Quick Links
Standby / Alert
Red LED
Flash Light
Light Button
Volume UP
Volume DOWN
MODE Button
SPECIFICATIONS
Dimensions
2.87 L x 5.15 H x 1.29 D in
(73 L x 131 H x 33 D mm)
Weather Band (7 Channels)
-6dB // 162.4000 - 162.5500MHz
AM Band
82dB // 540-1700 KHz
FM Band
10dB // 87.5 -108 MHz
Operating Temperature
32°F to 122°F (0°C to 50°C)
Storage Temperature
14°F to 122°F (-10°C to 50°C)
Battery
3 " AA" LR6 Alkaline (not included)
Battery Life
1 to 2 Years (depending on use)
Optional A/C cord
6 volt (not included)
Support Information:
http://www.lacrosseclock.com/support
Model No.: T83738
HANDHELD WEATHER RADIO
AM/FM | NOAA WEATHER BAND
ON/OFF Button
Channel UP
Channel DOWN
Earphone Jack
AC/DC
Power Port
Lanyard
Anchor Shaft
http://www.lacrosseclock.com/support
Model No.: T83738
Instruction Manual
LCD LAYOUT
Radio Mode
(AM/FM/WB)
LCD
With
Backlight
Frequency
Built -In
Speaker
Hands-Free
Metal Clip
Telescoping
Antenna
Low Battery
Indicator
Volume
Level
Battery
Compartment
Battery
Cover
Page | 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for La Crosse T83738
Summary of Contents for La Crosse T83738
- Page 1 Model No.: T83738 Instruction Manual HANDHELD WEATHER RADIO AM/FM | NOAA WEATHER BAND Standby / Alert LCD LAYOUT Low Battery Indicator Red LED Radio Mode Volume Flash Light (AM/FM/WB) Level Light Button With Backlight Frequency Volume UP Built -In Speaker...
- Page 2 AM radio // FM radio // WB radio Use the CH buttons (▲▼) to select the station. Hold the CH buttons to search for the next available station. Press the VOL buttons (▲▼) to adjust volume. Model No.: T83738 http://www.lacrosseclock.com/support Page | 2...
- Page 3 1-year from the original retail purchase, La Crosse McCormick, LLC will, at La Crosse McCormick, LLC ’s option, either repair or replace same without charge (but no cash refund will be made).
- Page 4 Mail to: La Crosse McCormick Warranty Department 2817 Losey Blvd S La Crosse, WI 54601 7. REPAIR/EXCHANGE: The radio will be repaired or exchanged upon its receipt if it is under warranty. 8. SERVICE TIMELINE: Please allow approximately 2-4 weeks for the radio to be serviced under warranty.
