To:
#501, 222-12 MARIOTOWER, GURO3-DONG, GURO-KU, SEOUL, KOREA
"
19
TFT LCD MONITOR with Sharpening Style
1. Introduction
With an LCD Panel Monitor using a TFT Color LCD, you can use SX1900 a substitution of general PC
Monitor because it can receive the R.G.B input of PC VGA Signal. SX1900 has OSD Function in order to
display the best quality of the screen according to VGA Cards' features. Besides, Touch Screen is available
by customer's request, it can be usable simultaneously with PS/2 Mouse.
Safety Precautions
The safety recommendations outlined in this section are to be read, understood and followed before
operating the product. Keep this information in a safe place for future reference. Failure to comply with any of
the following safety procedures could result in serious hazard.
A. Do not operate product for any purposes other than its intended use.
B. This product is intended for indoor use only.
C. Do not operate product if power cord is damaged in any way.
D. Do not insert object into openings.
E. Do not immerse product in water or permit liquids to spill inside.
F. Turn off power when attended or not in use unplug product before moving it or when it is not
in use for an extended period of time.
Note : These specifications are subject to change for up-date without notification
Jinyoung Contech Co., Ltd.
TEL : 82-2-890-6400
HOME PAGE :
http://www.jyct.com/
SX1900
- With Touch Screen (Optional)
TFT LCD Monitor : SX1900 1/8
FAX : 82-2-890-6406
Issued Date :
Oct 26, 2003
Page :
8pages
'
USER
S MANUAL
Advertisement
Table of Contents
Summary of Contents for Jinyoung SX1900
- Page 1 1. Introduction With an LCD Panel Monitor using a TFT Color LCD, you can use SX1900 a substitution of general PC Monitor because it can receive the R.G.B input of PC VGA Signal. SX1900 has OSD Function in order to display the best quality of the screen according to VGA Cards’...
- Page 2 Weight : Net ; 7.4 kg, Gross ; 9.9kg Refresh Rate : Max. 1280 x 1024 @ 75Hz (60Hz for optimal display) Main Frequency : Max. 157.5MHz Frequency : Hor. 31.5~80 KHz, Ver. 56~75Hz Compatibility of Vertical Frequency TFT LCD Monitor : SX1900 2/8...
- Page 3 Drift compensation for fluctuations in the temperature and humidity Antiglare scratch resistant finish Gloved or Ungloved finger or Stylus activation Chemically strengthened glass backing panel Optically bonded buffer layer Transmittance : Typ. >80% Durability : Point Activation Typ. 1,000,000 Gouge Hardness 3H TFT LCD Monitor : SX1900 3/8...
-
Page 4: Osd Functions
Super RGB Item Automatic adjustment for Color Level. User can adjust warmness as Color Temperature Item users please. Adjust the warmness of the image displayed. 4200K The higher temperature the coolest image looks like. TFT LCD Monitor : SX1900 4/8... - Page 5 User Value Initial Item Image Sharpness Adjust sharpness of the image. Adjust Item Adjust Dos screen resolution to 640 x 400 or 720 x 400 DOS Mode Select Item Menu Exit Item OSD Exit TFT LCD Monitor : SX1900 5/8...
- Page 6 Result of using LCD do not identify with resolution of VGA Card in In order to remove the phenomenon, The VGA mode in PC should be adjusted into the mode (resolution) that can be supported by LCD. TFT LCD Monitor : SX1900 6/8...
- Page 7 4. Connectors ※ Touch is optional. 5. Dimensions Monitor Dimensions VESA Standard ARM Mount. TFT LCD Monitor : SX1900 7/8...
- Page 8 Appendix 1. Packing List LCD Monitor LCD Monitor Manual AC Power Cord VGA Cable Supporters, 8PCS Touch Cable (Optional) Touch Screen Install CD (Optional) Touch Screen User’s Manual (Optional) TFT LCD Monitor : SX1900 8/8...
