Ultrak JPD-101 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
JOYSTICK
CONTROLLER
Ultrak
, Inc.
®
4465 Coonpath Road
Carroll, OH 43112
(800) 443-6680•(740) 756-9222•FAX (740) 756-4237
518007-3960-F
USER'S MANUAL
JPD-101
KEMU040019
April 25, 2001

Advertisement

Table of Contents
loading

Summary of Contents for Ultrak JPD-101

  • Page 1 JPD-101 JOYSTICK CONTROLLER USER’S MANUAL Ultrak , Inc. ® 4465 Coonpath Road Carroll, OH 43112 (800) 443-6680•(740) 756-9222•FAX (740) 756-4237 518007-3960-F KEMU040019 April 25, 2001...
  • Page 2 WARNING NOT FOR OUTDOOR USE. TO REDUCE A RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. WARNING THIS IS A CLASS A PRODUCT. IN A DOMESTIC ENVIRONMENT, THIS PRODUCT MAY CAUSE RADIO INTERFERENCE IN WHICH CASE THE USER MAY BE REQUIRED TO TAKE ADEQUATE MEASURES.

  • Page 3: Declaration Of Conformity

    MUX-100 – may be followed by any number of alphanumeric characters MUX-05 – may be followed by any number of alphanumeric characters Joystick Controller* JPD-100, JPD-101, JPD-200 - may be followed by any number of alphanumeric characters. Small System Interface* SSI-100 - may be followed by any number of alphanumeric characters.
  • Page 4 Issue 1, Revision A – July 1997 – added caution to plug programming keyboard into controller before power-up of system to ensure proper operation. Issue 1, Revision B – January 1998 – updated installation drawing for JPD-101/R in Appendix C.
  • Page 5 JPD-101 Controller alone. See Section 3 of this manual for programming “Quick” PreShots. An operator can send a SmartScan unit to a programmed PreShot using the JPD-101 Controller. When the SmartScan unit is sent to a PreShot, the title of the PreShot is added to the video signal.
  • Page 6 518007-3960-F KEMU040019 April 25, 2001...

  • Page 7: Table Of Contents

    TABLE OF CONTENTS Page SECTION 1. INTRODUCTION ..................1-1 1.1 DESCRIPTION ....................1-1 1.2 OPERATION......................1-1 1.3 INSTALLATION ....................1-3 1.4 SPECIFICATIONS.....................1-5 SECTION 2. OPERATION ..................2-1 2.1 CONTROLS AND INDICATORS ...............2-1 2.1.1 Top Panel Controls and Indicators............2-1 2.1.2 Rear Panel Controls and Indicators............2-10 2.2 OPERATION....................2-11 2.2.1 LCD Display Language Selection ............2-13...
  • Page 8 Camera ID Display on Monitor..............2-54 2.2.18 Pan, Tilt, Zoom, and Focus Azimuth Display/Error Log Display....2-56 SECTION 3. PROGRAMMING..................3-1 3.1 PRESHOTS .......................3-1 3.2 PROGRAMMING THE EIGHT FUNCTION KEYS ON THE JPD-101 CONTROLLER ......................3-3 3.2.1 Programming a Function Key..............3-4 3.2.2 Modify an Action Programmed for a Function Key.
  • Page 9 Stand-Alone Controller Installation............4-6 4.3.2 One Controller And CATS Video Switcher Installation......4-8 4.3.2.1 JPD-101 Connected to Front Panel of CATS Video Switcher.....4-8 4.3.2.2 JPD-101 Connected to Rear Panel of CATS Video Switcher....4-10 4.3.3 Two Controllers Linked Together Installation........4-12 4.3.4...
  • Page 10 Figure 4-7. TWO CONTROLLERS LINKED TOGETHER W/CATS VIDEO SWITCHER (REAR COMM CONNECTOR) ..........4-18 Figure C-1. JPD-101/R AS A STAND-ALONE CONTROLLER ........C-3 Figure C-2. JPD-101/R CONNECTED TO THE COMM CONNECTOR OF THE CATS VIDEO SWITCHER ................ C-5 Figure C-3. JPD-101/R CONTROLLER CONNECTED TO THE FRONT PANEL ON THE CATS VIDEO SWITCHER ............
  • Page 11 DIA-01/X Control Interface Adapter (D/N 515558-4430) ..........4-22 DIA-02 Control Interface Adapter (D/N 517172-1430)..........4-23 DIA-02/X Control Interface Adapter (D/N 517172-3430) ..........4-24 JPD-101/R Joystick Controller Unit Installation (D/N 700385-1430)......C-9 DIA-01/R Control Interface Panel Rack Mount (D/N 515979-1430)......C-10 DIA-02/R Control Interface Panel Rack Mount (D/N 515979-2430)......C-11...
  • Page 12 This page left blank intentionally. 518007-3960-F KEMU040019 April 25, 2001...

  • Page 13: Section 1. Introduction

    FastScan pan and tilt units, SmartScan pan and tilt units, and CAT video switchers. There are various models of FastScan and SmartScan pan and tilt units. The features vary between models. The JPD-101 Controller is designed to control the many different features of all the models. The JPD-101 may have a feature that is not supported by your model pan and tilt unit.
  • Page 14 Freeze and unfreeze the video scene in the KD6 UltraDome. • Invoke the flashback function in the KD6 UltraDome The JPD-101 Controllers allow the operator to have a primary control camera and monitor and a secondary control camera and monitor. If a secondary...

  • Page 15: Installation

    There are four standard installations for the JPD-101 Controllers. Stand-Alone Controller When the JPD-101 Controller is used as a stand-alone controller, a DIA- 01 or DIA-01/X Control Interface is required. The Control Interface Adapter provides the +5 Vdc power required to operate the JPD-101 Controller.
  • Page 16 JPD-101 with a CATS Video Switcher When the JPD-101 Controller is installed with a CATS Video Switcher, the controller can be plugged into the front panel controller connector on the CATS Video Switcher. The front panel controller connector provides the +5 Vdc required for the controller.

  • Page 17: Specifications

    Two JPD-101 Controllers linked together with a CATS Video Switcher Two JPD-101 Controllers can be linked together using two DIA-02 Control Interface Adapters and then connected to a CATS Video Switcher. One of the controllers is configured as the master unit and the other is configured as the slave unit.
  • Page 18 This page left blank intentionally. 518007-3960-F KEMU040019 April 25, 2001...

  • Page 19: Section 2. Operation

    SECTION 2. OPERATION CONTROLS AND INDICATORS 2.1.1 Top Panel Controls and Indicators. Figure 2-1. CONTROLS AND INDICATORS, TOP PANEL 518007-3960-F KEMU040019 April 25, 2001...
  • Page 20 LARGE JOYSTICK OPERATION LARGE JOYSTICK The large joystick controls the pan, tilt, and zoom functions of a Fastscan/Smartscan unit. The joystick control is rate proportional; the farther the joystick is moved, the faster the function is performed. The large joystick is also used to halt VectorScans and Tours in a SmartScan unit and return the SmartScan to manual control.
  • Page 21 SMALL JOYSTICK OPERATION PASS Function If the PASS function is enabled in the SmartScan unit, the pan and tilt speed range is a function of the lens zoom angle. As the lens is zoomed in, the maximum pan and tilt speeds are reduced and the low speed control is expanded.
  • Page 22 SMALL JOYSTICK OPERATION MANUAL IRIS CONTROL STEP 1 Press the IRIS key on the function keypad and then the 2 key on the numeric keypad. IRIS When manual iris is selected for the control camera, the letter I appears on the second line of the LCD display.
  • Page 23 SMALL JOYSTICK OPERATION AUTOMATIC IRIS The operator can change back to automatic iris anytime while controlling the camera. STEP 1 Press the IRIS key on the function keypad and then the 1 key on the numeric keypad. IRIS When automatic iris is selected, the letter I disappears from the second line of the LCD display.
  • Page 24 When programming the specific actions for the function keys, moving the joystick up and down can also be used to scroll through the actions (one through eight). When the JPD-101 is in the function key programming mode, the lens focus and iris functions are not operational.
  • Page 25 LCD DISPLAY NUMERIC KEYPAD LCD DISPLAY The display is a 2X20 EL back light super twist LCD. The viewing angle of the display may be changed by turning the screwdriver adjustment on the back panel (see figure 2-2). The first line of the display indicates the primary monitor (number) and camera (number) the hand controller unit is controlling.
  • Page 26 - Program and Run Tours (OPT) - Freeze and Unfreeze video in the KD6 Dome (OPT) - Invoke the flashback function in the KD6 Dome (OPT) The MCALL and ALARM keys are not functional on the JPD-101 Controllers. 518007-3960-F KEMU040019...
  • Page 27 FUNCTION KEYS 1-8 FUNCTION KEYS 1-8 Function keys 1 through 8 are programmable using the two 12-key keypads and the small joystick. These keys can be programmed to perform a single action or up to eight actions simultaneously. If the operator does not want the actions to occur simultaneously, a delay time (wait) can be inserted as an action between actions.

  • Page 28: Rear Panel Controls And Indicators

    2.1.2 Rear Panel Controls and Indicators. Figure 2-2. CONTROLS AND INDICATORS, REAR PANEL VIEWING ANGLE ADJUSTMENT This screwdriver adjustment is used to change the viewing angle of the LCD Display. 8-PIN TELEPHONE JACK CONNECTOR This connector accepts +5 Vdc power for the Joystick Controller and inputs/outputs RS-422 control data.

  • Page 29: Operation

    Improper Operation May Occur. Operation can begin when power is applied to all components in the system. Upon power-up of a JPD-101 Controller, the LCD display shows the control camera and control monitor. The control camera and control monitor displayed upon power up depends on the configuration of the controller.
  • Page 30 DIA-02 Control Interface Adapter and then to the domes or video switcher. When two JPD-101 Controllers are linked together and communication is enabled, the LCD display updates when both controllers have the same control monitor and one of the operators changes the control camera. For example, the master controller has control monitor 1 and control camera 3, and the slave controller has control monitor 1 and control camera 3.

  • Page 31: Lcd Display Language Selection

    LCD LANGUAGE 2.2.1 LCD Display Language Selection Upon power-up of the controller, the second line of the LCD display shows the firmware and revision, then: CNTL – CAM 1 MON 1 OPT>1 >1 CHANGE LANG The LCD displays can be presented in English, French, German, and Spanish.
  • Page 32 SET ADDRESS IN KD6 Z-SERIES 2.2.2 Setting the Address in the KD6 Z-Series Dome To set the address of a KD6 Z-Series Dome, you must know the serial number. The serial number is eight (8) digits and can be located on the KD6 Z-Series Dome pan and tilt unit.

  • Page 33: Primary Control Camera And Control Monitor

    PRIMARY CONTROL CAMERA 2.2.3 Primary Control Camera and Control Monitor. Upon power-up of the system, the primary control camera and monitor are camera one and monitor one. A secondary control camera/monitor combination, if desired, has to be selected. The first line of the display on the controller shows the CAM and the MON the controller is controlling.
  • Page 34 PRIMARY CONTROL CAMERA Camera #>ENTER ENTER Camera#>CNTL CNTL The controller sends a command to the switcher to switch the selected camera to the monitor currently displayed on the controller. NOTE If a camera number is displayed on the first line of the JPD display, but the operator cannot manually control that camera, press the CNTL key to get manual control.
  • Page 35 PRIMARY CONTROL CAMERA Example: The display on the controller shows CAM 1 and MON 1. CNTL - CAM 1 MON 1 Enter the following command sequence to change the control camera to 5. 5>ENTER 5>CNTL Now, the controller display shows CAM 5/MON1. CNTL - CAM 5 MON 1 All control commands are sent to camera 5 and the video from camera 5...
  • Page 36 PRIMARY CONTROL MONITOR CHANGE PRIMARY CONTROL MONITOR To change the control monitor (but not the control camera), enter the one of the following command sequences. a. Monitor #>MON>ENTER ENTER b. Monitor #>MON>CNTL CNTL c. Press MON. The following message appears on the controller LCD display. CNTL - CAM 1 MON 1 Enter MON.
  • Page 37 PRIMARY CONTROL MONITOR Example: The display on the controller shows CAM 1/MON 1. CNTL - CAM 1 MON 1 Enter the following command sequence to change the control monitor to 3. 3>MON>ENTER 3>MON>CNTL MON>3>ENTER>ENTER MON>3>ENTER>CNTL Now the display shows CAM 1/MON 3. CNTL - CAM 1 MON 3 All control commands are performed on camera 1 and the video from...

  • Page 38: Secondary Control Camera And Monitor

    SECONDARY CONTROL CAMERA 2.2.4 Secondary Control Camera And Monitor. The secondary camera and monitor are displayed on the second line of the display. The camera number can be entered first and the monitor number second or vice versa. If the monitor number is entered first, it appears on the second line. When the camera number is entered, the controller places the camera number in front of the monitor number.
  • Page 39 SECONDARY CONTROL CAMERA Example: Select camera 2 as the secondary camera. 2>CAM The number 2 shows up on the second line of the controller display. CNTL - CAM 1 MON 1 All automatic commands (PreShots, VectorScans) are sent to camera 518007-3960-F 2-21 KEMU040019...
  • Page 40 SECONDARY CONTROL MONITOR SELECTING A SECONDARY MONITOR To select a secondary monitor, enter one of the following command se- quences. Monitor #>MON MON>Monitor #>ENTER ENTER The secondary monitor appears on the second line of the controller display. Example: Select monitor 2 as the secondary monitor. 2>MON >2>ENTER Monitor 2 appears on the second line of the controller display.
  • Page 41 SECONDARY CAMERA/MONITOR CALL UP SECONDARY CAMERA TO SECONDARY MONITOR To switch the video of the secondary camera to the secondary monitor, the secondary camera and monitor must be selected first and displayed on the second line of the controller LCD display. Press the ENTER key on the controller.

  • Page 42: Switch Secondary Control To Primary Control

    SECONDARY CONTROL TO PRIMARY CONTROL 2.2.5 Switch Secondary Control To Primary Control. To have the secondary camera/monitor combination displayed become the primary camera/monitor combination, press CNTL. The camera/monitor combination on the second line of the LCD display moves to the first line of the display.

  • Page 43: Call Up Any Camera To Any Monitor

    VIDEO SWITCHING 2.2.6 Call Up Any Camera To Any Monitor. To call up any camera to any monitor without giving up PreShot and VectorScan control of the primary camera, perform the procedures for calling up a secondary camera to a secondary monitor. Then clear them from the display on the controller by pressing the CLEAR key until the second line of the display is empty.
  • Page 44 VIDEO SWITCHING 2>MON CNTL - CAM 1 MON 1 ENTER The controller sends out a command to switch camera 2 to monitor 2. CLEAR CNTL - CAM 1 MON 1 CLEAR CNTL - CAM 1 MON 1 Camera 2 remains on monitor 2 until the operator calls up another camera to monitor 2.

  • Page 45: Preshots

    PRESHOTS 2.2.7 PreShots Each SmartScan unit can store up to 100 PreShots (00-99). The KD6 Z- Series can store up to 64 PreShots (1-64). A list of the programmed PreShots for each SmartScan unit can be called up using the controller for display on a monitor.

  • Page 46: Go To Preshot

    PRESHOTS 2.2.7.2 Go To PreShot A PreShot call is sent to the control camera unless a secondary control camera is selected, then it is sent to the secondary camera. To view the PreShot scene, the camera must be called up on a monitor. There are two command sequences to go to a PreShot.
  • Page 47 PRESHOTS Example: The controller display shows: CNTL - CAM 1 MON 1 (no secondary camera/monitor selected) Send camera one to PreShot 2. Enter one of the two following command sequences. 2>PSHOT PSHOT>2>ENTER SmartScan unit one (camera 1) goes to PreShot position 2. The video from PreShot 2 and the title of PreShot 2 are viewed on monitor 1.
  • Page 48 PRESHOTS Note: on some pan and tilt models, the PreShot title and camera ID display positions are programmable. They may not be located in the positions shown. The KD6 Z-Series does not display any on-screen messages. 518007-3960-F 2-30 KEMU040019 April 25, 2001...

  • Page 49: Vectorscans

    VECTORSCANS 2.2.8 VectorScans. Each SmartScan, SmartScan Pro II, SmartScan III series, or KD6 unit can store up to 10 VectorScans (0-9). A list of the programmed VectorScans for each unit can be called up for display on a monitor using the controller. The contents of each VectorScan can be called up for display on a monitor using the controller.
  • Page 50 VECTORSCANS Enter the 1 PreShot # (1-64) Press Enter Enter Enter a dwell time (0-30 seconds) 0-30 Press Enter Enter Enter the next PreShot # (1-64) Press Enter Enter Enter a dwell time (0-30 seconds) 0-30 Press Enter Enter • Continue entering PreShot numbers •...

  • Page 51: List Vectorscans (Not Applicable To Valudome)

    VECTORSCANS 2.2.8.2 List VectorScans (Not applicable to KD6 Z-Series) The list displays the VectorScan numbers and their titles. The listing cannot be edited. Perform the following command sequence to view the list of VectorScans for the primary (or secondary, if selected) control camera.

  • Page 52: List Vectorscan Contents (Not Applicable To Valudome)

    VECTORSCANS Press 1 to view the next page of the list. Press 2 when done viewing the list. 2.2.8.3 List VectorScan Contents (Not applicable to KD6 Z-Series) The contents of each programmed VectorScan for each SmartScan unit can be called up using the controller for display on a monitor. Perform the following command sequence to view the contents of a programmed VectorScan.

  • Page 53: Run Vectorscan

    VECTORSCANS SmartScan unit. The VectorScan contents cannot be edited from this listing. Press 1 to move up one line in the list. Press 2 to move down one line in the list. Press 3 to exit the list. 2.2.8.4 Run VectorScan There are two command sequences that can be used to start a programmed VectorScan on a SmartScan unit.
  • Page 54 VECTORSCANS Enter VectorScan # Press ENTER VSCAN ENTER Example: The controller display shows: CNTL - CAM 1 MON 1 (no secondary camera/monitor selected) Start VectorScan 1 on Camera 1. Enter one of the following command sequences. 1>VSCAN VSCAN>1>ENTER SmartScan unit one moves to the first PreShot listed in the VectorScan and remains there for the specified dwell time.

  • Page 55: Stop Vectorscan

    VECTORSCANS PreShot Title Note: On some model pan and tilt units, the PreShot title and camera ID display positions are programmable. They may not be located in the positions shown. The KD6 Z-Series Dome does not display any on-screen messages. CAM 001 A MONITOR DISPLAY The SmartScan unit goes to the next PreShot in the list and remains...

  • Page 56: Sector Id List (Not Applicable To Valudome)

    SECTOR ID'S 2.2.9 Sector ID List (not applicable to KD6 Z-Series) Sector ID titles are added to the video signal of the SmartScan camera when an operator is manually controlling a SmartScan and the SmartScan is positioned in a programmed Sector ID. A listing of the programmed Sector ID's can be called-up for the primary (or secondary, if selected) control camera for display on a monitor.

  • Page 57: Monitor Sequencing (1-32)

    Refer to Section 3 for programming procedures. START/STOP SEQUENCE Enter the following commands on a JPD-101 to start a sequence on a video output (monitor). The sequence runs continuously until the operator stops it. The same command toggles between the start and stop functions. The commands are in bold typeface separated with the symbol >.
  • Page 58 MONITOR SEQUENCING 2> ENTER> CNTL - CAM 1 MON 1 1>ON/OFF 2>DEL 3>PGM 1> CNTL - CAM 1 MON 1 Run/Stop Seq. - 2 To stop the sequence, perform the same steps. DELETE A SEQUENCE To delete a programmed sequence for a video output in its entirety, perform the following command string.
  • Page 59 MONITOR SEQUENCING 2> ENTER CNTL - CAM 1 MON 1 1>ON/OFF 2>DEL 3>PGM CNTL - CAM 1 MON 1 Delete Seq. - 2 518007-3960-F 2-41 KEMU040019 April 25, 2001...

  • Page 60: Auxiliary Contact Output Control (On/Off)

    AUXILIARY CONTROL 2.2.11 Auxiliary Contact Output Control (ON/OFF) The controller can be used to turn auxiliary devices on or off. The CATS Video Switcher (1-4), the CRX-800 Series Control Receivers (1-6) and the AIF-100/CO Contact Output Units (1-8) all have contact outputs for connection to VCR's, flood lights, etc.
  • Page 61 AUXILIARY CONTROL Press AUX> CNTL - CAM 1 MON 1 Enter Aux. No. Auxiliary #>ENTER> CNTL - CAM 1 MON 1 1>ON 3>OFF CNTL - CAM 1 MON 1 Aux No. nn ON ENTER OFF COMMAND SEQUENCE There are two command sequences to turn an auxiliary device off. Perform one of the following command sequences.
  • Page 62 AUXILIARY CONTROL Press AUX> CNTL - CAM 1 MON 1 Enter Aux. No. Auxiliary #>ENTER> CNTL - CAM 1 MON 1 1>ON 3>OFF CNTL - CAM 1 MON 1 Aux No. nn OFF ENTER Example: Your system contains a SmartScan camera viewing an entrance door and a VCR for recording scenes from that SmartScan camera.
  • Page 63 AUXILIARY CONTROL Call up the address of the AIF-100/CO as the control camera. The address is 2. 2>CNTL The controller display should read: CNTL - CAM 2 MON 1 Turn Auxiliary 1 ON. 1>AUX>1 The controller sends out an ON message to address 2, contact 1. Turn the Auxiliary off.

  • Page 64: Manual Control Of Smartscan

    MANUAL CONTROL (SMARTSCAN) 2.2.12 Manual Control of SmartScan. There are two ways to return manual control of a SmartScan Unit to the controller during an automatic operation such as a VectorScan. SmartScan Unit must be the primary control camera on the display. MOVE THE LARGE JOYSTICK IN ANY DIRECTION.

  • Page 65: Find Home

    FIND HOME (SMARTSCAN) 2.2.13 Find Home. The Home position is a reference point used by the SmartScan unit to define a starting position for the pan, tilt, and zoom functions. The "Find Home" function should be performed upon power-up of the unit to orient the SmartScan unit to a reference point prior to programming or performing any PreShots, VectorScans, etc.

  • Page 66: Freeze Or Unfreeze Video (Kd6 Ultradome Only)

    FREEZE OR UNFREEZE VIDEO & FLASHBACK FUNCTION 2.2.14 Freeze or Unfreeze Video & Flashback Function (KD6 UltraDome only) To freeze the camera video scene, perform the following procedure. Press OPT Press 1 Press 3 (FCT ON or FCT OFF) This command activates (FCT ON) or deactivates (FCT OFF) Function keys 4 and 8.

  • Page 67: Tours (Kd6 Ultradome Only)

    (120 seconds). When a PTZ tour is run, the scan performs the pan, tilt, and zoom commands that were performed during the PTZ tour programming mode. 2.2.15.1 Programming Tours Perform the following procedure to program a tour using the JPD-101 controller. Press OPT Press 4 (PROG) Press 1 (TOUR)

  • Page 68: Run Tour

    (120 seconds). To end programming before the unit times out, press 3 (END). 2.2.15.2 Run Tour To start a programmed tour using the JPD-101 controller, perform the following procedure. Press OPT Press 1 (MISC) Press 4 (TOUR ON) TOUR ON activates function keys 5, 6, and 7 to run tours 1, 2, and 3, respectively.

  • Page 69: Stop Tour

    TOURS 2.2.15.3 Stop Tour To stop a tour, manually control the camera where the tour is running. 518007-3960-F 2-51 KEMU040019 April 25, 2001...

  • Page 70: Joystick Diagnostics

    DIAGNOSTICS 2.2.16 Joystick Diagnostics. A diagnostics menu can be called up on the controller LCD display to verify the large joystick on the controller is operating correctly. There are three diagnostic selections: Offset, Actual, and Auto_Zero. Each setting has a range of 0 to 256. When the joystick is in the neutral position, these numbers should all be 128.
  • Page 71 DIAGNOSTICS Offset shows the values the controller is sending out when the joystick is moved. P = Pan Setting T = Tilt Setting Z = Zoom Setting Actual 2> CNTL - CAM 1 MON 1 P=nnn T=nnn Z=nnn Actual shows the values of the pan, tilt, and zoom at the present joystick location.

  • Page 72: Camera Id Display On Monitor

    CAMERA ID DISPLAY 2.2.17 Camera ID Display on Monitor. The SmartScan units are factory set to add the camera number to the video signal. The SmartScan unit also sends out whether the SmartScan unit is under manual control or automatic control (PreShot or VectorScan). When the SmartScan unit is called up on a monitor, the displays can be viewed on the monitor.
  • Page 73 CAMERA ID DISPLAY This display can be enabled (On) or disabled (Off). To enable or disable the display for a SmartScan unit, it must be the control camera on the controller. Enter the following command sequence to control the camera display.

  • Page 74: Pan, Tilt, Zoom, And Focus Azimuth Display/Error Log Display

    AZIMUTH/ERROR LOG 2.2.18 Pan, Tilt, Zoom, and Focus Azimuth Display/Error Log Display. A display showing the azimuth coordinates of the pan and tilt and an error log display for the primary control camera can be turned on for diagnostic purposes. The zoom and focus coordinates are also displayed with the pan and tilt azimuth coordinates if the primary control camera is a SmartScan unit.
  • Page 75 AZIMUTH/ERROR LOG CAM nnn E To return to the azimuth display, enter OPT>6>3 again. This command toggles between the two displays. Azimuth Display and Error Log Display OFF The following command sequence turns off both the azimuth display and the error log display.

  • Page 76: Table 2-1. Control Commands

    Table 2-1. CONTROL COMMANDS Command Description (Keystrokes are separated by >) OPT>1>1 Select LCD Display Language OPT>1>2 Set address in KD6 Z-Series 1. #>CNTL Select Primary Control Camera 2. #>ENTER 1. #>MON>ENTER Select Primary Control Monitor 2. #>MON>CNTL 1. #>CAM Select Secondary Control Camera 2.

  • Page 77: Section 3. Programming

    There are two methods for programming PreShots: “Quick” PreShots can be programmed using only the JPD-101 Controller. A PreShot programmed using the JPD-101 Controller is given a number by the operator and the JPD-101 Controller automatically assigns the title of the PreShot.
  • Page 78 The PreShot is stored in the SmartScan unit. PreShots can also be programmed using the KBD-100A keyboard and the JPD-101 Controller. This method does not apply to the KD6 Z-Series. Use procedure 1 to program and store PreShots in the KD6 Z-Series.

  • Page 79: Programming The Eight Function Keys On The Jpd-101 Controller

    PROGRAMMING THE EIGHT FUNCTION KEYS ON THE JPD-101 CONTROLLER Function keys one through eight on the JPD-101 Controller can be programmed to perform a single action such as calling a camera to a monitor, sending a SmartScan unit to a PreShot, running a VectorScan on a SmartScan unit;...

  • Page 80: Programming A Function Key

    The display appears with the cursor highlighting the Edit option. If Edit is not highlighted, move the small joystick on the JPD-101 left or right until Edit is highlighted. Push the small joystick up or down to execute the Edit option.
  • Page 81 Key#1/#1 Edit Exit Display Definitions Key#1/#1 = Function key #1/Step #1 Edit = Create a new step or modify the existing step Exit = Exit the Edit command; returns the user to the previous display Highlight Edit and push the small joystick up or down. The following display appears.
  • Page 82 Type the VectorScan No. (0-9) and press ENTER Key#1/#1 VectorScan Enter Camera No._ Enter the SmartScan unit number the VectorScan is stored in and press ENTER. The following display appears on the JPD-101. Key#1/#1 Edit Exit VectorScan-n Cam-nnn P = PreShot To program a PreShot as the first action, place the cursor on the P and move the small joystick up or down.
  • Page 83 Enter the SmartScan unit number the PreShot is stored in and press ENTER. The following display appears on the JPD-101. Key#1/#1 PreShot PreShot-n CAM-nnn S = Sequence To program a Monitor Sequence as the first action, a CATS Video switcher must be installed in the system. Monitor Sequences are stored in the CATS Video Switcher.
  • Page 84 Key#1/#1 Call Enter Monitor No._ Type the Monitor Number and press ENTER. The following display appears on the JPD-101. Key#1/#1 Edit Exit Call Cam-n Mon-n Auxiliary To control an auxiliary device, the system must have a CATS Video Switcher with the RCO-4 option installed, an AIF-100/CO Contact Output Unit, or a CRX-800 Series Control Receiver.
  • Page 85 Aux-n Cam-n OFF W = Wait A wait time can be programmed as one of the actions. The wait function causes the JPD-101 to "wait" the specified amount of time before performing the next action programmed for the Function key.
  • Page 86 1, 3, and 6 are programmed and steps 2, 4, 5, 7, and 8 are left blank, the JPD-101 consolidates the steps into 1, 2, and 3 when the operator exits the programming mode.

  • Page 87: Modify An Action Programmed For A Function Key

    Note: n = function key # The display appears with the cursor highlighting the Edit option. If Edit is not highlighted, move the small joystick on the JPD-101 left or right until Edit is highlighted. Push the small joystick up or down to execute the Edit option.
  • Page 88 When done modifying a function key, exit the programming mode by executing the Exit menu option for each display until the message DONE appears on the JPD-101 display. To execute the Exit option in a menu move the small joystick left or right until Exit is highlighted; then move the small joystick up or down.

  • Page 89: Inserting An Action Between Actions For A Function Key

    JPD-101 is displaying. Example: To insert an action between actions 4 and 5, scroll through the actions until action 5 is displayed on the JPD-101. Move the cursor to I and push the small joystick up or down. Program the inserted action as desired.

  • Page 90: Clearing A Function Key

    3.2.5 Clearing a Function Key. To clear the programming from a function key, perform the following steps. Press PRGM. Press 1. Select the function key by pressing it. Move the cursor to the C for Clear. Push the small joystick up or down. The following display appears Clear Key #n N = No...

  • Page 91: Programming Monitor Sequences In The Cats Video Switcher

    Below are examples of the displays that have the Exit function. Key #1/#1 Edit Exit Call Cam-n Mon-n The Exit option in the above display returns the operator to the Edit display. Key #n Programming Mode Edit Clear Exit The Exit option in the above display ends programming and returns the operator to the control display.
  • Page 92 Type the monitor number (1-15) you are programming the sequence for and press the ENTER key on the controller. The following prompt appears on the controller LCD display. CNTL-CAM 1 MON 1 1>ON/OFF 2>DEL 3>PRG Type 3 (program) on the numeric keypad. The following prompt appears on the controller LCD display.
  • Page 93 The following message is displayed briefly. CNTL-CAM 1 MON 1 Program is done The controller sends the data to the video switcher and the video switcher stores it. 518007-3960-F 3-17 KEMU040019 April 25, 2001...
  • Page 94 This page left blank intentionally. 518007-3960-F 3-18 KEMU040019 April 25, 2001...

  • Page 95: Section 4. Setup And Installation

    SECTION 4. SETUP AND INSTALLATION SETUP PROCEDURES Since the JPD-101 Controller can be used as stand-alone unit or two controllers can be linked together, they must be setup prior to installation for proper operation. The controller must be configured as a master unit or a slave unit and communications (between two controllers) must be enabled or disabled.

  • Page 96: Master/Slave

    Figure 4-1. JUMPER SETTINGS 4.1.1 Master/Slave. If there is only one JPD-101 Controller installed, it must be configured as a master unit for proper operation of the system. If there are two controllers linked together, one must be configured as the master and one as the slave.

  • Page 97: Enable/Disable Communications

    Table 4-1. MASTER/SLAVE CONFIGURATION Master Slave JPD-101 Jumper W8 4.1.2 Enable/Disable Communications. If only one controller is used in a system, communication is disabled. If two controllers are linked together in a system, communication must be enabled in both units.
  • Page 98 01/X, DIA-02, or DIA-02/X Control Interface Adapter, DIA-01/R Interface Panel, or the controller connector on a CATS Video Switcher. The control interface adapters and controller connector on the video switcher provide the +5 Vdc power required to operate the JPD-101 Controller. CAUTION commercially...

  • Page 99: Equipment Interconnections

    3 Reset 4 Ground 5 5 Volt EQUIPMENT INTERCONNECTIONS There are four basic installations for the JPD-101 Controllers. As a stand-alone unit controlling FastScan/SmartScan units With a CATS Video Switcher controlling the video switcher and FastScan/SmartScan units Two controllers (master/slave) can be linked together for two control...

  • Page 100: Stand-Alone Controller Installation

    4.3.1 Stand-Alone Controller Installation. When used as a stand-alone unit, the controller requires a DIA-01, DIA-01/X or DIA-01/R Control Interface Adapter. These units provide the +5 Vdc required to operate the controller and provide the cabling interface block to the FastScan/SmartScan units. Make sure the controller is configured as master and communication is disabled.

  • Page 101: Figure 4-2. Jpd-101 Controller As A Stand-Alone Unit

    Figure 4-2. JPD-101 CONTROLLER AS A STAND-ALONE UNIT...

  • Page 102: One Controller And Cats Video Switcher Installation

    Matrix Video Switcher User's Manual (M/N 517462-1960) for this setup. 4.3.2.1 JPD-101 Connected to Front Panel of CATS Video Switcher. Plug the coiled cable supplied with the controller into the controller connector on the front panel of the video switcher. Refer to Figure 4-2 for a typical interconnection.

  • Page 103: Figure 4-3. Typical Interconnect With Jpd-101 Smart Hand Controller And Cats Video Switcher

    Figure 4-3. TYPICAL INTERCONNECT WITH JPD-101 SMART HAND CONTROLLER AND CATS VIDEO SWITCHER...

  • Page 104: Connected To Rear Panel Of Cats Video Switcher

    4.3.2.2 JPD-101 Connected to Rear Panel of CATS Video Switcher. To connect the controller to the rear panel COMM connector, a DIA-01 Control Interface Adapter is required to operate the controller. The DIA- 01 can be a maximum of 4000 feet from the CATS Video Switcher COMM port.

  • Page 105: Figure 4-4. Jpd-101 Controller W/Cats Video Switcher (Rear Panel Connector)

    Figure 4-4. JPD-101 CONTROLLER W/CATS VIDEO SWITCHER (REAR PANEL CONNECTOR)

  • Page 106: Two Controllers Linked Together Installation

    4.3.3 Two Controllers Linked Together Installation. When linking two controllers together, two DIA-02 Control Interface Adapters are required. Refer to Figure 4-4 for a typical interconnection. Make sure one unit is configured as a master and one as a slave. Make sure communication is enabled on both units.

  • Page 107: Figure 4-5. Two Jpd-101 Controllers Linked Together

    Figure 4-5. TWO JPD-101 CONTROLLERS LINKED TOGETHER...

  • Page 108: Two Controllers Linked Together And A Cats Video Switcher Installation

    Using RS-422 1-twisted pair shielded cable (P/N 849518-0334), connect the transmit terminals on the DATA IN side of the DIA-02 connected to the master controller to the FastScan/SmartScan units. DIA-02 DATA IN SIDE FastScan/SmartScan Master Controller J2 Connector Black, TX+ Pin 4, Data + Red, TX- Pin 3, Data -...

  • Page 109: Figure 4-6. Two Controllers Linked Together W/Cats Video Switcher (Front Panel Connector)

    Figure 4-6. TWO CONTROLLERS LINKED TOGETHER W/CATS VIDEO SWITCHER (FRONT PANEL CONNECTOR)
  • Page 110 Make sure one unit is configured as a master and one as a slave. Make sure communication is enabled on both units. Master Unit = Jumper W8 OUT Slave Unit = Jumper W8 IN Communication Enabled Both Units = Jumper W6 IN Using RS-422 2-twisted pair shielded cable (P/N 849518-0327), connect the terminals on the DATA IN side on the two DIA-02 Control Interface Adapters for communication between the two...

  • Page 111: Two Controllers Connected To Cats Video Switcher Rear Panel Input

    The COMM connector on the rear panel of the CATS Video Switcher has 4 output ports for connection to the FastScan/SmartScan units. Refer to the CATS Video Switcher User's Manual (M/N 517462-1960) for connection to the FastScan/SmartScan domes. 4.3.4.2 Two Controllers Connected to CATS Video Switcher Rear Panel Input.

  • Page 112: Figure 4-7. Two Controllers Linked Together W/Cats Video Switcher (Rear Comm Connector)

    Figure 4-7. TWO CONTROLLERS LINKED TOGETHER W/CATS VIDEO SWITCHER (REAR COMM CONNECTOR)

  • Page 113: Installation Drawings

    The following drawings may be used as a reference before performing a system- level installation. Title Page JPD-101 Controller Unit Installation (D/N 517057-2430) ....4-20 DIA-01 Control Interface Adapter (D/N 515558-2430) .......4-21 DIA-01/X Control Interface Adapter (D/N 515558-4430)....4-22 DIA-02 Control Interface Adapter (D/N 517172-1430) .......4-23 DIA-02/X Control Interface Adapter (D/N 517172-3430)....4-24...
  • Page 114 518007-3960-F KEMU040019 April 25, 2001...
  • Page 115 518007-3960-F KEMU040019 April 25, 2001...
  • Page 116 518007-3960-F KEMU040019 April 25, 2001...
  • Page 117 518007-3960-F KEMU040019 April 25, 2001...
  • Page 118 518007-3960-F KEMU040019 April 25, 2001...

  • Page 119: Section 5. Maintenance

    SECTION 5. MAINTENANCE MAINTENANCE PROCEDURES Preventive Maintenance Use of preventive maintenance allows detection and correction of minor faults before they become serious enough to cause equipment failure. As a result, major repairs can be avoided, and the equipment can be maintained in an operable condition with a minimum of maintenance.
  • Page 120 QUALIFIED PERSONNEL ONLY. Battery Replacement The JPD-101 unit has a lithium battery located on the control board at XU4A. The life expectancy of the battery is 10 years. If necessary, replace the battery with a Dallas #DS1213C. This battery is also available through Ultrak, part number 840301-0025.
  • Page 121 RETURNING EQUIPMENT TO ULTRAK Any equipment returned to Ultrak for warranty or service repair must have a prior written Authorization to Return Material (ARM) form completed for its repair. Contact: ® Ultrak , Inc. Service Department 4465 Coonpath Road Carroll, Ohio 43112...
  • Page 122 This page left blank intentionally. 518007-3960-F KEMU040019 April 25, 2001...
  • Page 123 APPENDIX A. REFERENCE MATERIALS USER'S MANUAL INDEX The following user's manuals are for equipment associated with the JPD-101 or JPD-101A Joystick Controller Unit. Title Manual Number Universal SmartScan, SmartScan Pro, and SmartScan Pro II Operation and Programming Manual 518005-5960 FastScan and FastScan Pro II Assembly Operations Manual (9”...
  • Page 124 FastScan and FastScan Pro II Installation (15” Single Board 517955-1030) 518427-2960 SmartScan IIIB Operation and Programming 518116-2960 SmartScan IIIB Installation Manual 700499-1960 SmartScan IIIC Operation and Programming 518274-2960 SmartScan IIIC Installation Manual 518358-1960 KD6 Operation and Programming 518584-2960 KD6 Installation Tips and Maintenance 518565-1960 KD6 Z-Series Operation and Programming 518854-1960...
  • Page 125 APPENDIX B. QUICK REFERENCE GUIDE JPD-101 CONTROLLER ® ® FASTSCAN /SMARTSCAN MANUAL CONTROL FUNCTION PROCEDURE (Keystrokes are separated by a “>“) Select Control Camera Camera #> CNTL Select Control Monitor Monitor #> MON> CNTL Select 2nd Camera Camera #> CAM Select 2nd Monitor Monitor #>...

  • Page 126: Cats Video Switcher

    AUXILIARY CONTROL (Control Camera) FUNCTION PROCEDURE (Keystrokes are separated by a “>“) Auxiliaries at Control Camera (Camera Auxiliary #> AUX 1 = CATS Video Switcher Contact Outputs or SSI-100 Contact Outputs AUX> Auxiliary #> ENTER> 1 (ON) or 3 (OFF) ®...
  • Page 127 PROGRAMMING THE EIGHT FUNCTION KEYS All Keystrokes are performed on the JPD-101 Keypads. FUNCTION DEFINITION PROCEDURE (Keystrokes are separated by a “>“) Programming the Each function key can be NOTES Eight Function programmed to perform Pushing the small joystick up...
  • Page 128 PROGRAMMING THE EIGHT FUNCTION KEYS (CONT) All Keystrokes are performed on the JPD-101 Keypads. FUNCTION DEFINITION PROCEDURE (Keystrokes are separated by a “>“) Programming the S = Sequence Eight Function Monitor #> ENTER Keys (Cont) NEAR (go to next step) C = Video Switcher Call Camera #>...
  • Page 129 PROGRAMMING THE EIGHT FUNCTION KEYS (CONT) All Keystrokes are performed on the JPD-101 Keypads. Modify a Function Delete a Step Key (Cont) PRGM> 1> Function Key #> NEAR> NEAR or FAR until step to be deleted is displayed> Highlight EDIT> Highlight D> NEAR Clear Function Key PRGM>...
  • Page 130 This page left blank intentionally.

  • Page 131: C.1 Description

    APPENDIX C. INSTALLATION JPD-101/R RACK MOUNT JOYSTICK CONTROLLER DESCRIPTION The JPD-101/R Joystick Controller is designed for use in a system that requires a rack mounted controller. The operation of this controller is the same as the standard JPD-101. INSTALLATION The JPD-101/R Joystick Controller has terminal block, TB1, on the back for connection to a power supply and to RS-422 control data.

  • Page 132: C.2.1 Stand-Alone Controller

    C.2.1 Stand-Alone Controller. If the JPD-101/R Controller is used as a stand-alone controller, perform the following steps for installation. The supplied coiled cable with telephone jacks on both ends is not used for this installation. Unplug the coiled cable from the terminal block.

  • Page 133: Figure C-1. Jpd-101/R As A Stand-Alone Controller

    Figure C-1. JPD-101/R AS A STAND-ALONE CONTROLLER 518007-3960-F KEMU040019 April 25, 2001...

  • Page 134: Cats Video Switcher Rear Panel Installation

    C.2.2 CATS Video Switcher The JPD-101/R Controller can be connected to the front panel controller connector or the rear panel COMM connector on the CATS Video Switcher. Both ports on the CATS Video Switcher cannot be used at the same time.

  • Page 135: Figure C-2. Jpd-101/R Connected To The Comm Connector Of The

    Figure C-2. JPD-101/R CONNECTED TO THE COMM CONNECTOR OF THE CATS VIDEO SWITCHER 518007-3960-F KEMU040019 April 25, 2001...

  • Page 136: Cats Video Switcher Front Panel Installation

    C.2.2.2 CATS Video Switcher Front Panel Installation Perform the following procedures to connect the JPD-101/R Controller to the front panel controller connector. Connect the 6-pin DIN male connector attached to the controller’s rear panel terminal block TB-1 to the 6-pin DIN female connector attached to the additional terminal block.

  • Page 137: Figure C-3. Jpd-101/R Controller Connected To The Front Panel On The Cats Video Switcher

    Figure C-3. JPD-101/R CONTROLLER CONNECTED TO THE FRONT PANEL ON THE CATS VIDEO SWITCHER 518007-3960-F KEMU040019 April 25, 2001...

  • Page 138: Installation Drawing

    INSTALLATION DRAWING The following installation drawing is provided. Title Drawing Number Page JPD-101/R Joystick Controller Unit Installation 700385-1430 DIA-01/R Control Interface Panel Rack Mount 515979-1430 C-10 DIA-02/R Control Interface Panel Rack Mount 515979-2430 C-11 518007-3960-F KEMU040019 April 25, 2001...
  • Page 139 518007-3960-F KEMU040019 518007-3960-F KEMU040019 April 25, 2001 April 25, 2001...
  • Page 140 518007-3960-F KEMU040019 April 25, 2001...
  • Page 141 518007-3960-F KEMU040019 April 25, 2001...
  • Page 142 This page left blank intentionally. 518007-3960-F C-12 KEMU040019 April 25, 2001...
