Summary of Contents for ISHIMA Rave M1.0S

  • Page 1 Instruction Manual...
  • Page 2: Table Of Contents

    This manual is protected by a copyright and nothing from this edition may be reproduced or used without any prior written authorisation. Whilst every effort has been made to ensure the accuracy of the information in this manual, errors do creep in and ISHIMA RACING ©...
  • Page 3: Safety Precautions

    I. Safety precautions This radio controlled model is NOT a toy. Is is recommended that children under the age of 16 are under adult supervision when oper- ating an RC model. It is important that you read and respect the instructions of this handbook. You alone are responsible for this model’s safe operation, therefore you should take enough safety precautions prior to operating this model.
  • Page 4: Assembly Of Your Model

    IV . Assembly of your model BAG A FROnT & REAR dIFFEREnTIAlS Front & Rear differentials Diff Case (F/R) RVB-S034 Diff. Drive Cap Joint Ø2 x 9 mm Pin RVB-S055 RVB-S103 O-ring Ø5x1,5mm RVB-S189 Ball bearing Ø8x16x5mm Diff. bevel gear 18T RVB-S144 RVB-S070 Ø2 x 9 mm Pin...
  • Page 5: Center Differential

    BAG B CEnTER dIFFEREnTIAl Center diff. Diff Case (F/R) RVB-S034 Ø2 x 9 mm pin Center diff.out drive RVB-S056 RVB-S103 Ball bearing Diff. bevel gear 18T Ø8x16x5mm RVB-S070 RVB-S144 Ø2 x 9 mm Pin O-ring RVB-S103 RVB-S189 Shim ring RVB-S089 Diff.
  • Page 6: Assembly Of Front Gearbox

    High Speed Grease Shim ring Ball bearing Ø13x16x0,2mm Ø8 x 16 x 5 mm RVB-S088 RVB-S144 Shim ring Ø13x16x0,2mm RVB-S088 RAVE M1.0S Pinion Gear13T R/H M3 x 12mm RVB-S069 OPTION CNC Racing Pinion Gear13T Shim ring RVB-S069-R (option) Ø13x16x0,2mm RVB-S088 Gearbox...
  • Page 7: Assembly Of Front Shock Tower

    BAG E ASSEMBly OF FROnT ShOCk TOwER RAVE M1.0S CNC Front Shock Tower 6061 M1.0S RVB-S078-S Front Body Mount RVB-S046 RAVE M1.0R CNC Front Shock Tower 7075 M1.0R RVB-S078-R R/H M3 x 12mm (5) Screwbag RVB-S141 BAG E ASSEMBly OF FROnT SuSPEnSIOn ARMS...
  • Page 8: Assembly Of The Front Stabilizer

    ASSEMBly OF ThE FROnT SuSPEnSIOn PlATE R/H M3 x 8mm (4) Front Upper Susp. Plate RVB-S080 R/H M3 x 12mm (2) RAVE M1.0S Front Upper Susp. Hinge Pin Holder Plastic: RVB-S043-S OPTION CNC Front Upper Susp. Hinge Pin Holder 7075: RVB-S043-R...
  • Page 9: Assembly Of The Front Suspension Arms

    BAG G ASSEMBly OF ThE FROnT SuSPEnSIOn ARMS E-Clip bag: RVB-S141 Caster clip set RVB-S199 Front Upper Susp. Arm RVB-S026 Set screw M4 x 4mm (Upper position) E-clip 3mm (2) Front Upper Hinge Pin Front Upper Toe In Adjuster set Ø4x49mm RVB-S049 RVB-S073...
  • Page 10: Assembly Of The Front Steering System

    ASSEMBly OF ThE FROnT STEERInG SySTEM BAG I ASSEMBly OF ThE SERVO SAVER Servo saver complete #RVB-S063 R/H M3 x 8mm (2) Ball Bearing Ø6x10x3mm RVB-S146 CNC Steering Plate 6061 RVB-S081 Servo Saver Pie R/H M3 x 8mm (2) Ball Ø6mm (2) RVB-S099 Ball Bearing Ø6x10x3mm...
  • Page 11: Installing The Servo Saver

    Screwbag R/H M3 x 8mm RVB-S141 Servo Saver Shaft RVB-S062 BAG J ASSEMBly OF ThE REAR SuSPEnSIOn RAVE M1.0S Rear stiffener support plast. E-Clip bag: RVB-S141 RVB-S184-S R/H M3 x 12mm (2) OPTION CNC Rear Stiffener Support 7075 RVB -S184-R RAVE M1.0S...
  • Page 12: Rear Stabilizer

    BAG k REAR STABIlIZER Rear Sway Bar 2.7mm : RVB-S108 Set Screw Stabilizer Ball (OPTION) 2.8mm : RVB-S109 M3 x 3mm RVB-S100 2.9mm : RVB-S110 Ball End 6mm Make sure that the sway bar moves freely! RVB-S051 M3 x 12mm R/H M3 x 16mm Ball 6mm RVB-S102...
  • Page 13: Rear Suspension

    Ball Ø7mm RVB-S050 RVB-S050 Nylstop M3 R/H M3 x 23mm R/H M3 x 8mm Nylstop M3 BAG n CEnTER dIFFEREnTIAl RAVE M1.0S Brake Pad Holder Center Diff. Mount set RVB-S059 RVB-S028-S OPTION CNC 7075 Center Diff. Mount set (option) RVB-S028-R...
  • Page 14: Assembly Of The Drive Trains On The Chassis

    BAG O ASSEMBly OF ThE dRIVE TRAInS On ThE ChASSIS RAVE M1.0S CNC Chassis M1.0S: RVB-S077-S RAVE M1.0R left & Right Side Guard CNC 7075 Chassis M1.0R: RVB-S077-R RAVE M1.0RR CNC 7075 Lightened Chassis M1.0RR: RVB-S077-RR Side Guard (2) RVB-S032...
  • Page 15: Assembly Of The Chassis Stiffeners

    BAG P ASSEMBly OF ThE ChASSIS STIFFEnERS FR & RE Chassis stiffeners Screwbag RVB-S141 RAVE M1.0S Chassis stiffener set (plastic) RVB-S036-S RAVE M1.0R CNC Chassis stiffener set 7075 RVB-S036-R Nylstop M3 R/H M3 x 20mm R/H M3 x 12mm (2)
  • Page 16: Assembly Of The Radio Plate

    BAG R ASSEMBly OF ThE RAdIO PlATE Ball End Ø6mm RVB-S098 Steering Servo Turnbuckle M3x30mm RVB-S157 * Servo Horn Set RVB-S132 17mm Ball End Ø6mm RVB-S098 *Servo Horn (Steering) RVB-S132 Servo Ball Ø6mm RVB-S099 Servo holder RVB-S076 Steering Servo Mount RVB-S047 R/H M3 x 16mm (4) R/H M3 x 6mm...
  • Page 17: Assembly Of The Radio Plate

    BAG S ASSEMBly OF ThE RAdIO PlATE Receiver Box Set Antenna Tube RVB-S172 Switch R/H M3 x 8mm (2) Switch Cover Plate RVB-S031 Receiver Silicone Switch Cover RVB-S155 Radio Box Screwbag RVB-S031 RVB-S141 R/H M3 x 8mm (2) F/H M3 x 10mm (6)
  • Page 18: The Fuel Tank

    BAG T ThE FuEl TAnk R/H M3 x 12mm (2) Fuel Tank with integrated fuel filter RVB-S093 Fuel Tank Post RVB-S045 Screwbag RVB-S141 F/H M3 x 10mm (2) Fuel Guard Extra Fuel Filter (option) RVB-S212 Fuel Filter Holder RVB-S096 Central fuel guard Plate RVB-S035 R/H M3 x 8mm (2) R/H M3 x 8mm...
  • Page 19: Assembly Of The Clutch System

    (Included with the engine) FlyWheel RVB-S122 Nylstop M3 (4) Flywheel Nut RVB-S123 OPTION CNC Racing Clutch Bell 13T RVB-S213 RAVE M1.0S CNC Racing Clutch Bell 14T RVB-S214 CNC Engine Mount CNC Racing Clutch Bell 15T RVB-S215 RVB-S085-S RAVE M1.0R Clutch Spring 0.9mm RVB-S124 CNC Racing Engine Mount Clutch Spring 1.1mm RVB-S126...
  • Page 20: The Throttle Control Linkage

    BAG V ThE ThROTTlE COnTROl lInkAGE Muffler Manifold RVB-S166 Set screw M4x4mm Exhaust Silicon joint RVB-S167 Muffler Stay RVB-S193 Muffler M1.0S RVB-S168 Set screw M4x4mm Muffler Holder Wire RVB-S185 F/H M4x8mm Throttle Control linkage Brake Rod Throttle control linkage set Set screw M3 x 3mm RVB-S119...
  • Page 21: The Fr & Re Shock Absorbers

    BAG w ThE FR & RE ShOCk ABSORBERS Front Shock * Shock rebuild kit * Complete Front Shock Set RVB-S007 RVB-S003 Shock Body Front RVB-S005 Apply some oil to insert the shock Nylstop M2.5mm shaft easily in the shock body. Shock Piston 2-Hole RVB-S010 Teflon washer...
  • Page 22: Assembly Of The Front And Rear Shock Absorbers

    BAG w ASSEMBly OF ThE FROnT And REAR ShOCk ABSORBERS Nylstop M3 Front Shocks Screwbag RVB-S141 Nylstop M3 Shock bushing RVB-S064 Ball Ø6mm RVB-S182 R/H M3 x 20mm M3 Washer (2) Nylstop M3 (2) Shock Spring Adjuster R/H M3 x 20mm 1, 2 and 5mm RVB-S015 Shock Spring Collar...
  • Page 23: Assembly Of The Rear Wing

    BAG X ASSEMBly OF ThE REAR wInG wing & wing Stay wing Stay set RVB-S037 R/H M3 x 12mm (2) Screwbag RVB-S141 R/H M3 x 12mm (2) R/H M3 x 20mm (2) R/H M3 x 16mm (2) F/H 3 x 12mm Wing stay washer plastic RVB-S195 Wing Black RVB-S038-B...
  • Page 24: Throttle Linkage & Assembly Of The Air Filter

    ThROTTlE lInkAGE & ASSEMBly OF ThE AIR FIlTER linkage Adjustment Full Throttle position >>> Brake at neutral position! neutral Position >>> Carburetor max open!!! >>> Max 1.1mm open!!! Full Brake Position >>> Max 1.1mm open!!! Airfilter Air Filter complete SET : RVB-S129 Use special air-filter oil on the inner sponge filter (not on the outer filter) to stop dust from getting into the engine.
  • Page 25: Fuel Line & Tires

    FuEl lInE & TIRES Fuel line Fuel Line Tires - Mount the insert and the tires on the rims - Carefully glue the tires to the rims using Cyano Glue Tire (2pcs) MP-S001-1 Foam Insert (2pcs) MP-S100-2 Wheel Black RVB-S133-B Wheel White RVB-S133-W Wheel Yellow RVB-S133-Y Tire glued on wheel (2pcs)
  • Page 26: Cut Out Of The Body

    CuT OuT OF ThE BOdy Body - Remove the protective film after cutting Body clear: RVB-S001 Body painted: RVB-S002 Ishima Buggy Body Pin RVB-S040...
  • Page 27: Install The Stickers

    InSTAll ThE STICkERS Sticker sheet RAVE-S: RVB-S092-S Sticker sheet RAVE-R: RVB-S092-R Sticker sheet RAVE-RR: RVB-S092-RR • Remove the protective film on the body before installing the stickers...
  • Page 28: Spare & Optional Parts

    V . Spare & Optional Parts ITEM nR RAVE-S & RAVE-R ITEM nR RAVE-S & RAVE-R RVB-S001 BODY CLEAR RVB-S049 FRONT/REAR TOE IN ADJUSTER SET RVB-S002 BODY PAINTED RVB-S050 REAR UPPER ARM BALL END 7MM RVB-S003 FRONT SHOCK SET (2) RVB-S051 SWAY BAR MOUNT BALL END 3MM RVB-S004...
  • Page 29 RVB-S090-2 DIFF SHIM RING 3X10X0,2MM RVB-S176 RADIO PLATE STAND RVB-S091 DIFF GASKET RVB-S177 TRANSPONDER SUPPORT RVB-S092-S STICKER SHEET RAVE M1.0S RVB-S184-S REAR STIFFENER SUPPORT RVB-S092-R STICKER SHEET RAVE M1.0R RVB-S184-R CNC REAR STIFFENER SUPPORT 7075 RVB-S092-RR STICKER SHEET RAVE M1.0RR...
  • Page 30: Vi. Engine

    VI. Engine CaRbuRetoR Complete • RVb-m25.009 RVB-M25.014 RVB-M25.011 RVB-M25.020 RVB-M25.024 RVB-M25.016 RVB-M25.013 RVB-M25.028 RVB-M25.012 RVB-M25.026 RVB-M25.023 RVB-M25.027 RVB-M25.029 RVB-M25.037 RVB-M25.019 ISHIMA ENGINE .25 #RVB-M25 RVB-M25.045 RVB-M25.035 RVB-M25.025 RVB-M25.015 RVB-M25.036 RVB-M25.018 RVB-M25.004 RVB-M25.042 RVB-M25.021 RVB-M25.006 RVB-M25.001 RVB-M25.005 RVB-M25.032 RVB-M25.022 RVB-M25.007 RVB-M25.008 RVB-M25.040...
  • Page 31: Vii. Carburetor Setting

    VII. Carburetor setting Turn (30°) the high speed needle to rich or to lean the engine. ATTEnTIOn: Do not set the carburetor settings too “lean” . It results in higher temperatures, less lubrication and it could block the engine (overheating the engine). “Rich” setting gives less performance but improves the cooling, lubrication and therefore a longer life of the engine.
  • Page 32: Ix. Transmitter

    IX. Transmitter...
  • Page 33: Handling Procedure

    hAndlInG PROCEduRE...
  • Page 34: Trims & Servo Reverse

    TRIMS & SERVO REVERSE...
  • Page 35: Setup Sheet

    driver: ___________________________________________ date: ____________________________________________ Track: ____________________________________________ Setup Sheet Front suspension Rear suspension Anti-roll bar: ____________ wheelbase: ____________ Anti-roll bar: ____________ wheelbase: ____________ Camber angle: _________ Toe angle: ______________ Camber angle: _________ Toe angle: ______________ Shock ______ Shock position position: ____ ➊...
  • Page 36 www.ishimaracing.com UNIVERSAL POWER ENTERPRISES LTD 2-6 GRANVILLE ROAD ALBION PLAZA, 11/F, ROOM 1105 TSIMSHATSUI, KOWLOON HONG KONG TEL: (852) 2721 0127 FAX: (852) 2721 3711 Email: sales@upe-hk.com...

This manual is also suitable for:
