- Page 1 EZWall-Pro User Manual Multi-Format Video Wall Processor 2x2 HD Video Wall Controller HDMI, VGA, Composite and Y/Pb/Pr Inputs Integrated USB Media Player...
-
Page 2: What's In The Box
IR REMOTE CONTROL CONTROL VIA ETHERNET 9-11 FIRMWARE UPDATE 12-13 LIMITED WARRANTY STATEMENT WHAT'S IN THE BOX? PART NO. QTY DESCRIPTION EZWall-Pro: 2X2 Video Wall Con- EZW2X2-S troller CCPWR06 Power supply cord EZ-RMT (NEC 38 KHz) IR Remote Control SM-EYE IR Receiver... - Page 3 SmartAVI products’ signature ease of use. In this guide, you will learn how to install and optimize your experience with the EZWall-Pro using basic steps. We will cover setting the hard- ware up, activating and connecting your systems, and offer helpful tips on how to best use EZWall-Pro’s ex- cellent selection of picture modes to enhance your video wall.
-
Page 4: Technical Specifications
Photos Max Resolutions * JPEG - 15360x8640, BMP - 9600x6400, PNG - 9600x6400 Max TXT resolution: 1200x800 Other Max ANSI/UNICODE GB/UTF8 file size: 1MB *PLEASE NOTE: EZWall-Pro only supports the primary formats listed above. Any unlisted formats are not compatible with EZWall-Pro. -
Page 5: Hardware Installation
3. Connect any input to their corresponding signal source (Blu-Ray player, computer, etc) 4. Optionally connect the IR receiver to the IR input jack at the back of the EZWall-Pro. 5. Optionally connect an RS-232 cable from a PC to the RS-232 port of the unit for additional control. -
Page 6: Front Panel Control
FRONT PANEL CONTROL To switch to Video Wall mode, press the WALL button. To switch to Clone mode, press the CLONE button. To switch between listed sources, press: 1. AV 1 2. AV 2 3. VGA 4. Y/PB/PR 5. USB * HDMI (Press once for HDMI 1 and twice for HDMI 2) Figure 6-1 Figure 6-2... - Page 7 USB to RS-232 adapter. Check the RS-232 connections on your computer and the EZWall-Pro to determine if you need a male to male, female to female or male to female cable. Establish a connection to EZWall-Pro: 1.
-
Page 8: Ir Remote Control
IR REMOTE CONTROL BUTTON DESCRIPTION Select AV1 Select AV2 Select VGA Input YPbPr Select YPbPr Input Select between 2 HDMI Inputs. Press HDMI once for HDMI 1 and twice for HDMI 2 Select USB Mode ** Center Button USB Mode Enter ▲... -
Page 9: Control Via Ethernet
CONTROL VIA ETHERNET EZWall-Pro TCP/IP control is a feature that allows mode switching and other configurations to be controlled remotely via HTTP. Manage your EZWall-Pro with ease from anywhere in the world. First you must find the IP address for the EZ- Wall-Pro. - Page 10 CONTROL VIA ETHERNET (Continued) Click on the LOG IN tab in the top tool bar. Enter the User ID and Password in the Login page. The User ID and Password are case sensitive. User ID = admin, Password = 1234 You can change the User ID and password by click- ing the ADMINISTRATION button.
- Page 11 CONTROL VIA ETHERNET (Continued) You can use the internal web page to set the EZWall-Pro to Wall Mode or Clone Mode and set the desired source*. See Figures 11-1 and 11-2. Figure 11-1 Figure 11-2 * USB player requires the IR Remote Control for navigation and media selection.
-
Page 12: Firmware Update
5. Initially the Status light in the lower right side of the chip45boot2 window will be dark. Status will appear next to it. The boot loader in the EZWall-Pro is only accessible for a few seconds after you power up the EZ- Wall-Pro. - Page 13 FIRMWARE UPDATE (Continued) Click on the "Select Flash Hexfile" button. Navigate to and select the .hex firmware file. Click the "Program Flash" button. A green progress bar will display under the "Program Flash" button. The Status light will turn yel- low and display "Uploading".
-
Page 14: Limited Warranty Statement
Smart-AVI limited warranty is valid in any country where the covered product is distributed by Smart-AVI. Limitations of warranty To the extant allowed by local law, neither Smart-AVI nor its third party suppliers make any other warranty or condition of any kind whether expressed or implied with respect to the Smart-AVI product, and specifically disclaim implied warranties or conditions of merchantability, satisfactory quality, and fitness for a particular purpose.
