Introduction
Thank you for purchasing the Polyana-JT. Polyana-JT is a communication
device that delivers loud, clear, speech output for those who type or scan. The
Polyana-JT is based upon a high performance
Windows CE, mini-computer, which is also
small, lightweight and has a bright, easy-to-read
display.
Persona is the communication software that runs
on the Polyana-JT and speaks the text aloud as
it is entered. Persona provides assistive
features such as word prediction/word
completion, abbreviation-expansion,
pronunciation, Sticky Keys and more to
help reduce the time and effort
required for creating real-time
communication.
Persona is divided into two modes of
operation, Keyboard and Scan modes. The
Keyboard Mode is for typing on the physical keyboard.
Scan Mode is for selecting from an on-screen keyboard using an
external scan switch.
The Polyana-JT does not have a touch screen.
NOTE:
Turning On the Unit
Press and hold the Power button for 2 - 4 seconds and then let go. Wait up to 1
minute for the Windows Desktop to appear before using the device.
does not start automatically, start Persona by clicking on the
Persona
menu item or by double-clicking on the Persona Desktop icon, if it
exists.
DO NOT click repeatedly on the Persona icon. It may take up to 15
NOTE:
seconds before seeing the Persona splash screen.
Persona will start up in either the Keyboard mode or Scan mode, depending
upon the mode Persona was in when the program was last used.
If you prefer not to wait a few minutes for Polyana-JT to turn on
NOTE:
and for Persona to load, then we recommend that Polyana-JT not
be turned off. Refer to Sleep Mode (Page 6).
ZYGO Industries, Inc.
7409 SW Tech Center Drive, Suite 125
U.S.A. / Canada: (800) 234-6006 TEL: (503) 684-6006
This Quick-Start Guide only has fundamental operating instructions, primarily for the
communication program, Persona. Read the J-Pro Quick Start Guide and User's Manual
for operation of the hardware and the Polyana-JT Operation Manual for complete
instructions for Persona. A basic knowledge of Personal Computers is required.
PO Box 1008
Quick-Start Guide for
Polyana–JT
Portland, OR 97207-1008
Tigard OR 97223-8082
Persona
with
1 OCT 2009
If Persona
Start/Programs/
FAX: (503) 684-6011
1
Advertisement
Table of Contents
Summary of Contents for ZYGO Polyana-JT
- Page 1 Persona will start up in either the Keyboard mode or Scan mode, depending upon the mode Persona was in when the program was last used. If you prefer not to wait a few minutes for Polyana-JT to turn on NOTE: and for Persona to load, then we recommend that Polyana-JT not be turned off.
- Page 2 • Approximate run time on batteries is • Change settings (Preferences). 4–6 hours. • Help and Exit Persona. • Charge time is about 2.5 hours. • CAUTION: The Polyana-JT can get Edit Menu very hot while charging. • Undo last action. Stick Keys Indicator •...
- Page 3 4–6 hours. create words and sentences by • Charge time is about 2.5 hours. suggesting words. • The Polyana-JT can get very • The word library starts out with CAUTION: hot while charging. 2,000 words and grows as it learns new words as they are Main Text Box typed.
- Page 4 Go to Preferences by selecting “Preferences” from the “File” menu in Keyboard mode or, by simultaneously pressing “Ctrl” and “P” while in Scan mode. Preferences is divided into 4 sections. ZYGO Industries, Inc. PO Box 1008 Portland, OR 97207-1008 7409 SW Tech Center Drive, Suite 125 Tigard OR 97223-8082 U.S.A.
- Page 5 Appearance • For text boxes, select font style, size, color, and background colors. • Select the highlight color. ZYGO Industries, Inc. PO Box 1008 Portland, OR 97207-1008 7409 SW Tech Center Drive, Suite 125 Tigard OR 97223-8082 U.S.A. / Canada: (800) 234-6006 TEL: (503) 684-6006...
- Page 6 USB flash disk will be the same. Otherwise, the document name will be PrintJob.txt. Sleep Mode Sleep mode means that the Polyana-JT will conserve power when it is not in use but will always be on and ready for use. Sleep mode can be accomplished by going to Control Panel/Display/Backlight .
- Page 7 Turning Off the Unit If Polyana-JT is not going to be used for an extended period of time, press and hold the Power button for about 6 seconds and then let go. Or, close the cover. This depends upon the setting of “Shutdown on Lid Close”...
- Page 8 • Click on the “Taskbar and Start Menu” menu item. • Place a check mark in the 3 check-boxes within the “General” tab. • Click OK to complete the task. ZYGO Industries, Inc. PO Box 1008 Portland, OR 97207-1008 7409 SW Tech Center Drive, Suite 125 Tigard OR 97223-8082 U.S.A.
