- Page 1 Installation Manual AS41 Hi-Fi Landscape Audio System Model: AS41SYS V 1.2...
-
Page 2: Table Of Contents
Table of Contents Introduction Installation Requirements and Recommendations 2 What’s Included Required Tools/Items Planning Speaker Location Subwoofer Location Amplifier & Wiring Plan Installation Troubleshooting Technical Assistance Specifications Warranty Three-Year Warranty Requirements and Warranty Coverage Return Process 844·674·4461 TECHSUPPORT@ACOUSTASCAPE.COM... -
Page 3: Introduction
AS41HI-FI LANDSCAPE AUDIO SYSTEM MANUAL Introduction Thank you for purchasing the AcoustaScape™ AS41 Hi-Fi Land- scape Audio System. You are about to enjoy an incredible listen- ing experience created specifically for outdoor environments. AcoustaScape™ engineers have invested countless hours creating loudspeakers that deliver amazing sonic performance from en- closures that can withstand the harshest elements. -
Page 4: Installation Requirements And Recommendations
-- heavier gauge wire is always OK. Planning The AcoustaScape™ speakers and subwoofer should be strategi- cally placed to evenly distribute sound throughout the outdoor area. Fully plan out the locations of all speakers, subwoofers and buried wires before beginning the installation process. -
Page 5: Speaker Location
Select a location for the subwoofer somewhat near the middle of the speaker arrangement. For more bass, install the subwoofer near a wall or other solid surface. Subwoofers should be posi- tioned away from standing water. AS4SAT Expansion Pack Speakers Patio (Listening Area) Subwoofer AS4SAT Expansion Pack Layout Example WWW.ACOUSTASCAPE.COM... -
Page 6: Amplifier & Wiring Plan
Ideally, all the speakers and subwoofer will be connected to two parallel wire runs, and these wires will be buried in a single trench. The AcoustaScape™ system is designed for the speakers to be evenly divided between these two wire runs, with the subwoofer connect to both. -
Page 7: Installation
Dig a 5” trench where you plan on laying out the wire. Run the wire from the amplifier to your first speaker location. WWW.ACOUSTASCAPE.COM... - Page 8 Run the wires to the next speaker and connect them the same way, but this time connect the right channel positive and negative wires. Continue connecting the speakers like this, alternating left 844·674·4461 TECHSUPPORT@ACOUSTASCAPE.COM...
- Page 9 Audio Source Subwoofer SUBA150 Satellites Expandable System AS41 System Wiring Guide 2Ch Amplifier Without Separate L A N D S C A P E A U D I O Subwoofer Amplifier Audio Source Subwoofer Expandable Satellites System 2Ch Amplifier WWW.ACOUSTASCAPE.COM...
-
Page 10: Troubleshooting
Check to be certain that the volume isn’t turned up past 80% on any device. Try changing sources to be certain that the selection you’ve chosen is a good quality recording. 844·674·4461 TECHSUPPORT@ACOUSTASCAPE.COM... -
Page 11: Technical Assistance
Most emails are answered within 2 hours of receipt during regular business hours; emails received after hours will be answered promptly the next business day. Phone: (844) 674-4461 Hours of operation: 8:00am - 5:00pm (Pacific Time), Mon - Fri Email: techsupport@acoustascape.com WWW.ACOUSTASCAPE.COM... -
Page 12: Specifications
Specifications Model Number AS41SYS Part Number AS4100SYS Speaker Subwoofer Tweeter Dome Tweeter Diameter 0.75” (20mm) Injection molded Woofer Cone Polypropylene polypropylene Woofer Diameter 4.25” (110mm) 8” (200mm) Frequency Response 120Hz - 20KHz ±3dB 32Hz – 120Hz ±3dB Recommended 35 to 200 Watts... - Page 13 AS41HI-FI LANDSCAPE AUDIO SYSTEM MANUAL 9.8in 250mm 3.1in 80mm 7.1in 180mm 4.2in 106mm 11.2in 285mm WWW.ACOUSTASCAPE.COM...
-
Page 14: Warranty
AcoustaScape™ authorized deal- er. If the product is determined to be defective, it will be repaired or replaced at AcoustaScape’s™ discretion. If the product must be replaced yet it is no longer manufactured, it will be replaced with a model of equal to or greater value that is the most similar to the original. -
Page 15: Requirements And Warranty Coverage
• Accidental damage • Damage caused by abuse or misuse • Damage caused by attempted repairs/modifications by anyone other than AcoustaScape™ or an authorized dealer • Damage caused by improper installation • Normal wear, maintenance, and environmental issues • Damage inflicted during the return shipment... - Page 16 ©2015 AcoustaScape™. All copyrighted, trademarked and patented elements mentioned herein are the sole property of AcoustaScape™.
