INSTRUCTION MANUAL
PRODUCT TYPE
DIGITAL TORQUE WRENCH

DEAR USER

Thank you for purchasing this digital torque wrench.
This manual will help you to use the many features
of your new digital torque wrench.
Before operating the torque wrench, please read
this manual completely, and keep it nearby for fu-
ture reference.

MAIN FEATURES

Digital torque value readout.
■
+/-2% for torque accuracy.
■
CW and CCW operation.
■
Peak and hold track mode selectable.
■
Buzzer and LED indicator for the 9 pre-settable
■
target torques.
Engineering units (Nm, ft-lb, in-lb, kg-cm)
■
selectable.
50 data memory for recall and joint torque
■
auditing.
Auto sleep after about 5 minutes idle.
■
Both AA and rechargeable batteries are
■
compatible.
MODEL
7314-1030
7338-1135
7312-1200
7312-1340

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7314-1030 and is the answer not in the manual?

Questions and answers

Related Manuals for Polar Electro 7314-1030

Summary of Contents for Polar Electro 7314-1030

  • Page 1 INSTRUCTION MANUAL PRODUCT TYPE MODEL DIGITAL TORQUE WRENCH 7314-1030 7338-1135 7312-1200 7312-1340 MAIN FEATURES Digital torque value readout. ■ +/-2% for torque accuracy. ■ DEAR USER CW and CCW operation. ■ Thank you for purchasing this digital torque wrench. Peak and hold track mode selectable.
  • Page 2 Down button Power on/clear mode Pre-setting number P (Peak hold) / T (Track mode) SELECTION GUIDE MAX. OPERATION TORQUE SQUARE DRIVE MODEL INCHES ft-lb in-lb kg-cm 7314-1030 22.12 265.5 306.1 7338-1135 99.5 1195 1378 7312-1200 147.5 1770 2041 7312-1340 250.7...

  • Page 3: Specifications

    TORQUE TORQUE ” + /- 1 increment. The torque accuracy is a typical value. Calibration point is at the middle line of the five anti-grip lines on 7314-1030 1.5~30 the rubber handle. For keeping the accuracy, calibrate the 7338-1135 6.8~135 wrench for a constant period time (1 year).
  • Page 4 BEFORE USING THE WRENCH SETUP Unit selection Battery Installation /setting Pre-setting no. Remove the battery cap. ■ Power on/clear Up/down buttons Insert two R6/AA batteries matching the -/+ ■ polarities of the battery to the battery compartment. 1. Pre-setting no. Replace the battery cap and rotate it tightly ■...
  • Page 5 TRACK MODE OPERATION 3. Set torque value START Pre.setting torque value (System initial) Press *Note 1 Increase max. torque value Setting target torque Press Apply torque Decrease max. torque value Current torque value Note: The “Unit selection” is cyclic. Reach 80% of target torque 4.
  • Page 6 PEAK HOLD MODE OPERATION PEAK HOLD MODE RECORDED VALUE REVIEW START *Note 1 (System indicate) Peak hold/Track mode *Note 1 Long press *Note 2 Setting target torque *Note 2 Set Peak/Track mode Recording Apply torque Press Auto change Released *Note 3 Record no.

  • Page 7: Maintenance And Storage

    COMMUNICATION MAINTENANCE AND STORAGE Precaution: Attention! 1. Communication function is only supported One-year periodic recalibration is necessary to maintain on some models. Check the model no. and accuracy. Please contact your local dealer for calibra- its specification before using communication tions.
  • Page 8 POLAR TOOLS A/S SOLDALEN 9 . 7100 VEJLE . DENMARK . INFO@POLARTOOLS.COM . WWW.POLARTOOLS.COM...
