Summary of Contents for DAAB FAAC C850
- Page 1 Users manual Operator FAAC C850 Users manual FAAC Nordic AB BOX 125, SE-284 22 PERSTORP SWEDEN TEL. +46 435 77 95 00 FAX +46 435 77 95 29 www.faac.se...
-
Page 2: Description And Technical Specifications
Users manual Operator FAAC C850 General These instruction apply to the following models: C850 The C850 is an electromechanical operator designed for moving sliding gates. The non-reversing system is guaranteed by an electric brake that prevents manual movement of the sliding leaf when the motor is stopped, and therefore does not require an electric lock. -
Page 3: Installing The Automated System
Users manual Operator FAAC C850 Dimensions Angled Non-Angled Installing the automated system Preliminary checks For the safety and correct operation of the automated system, ensure that the following conditions are met: • The gate structure must be designed to be automated. In particular, the diameter of the wheels must conform to the weight of the gate being automated, there must be a guide on top and mechanical limit switches sized to suit the weight and speed of the movable leaf, to avoid derailment of the gate;... - Page 4 Users manual Operator FAAC C850 Placing the operator Place the operator to make the rack centered on the pinion. Use the nuts and washers to move the operator vertically, please see drawing on next page for measures. Use a level to make sure the operator is perfectly horizontal.
-
Page 5: Installing The Rack
Users manual Operator FAAC C850 Installing the rack www.faac.se... -
Page 6: Adjusting The Limit Switches
Users manual Operator FAAC C850 Adjusting the limit switches 1. Loosen the screws and remove the limit switch unit cover. 2. Set the sliding leaf in open position, leaving enough room for ramping down the speed before stop. 3. Loosen the central locking screw of the limit switch unit. -
Page 7: Manual Release
Users manual Operator FAAC C850 Manual release To release the gear motor, proceed as follows: Insert the provided key and turn clockwise Turn the release system clockwise until it reaches the mechanical stop. Open or close the gate manually. To lock the gear motor, proceed as follows: 1.
