Trademarks and Legal Notices
Nino® and its logo are registered trademarks of Nino Robotics® (France). iPhone and iOS are registered trademarks of Apple Inc. Android is a
registered trademark of Google Inc. The owners reserve all rights to their trademarks mentioned in this manual and Nino Robotics reserves all rights
to Nino® and its logo.
Nino Robotics possesses various patents relating to the Nino® personal transportation robot as well as other patents pending. This manual was
developed by Nino Robotics, which reserves all copyrights on it. No institute or individual may copy or distribute this manual in whole or in part or
make use of the above-mentioned patents without the express written consent of Nino Robotics.
We have tried as much as possible to include a description and instructions for all of Nino®'s functions at the time of printing, but there may still be
differences with what you have purchased due to improvements or changes in the design of the functions. Please visit our website at
Nino-robotics.com to download and consult the latest electronic user manual for the device.
Nino Robotics reserves the right to explain any difference between the latest version of the product and that described in this manual in terms of
color or appearance.
- I -
®
Nino
user manual
Advertisement
Table of Contents
Related Manuals for nino robotics NIno
Summary of Contents for nino robotics NIno
- Page 1 Trademarks and Legal Notices Nino® and its logo are registered trademarks of Nino Robotics® (France). iPhone and iOS are registered trademarks of Apple Inc. Android is a registered trademark of Google Inc. The owners reserve all rights to their trademarks mentioned in this manual and Nino Robotics reserves all rights to Nino® and its logo. Nino Robotics possesses various patents relating to the Nino® personal transportation robot as well as other patents pending. This manual was developed by Nino Robotics, which reserves all copyrights on it. No institute or individual may copy or distribute this manual in whole or in part or make use of the above-mentioned patents without the express written consent of Nino Robotics. We have tried as much as possible to include a description and instructions for all of Nino®’s functions at the time of printing, but there may still be differences with what you have purchased due to improvements or changes in the design of the functions. Please visit our website at Nino-robotics.com to download and consult the latest electronic user manual for the device. Nino Robotics reserves the right to explain any difference between the latest version of the product and that described in this manual in terms of color or appearance. - I - ® Nino user manual...
- Page 2 About this manual Thank you for choosing the Nino® personal transportation robot. In this manual, you will find the operating instructions for Nino®, which will help you to: Gain an understanding of the basic operation of Nino®, its driving methods, and its remote control; Familiarize yourself with safe driving methods as well as the techniques that must be learned to move around as pleasantly and safely as possible; Understand the structures and operational modes of Nino® as well as how to perform regular maintenance; Achieve the maximum benefit from your Nino® in total safety. Make sure that you have read and understood the significance of the following symbols. This manual does not eliminate the need for mandatory training from your authorized retailer or lessor. Danger! Caution! Q&A Info - II - ® Nino user manual...
-
Page 3: Table Of Contents
1. Introduction ........................................... 6 1.2 Nino® diagram ........................................ 7 2. Serial number/warranty certificate .................................... 8 3. Safe driving guide ...................................... 1 0 3.1 Operating diagram ........................................ 1 1 3.2 What not to do with the Nino .................................... 1 2 3.3 Driving modes ........................................ 1 3 3.4 Active security ........................................ 1 4 3.5 Smart safety system/automatic protection ................................ 1 4 4. En route to your first ride! .................................... 1 6 4.1 Preparation ........................................... 1 6 4.2 Starting the Nino® ........................................ 1 7 4.3 Steps to take before getting on your Nino® ................................. 1 7... - Page 4 4.4 Getting on your Nino® and maintaining balance .............................. 1 8 4.5 Driving forward/reversing .................................... 2 0 4.6 Braking .......................................... 2 1 4.7 Turning .......................................... 2 2 4.8 Assisted power ........................................ 2 3 4.9 Navigating sidewalks ...................................... 2 4 4.10 Introduction to the different operating modes .............................. 2 5 4.11 Getting to know the remote and in-dash key systems ............................ 2 5 5. Other functions ........................................ 2 7 5.1 Your vehicle's companion ..................................... 2 7 5.2 Electronic kickstands ...................................... 2 8...
- Page 5 6. Daily maintenance ...................................... 3 0 6.1 Cleaning and storage ...................................... 3 0 6.2 Battery transport and maintenance .................................. 3 1 6.3 Checking for loose screws .................................... 3 2 6.4 Checking tire pressure ...................................... 3 3 6.5 Handling and storage in the trunk of the car ................................ 3 3 6.6 Regular maintenance ...................................... 3 4 7. Technical data sheet ...................................... 3 5 Contact us ............................................ 3 6 - V - ® Nino user manual...
-
Page 6: Introduction
1. Introduction 1.1 What is Nino®? The Nino® personal transportation robot is a new generation of electric auto-balanced seated vehicle, equipped with automatic and smart functions. The driver moves him/ herself while seated on the robot and operates it with the movements of the upper body (torso) or controls it with the aid of mobile devices such as smartphones in future versions. Nino® is proud to present the following functions: It is auto-balanced: its wheels can pivot on the spot. When driving, the operator controls the machine with the position of his/ her body instead of an accelerator and a brake, which makes steering comfortable and intuitive. The robot can balance itself automatically so that if the driver is there and leans forward, the wheels will turn forward. The wheels will turn backwards if the driver leans back. The driver can also turn right or left simply by turning the steering bar in the corresponding direction. The balance of the Nino® depends on the working efficiency of its high-speed processor, the precision of its gyroscope, and the motor. If one of these malfunctions, the machine will lose balance. Therefore, a powerful dual-backup control system is specifically provided in the Nino®—meaning that each essential circuit system in the machine is equipped with a backup system. If one essential module stops working, it will be taken over by its backup, thus maximizing safety during movement. The Nino® has a projection surface similar to that of a person and offers great handling. It can thus access the majority of areas where it is possible to walk, including trails, sidewalks, hallways, rooms, and elevators. - 6 - ® Nino user manual... -
Page 7: Nino® Diagram
1.2 Nino® diagram - 7 - ® Nino user manual... -
Page 8: Serial Number/Warranty Certificate
2. Serial number/warranty certificate The warranty certificate contains the details of the guaranteed items, the information necessary for accessing maintenance service and ordering accessories, the effective warranty date signed by your retailer, the contact information of the latter, and his/her stamp. Furthermore, a label with a unique serial number is affixed to the first page of your warranty certificate. The serial number is a combination of 14 numbers and letters that you can find: on the first page of the warranty certificate; Ø on the part that supports the battery on the base of the main structure; Ø on the outer side of the packaging. Ø - 8 - ® Nino user manual... - Page 9 2.1 Nino® diagram - 9 - ® Nino user manual...
-
Page 10: Safe Driving Guide
THIS SECTION IS VERY IMPORTANT. PLEASE READ IT ATTENTIVELY AND ENSURE THAT YOU HAVE UNDERSTOOD ALL THE INSTRUCTIONS. NINO® IS NOT RESPONSIBLE FOR ANY LOSSES, DAMAGES, ACCIDENTS, OR DISPUTES WHICH MAY RESULT FROM THE FAILURE TO RESPECT THE SAFETY INSTRUCTIONS DISCUSSED IN THIS SECTION. THE DRIVER TRAINING FROM YOUR RETAILER IS OBLIGATORY. -
Page 11: Operating Diagram
Raising the kickstand Gyro-stabilized device Turning left Turning right Moving forward Stopping Braking and reversing Lowering the kickstand/ parking - 11 - ® Nino user manual... -
Page 12: What Not To Do With The Nino
3.2 What not to do with the Nino® Do not use your Nino® in dangerous areas or contrary to the usual precautions, such as in places where there are damaged Ø pathways (potholes, etc.) or puddles more than 3 cm deep. Do not climb or descend staircases. Do not lift your Nino® off the ground when it is activated. Do not drive on emergency lanes or Ø on one wheel. Do not drive on the highway or the road. Ø Ø Do not drive with multiple people on the Nino®, especially while carrying a baby. Do not let go of the steering bar with both hands at once. Ø Do not let children under the age of 14 drive the Nino® without supervision. Driving it is also forbidden for pregnant women, people in a state of inebriation or suffering from mental disorders, cardiac diseases, or handicaps limiting their ability to drive. Do not drive the Nino® in a dangerous environment, particularly places exposed to accidents linked to fire or explosions due to Ø flammable products/liquids/dust and fibres, to gas, etc. Avoid driving in reverse at high speed or navigating tight corners in reverse. Do not use the telephone while driving. Ø Ø Do not drive in inclement weather and on roads in bad condition in the rain or freezing rain that makes the road surface slippery. Do not go against the recommendations of this manual, especially those clearly indicated with a “warning” or a “danger.” Ø 3.3 Driving modes Comport yourself in a civilized manner without entering into conflict with the people around you. Ø - 12 - ® Nino user manual... -
Page 13: Active Security
Ø Ø Respect the right of way for pedestrians and avoid startling them. When you find yourself behind someone, indicate your presence and pass them on the left while reducing your speed. When you find yourself in front of someone, keep to the right while slowing down. Ø When you find yourself in a crowd, slow down and adjust your speed to match the pedestrians until a safe path allows you to pass. Driving quickly in a crowd may prove dangerous. When you are traveling with other Nino® drivers, maintain a safe distance between yourselves and keep yourself away from any Ø dangers or obstacles. Do not drive side by side unless there is enough room on your left to allow pedestrians to pass. Do not park your Nino® in a place that could block the passage of pedestrians. Ø Ø Do not drive your Nino® in an area that is insufficiently lit. If this is truly necessary, slow down, take caution, and use the headlights to make yourself noticed. UNDER NO CIRCUMSTANCES IS THE DRIVER TO LEAN ON THE STEERING BAR. IT IS DANGEROUS AND IT IS ONE OF THE MAJOR CAUSES OF ACCIDENT AND INJURY BECAUSE THE NINO® MAY LOSE BALANCE, ESPECIALLY DURING ACCELERATION OR WHILE DRIVING AT A HIGH SPEED. Stay relaxed while driving, with elbows slightly bent and head straight. Driving in reverse is dangerous. Avoid this unless it is only for a Ø... -
Page 14: Smart Safety System/Automatic Protection
Do not drive in difficult conditions if you cannot adhere to the safety advice and warnings given in this manual or if you are under the Ø influence of drugs or alcohol. Ø For your safety, do not use your Nino® and recharge it in case of insufficient battery life. The same applies in cases of repeated warnings or if the speed is limited. Please place any items that you are carrying in your backpack instead of putting them on the floor. Ø Ø Make sure that the Nino® is switched off and the kickstands are withdrawn before transport; otherwise, a rapid rotation of the wheels may cause injuries. It is recommended to transport the Nino® with two people. Do not raise it by the wing, as you may pinch your fingers. Ø Check that no screws are missing and that no part is damaged before use. Do not start the Nino® as long as these problems have not been resolved. Perform regular maintenance on your Nino® in accordance with section 7 of this manual. Ø 3.5 Smart safety system/automatic protection In the following situations, the Nino® will reduce its speed automatically to a level which will ensure your protection: Overload or prolonged handling on a slope. The smart protection will be activated and the Nino® will tilt backwards to remind the Ø driver that he/she should stop when the load on the Nino® exceeds the weight initially provided for too long. This may happen in the following cases: when prolonged parking on a steep slope is felt as an overload by the device or in case of an overweight driver. When these situations arise, the driver must exit the Nino®. The driver may fall if he/she remains on the device after more than 5 seconds of standby. Insufficient battery life. When the battery life is less than 40%, the maximum speed in balanced mode is reduced, meaning the Nino® Ø limits its speed. Insufficient battery power. If the smart safety system is activated during movement because the power level of your battery is too low Ø (generally below 10%), you must deploy the kickstands in parking mode immediately and recharge the Nino®. In this case, the floor will position itself so as to force the driver to stop if he/she continues to move. - 14 - ® Nino user manual... - Page 15 Internal default. The Nino®’s smart safety mode detects any internal default (such as a loss of power in the battery or a rupture of a Ø balance sensor unit). If the driver is still driving the Nino® when this happens, he/she must stop the Nino® and contact customer service to have it repaired. If you hear the alarm just after turning on the ignition, then that may indicate that the battery is not sufficiently charged. In this case, recharge it. If you have installed the application Ninedroid on your smartphone (free application), you can use the “smart diagnostics” function on the application to determine what the problem is and how to resolve it. If the problem persists, please send an email as soon as possible to our customer service team : info@nino-robotics.com The specific error code with the key icon appears on the dashboard of the application. Ø - 15 - ® Nino user manual...
-
Page 16: En Route To Your First Ride
4. En route to your first ride! 4.1 Preparation For your first ride, choose an adequate location, inside or outside, with an area of at least 16 m (4m x 4m). Ensure that the floor is flat Ø without wet or slippery surfaces, with no obstacles, automobiles, bicycles, pets, children, or other objects that could divert your attention. You will need the help of an instructor certified by Nino Robotics. Ø Ø Place your Nino® at the centre of the space that you have chosen. Ø You must be familiar with all the functions of the remote key. - 16 - ® Nino user manual... -
Page 17: Starting The Nino
4.2 Starting the Nino® Use the remote key and push the “Power on/off” button to start the Nino®. When you hear the starting signal, the lights on the dashboard will flash, then light up successively. Finally, the battery indicator will appear, which means that the start-up of the Nino® was successful. Power button on the remote key. You must always start and stop flat. If you are driving a Nino® for the first time, do not be in a hurry to get on it. For your safety, practice the following steps for a few minutes. 4.3 Steps to take before getting on your Nino® First of all, turn on the machine by clicking the ON button on the remote control. Then, please remove the central bar, place your back to the Nino, and sit firmly on the bottom of the seat. Afterwards, please put the directional bar back to the central level. The Nino® will then be in standby mode. From there, please lift the electric kickstand by pressing on the lift control for the stands (top arrow) on the side of the Nino. The Nino® will then be in assisted driving and auto-balanced mode. - 17 - ® Nino user manual... -
Page 18: Getting On Your Nino® And Maintaining Balance
Do not sit on the Nino® if the kickstands are not resting on the ground. 4.4 Getting on your Nino® and maintaining balance The majority of beginners only need a few minutes to familiarize themselves with the operation of the Nino®. It is obligatory that your instructor remains beside the Nino® and helps to keep you at the steering bar to ensure that nervousness doesn’t make you awkward for your first use. Ø Sit on the seat and look in front of you instead of at the ground while you are seated on the Nino®. Place your feet well forward on the footrest. Ø Push the button on the side (after having started the Nino) to lift the electronic kickstands while looking forward and remaining still. Ø - 18 - ® Nino user manual... - Page 19 TRANSFER FOR PEOPLE IN WHEELCHAIRS. TO GET OFF THE NINO, FOLLOW THESE STEPS IN THE REVERSE ORDER. The more relaxed you are, the easier it will be to maintain balance. It is much easier than riding a bicycle. Certain people sway back and forth when they get on the Nino® for the first time, but if you imagine the Nino® as a flat place, that can help you to maintain balance. Sit down, relax, and let your instructor hold the steering bar, and soon you will stop swaying. - 19 - ® Nino user manual...
-
Page 20: Driving Forward/Reversing
4.5 Driving forward/reversing Ø Lean your torso and your shoulders slightly forward to sense the movement of the Nino®, then return to your position to sense the deceleration and stop. Just be moderate and repeat this action several times to adapt to the movements controlled by your body’s centre of gravity. Forward motion Stopping Braking and reversing - 20 - ®... -
Page 21: Braking
For a beginner, it is necessary to act slowly and gently. The posture of your body should be relaxed in order to avoid swaying. Overly abrupt back-and-forth movements can make the wheels slip or cause a loss of control. This is very dangerous and should be avoided. Tilt your chest and shoulders slightly backwards to brake and reverse the Nino® progressively. Then return to your initial position to Ø sense the deceleration and stop the machine. Repeat the movement several times and avoid falling or striking a wall or any other obstacle. Driving in reverse is dangerous. It should not be a normal form of driving. Only do it for a distance of less than one meter. It is preferable to turn and continue forward. If you drive backwards at an excessive speed, the Nino® will begin to shake and an alarm signal will sound. 4.6 Braking If you move your centre of gravity in the opposite direction from where you are driving, you will be able to stop your Nino®. To do this, proceed in the following manner. When you are advancing forward, lean your chest and shoulders backwards. This will stop the Nino®. Find a spot or take a few laps and train yourself to stop while maintaining balance. - 21 - ® Nino user manual... -
Page 22: Turning
Try to stop the Nino® in a moderate and progressive fashion rather than abruptly. Move the weight of your body slowly in the direction of travel so that the Nino® stops smoothly. On asphalt-type surfaces, the emergency braking distance when the Nino® is moving rapidly is 4 meters. Never accelerate or brake suddenly on a wet or slippery road because that may cause the wheels to slip, leading to an accident and causing injuries. 4.7 Turning When you tilt the navigation bar to the left or right, the Nino® turns in the corresponding direction. Teach yourself to turn. Turn slowly in the direction you desire. Repeat these movements until you have mastered the technique. Train yourself to make turns on the spot once you have familiarized yourself with driving forwards and backwards and braking. Tilt the bar in the direction you wish to turn. The angle should be the same as that of the steering bar. Make several attempts in order to master the technique. Whether you are stopped or in motion, never turn abruptly. Your body can lose balance. Consequently, when you plan to turn, slow down and lean your body in the desired direction so as to improve your stability. -
Page 23: Assisted Power
Ask your instructor to help you to get out one step at a time and to hold the navigation bar (except for people in wheelchairs). Furthermore, for 15 seconds, the kickstands can be activated even if the Nino® is turned off (to allow you to store it in the dedicated flycase). To get down from the Nino: Push the lateral button to extend the kickstand downwards. Do not touch the remote control because the device will automatically enter standby mode after the kickstands have been activated. Remove the central bar and exit by the front of the vehicle or lower the armrests and exit out the side. Turn off the machine with the remote control and the OFF button. 4.8 Assisted power Once you have gotten off the Nino® and after having remounted the electronic kickstands, it will return from balanced mode to assisted power mode. Accordingly, the Nino® will advance/reverse or slightly turn according to your movement of the steering bar. Switch to assisted power to bypass sidewalks, bumps, stairs, or dangerous or unsuitable terrain along the side of the road. - 23 - ® Nino user manual... -
Page 24: Navigating Sidewalks
4.9 Navigating sidewalks Climbing a sidewalk more than 5cm high (max 15 cm) with assistance Descending from a sidewalk up to 15cm high - 24 - ® Nino user manual... -
Page 25: Introduction To The Different Operating Modes
4.10 Introduction to the different operating modes The Nino® offers the following operating modes (Status): Off mode: In “off mode,” all the electronic control systems are stopped. Only the remote key remains functional in order to Ø start up the device again. Standby mode: the Nino® is on, but it does not maintain balance by itself. In standby mode, the majority of systems are Ø activated, but the motor control system is resting, although it can be activated every now and then if necessary. Balanced mode: the Nino® balances itself and all systems are operating at full power. This state assumes the presence of a Ø person on the device or close to it and with a limited speed. 4.11 Getting to know the remote and in-dash key systems The appearance of the remote key and the functions of its different buttons are described in the following table. You may carry it on the keychain provided by us so you do not lose it. On the remote key, you will find four buttons defined in the table below: Ignition ; Locking; Information ; Passage at limited speed . Each of these buttons may be activated in two ways—namely, by a long pressure, which lasts more than 1.5 seconds, and by a short pressure, which lasts less than 1.5 seconds. - 25 - ® Nino user manual... - Page 26 - 26 - ® Nino user manual...
-
Page 27: Other Functions
12VDC. The Nino® car charger can therefore normally function if your cigarette lighter operates at 15A or more. If this is not the case, the car charger may not work or the fuse in your car might melt. You may only use the Nino® car charger if your car is moving. Do not use it very long if your car is stopped because the battery capacity of the Nino® may be higher than that of your car. Charging your Nino® while your car is stopped may drain the battery in your vehicle and you may not be able to start it again. - 27 - ®... -
Page 28: Electronic Kickstands
5.2 Electronic kickstands The Nino® models are equipped with electric kickstands for parking. You can use these kickstands for parking your Nino® and to allow you to put the Nino® into standby mode automatically. You must put down the electronic kickstands before getting off the Nino! The kickstand may only be used when you have come to a stop with the Nino®. To avoid others using your Nino® recklessly, we strongly recommend that you lock or switch off your device whenever you are away from it. 5.3 Integrated USB charging port You will find a USB port on the steering bar of your Nino® that fits any standard USB device and produces a current up to 5V/1A. You can recharge your Nino® via this port with a device having an external USB port. This USB port works only when the Nino® is switched on. It is only intended to provide current up to a maximum voltage of 5V/1A. It does not have the ability to transmit data. Do not connect any USB device using a current greater than 1A. If you connect devices with a high energy demand, you risk cutting power to the dashboard and compromising your safety while driving. - 28 - ® Nino user manual... -
Page 29: Tire Replacement
5.4 Tire replacement Replace tires that have been worn out by use because they can compromize your safety during travel, and immediately replace any punctured tires (tread depth from the surface of the tire <1mm or totally worn). We suggest that you call our customer service line for any tire replacements because it is tubular and must be installed and taken apart with tools specific to Nino. However, if you prefer to perform the replacement yourself, we recommend that you replace the tire/rim assembly in its entirety. - 29 - ® Nino user manual... -
Page 30: Daily Maintenance
You can use a shower or watering hose (the water pressure must be less than 1Mpa or 145PSI) to clean the tires and the external parts. Then, wipe it down and place it in a well-ventilated area in order to avoid any erosion. Difficult-to-remove dirt on the plastic surfaces may be cleaned with a toothbrush and a bit of toothpaste. Afterwards, clean it with a wet cloth. This method can also be adopted to eliminate scratches on the surface. Dry the Nino® in a cool, enclosed area. Do not leave it outside for a prolonged duration. Exposure to the sun or to a hot or cold environment could prematurely alter its appearance. When you clean your Nino®, make sure that it is switched off and disconnected. These latter situations would not be covered by the warranty! Do not leave your Nino® under a tap and do not leave it soaking in the water. The water could penetrate the interior and irreparable damages could result. These damages would not be covered by the warranty! Do not clean the Nino® with alcohol, a spray, diesel, acetone, or any other volatile or abrasive chemical solvent. These substances could ruin the appearance and the internal structure of the Nino®. These damages would not be covered by the warranty! - 30 - ® Nino user manual... -
Page 31: Battery Transport And Maintenance
6.2 Battery transport and maintenance The battery on the Nino® demands the greatest attention. A well-maintained battery can ensure optimal performance, even after a 20 or 30,000 km trip, whereas if you neglect it, it can function well below its abilities or become damaged after only a few months. In order to prolong the life of your battery, you must perform the maintenance and verifications according to the following recommendations: Read the recommendations on the label of the battery closely. Keep the battery in a dry environment where the temperature is between 0°C and 40°C. Using or storing the battery in a very high temperature environment (above 50°C) or in a very low temperature (below -20°C) will affect its lifespan. Try to store your battery in a cool and dry environment. In an extremely humid environment, the dew or the water may infiltrate the battery, quickly leading to damages. If a humid environment is unavoidable, store it in an airtight bag. Do not use the full capacity of the battery and recharge it daily, but do so when there is still 10%-20% power remaining. Recharge the battery each time you have finished using your Nino®. Frequent recharging will not affect its performance or its longevity, but using it until it is totally drained certainly will. If the battery is mounted on the Nino, the receptor on the remote control will continue to consume energy. In addition: It is not necessary to take out the battery when the period of non-use of the Nino® does not exceed 30 days, but remember to completely recharge the battery before storing it. Completely recharge the battery, take it out, and store it in a cool and dry place if you don’t expect to use your Nino® for a period longer than 30 days. When the battery must be stored for a very long period (more than 180 days), recharge it every 5 or 6 months in order to conserve its capacity and its lifespan. Remember to recharge the battery after each trip. Using the battery until it is completely drained may cause irreversible damages that are not covered under the warranty. - 31 - ®... -
Page 32: Checking For Loose Screws
The battery on the Nino® is equipped with ion cells with various protective functions. It is the holder of the UN38.3 aerial transportation certificate, the drop test certificate at 1.5, and the UL certificate. Fire, explosion, or shocks will not occur during normal use, but as a precautionary measure, do not penetrate the battery with a pointed object, do not strike it with heavy objects, and do not expose it to fire or water, which could put you in danger or pollute the environment. Most airline companies or express delivery companies such as UPS, DHL, and TNT can deliver the battery to you by airplane on the condition that you present them with the UN38.3 test report and the other compliance tests. These documents can be downloaded from our official website in the “support & service” section. You may also obtain a copy of these documents from the customer service department of your retailer. However, we cannot guarantee that all express delivery companies will agree to transport the Nino®’s battery, since their decisions may be affected by changes in aerial transportation rules and by the security regulations of different countries, airlines, or airports. 6.3 Checking for loose screws Thanks to a special treatment, all the screws on the Nino® are designed so as not to loosen, but as a safety measure, perform a verification of the screws on the rims, on the steering bar, on the battery, on the wing, on the floor, on the dashboard, etc., or have this done at one of our stores. Shake these components yourself to see if they move or if they emit sounds that could indicate that they are loose. If this is the case, tighten them with the tools provided with the product. 6.4 Checking tire pressure Under normal conditions, the pressure of the tires should be kept between 10 PSI and 15 PSI (70-100 kPa). Tire pressure should not exceed 25 PSI (170 kPa). Overly high tire pressure many diminish their resistance to friction, prolonging the number of kilometers but perhaps altering the effect of the shocks, whereas a low tire pressure will reduce the number of kilometers ensured by the battery, but will suit steep roads. Each of these two cases may accelerate wear and tear on the tires. - 32 - ® Nino user manual... -
Page 33: Handling And Storage In The Trunk Of The Car
6.5 Handling and storage in the trunk of the car Handle the Nino® in a reasonable manner according to the following guidelines: Ensure that it is switched off and that the kickstands are raised. If the Nino® is not properly secured in your trunk, then please lower the kickstands to keep it more stable. Remove the steering bar if you wish to place the Nino® in the trunk of your car. If you possess a container adapted to your trunk, use it to store the Nino® and keep it secure. Ask for help from another person to put the Nino® in their trunk. An adapted ramp may be provided as an option on our dedicated website. 6.6 Regular maintenance Besides fixing the screws, changing the tires, the fenders, and the battery, there are no other parts able to be repaired by the user. In addition, do not take it apart yourself. In case of problems, contact us or an authorized repair service. - 33 - ® Nino user manual... - Page 34 Send your Nino® to your retailer regularly for maintenance. Your safety and the optimal performance of your device will thus be ensured. - 34 - ® Nino user manual...
- Page 35 - 35 - ® Nino user manual...
-
Page 36: Contact Us 3
Contact us You can contact us in the following manner if you wish to consult us regarding problems related to driving, the maintenance of the device, and safety, or to indicate a product breakdown. We are at your service. Nino Robotics Headquarters: Tel: +34 951 20 89 60 646 262035 Email (information): info@nino-spain.com Website: www.Nino-spain.com - 36 - ® Nino user manual...
