Summary of Contents for Digital ID View IV-PBC-01
-
Page 1: User Manual
Law Enforcement Audio＆Video Recorder User Manual Model#: IV-PBC-01 Page 1 of 16 12000 Ford Road, Suite 110 Dallas, TX 75234 Tel: 972-247-1203 Fax: 972-247-1291 www.idview.com... - Page 2 I. Product Overview Digital IDView’s Police Body Camera is the latest law enforcement device that records high quality video and audio. This device applies multiple state of the art video and audio processing technologies. By offering comprehensive functions and reliable performance, it can be widely used for various solutions besides law enforcement including: security guards, the hospitality industry, court systems, delivery drivers, and any individual or company that would like to protect themselves...
- Page 3 1. Laser Sight 12. Mini USB 2. LED Fill Light 13. Power on/off 3. IR LES Light 14. PTT 4. Metal Clip 15. Video recording 5. Return/Instant Playback 16. Photograph 6. Display off/Fill-in Light 17. Audio recording 7. Confirm/Playback 18. IR/Up/Zoom in 8.
-
Page 4: On-Screen Display
On-Screen Display Page 4 of 16 12000 Ford Road, Suite 110 Dallas, TX 75234 Tel: 972-247-1203 Fax: 972-247-1291 www.idview.com... - Page 5 RECORDING Sensor 5MP CMOS Video Resolution 1920x1080P@30FPS/ 440 x080P @30FPS/1290x720 @30FPS/848 x480 PH@60FPS/848x480 @30FPS Video Format .MOV Fast-Forward 2X, 4X, 8X Rewind 2X, 4X, 8X Audio Input High Quality Built-in Microphone Audio Forward AAC2. / .WAV Watermark User ID, Time and Date Stamp Embedded into Video Camera 16 Megapixel Camera Support Burst Shot (3 or 5 photos) Image Format...
- Page 6 II. Main Features Strong night vision with the ability to see and capture high quality video of individuals and facial features clearly and efficiently within 10m in complete darkness. Double-filter switch, no color cast in the daytime, clearer image at night.
- Page 7 recording. Ability to play back audio recording, video recording, and snap shots. Video data will be partitioned and saved automatically, avoiding the data loss caused by faulty operation. Three kinds of operation prompts: vibration, LED light, and audio. III.
-
Page 8: Video Recording
Waterproof level: IP66 Drop resistance level: 2.5 meters, 8 feet flame-retarded shell Reference Data: Battery capacity: 2800mAh Full charge time: 180 minutes Standby time: 600 minutes Continuous recording time: 480 minutes (fully charged battery, IR closed, resolution ratio 640*480) ... -
Page 9: Photo-Shooting
device will give two short vibrations together with a beep prompt, the indicating light will stop blinking, and the device will stop recording and will save the video file. When the device is in the power-off state, press the recording button for 3 seconds, the device will power on automatically and start the video-recording function. - Page 10 and a yellow indicating light that blinks on top of the device. The screen will display a picture indicating that audio-recording is taking place. Once the audio-recording has been completed, press the sound-recording button again to end and save the audio file. ...
-
Page 11: Audio Playback
When the device is in the preview state, press the “Playback” button to enter the playback menu, select the video playback options. After entering the video playback menu, press the “Up” or “Down” button to select the video intended for playback. Press the “OK”... - Page 12 After the device is turned on and is in standby mode, press the menu button, and select the parameter settings, and then select the option for “Resolution” and press the “OK” button to enter. The device has 4 different resolutions to select: 1920*1080, 1440*1080, 1280*720, and 848*480H.
- Page 13 Continuous Capture Continuous capture is the process of taking continuous snapshot photos and is available during recording or when the device is in standby mode. To activate the continuous capture feature, press the “Menu” button to enter into the “Parameters Settings” and select the option for “Continuous”, press the “OK”...
- Page 14 Sound After the device is turned on and in standby mode, press the “Menu” button to enter into the “Parameters Settings” and select the “Sound” option. Press the “OK” button to enter and select one of the three options of High, Medium or Low. Press the “Up” or “Down”...
-
Page 15: Auto Shut Off
previous menu. Factory Default is set for the highest level of brightness. Auto Shutoff The device can be set to power off automatically due to inactivity and has four options of off, 3min, 5min and 10min increments. After the device is turned on and in standby mode, press the “Menu”... - Page 16 Language The equipment has two languages to select; Chinese and English. After the device is turned on and is in standby mode, press the menu button, and select the parameter settings. Scroll through the options by pressing “Up” or “Down” and press the “OK” button to select the highlighted feature.
