handset is named by following this programming sequence: 1) Press PROG. >CALL LOG PHONE BOOK 2) Press the _ key eight times. >HANDSET NAME LANGUAGE 3) Press PROG to enter the handset name sub-menu. NAME 4) Enter handset name (characters are entered in the same way as for the Phone Book). NAME DAD'S PHONE 5) Press PROG to confirm the setting and to return to idle mode.
Page 23: Voip Settings
CALL LOG VOIP Settings Advanced users may access technical information about the configuration of the 6001S in order to diagnose and troubleshoot technical issues. The View Settings menu allows you to review the telephone number and IP address assigned to •...
Page 24 The following status messages are shown in the idle mode (in prioritized order): When the Handset is out of range, an "out of service" message is shown in line one. OUT OF SERVICE When the Handset does not have a valid registration, the display shows: NOT REGISTERED PLACE IN BASE If a new battery has been inserted (or the battery has been run down) and the battery voltage is too low to...
Page 25: Led Indication - Handset Antenna
Troubleshooting The 6001S uses your existing broadband Internet connection for placing and receiving calls. For successful operation it must be able to communicate with your home router without error. The most common indication of an error is that you do not hear dialtone after you push the Talk button on the handset, and the display says “No Line”.
Page 26: Consumer Information
If not, enable DHCP on your home router, or contact SunRocket for help on manually setting an IP address in the 6001S. Your home router may have a firewall that is blocking access to SunRocket. Contact SunRocket for help on programming your firewall to eliminate this block.
Page 27 • Products purchased and/or operated outside of the U.S., its territories, or Canada • Products services by the owner or a service facility not expressly authorized by American Telecom • Products purchased more than 12 months from the current date •...
