Coopers st06837i Owner's Manual

Hide thumbs

Advertisement

Table of Contents

Enlarged version
U.K. WIRING INSTRUCTIONS
The wires in the mains lead are coloured in accordance with the following code:
BLUE
NEUTRAL
BROWN
LIVE
GREEN/YELLOW EARTH
As the colours of the wire in the mains lead of this appliance may not correspond with the colour
markings identifying the terminals on your plug, proceed as follows:
• The wire which is coloured BLUE must be connected to the terminal which is
marked with the letter N or coloured black.
• The wire which is coloured BROWN must be connected to the terminal which is
marked with the letter L or coloured red.
• The wire which is coloured GREEN/YELLOW must be connected to the terminal
which is marked with the letter E or (earth symbol) and is coloured GREEN or
GREEN/YELLOW.
WARNING: THIS APPLIANCE MUST BE EARTHED
The Despatch Centre, Haslemere Industrial Estate, Pig Lane, Bishop's Stortford CM23 3HG. Tel: 01279 757100.
HIGH PERFORMANCE KITCHENWARE
Electric Mandoline Slicer Owner's Manual
Slicer Blade & Insert
Slicer Blade & Insert
(thin/thick)
(thin/thick)
Thin Julienne
Thin Julienne
Insert
Insert
Thick Julienne
Thick Julienne
Insert
Insert
Grater
Grater
French Fry Blade
French Fry Blade
Thank you for purchasing our product
Please read this manual thoroughly for
proper operation.
Please keep this manual for future use.
Ice Shaver
Safety Information
1-2
Product Identification
and Specifications
3
Usage
Assembly
4
Operation
5-6
To Use Each Blade & Insert
(1) Slicer Blade & Insert
7-8
(2) Julienne Inserts
9-10
(3) Grater
11
(4) French Fry
12
(5) Ice Shaver
13
Care & Storage
14
Safety Rules
15
Troubleshooting Guide
16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the st06837i and is the answer not in the manual?

Questions and answers

Related Manuals for Coopers st06837i

Summary of Contents for Coopers st06837i

  • Page 1 U.K. WIRING INSTRUCTIONS HIGH PERFORMANCE KITCHENWARE Electric Mandoline Slicer Owner’s Manual The wires in the mains lead are coloured in accordance with the following code: BLUE NEUTRAL BROWN LIVE GREEN/YELLOW EARTH As the colours of the wire in the mains lead of this appliance may not correspond with the colour markings identifying the terminals on your plug, proceed as follows: •...

  • Page 2: Important Safeguards

    IMPORTANT SAFEGUARDS Make sure the product is "OFF" Only operate the product on a flat when not in use, before putting on surface. or removing blades and inserts, When using electric appliances, basic safety precautions and before cleaning. Hold and pull should always be followed including the following: power plug when disconnecting from the power outlet.
  • Page 3 PRODUCT IDENTIFICATION AND SPECIFICATIONS USAGE (example: when use Slicer Blade) ASSEMBLY Medium Medium Food Pusher Slide the Collection cup into Connect the Main Unit Small Food Chute the Container. to the Cover. Large Food Pusher Food Chute Position the dents of * Large and Medium Food Pushers function as Food Chutes.
  • Page 4 USAGE TO OPERATE HOW TO INSERT / HOW TO CHOOSE THE OPENINGS Insert vegetable into the Large Food Chute. You have three types of Food Chutes (Small, Medium, Large). Choose the most appropriate that fits the vegetable. For thick vegetables For medium vegetables Press the vegetable into the Food Chute with Food Pusher and press the Switch Ring onto the Switch Dent of the Main Unit.
  • Page 5 Switch off the appliance and ensure all moving parts USAGE have stopped before changing accessories. CAUTION TO USE EACH BLADE & INSERT 1. TO SLICE VEGETABLE Cut Preparation Vegetables Preparation Before inserting, pare vegetables and cut into the Before inserting, make the following Prepare the Slicer Blade.
  • Page 6 USAGE TO USE EACH BLADE & INSERT 2. TO MAKE JULIENNE STRIPS Vegetables Preparation Direction of vegetables in the Opening Before inserting, pare vegetables and cut into the Make the vegetable fiber parallel to the Prepare the Slicer Blade size which can be inserted into the Food Chute. cutter motion direction.
  • Page 7 USAGE USAGE TO USE EACH BLADE & INSERT TO USE EACH BLADE & INSERT 4. FRENCH FRY BLADE 3. TO USE GRATER Prepare the French Fry Blade. Place the Grater on the Plate Place the Plate Frame on the Large Frame.

  • Page 8: Care And Storage

    USAGE CARE & STORAGE TO USE EACH BLADE & INSERT BEFORE CARING FOR THE UNIT AND PROPER MAINTENANCE, 5. TO USE ICE SHAVER DISCONNECT THE PLUG To assemble the Ice Shaver Prepare the ice Blades and Inserts Main Unit Use the ice cube made in the This shaver is designed to shave the ice.

  • Page 9: Safety Rules

    SAFETY RULES TROUBLESHOOTING GUIDE Follow the instructions to operate the unit. Do not misuse the unit. DO NOT OPERATE WITHOUT VEGETABLE. In case of trouble Disconnect the Switch Ring & Switch Dent Do not process prohibited items when inserting or removing the vegetable. WHEN CAUSE MEASUREMENT...
  • Page 10 NOTES Dispose the packaging at your local recycling centre. Dispose paper and carton separately from plastic bags at your local recycling centre. Dispose the appliance at the end of its lifespan at your local authorised household waste recycling centre.
