Warranty Information
Cooler Master guarantees that this device is free of defect in material and
workmanship, and provides a two-year limited hardware warranty for the device
commencing from the date of purchase. Please keep your receipt for proof of
purchase.
This product is designed for computer usage only. Using this device in any other
capacity voids the warranty. If you are not familiar with computer hardware
installation, please ask for professional assistance.
The warranty offered covers normal use. Defect or damage that result from
improper operation, storage, misuse or abuse, accident or neglect, which are not
the fault of Cooler Master, are exclude from warranty coverage.
Note: the warranty is voided by removal or alternation of product or parts identification labels.
Chapter 1: Product Overview
Specifications:
Available Color
Silver/Black
Dimensions
L485 x W208 x H442 mm
Weight
10kg
Material
Aluminum bezel, SECC chassis
M/B Type
ATX 12" x 9.6" (30.5cm x 24.5 cm);Micro-ATX
5.25"
5 (Exposed)
3.5"
1 (Exposed); 5 (Hidden)
Cooling System
One 120x120x25mm front fan ( Intake);
One 120x120x25mm rear fan ( Exhaust ) (optional)
I/O Panel
USB2.0 x 2; MIC x 1; SPK x 1; IEEE1394 x 1
Power Supply
Standard ATX PS2, 380W or 430W (optional)
Specification & Parts list
Centurion 532
English
1
Advertisement
Table of Contents
Related Manuals for Cooler Master Centurion 532
Summary of Contents for Cooler Master Centurion 532
- Page 1 English Warranty Information Cooler Master guarantees that this device is free of defect in material and workmanship, and provides a two-year limited hardware warranty for the device commencing from the date of purchase. Please keep your receipt for proof of purchase.
- Page 2 Centurion 532 English Item Parts Name Item Parts Name Panel Filter 22 USB Alumnus Post 23 Casing Panel 24 Left Side Casing Fan Filter 25 Right Side Casing Big Shield 26 Pad Small Shield 27 Side Panel Screws Big Shield Filter...
- Page 3 Centurion 532 English Chapter 2: Installation Removing side panels 1. Loosen the screws manually; slide the side casing backward to remove 2. To assemble it, please follow the above step reversely. Installing the Motherboard 1. Remove the side casing. 2. Lie down the casing.
- Page 4 Centurion 532 English Installing Drives (CD-ROM, FDD and HDD) 1. Loosen the latches on upper/lower side of the panel inside the casing. 2. Loosen the panel from one side first, then the other. Then you can remove the front panel.
- Page 5 Centurion 532 English Take out the HDD rail from the package. Install it on the HDD and have the screw holes aligned. Insert the assembled HDD into the hardware rack. Installing the power devices 1. Remove side casing. 2. Place the power supply on the...
- Page 6 Centurion 532 English I/O Function Panel Installation Guide Please refer to the illustration on the section of USB2.0, IEEE 1394a, and Audio connector from the motherboard user’s manual. Please select the motherboard which used the same USB2.0, IEEE1394, AC’97 standard as below;...
